60% of the World without Internet Access

8% 80% About 60% of the World population do not have access to the Internet, wired or wireless Over 4 Billion people Worldwide without Internet Access ?

http://www.internetlivestats.com/internet-users/

2

World Map Scaled According To Population Size

Source: http://www.iflscience.com/environment/world-map-scaled-population-size http://www.internetworldstats.com/stats.htm

Africa: 27.5% Asia: 34.8% 52.4% 87% 70% 72% 48.1%

3

Rural and Small town America

Source: https://www.fcc.gov/reports/2015-broadband-progress-report http://mobilefuture.org/resources/the-truth-about-spectrum-deployment-in-rural-america/

FCC 2015 Broadband Progress Report 17% of all Americans (55 million) & 53% of rural Americans (22 million) lack access to Broadband.

Only 8 percent of urban Americans lack access to broadband.

Wireless Revenue Potential/ mile2

Major urban center: $248,000 Least densely populated: $262

Broadband: 25 Mbps/3 Mbps

4

Connectivity Omnification

Omnify: Order of magnitude increase every five years

1,000X in 15 years Exabyte  Zetabyte (1,000X)

2013  2028

1 Zetabyte = 200 GB/month for 5 Billion 5G and Wi-Fi to carry similar traffic 1Tb/s peak data rate

Wi-Fi: 2027 Cellular: 2030

5

REEFS Approach to Zetabyte Network Design

R Reliable EE Energy Efficient F Faster S Smaller

6

Trillion times improvement in the Last 60 years

1956, 5MB hard drive 1946, ENIAC, 30Tons, 167,000,000mm2, 150,000W, 5K ops/s Samsung Exynos 7420 processor

Octacore (2.1GHz & 1.5 GHz cores) 78 mm2, ~1W

Samsung 16TB SSD (2.5in)

7

REEFS Limits

𝑔

𝑄 = 𝐷5 ℎ𝐻 = 1.855 ×1034GHz

=18,550000000,000000000000,000000000000 GHz =18.55 Billion Trillion Trillion GHz

𝑚𝑄 =

ℎ𝐻 𝐷3 = 1.616 ×10−35m =

1.616 100,000000000000,000000000000nm

𝐹1−𝑐𝑗𝑢 = 𝑙𝑈 ln 2=2.87× 10−21 Joule

𝑁𝑗𝑜𝑗𝑛𝑣𝑛 𝐹𝑜𝑓𝑠𝑕𝑧 =

2.87 1,000000,000000nJ/bit

R Reliable EE Energy Efficient F Faster S Smaller

8

Millimeter waves – path to REEFS Wireless Systems

XS Antennas XL Bandwidth Millimeter waves (3-300 GHz) Faster Smaller

< 3

>3GHz 300GHz

f

Bandwidth  Data Rates  Capacity

9

Millimeter Waves for 5G

Samsung presents Millimeter wave mobile system concept at IEEE WCNC Samsung demos Gb/s system at 28GHz with 2Km range Samsung demos 7.5Gb/s peak data rate & 1.2 Gb/s at 100 Km/h FCC NOI to examine use

• f bands

above 24GHz for mobile broadband 3GPP 5G Workshop Over 20 companies support Millimeter waves FCC NPRM

• n Millimeter

wave spectrum for 5G

Oct 17 Sep 17 Oct 23 Mar 28

2011 2013 2014 2014 2015 2015

Oct 14 May 13

http://wcnc2011.ieee-wcnc.org/tut/t1.pdf

10

(Myth)2 #1: Higher path loss (even in Free space)

Ω𝐵 = 𝜇2 𝐵𝑓

𝑄

𝑠

𝑄𝑢 = 𝐵𝑢𝐵𝑠 𝑠 2

X times higher frequency propagates X times longer in free space

For the same transmit and receive antenna aperture sizes

11

(Myth)2 #2: Low Probability of Line-of-Sight (LoS)

