slide-1
SLIDE 1

Fundamentals of Internet Connections

Fundamentals of Internet Connections Objectives

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 1 / 17

slide-2
SLIDE 2

Fundamentals of Internet Connections

Fundamentals of Internet Connections Objectives

◮ To understand programming of clients that connect to servers via TCP

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 1 / 17

slide-3
SLIDE 3

Fundamentals of Internet Connections

Fundamentals of Internet Connections Objectives

◮ To understand programming of clients that connect to servers via TCP ◮ To understand the basics of programming of servers that accept TCP

connections

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 1 / 17

slide-4
SLIDE 4

Fundamentals of Internet Connections

Fundamentals of Internet Connections Objectives

◮ To understand programming of clients that connect to servers via TCP ◮ To understand the basics of programming of servers that accept TCP

connections

◮ To practice programming of application-level internet connections (HTTP)

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 1 / 17

slide-5
SLIDE 5

Fundamentals of Internet Connections

Fundamentals of Internet Connections Objectives

◮ To understand programming of clients that connect to servers via TCP ◮ To understand the basics of programming of servers that accept TCP

connections

◮ To practice programming of application-level internet connections (HTTP) ◮ Knowledge from this lecture will be needed at a lab but not necessarily at

the project

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 1 / 17

slide-6
SLIDE 6

Fundamentals of Internet Connections

Fundamentals of Internet Connections Objectives

◮ To understand programming of clients that connect to servers via TCP ◮ To understand the basics of programming of servers that accept TCP

connections

◮ To practice programming of application-level internet connections (HTTP) ◮ Knowledge from this lecture will be needed at a lab but not necessarily at

the project

◮ But it is important also for practicing Java code writing and Java

documentation lookup

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 1 / 17

slide-7
SLIDE 7

Fundamentals of Internet Connections

TCP connections

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 2 / 17

slide-8
SLIDE 8

Fundamentals of Internet Connections

TCP connections

Application (HTTP, FTP, Telnet) (HTTP, FTP, Telnet) Application

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 2 / 17

slide-9
SLIDE 9

Fundamentals of Internet Connections

TCP connections

Transport (TCP, UDP, ...) Application (HTTP, FTP, Telnet) (HTTP, FTP, Telnet) Transport (TCP, UDP, ...) Application TCP connection

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 2 / 17

slide-10
SLIDE 10

Fundamentals of Internet Connections

TCP connections

(IP, ...) Transport (TCP, UDP, ...) Application (HTTP, FTP, Telnet) (HTTP, FTP, Telnet) Transport (TCP, UDP, ...) (IP, ...) Network Application Network TCP connection

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 2 / 17

slide-11
SLIDE 11

Fundamentals of Internet Connections

TCP connections

(IP, ...) Transport (TCP, UDP, ...) Application (HTTP, FTP, Telnet) (HTTP, FTP, Telnet) Transport (TCP, UDP, ...) (IP, ...) Physical layer Network Application Network (Ethernet, FDDI, LocalTalk, drivers, ...) TCP connection

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 2 / 17

slide-12
SLIDE 12

Fundamentals of Internet Connections

TCP connections

(IP, ...) Transport (TCP, UDP, ...) Application (HTTP, FTP, Telnet) (HTTP, FTP, Telnet) Transport (TCP, UDP, ...) (IP, ...) Physical layer Network Application Network (Ethernet, FDDI, LocalTalk, drivers, ...) TCP connection

◮ TCP achieves a circuit-based connection (like a phone call) over the

packet-based IP network

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 2 / 17

slide-13
SLIDE 13

Fundamentals of Internet Connections

TCP connections

(IP, ...) Transport (TCP, UDP, ...) Application (HTTP, FTP, Telnet) (HTTP, FTP, Telnet) Transport (TCP, UDP, ...) (IP, ...) Physical layer Network Application Network (Ethernet, FDDI, LocalTalk, drivers, ...) TCP connection

◮ TCP achieves a circuit-based connection (like a phone call) over the

packet-based IP network

◮ A client connects to a server on another machine. That server ”listens to”

a specific port on that machine.

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 2 / 17

slide-14
SLIDE 14

Fundamentals of Internet Connections

java.net.Socket

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 3 / 17

slide-15
SLIDE 15

Fundamentals of Internet Connections

java.net.Socket

◮ A socket is an ”endpoint for communication”.

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 3 / 17

slide-16
SLIDE 16

Fundamentals of Internet Connections

java.net.Socket

◮ A socket is an ”endpoint for communication”.

◮ It represents a TCP connection DD1335 (Lecture 4) Basic Internet Programming Spring 2010 3 / 17

slide-17
SLIDE 17

Fundamentals of Internet Connections

java.net.Socket

◮ A socket is an ”endpoint for communication”.

◮ It represents a TCP connection ◮ but one can build sockets over any transport protocol DD1335 (Lecture 4) Basic Internet Programming Spring 2010 3 / 17

slide-18
SLIDE 18

Fundamentals of Internet Connections

java.net.Socket

◮ A socket is an ”endpoint for communication”.

◮ It represents a TCP connection ◮ but one can build sockets over any transport protocol

◮ To create a Socket you need to know what machine you want to connect

to, and to what port Socket(String machineName, int port)

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 3 / 17

slide-19
SLIDE 19

Fundamentals of Internet Connections

java.net.Socket

◮ A socket is an ”endpoint for communication”.

