The 6 GHz Band: Say Goodbye to the Stone Age of Wi-Fi

Chuck Lukaszewski VP, Wireless Strategy & Policy

2

Bands & Channelization Under Study in US & EU/CEPT

6425 MHz

40 40 40 40 40 40 40 40 40 80 80 80 80 40 80 160 40 40 40 40 80 80 160 160 160 160 80 80 80 40 40 40 40 40 40

20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20

40 40 40 40 40 80 160 160 80 80 80 40 40 40

20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20

40

20 20 20

5925 MHz 7125 MHz 6875 MHz 6525 MHz

UNII-5

UNII-6

UNII-7 UNII-8 5925 - 6425

24 x 20 MHz 12 x 40 MHz 6 x 80 MHz 3 x 160 MHz 40 40 40 40 40 80 80 80 80 160 40 40 40 40 80 80 160 160 40 40 40

20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20

59 x 20 MHz 29 x 40 MHz 14 x 80 MHz 7 x 160 MHz

500 Megahertz in Europe 1.2 Gigahertz in USA &

3

6 GHz Timeline

2017 2018 2019 2020 2021+

Initial Advocacy at FCC FCC Notice of Inquiry (NOI) August 802.11ax PAR Revised FCC Notice of Proposed Rulemaking (NPRM) October NPRM Reply Phase Complete March 18 FCC Report & Order April 23 First 6 GHz APs Ship in USA 4Q 2020 First 6 GHz Radios Announced January 8 CEPT Technical and Regulatory Studies Begin EC Mandate ECC Report 302 Published May ETSI Standards Process Final Report 73 March ECC Decision Final Report “B” from CEPT to EC November National Regulations Published UK Ofcom Consultation January . Draft Report 73 from CEPT to EC July

2021

EC Decision January Draft Report “B” July

4

US Draft Report & Order Outcome

• Indoor low power across the entire band without AFC @ 5 dBm/MHz; Prohibition on connectors
• Automated Frequency Coordination (AFC) required in UNII-5/7 for “full” power indoor and all outdoor APs
• FNPRM on “Very Low Power” class for portable APs and short-range applications

6 dB Below AP (Peak?)

STANDARD POWER AP 6425 MHz 5925 MHz 7125 MHz 6875 MHz 6525 MHz

UNII-5 UNII-6 UNII-7 UNII-8 36 dBm with AFC 36 dBm with AFC 36/AFC 14 dBm 14 dBm

LOW POWER INDOOR AP VERY LOW POWER AP CLIENT DEVICES

FNPRM

5 dBm / MHz

FNPRM

5

5 GHz EIRP vs. 6 GHz Power Spectral Density for Low Power Indoor

Channel Width 20 MHz 40 MHz 80 MHz 160 MHz 320 MHz Noise floor vs. 20MHz +0 dB +3 dB +6 dB +9 dB +12 dB 5 GHz UNII-2b EIRP (Constant) 30 dBm 30 dBm 30 dBm 30 dBm 30 dBm PSD 17 dB 14 dB 11 dB 8 dB 5 dB "Net" EIRP 30 dBm 27 dBm 24 dBm 21 dBm 18 dBm 6 GHz LPI EIRP 18 dBm 21 dBm 24 dBm 27 dBm 30 dBm PSD (Constant) 5 dB 5 dB 5 dB 5 dB 5 dB "Net" EIRP 18 dBm 18 dBm 18 dBm 18 dBm 18 dBm
