University of Bristol 6 th October 2016 George Gibberd, MEng., C.Eng., MIMechE Everoze & Partners Bristol www.everoze.com Congratulations! Youve chosen Engineering! Youve chosen Bristol You can make a career out of

slide-1
SLIDE 1

University of Bristol 6th October 2016

George Gibberd, MEng., C.Eng., MIMechE Everoze & Partners Bristol www.everoze.com

slide-2
SLIDE 2

Congratulations!

 You’ve chosen Engineering!  You’ve chosen Bristol  You can make a career out of decarbonisation  As a renewables engineer:

 you will never be unemployed  you should never be bored  you will be challenged to the hilt  you get to play with some fantastic “big boys toys”  you will make a real difference to society  you will contribute the nation’s wealth  you will never be very rich………

slide-3
SLIDE 3

 but neither ……….

slide-4
SLIDE 4

Be prepared for change

 Huge change in 30 years:

 No mobile phones  No laptops  No internet  No google  No antisocial media

 You will see even greater changes  As engineers you will be behind those changes

slide-5
SLIDE 5

Wind Energy 30 years ago

Picture: Courtesy Gary Johnson

slide-6
SLIDE 6

My Career - Hydropower

slide-7
SLIDE 7

2000MW coal plant

slide-8
SLIDE 8

Performance testing & emissions

slide-9
SLIDE 9

Nuclear

slide-10
SLIDE 10

UK Tidal Stream Resource

3-6GW UK Tens of GW worldwide + Run of river

slide-11
SLIDE 11

Tidal Stream

  • Seaflow Project
  • 300kW tidal stream generator
  • Severn estuary, 2003
slide-12
SLIDE 12

Seaflow statistics

  • 11m rotor diameter.
  • 16m LAT, 11m tidal range (note surface

tip clearances)

  • MSP ~5.4kt. Design Hs 7m.
  • Access by RIB to ladder on pile.
  • Weather-limited.
  • OEM access for repairs proved difficult.
  • Power and load fluctuations first

identified, characteristics of tidal machines.

slide-13
SLIDE 13

Seaflow rotor

slide-14
SLIDE 14

Seaflow installation

slide-15
SLIDE 15

SeaGen 1.2MW twin rotor

  • Strangford Lough narrows - 2008
  • Twin 16m diameter rotors.
  • 26m water, 3.2m tidal range.
  • MSP ~7.3t. Minimal wave.
  • Access by RIB to pile ladder, as per

Seaflow, but sheltered location and very close to shore.

  • Passed 2000MWh mark (Oct 2010).
slide-16
SLIDE 16

SeaGen Installation

slide-17
SLIDE 17

Tidal Generation Ltd – 2005 to 2010 Founder and technical director

  • Established TGL with two colleagues,

and grew to 18 staff.

  • Put together an industrial consortium

for a DTI-funded R&D programme.

  • Developed concepts for the turbine,

foundation & installation, and O&M strategy.

  • Tested concepts separately at both

tank and full scale, supported by numerical modeling.

  • Sept 2010 - 500kW prototype

successfully generating at EMEC.

Picture: Tidal Generation Ltd.

slide-18
SLIDE 18

First ideas:

slide-19
SLIDE 19

First ideas:

slide-20
SLIDE 20

Bristol University Tank Testing

slide-21
SLIDE 21

More serious testing at IFREMER

Pictures: Tidal Generation Ltd.

slide-22
SLIDE 22

A new idea:

Picture: TGL Alstom

slide-23
SLIDE 23

Full scale testing of deployment concept

slide-24
SLIDE 24

TGL – foundation construction

  • Tripod design developed with SLP.
  • Fabricated and loaded out at SLP’s

Lowestoft yard.

  • Towed to EMEC onboard crane barge.
  • Placed in 45m at LAT on rocky bed.
  • Exposed site, 9kt peak spring currents

measured.

Picture: Rolls Royce Tidal Generation Ltd.

slide-25
SLIDE 25

Picture: Rolls Royce Tidal Generation Ltd.

slide-26
SLIDE 26

Towage up east coast to Orkney

Picture: George Gibberd

slide-27
SLIDE 27

TGL – underwater rock drilling

  • At TGL developed a novel underwater

rapid rock socket drilling technology for tidal sites.

  • Used successfully on site during 2009

to secure tripod.

  • Deployed from moored barge.

Picture: Rolls Royce Tidal Generation Ltd.

slide-28
SLIDE 28

Trial fit onto tripod pile sleeve

Picture: Rolls Royce Tidal Generation Ltd.

slide-29
SLIDE 29

Percussive drill

Picture: Rolls Royce Tidal Generation Ltd.

slide-30
SLIDE 30

Overboarding the drill rig

Picture: Rolls Royce Tidal Generation Ltd.

slide-31
SLIDE 31

Going fishing for a tripod….