◮ It represents a TCP connection ◮ but one can build sockets over any transport protocol

◮ To create a Socket you need to know what machine you want to connect

to, and to what port Socket(String machineName, int port)

◮ throws java.net.UnknownHostException if host not found DD1335 (Lecture 4) Basic Internet Programming Spring 2010 3 / 17

slide-20
SLIDE 20

Fundamentals of Internet Connections

java.net.Socket

◮ A socket is an ”endpoint for communication”.

◮ It represents a TCP connection ◮ but one can build sockets over any transport protocol

◮ To create a Socket you need to know what machine you want to connect

to, and to what port Socket(String machineName, int port)

◮ throws java.net.UnknownHostException if host not found ◮ throws java.io.IOException if you can’t connect (e.g. when there’s no

server listening on that port!)

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 3 / 17

slide-21
SLIDE 21

Fundamentals of Internet Connections

java.net.Socket

◮ A socket is an ”endpoint for communication”.

◮ It represents a TCP connection ◮ but one can build sockets over any transport protocol

◮ To create a Socket you need to know what machine you want to connect

to, and to what port Socket(String machineName, int port)

◮ throws java.net.UnknownHostException if host not found ◮ throws java.io.IOException if you can’t connect (e.g. when there’s no

server listening on that port!)

◮ Once you built your socket, you may access two streams

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 3 / 17

slide-22
SLIDE 22

Fundamentals of Internet Connections

java.net.Socket

◮ A socket is an ”endpoint for communication”.

◮ It represents a TCP connection ◮ but one can build sockets over any transport protocol

◮ To create a Socket you need to know what machine you want to connect

to, and to what port Socket(String machineName, int port)

◮ throws java.net.UnknownHostException if host not found ◮ throws java.io.IOException if you can’t connect (e.g. when there’s no

server listening on that port!)

◮ Once you built your socket, you may access two streams

◮ one stream to talk to the server: OutputStream getOutputStream() DD1335 (Lecture 4) Basic Internet Programming Spring 2010 3 / 17

slide-23
SLIDE 23

Fundamentals of Internet Connections

java.net.Socket

◮ A socket is an ”endpoint for communication”.

◮ It represents a TCP connection ◮ but one can build sockets over any transport protocol

◮ To create a Socket you need to know what machine you want to connect

to, and to what port Socket(String machineName, int port)

◮ throws java.net.UnknownHostException if host not found ◮ throws java.io.IOException if you can’t connect (e.g. when there’s no

server listening on that port!)

◮ Once you built your socket, you may access two streams

◮ one stream to talk to the server: OutputStream getOutputStream() ◮ one stream to listen to the server’s response: InputStream

getInputStream()

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 3 / 17

slide-24
SLIDE 24

Fundamentals of Internet Connections

java.net.Socket

◮ A socket is an ”endpoint for communication”.

◮ It represents a TCP connection ◮ but one can build sockets over any transport protocol

◮ To create a Socket you need to know what machine you want to connect

to, and to what port Socket(String machineName, int port)

◮ throws java.net.UnknownHostException if host not found ◮ throws java.io.IOException if you can’t connect (e.g. when there’s no

server listening on that port!)

◮ Once you built your socket, you may access two streams

◮ one stream to talk to the server: OutputStream getOutputStream() ◮ one stream to listen to the server’s response: InputStream

getInputStream()

◮ When you are done with the socket you call close() on the streams and

the socket (in that order) to free network resources on the machine

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 3 / 17

slide-25
SLIDE 25

Fundamentals of Internet Connections

Connect to an Echo port

This program sends some text to an echo port (7) and prints the response on the screen. Start the program with java TextToEcho www.nada.kth.se "some message" import java.io.*; import java.net.*; public class TextToEcho { public static void main(String argv[]) throws IOException, UnknownHostException { Socket conn = new Socket(argv[0], 7); PrintWriter talk = new PrintWriter(new OutputStreamWriter(conn.getOutputStream())); Reader listen = new InputStreamReader(conn.getInputStream()); talk.print(argv[1]); talk.flush(); /* we make sure that the chars reach the server */ char buffer[] = new char[80]; int n = listen.read(buffer, 0, 80); System.out.println("The server said: " + new String(buffer, 0, n)); talk.close(); listen.close(); conn.close(); } }

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 4 / 17

slide-26
SLIDE 26

Fundamentals of Internet Connections

Some comments on socket programs

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 5 / 17

slide-27
SLIDE 27

Fundamentals of Internet Connections

Some comments on socket programs

◮ Once we master streams, creating socket programs is easy.

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 5 / 17

slide-28
SLIDE 28

Fundamentals of Internet Connections

Some comments on socket programs

◮ Once we master streams, creating socket programs is easy.

◮ A socket is just a pair of streams DD1335 (Lecture 4) Basic Internet Programming Spring 2010 5 / 17

slide-29
SLIDE 29

Fundamentals of Internet Connections

Some comments on socket programs

◮ Once we master streams, creating socket programs is easy.

◮ A socket is just a pair of streams

◮ If you start reading from the server before you are sure that the server will

respond, your program might wait forever!

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 5 / 17

slide-30
SLIDE 30

Fundamentals of Internet Connections

Some comments on socket programs

◮ Once we master streams, creating socket programs is easy.