𝑠

𝑜 =

𝑜𝑒1𝑒2 𝑒1 +𝑒2

Millimeter waves provide higher likelihood of LOS due to smaller Fresnel zones

Not bothered by objects around the Line-of-Sight

12

(Myth)2 #3: Suitable for Small Cells only

The “Free-space” (on Earth) path loss exponent smaller at Millimeter waves

Ground reflection not an issue

 = 2  = 2ℎ𝑢ℎ𝑠 𝑒

13

Myths about Millimeter Waves

Myth Reality

Higher path loss (even in Free space) 𝑄

𝑠

𝑄𝑢 = 𝐵𝑢𝐵𝑠 𝑠22 Millimeter waves propagate longer for the same antenna area Low probability of LoS 𝑠

𝑜 =

𝑜𝑒1𝑒2 𝑒1 +𝑒2 Millimeter waves provide higher likelihood of LOS due to smaller Fresnel zones Suitable for small cells

• nly

 = 2  = 2ℎ𝑢ℎ𝑠 𝑒 The “Free-space” (on Earth) path loss exponent smaller at Millimeter waves Have higher Noise  𝑔 =

ℎ𝑔 𝑙𝑈

𝑓

ℎ𝑔 𝑙𝑈

−1

Noise reduces with frequency, effect is small though at frequencies of interest Loss (do not bend) around corners 𝐽  = 𝐽0𝑡𝑗𝑜𝑑2 𝑒  𝑡𝑗𝑜  Millimeter waves comes out of an opening with more focused energy

Absorption (by Foliage, Rain) and Diffused Reflections…

14

Going smaller for Bigger Gains

Big Gains in coverage, capacity and energy efficiency via mmWave Beamforming Coalescence of access and back-haul

Antenna Aperture 𝐵𝑓 = 𝐸𝜇2 4𝜌 → 𝐸 = 4𝜌𝐵𝑓 𝜇2

Galaxy S6: 101 cm2

Ae

A4 paper: 623.7 cm2

Conventional sector antenna, 17dB gain

1m2

Ω𝐵 = 𝜇2 𝐵𝑓

15

Achieving Zetabyte with Terabit/s shared links

Parameter Value Comments Transmit Power 20 dBm Possibly multiple PAs Transmit Antenna Gain 32 dBi Element + array gain Carrier Frequency 100 GHz

• Ref. for calculations

Distance 200 meters Propagation Loss 118.42 dB Other path losses 10 dB Some NLOS Tx front end loss 3 dB Non-ideal RF Receive Antenna Gain 23 dB Element + array gain Received Power

• 56.42 dBm

Bandwidth (BW) 1 GHz BW / comm-core Thermal Noise PSD

• 174 dBm/Hz

Receiver Noise Figure 5.00 dB Thermal Noise

• 79 dBm

SNR 22.58 dB Implementation loss 5 dB Non-ideal baseband Spectram Efficiency (SE) 5.86 b/s/Hz Data rate / comm-core 5.86 Gb/s SE × BW Number of comm-cores 256 BW and MIMO cores Aggregate data rate 1.5 Terabit/s 256×5.86 Gb/s

WAP Tb/s shared Example: 256 cores 16 BW cores [16GHz], Each BW core having 16 Spatial Cores

16

'Green' buildings form a Faraday Cage effectively shielding all electrical fields from passing through In order to provide larger overall capacity in urban areas, Indoor and

• utdoor use parallel radio access

sharing the same spectrum

Indoor & Outdoor share the same spectrum

17

Expanding Mobile broadband to Rural and Small towns

Millimeter waves provide tremendous bandwidth to cover least densely populated areas with ultra- fast data rates Installing external antennas combined with radio repeaters inside the building can expand coverage to indoors

18

Millimeter waves enable Faster, Smaller and Energy- Efficient wireless systems Low-cost Tb/s shared links provide Zetabyte access each for cellular & Wi-Fi. Dream of ubiquitous access to & universal capture of information comes true

Every Being & Everything Connected!