Picture: Rolls Royce Tidal Generation Ltd.

slide-32
SLIDE 32

Jacuzzi time (7000cfm air)

Picture: Rolls Royce Tidal Generation Ltd.

slide-33
SLIDE 33

Turbine delivered to quayside

Picture: Rolls Royce Tidal Generation Ltd.

slide-34
SLIDE 34

Delivered to quayside at Kirkwall

Picture: Rolls Royce Tidal Generation Ltd.

slide-35
SLIDE 35

Shoreline testing

Picture: Rolls Royce Tidal Generation Ltd.

slide-36
SLIDE 36

Blades on, beginning to look like a turbine

Picture: Rolls Royce Tidal Generation Ltd.

slide-37
SLIDE 37

You mean it floats, too??

Picture: Rolls Royce Tidal Generation Ltd.

slide-38
SLIDE 38

Sails off into the sunset happily ever after….

Picture: Rolls Royce Tidal Generation Ltd.

slide-39
SLIDE 39

EMEC Tidal Site Activity

Reproduced with kind permission Jenny Norris, EMEC

slide-40
SLIDE 40

MeyGen Inner Sound project

Pictures: MeyGen

  • 4 x 1.5MW machines in Pentland Firth
  • Many years in development
  • Part funded public sources
  • Two turbine suppliers – Andritz

Hammerfest Hydro & Atlantis

  • Gravity base foundation
  • Site licensed for up to 398MW
slide-41
SLIDE 41

MeyGen Inner Sound project

Picture: MeyGen

slide-42
SLIDE 42

And if you think tidal is a challenge:

https://www.youtube.com/watch?v=u-9P2VflRWU

slide-43
SLIDE 43

Mechanical Engineering

Pictures: www.offshorewindbiz.com

slide-44
SLIDE 44

Electrical Engineering

(Apply Kirchoff’s law!)

Picture: www.cleantechnica.com Pictures: www.offshorewindbiz.com

slide-45
SLIDE 45

Civil Engineering

Picture: http://footo.nl/11Wed/oleg-strashnov Picture: www.marinespace.co.uk Picture: www.foundocean.com Picture: www,windcarrier.com

slide-46
SLIDE 46

Mud monkeys (sorry, geoscientists)

Picture: Flickr – Christina Maghill Picture: en.wikipedia.org Picture: www.ixsurvey.com.au

slide-47
SLIDE 47

Understanding ground conditions is vital

slide-48
SLIDE 48

Aeronautical Engineering

slide-49
SLIDE 49

Control Engineering

 Heart of the machine  Complex systems – dynamic & non-linear  Multi-input / multi-output  Floating wind offers new challenges – 6-DOF motion

slide-50
SLIDE 50

You are responsible for public safety

slide-51
SLIDE 51

Finally, yes even computer programmers have a role….

 Find yourself on the Venn diagram  Nerds & Geeks welcome  All major renewables progress will

be computer-dependent:

 Information processing & mgt.  Forecasting wind & solar yield  SCADA & maintenance  Smart metering  Grid management  Device controls

Picture: laughingsquid.com

slide-52
SLIDE 52

Where are renewables going?

 Electricity generation is only part of the low carbon picture:

 Renewable heat  Heat pumps  CHP & district heating schemes

 Renewables are only part of the electricity generation picture:

 Nuclear  Carbon Capture & Storage  Gas station backup capacity

 Energy efficiency – devices, zero carbon buildings  Energy management with increased percentage renewables on

the grid:

 Storage  Interconnection  Large users  Smart metering  Demand side management

slide-53
SLIDE 53

Where are renewables going?

 Societal changes such as Transport Electrification will have big impact:  Personal Energy Trading - Rooftop solar, domestic solar, batteries –

flexible usage

1976

Top speed: 6mph Range: 10 miles Acceleration: 0 to 6 (eventually)

2016

Top speed: 125mph Range: 250 miles Acceleration: 0 to 6o in 3.7s

Picture: en.wikipedia.org Picture: en.wikipedia.org

slide-54
SLIDE 54

Some points to consider

 Take the opportunity of university to acquire breadth and

depth of technical knowledge

 Take every chance you get to work with real plant  Understand how things are made  Maintain strong cross-disciplinary interests  Consider the human angle  Take CPD seriously:

 - read papers and journals  - be aware of new technologies on the horizon  - discuss ideas with tutors and peers  - don’t be afraid of iconoclasm

slide-55
SLIDE 55

Best reference text for renewables:

  • Free download:

https://www.withouthotair.com/

  • Easy to understand orders of

magnitude and rules of thumb

  • Good supporting technical

sections

slide-56
SLIDE 56

Thank you for your attention Questions?