◮ A socket is just a pair of streams

◮ If you start reading from the server before you are sure that the server will

respond, your program might wait forever!

◮ Forgetting to flush will sometimes cause the server not to receive anything

(so there’s no way it is going to respond)

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 5 / 17

slide-31
SLIDE 31

Fundamentals of Internet Connections

Some comments on socket programs

◮ Once we master streams, creating socket programs is easy.

◮ A socket is just a pair of streams

◮ If you start reading from the server before you are sure that the server will

respond, your program might wait forever!

◮ Forgetting to flush will sometimes cause the server not to receive anything

(so there’s no way it is going to respond)

◮ To see where your program is stuck: put println statements just before every

place where you suspect that the program hangs.

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 5 / 17

slide-32
SLIDE 32

Fundamentals of Internet Connections

Some comments on socket programs

◮ Once we master streams, creating socket programs is easy.

◮ A socket is just a pair of streams

◮ If you start reading from the server before you are sure that the server will

respond, your program might wait forever!

◮ Forgetting to flush will sometimes cause the server not to receive anything

(so there’s no way it is going to respond)

◮ To see where your program is stuck: put println statements just before every

place where you suspect that the program hangs.

◮ To kill the program: DD1335 (Lecture 4) Basic Internet Programming Spring 2010 5 / 17

slide-33
SLIDE 33

Fundamentals of Internet Connections

Some comments on socket programs

◮ Once we master streams, creating socket programs is easy.

◮ A socket is just a pair of streams

◮ If you start reading from the server before you are sure that the server will

respond, your program might wait forever!

◮ Forgetting to flush will sometimes cause the server not to receive anything

(so there’s no way it is going to respond)

◮ To see where your program is stuck: put println statements just before every

place where you suspect that the program hangs.

◮ To kill the program: ◮ Use Ctrl-Break on Windows DD1335 (Lecture 4) Basic Internet Programming Spring 2010 5 / 17

slide-34
SLIDE 34

Fundamentals of Internet Connections

Some comments on socket programs

◮ Once we master streams, creating socket programs is easy.

◮ A socket is just a pair of streams

◮ If you start reading from the server before you are sure that the server will

respond, your program might wait forever!

◮ Forgetting to flush will sometimes cause the server not to receive anything

(so there’s no way it is going to respond)

◮ To see where your program is stuck: put println statements just before every

place where you suspect that the program hangs.

◮ To kill the program: ◮ Use Ctrl-Break on Windows ◮ On Unix(-like): ctrl-Z, bg, ps, kill QUIT javaProcess DD1335 (Lecture 4) Basic Internet Programming Spring 2010 5 / 17

slide-35
SLIDE 35

Fundamentals of Internet Connections

Some comments on socket programs

◮ Once we master streams, creating socket programs is easy.

◮ A socket is just a pair of streams

◮ If you start reading from the server before you are sure that the server will

respond, your program might wait forever!

◮ Forgetting to flush will sometimes cause the server not to receive anything

(so there’s no way it is going to respond)

◮ To see where your program is stuck: put println statements just before every

place where you suspect that the program hangs.

◮ To kill the program: ◮ Use Ctrl-Break on Windows ◮ On Unix(-like): ctrl-Z, bg, ps, kill QUIT javaProcess

◮ Often reading from the server and writing to the server takes place in two

separate threads so reading can wait without blocking

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 5 / 17

slide-36
SLIDE 36

Fundamentals of Internet Connections

Some comments on socket programs

◮ Once we master streams, creating socket programs is easy.

◮ A socket is just a pair of streams

◮ If you start reading from the server before you are sure that the server will

respond, your program might wait forever!

◮ Forgetting to flush will sometimes cause the server not to receive anything

(so there’s no way it is going to respond)

◮ To see where your program is stuck: put println statements just before every

place where you suspect that the program hangs.

◮ To kill the program: ◮ Use Ctrl-Break on Windows ◮ On Unix(-like): ctrl-Z, bg, ps, kill QUIT javaProcess

◮ Often reading from the server and writing to the server takes place in two

separate threads so reading can wait without blocking

◮ What makes you know when the server will respond? The protocol!

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 5 / 17

slide-37
SLIDE 37

Fundamentals of Internet Connections

Some comments on socket programs

◮ Once we master streams, creating socket programs is easy.

◮ A socket is just a pair of streams

◮ If you start reading from the server before you are sure that the server will

respond, your program might wait forever!

◮ Forgetting to flush will sometimes cause the server not to receive anything

(so there’s no way it is going to respond)

◮ To see where your program is stuck: put println statements just before every

place where you suspect that the program hangs.

◮ To kill the program: ◮ Use Ctrl-Break on Windows ◮ On Unix(-like): ctrl-Z, bg, ps, kill QUIT javaProcess

◮ Often reading from the server and writing to the server takes place in two

separate threads so reading can wait without blocking

◮ What makes you know when the server will respond? The protocol! ◮ The echo server sends back immediately whatever it got

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 5 / 17

slide-38
SLIDE 38

Fundamentals of Internet Connections

Some comments on socket programs

◮ Once we master streams, creating socket programs is easy.

◮ A socket is just a pair of streams

◮ If you start reading from the server before you are sure that the server will

respond, your program might wait forever!

◮ Forgetting to flush will sometimes cause the server not to receive anything

(so there’s no way it is going to respond)

◮ To see where your program is stuck: put println statements just before every

place where you suspect that the program hangs.

◮ To kill the program: ◮ Use Ctrl-Break on Windows ◮ On Unix(-like): ctrl-Z, bg, ps, kill QUIT javaProcess

◮ Often reading from the server and writing to the server takes place in two

separate threads so reading can wait without blocking

◮ What makes you know when the server will respond? The protocol! ◮ The echo server sends back immediately whatever it got ◮ In other protocols (e.g. HTTP) the server waits until it has at least one line to send

before it starts responding

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 5 / 17

slide-39
SLIDE 39

Fundamentals of Internet Connections

HTTP request

Here is a program that makes a HTTP request and prints the result. java HttpAccess www.nada.kth.se index.html | more import java.io.*; import java.net.*; public class HttpAccess { public static void main(String argv[]) throws IOException, UnknownHostException { Socket conn = new Socket(argv[0], 80); PrintWriter talk = new PrintWriter(new OutputStreamWriter(conn.getOutputStream())); talk.println("GET /" + argv[1] + " HTTP/1.0"); /* HTTP command */ talk.println("Host: " + argv[0]); /* HTTP header(s) */ talk.println(); /* empty line, no content after */ talk.flush(); /* PrintWriter println() is not autoflush! */ BufferedReader listen = new BufferedReader(new InputStreamReader(conn.getInputStream())); String line; while ( (line = listen.readLine()) != null) System.out.println(line); talk.close(); listen.close(); conn.close(); } }

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 6 / 17

slide-40
SLIDE 40

Fundamentals of Internet Connections

Client-Server paradigm

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 7 / 17

slide-41
SLIDE 41

Fundamentals of Internet Connections

Client-Server paradigm

◮ Most of the Internet today is built around the client-server approach

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 7 / 17

slide-42
SLIDE 42

Fundamentals of Internet Connections

Client-Server paradigm

◮ Most of the Internet today is built around the client-server approach ◮ A server is a program that offers a service

(echoing characters, serving web pages, tell the time, . . . )

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 7 / 17

slide-43
SLIDE 43

Fundamentals of Internet Connections

Client-Server paradigm

◮ Most of the Internet today is built around the client-server approach ◮ A server is a program that offers a service

(echoing characters, serving web pages, tell the time, . . . )

◮ A client is a program that asks a server for a certain service

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 7 / 17

slide-44
SLIDE 44

Fundamentals of Internet Connections

Client-Server paradigm

◮ Most of the Internet today is built around the client-server approach ◮ A server is a program that offers a service

(echoing characters, serving web pages, tell the time, . . . )

◮ A client is a program that asks a server for a certain service ◮ The server waits for some client to connect

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 7 / 17

slide-45
SLIDE 45

Fundamentals of Internet Connections

Client-Server paradigm

◮ Most of the Internet today is built around the client-server approach ◮ A server is a program that offers a service

(echoing characters, serving web pages, tell the time, . . . )

◮ A client is a program that asks a server for a certain service ◮ The server waits for some client to connect ◮ The client initiates a conversation that respects a set of rules called

protocol

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 7 / 17

slide-46
SLIDE 46

Fundamentals of Internet Connections

Client-Server paradigm

◮ Most of the Internet today is built around the client-server approach ◮ A server is a program that offers a service

(echoing characters, serving web pages, tell the time, . . . )

◮ A client is a program that asks a server for a certain service ◮ The server waits for some client to connect ◮ The client initiates a conversation that respects a set of rules called

protocol

◮ Alternatives to client-server: remote procedure call (RPC), Web Services

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 7 / 17

slide-47
SLIDE 47

Fundamentals of Internet Connections

java.net.ServerSocket

A java.net.ServerSocket

◮ binds a port of the local machine

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 8 / 17

slide-48
SLIDE 48

Fundamentals of Internet Connections

java.net.ServerSocket

A java.net.ServerSocket

◮ binds a port of the local machine

◮ ServerSocket(int port) DD1335 (Lecture 4) Basic Internet Programming Spring 2010 8 / 17

slide-49
SLIDE 49

Fundamentals of Internet Connections

java.net.ServerSocket

A java.net.ServerSocket

◮ binds a port of the local machine

◮ ServerSocket(int port) ◮ throws java.io.IOException if the socket can’t be open (e.g. when the

port is not free!)

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 8 / 17

slide-50
SLIDE 50

Fundamentals of Internet Connections

java.net.ServerSocket

A java.net.ServerSocket

◮ binds a port of the local machine

◮ ServerSocket(int port) ◮ throws java.io.IOException if the socket can’t be open (e.g. when the

port is not free!)

◮ throws java.lang.SecurityException if our code is not allowed to

bind a TCP port.

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 8 / 17

slide-51
SLIDE 51

Fundamentals of Internet Connections

java.net.ServerSocket

A java.net.ServerSocket

◮ binds a port of the local machine

◮ ServerSocket(int port) ◮ throws java.io.IOException if the socket can’t be open (e.g. when the

port is not free!)

◮ throws java.lang.SecurityException if our code is not allowed to

bind a TCP port.

◮ e.g. if a Java applet downloaded from the Internet DD1335 (Lecture 4) Basic Internet Programming Spring 2010 8 / 17

slide-52
SLIDE 52

Fundamentals of Internet Connections

java.net.ServerSocket

A java.net.ServerSocket

◮ binds a port of the local machine

◮ ServerSocket(int port) ◮ throws java.io.IOException if the socket can’t be open (e.g. when the

port is not free!)

◮ throws java.lang.SecurityException if our code is not allowed to

bind a TCP port.

◮ e.g. if a Java applet downloaded from the Internet ◮ No need to catch this as it’s a RuntimeException DD1335 (Lecture 4) Basic Internet Programming Spring 2010 8 / 17

slide-53
SLIDE 53

Fundamentals of Internet Connections

java.net.ServerSocket

A java.net.ServerSocket

◮ binds a port of the local machine

◮ ServerSocket(int port) ◮ throws java.io.IOException if the socket can’t be open (e.g. when the

port is not free!)

◮ throws java.lang.SecurityException if our code is not allowed to

bind a TCP port.

◮ e.g. if a Java applet downloaded from the Internet ◮ No need to catch this as it’s a RuntimeException

◮ accepts connections from clients

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 8 / 17

slide-54
SLIDE 54

Fundamentals of Internet Connections

java.net.ServerSocket

A java.net.ServerSocket

◮ binds a port of the local machine

◮ ServerSocket(int port) ◮ throws java.io.IOException if the socket can’t be open (e.g. when the

port is not free!)

◮ throws java.lang.SecurityException if our code is not allowed to

bind a TCP port.

◮ e.g. if a Java applet downloaded from the Internet ◮ No need to catch this as it’s a RuntimeException

◮ accepts connections from clients

◮ Socket accept() returns the other endpoint of the connection DD1335 (Lecture 4) Basic Internet Programming Spring 2010 8 / 17

slide-55
SLIDE 55

Fundamentals of Internet Connections

java.net.ServerSocket

A java.net.ServerSocket

◮ binds a port of the local machine

◮ ServerSocket(int port) ◮ throws java.io.IOException if the socket can’t be open (e.g. when the

port is not free!)

◮ throws java.lang.SecurityException if our code is not allowed to

bind a TCP port.

◮ e.g. if a Java applet downloaded from the Internet ◮ No need to catch this as it’s a RuntimeException

◮ accepts connections from clients

◮ Socket accept() returns the other endpoint of the connection ◮ Communication with the client takes place on the input stream and output

stream of the returned Socket

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 8 / 17

slide-56
SLIDE 56

Fundamentals of Internet Connections

java.net.ServerSocket

A java.net.ServerSocket

◮ binds a port of the local machine

◮ ServerSocket(int port) ◮ throws java.io.IOException if the socket can’t be open (e.g. when the

port is not free!)

◮ throws java.lang.SecurityException if our code is not allowed to

bind a TCP port.

◮ e.g. if a Java applet downloaded from the Internet ◮ No need to catch this as it’s a RuntimeException

◮ accepts connections from clients

◮ Socket accept() returns the other endpoint of the connection ◮ Communication with the client takes place on the input stream and output

stream of the returned Socket

◮ accept() blocks until a request from a client comes! DD1335 (Lecture 4) Basic Internet Programming Spring 2010 8 / 17

slide-57
SLIDE 57

Fundamentals of Internet Connections

java.net.ServerSocket

A java.net.ServerSocket

◮ binds a port of the local machine

◮ ServerSocket(int port) ◮ throws java.io.IOException if the socket can’t be open (e.g. when the

port is not free!)

◮ throws java.lang.SecurityException if our code is not allowed to

bind a TCP port.

◮ e.g. if a Java applet downloaded from the Internet ◮ No need to catch this as it’s a RuntimeException

◮ accepts connections from clients

◮ Socket accept() returns the other endpoint of the connection ◮ Communication with the client takes place on the input stream and output

stream of the returned Socket

◮ accept() blocks until a request from a client comes!

◮ close() your server socket when you are done.

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 8 / 17

slide-58
SLIDE 58

Fundamentals of Internet Connections

java.net.ServerSocket

A java.net.ServerSocket

◮ binds a port of the local machine

◮ ServerSocket(int port) ◮ throws java.io.IOException if the socket can’t be open (e.g. when the

port is not free!)

◮ throws java.lang.SecurityException if our code is not allowed to

bind a TCP port.

◮ e.g. if a Java applet downloaded from the Internet ◮ No need to catch this as it’s a RuntimeException

◮ accepts connections from clients

◮ Socket accept() returns the other endpoint of the connection ◮ Communication with the client takes place on the input stream and output

stream of the returned Socket

◮ accept() blocks until a request from a client comes!

◮ close() your server socket when you are done.

◮ Rarely happens. Servers usually call accept() in an endless loop DD1335 (Lecture 4) Basic Internet Programming Spring 2010 8 / 17

slide-59
SLIDE 59

Fundamentals of Internet Connections

A simple echo server

This program starts an echo server. Start with: java SimpleEchoServer port import java.io.*; import java.net.*; public class SimpleEchoServer { public static void main(String argv[]) throws IOException { ServerSocket server = new ServerSocket (Integer.valueOf(argv[0]).intValue()); while (true) { Socket conn = server.accept(); System.out.println( new java.util.Date() + " " + conn.getInetAddress()); InputStream in = conn.getInputStream(); OutputStream out= conn.getOutputStream(); byte[] buffer= new byte[8192]; while((int n= in.read(buffer, 0, 8192))!=-1)

  • ut.write(buffer, 0, n);

in.close(); out.close(); conn.close(); } } }

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 9 / 17

slide-60
SLIDE 60

Fundamentals of Internet Connections

A simple echo server . . .

On Windows: Start server: start java SimpleEchoServer 7

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 10 / 17

slide-61
SLIDE 61

Fundamentals of Internet Connections

A simple echo server . . .

On Windows: Start server: start java SimpleEchoServer 7 Send message: java TextEcho localhost "blah blah blah"

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 10 / 17

slide-62
SLIDE 62

Fundamentals of Internet Connections

A simple echo server . . .

On Windows: Start server: start java SimpleEchoServer 7 Send message: java TextEcho localhost "blah blah blah" On Unix you need to add a non-default port as an echo port, e.g. 7777, then Start server: java SimpleEchoServer 7777 &

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 10 / 17

slide-63
SLIDE 63

Fundamentals of Internet Connections

A simple echo server . . .

On Windows: Start server: start java SimpleEchoServer 7 Send message: java TextEcho localhost "blah blah blah" On Unix you need to add a non-default port as an echo port, e.g. 7777, then Start server: java SimpleEchoServer 7777 & Send message: java TextEcho localhost 7777 "blah blah blah"

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 10 / 17

slide-64
SLIDE 64

Fundamentals of Internet Connections

Multithreaded servers

If a client connects to our echo server and sends crap for 20 minutes, all other clients will have to wait 20 minutes before they can get a response. To avoid that, most servers process requests concurrently in separate processes, or lightweight processes (threads)

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 11 / 17

slide-65
SLIDE 65

Fundamentals of Internet Connections

Multithreaded servers

If a client connects to our echo server and sends crap for 20 minutes, all other clients will have to wait 20 minutes before they can get a response. To avoid that, most servers process requests concurrently in separate processes, or lightweight processes (threads) Creating a thread for each request is very expensive, But we’ll do that for the sake of exemplification.

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 11 / 17

slide-66
SLIDE 66

Fundamentals of Internet Connections

Multithreaded servers

If a client connects to our echo server and sends crap for 20 minutes, all other clients will have to wait 20 minutes before they can get a response. To avoid that, most servers process requests concurrently in separate processes, or lightweight processes (threads) Creating a thread for each request is very expensive, But we’ll do that for the sake of exemplification. Advanced servers use thread pools. Instead of being destroyed at the end of the client request, the thread is put “on hold” in a pool, and reused when another request comes

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 11 / 17

slide-67
SLIDE 67

Fundamentals of Internet Connections

Multithreaded Echo Server

import java.io.*; import java.net.*; public class EchoServer implements Runnable { Socket conn; /* member variable, for run() */ public EchoServer(Socket s){ conn = s; } public static void main(String argv[]) throws IOException { /* run is a member method, must create object to call it */ ServerSocket server = new ServerSocket(Integer.valueOf(argv[0]).intValue()); while(true) new Thread(new EchoServer(server.accept())).start(); } public void run() { try { /* run does not throw any exceptions */ InputStream in = conn.getInputStream(); OutputStream out = conn.getOutputStream(); byte[] buffer = new byte[8192]; int n; while((n = in.read(buffer, 0, 8192))!=-1)

  • ut.write(buffer, 0, n);

in.close(); out.close(); conn.close(); } catch(IOException e) { e.printStackTrace(); } } }

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 12 / 17

slide-68
SLIDE 68

Fundamentals of Internet Connections

A simple HTTP server

This program starts a HTTP server which sends back whatever is sent to it. Start with: java SimpleHttpServer port. Access with a browser: http://localhost:port/someFile?someParam=someValue import java.io.*; import java.net.*; public class SimpleHttpServer { public static void main(String argv[]) throws IOException { ServerSocket server = new ServerSocket(Integer.valueOf(argv[0]).intValue()); while(true) { Socket con = server.accept(); BufferedReader listen = new BufferedReader(new InputStreamReader(con.getInputStream())); PrintWriter talk = new PrintWriter(new OutputStreamWriter(con.getOutputStream())); talk.println("HTTP/1.1 200"); /* HTTP command */ talk.println("Content-type: text/plain"); /* HTTP header(s) */ talk.println(); /* empty line, as requested */ String line; /* HTTP response content starts: */ while((line=listen.readLine()).length()>0) talk.println(line); talk.close(); listen.close(); con.close(); } } }

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 13 / 17

slide-69
SLIDE 69

Fundamentals of Internet Connections

Application-level connections

We’ve made a HTTP connection by hand, making a TCP socket and “speaking” the HTTP protocol over the socket.

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 14 / 17

slide-70
SLIDE 70

Fundamentals of Internet Connections

Application-level connections

We’ve made a HTTP connection by hand, making a TCP socket and “speaking” the HTTP protocol over the socket. Instead, we can use a ready-made application level class that does the dirty protocol job for us.

(IP, ...) Transport (TCP, UDP, ...) Application (HTTP, FTP, Telnet) (HTTP, FTP, Telnet) Transport (TCP, UDP, ...) (IP, ...) Physical layer Network HTTP connection Application Network (Ethernet, FDDI, LocalTalk, drivers, ...)

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 14 / 17

slide-71
SLIDE 71

Fundamentals of Internet Connections

Application-level connections

We’ve made a HTTP connection by hand, making a TCP socket and “speaking” the HTTP protocol over the socket. Instead, we can use a ready-made application level class that does the dirty protocol job for us.

(IP, ...) Transport (TCP, UDP, ...) Application (HTTP, FTP, Telnet) (HTTP, FTP, Telnet) Transport (TCP, UDP, ...) (IP, ...) Physical layer Network HTTP connection Application Network (Ethernet, FDDI, LocalTalk, drivers, ...)

At the server side, instead of speaking the HTTP protocol, we can use a ready-made and optimized server (like Apache) and simply program how to treat a request (e.g. via CGI, next time)

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 14 / 17

slide-72
SLIDE 72

Fundamentals of Internet Connections

java.net.URLConnection

◮ Communicates to a URL, over a number of protocols

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 15 / 17

slide-73
SLIDE 73

Fundamentals of Internet Connections

java.net.URLConnection

◮ Communicates to a URL, over a number of protocols ◮ You cannot construct a URLConnection directly.

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 15 / 17

slide-74
SLIDE 74

Fundamentals of Internet Connections

java.net.URLConnection

◮ Communicates to a URL, over a number of protocols ◮ You cannot construct a URLConnection directly.

◮ You need a java.net.URL first, then call openConnection() DD1335 (Lecture 4) Basic Internet Programming Spring 2010 15 / 17

slide-75
SLIDE 75

Fundamentals of Internet Connections

java.net.URLConnection

◮ Communicates to a URL, over a number of protocols ◮ You cannot construct a URLConnection directly.

◮ You need a java.net.URL first, then call openConnection()

◮ Before you connect, you can configure how the URLConnection will work

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 15 / 17

slide-76
SLIDE 76

Fundamentals of Internet Connections

java.net.URLConnection

◮ Communicates to a URL, over a number of protocols ◮ You cannot construct a URLConnection directly.

◮ You need a java.net.URL first, then call openConnection()

◮ Before you connect, you can configure how the URLConnection will work

◮ setDoInput(boolean), setDoOutput(boolean) output is false by default DD1335 (Lecture 4) Basic Internet Programming Spring 2010 15 / 17

slide-77
SLIDE 77

Fundamentals of Internet Connections

java.net.URLConnection

◮ Communicates to a URL, over a number of protocols ◮ You cannot construct a URLConnection directly.

◮ You need a java.net.URL first, then call openConnection()

◮ Before you connect, you can configure how the URLConnection will work

◮ setDoInput(boolean), setDoOutput(boolean) output is false by default ◮ setUseCaches(boolean) can force a “reload” if false DD1335 (Lecture 4) Basic Internet Programming Spring 2010 15 / 17

slide-78
SLIDE 78

Fundamentals of Internet Connections

java.net.URLConnection

◮ Communicates to a URL, over a number of protocols ◮ You cannot construct a URLConnection directly.

◮ You need a java.net.URL first, then call openConnection()

◮ Before you connect, you can configure how the URLConnection will work

◮ setDoInput(boolean), setDoOutput(boolean) output is false by default ◮ setUseCaches(boolean) can force a “reload” if false ◮ setRequestProperty(String name, String value) can set e.g. a HTTP

header

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 15 / 17

slide-79
SLIDE 79

Fundamentals of Internet Connections

java.net.URLConnection

◮ Communicates to a URL, over a number of protocols ◮ You cannot construct a URLConnection directly.

◮ You need a java.net.URL first, then call openConnection()

◮ Before you connect, you can configure how the URLConnection will work

◮ setDoInput(boolean), setDoOutput(boolean) output is false by default ◮ setUseCaches(boolean) can force a “reload” if false ◮ setRequestProperty(String name, String value) can set e.g. a HTTP

header

◮ connect() does the actual opening of a TCP connection (socket) and information

exchange

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 15 / 17

slide-80
SLIDE 80

Fundamentals of Internet Connections

java.net.URLConnection

◮ Communicates to a URL, over a number of protocols ◮ You cannot construct a URLConnection directly.

◮ You need a java.net.URL first, then call openConnection()

◮ Before you connect, you can configure how the URLConnection will work

◮ setDoInput(boolean), setDoOutput(boolean) output is false by default ◮ setUseCaches(boolean) can force a “reload” if false ◮ setRequestProperty(String name, String value) can set e.g. a HTTP

header

◮ connect() does the actual opening of a TCP connection (socket) and information

exchange

◮ If there is more information to send and you have called setDoOutput(true), you can

call getOutputStream() to send it

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 15 / 17

slide-81
SLIDE 81

Fundamentals of Internet Connections

java.net.URLConnection

◮ Communicates to a URL, over a number of protocols ◮ You cannot construct a URLConnection directly.

◮ You need a java.net.URL first, then call openConnection()

◮ Before you connect, you can configure how the URLConnection will work

◮ setDoInput(boolean), setDoOutput(boolean) output is false by default ◮ setUseCaches(boolean) can force a “reload” if false ◮ setRequestProperty(String name, String value) can set e.g. a HTTP

header

◮ connect() does the actual opening of a TCP connection (socket) and information

exchange

◮ If there is more information to send and you have called setDoOutput(true), you can

call getOutputStream() to send it

◮ This can be used for e.g. a HTTP POST request DD1335 (Lecture 4) Basic Internet Programming Spring 2010 15 / 17

slide-82
SLIDE 82

Fundamentals of Internet Connections

java.net.URLConnection

◮ Communicates to a URL, over a number of protocols ◮ You cannot construct a URLConnection directly.

◮ You need a java.net.URL first, then call openConnection()

◮ Before you connect, you can configure how the URLConnection will work

◮ setDoInput(boolean), setDoOutput(boolean) output is false by default ◮ setUseCaches(boolean) can force a “reload” if false ◮ setRequestProperty(String name, String value) can set e.g. a HTTP

header

◮ connect() does the actual opening of a TCP connection (socket) and information

exchange

◮ If there is more information to send and you have called setDoOutput(true), you can

call getOutputStream() to send it

◮ This can be used for e.g. a HTTP POST request

◮ After that, you can get various details about the response (headers)

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 15 / 17

slide-83
SLIDE 83

Fundamentals of Internet Connections

java.net.URLConnection

◮ Communicates to a URL, over a number of protocols ◮ You cannot construct a URLConnection directly.

◮ You need a java.net.URL first, then call openConnection()

◮ Before you connect, you can configure how the URLConnection will work

◮ setDoInput(boolean), setDoOutput(boolean) output is false by default ◮ setUseCaches(boolean) can force a “reload” if false ◮ setRequestProperty(String name, String value) can set e.g. a HTTP

header

◮ connect() does the actual opening of a TCP connection (socket) and information

exchange

◮ If there is more information to send and you have called setDoOutput(true), you can

call getOutputStream() to send it

◮ This can be used for e.g. a HTTP POST request

◮ After that, you can get various details about the response (headers)

◮ getContentType(), getContentLength(), getContentEncoding(),

getDate()

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 15 / 17

slide-84
SLIDE 84

Fundamentals of Internet Connections

java.net.URLConnection

◮ Communicates to a URL, over a number of protocols ◮ You cannot construct a URLConnection directly.

◮ You need a java.net.URL first, then call openConnection()

◮ Before you connect, you can configure how the URLConnection will work

◮ setDoInput(boolean), setDoOutput(boolean) output is false by default ◮ setUseCaches(boolean) can force a “reload” if false ◮ setRequestProperty(String name, String value) can set e.g. a HTTP

header

◮ connect() does the actual opening of a TCP connection (socket) and information

exchange

◮ If there is more information to send and you have called setDoOutput(true), you can

call getOutputStream() to send it

◮ This can be used for e.g. a HTTP POST request

◮ After that, you can get various details about the response (headers)

◮ getContentType(), getContentLength(), getContentEncoding(),

getDate()

◮ getHeaderField(String name) provides info on any response header DD1335 (Lecture 4) Basic Internet Programming Spring 2010 15 / 17

slide-85
SLIDE 85

Fundamentals of Internet Connections

java.net.URLConnection

◮ Communicates to a URL, over a number of protocols ◮ You cannot construct a URLConnection directly.

◮ You need a java.net.URL first, then call openConnection()

◮ Before you connect, you can configure how the URLConnection will work

◮ setDoInput(boolean), setDoOutput(boolean) output is false by default ◮ setUseCaches(boolean) can force a “reload” if false ◮ setRequestProperty(String name, String value) can set e.g. a HTTP

header

◮ connect() does the actual opening of a TCP connection (socket) and information

exchange

◮ If there is more information to send and you have called setDoOutput(true), you can

call getOutputStream() to send it

◮ This can be used for e.g. a HTTP POST request

◮ After that, you can get various details about the response (headers)

◮ getContentType(), getContentLength(), getContentEncoding(),

getDate()

◮ getHeaderField(String name) provides info on any response header ◮ getContent() or getInputStream() give you the response itself (i.e. the file you

requested in the case of a HTTP connection) Remember to close any stream that you request from the connection

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 15 / 17

slide-86
SLIDE 86

Fundamentals of Internet Connections

HTTP access with URLConnection

This program makes a HTTP request and prints data about the result, and the result itself. java URLAccess http://www.nada.kth.se/index.html import java.io.*; import java.net.*; public class URLAccess { public static void main(String argv[]) throws IOException { URLConnection con = new URL(argv[0]).openConnection(); con.connect(); System.out.println("type: " + con.getContentType()); System.out.println("length: " + con.getContentLength()); if(con instanceof HttpURLConnection) System.out.println("method: " +((HttpURLConnection)con).getRequestMethod()); BufferedReader content = new BufferedReader(new InputStreamReader(con.getInputStream())); String line; while((line = content.readLine()) != null) System.out.println(line); content.close(); } }

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 16 / 17

slide-87
SLIDE 87

Fundamentals of Internet Connections

Some more on URLConnection

Other protocols than HTTP are supported

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 17 / 17

slide-88
SLIDE 88

Fundamentals of Internet Connections

Some more on URLConnection

Other protocols than HTTP are supported Actually URL.openConnection() never returns a URLConnection object

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 17 / 17

slide-89
SLIDE 89

Fundamentals of Internet Connections

Some more on URLConnection

Other protocols than HTTP are supported Actually URL.openConnection() never returns a URLConnection object It allways return an object from one of it’s subclasses

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 17 / 17

slide-90
SLIDE 90

Fundamentals of Internet Connections

Some more on URLConnection

Other protocols than HTTP are supported Actually URL.openConnection() never returns a URLConnection object It allways return an object from one of it’s subclasses Most notably HttpURLConnection

DD1335 (Lecture 4) Basic Internet Programming Spring 2010 17 / 17
