5G and RF Safety Introduc duction Kevin Ramdas, Ph.D. TelecomTRAIN - - PowerPoint PPT Presentation

5G and RF Safety Introduc duction Kevin Ramdas, Ph.D. TelecomTRAIN Director Humber College Professor 2 RF RF Ener nergy gy in t ter erms of of r radiation Wha hat i t is 5G 5G? 1 1. Higher frequencies 2. More base stations 3.


slide-1
SLIDE 1

5G and RF Safety

slide-2
SLIDE 2

Introduc duction

2

TelecomTRAIN Director Humber College Professor

Kevin Ramdas, Ph.D.

slide-3
SLIDE 3

RF RF Ener nergy gy in t ter erms of

  • f r

radiation

slide-4
SLIDE 4

1 2 3

  • 1. Higher frequencies
  • 2. More base stations
  • 3. Beamforming

Wha hat i t is 5G 5G?

slide-5
SLIDE 5

Regu egulation

slide-6
SLIDE 6

Setting up a Compliance Program: Best Practices

Purpose: To provide important steps to help you establish your RF Safety Awareness program for your organization, which over time, will help you develop a more robust program.

Step 1 – Make it a priority Step 2 - Responsibility Step 3 - Improvement

slide-7
SLIDE 7

Step 1 – Make it a priority

Make safety and health your top priority – An employee who feels supported and safe is an engaged employee.

  • Be proactive
  • Lead by example
  • DO NOT rely on service providers
  • Establish and exercise a robust program
slide-8
SLIDE 8

Step 2: Responsibility

A wireless service provider (WSP) has an overall responsibility to comply with regulatory bodies in maintaining a safe and secure environment. But relying solely on the service provider should not be your responsibility.

  • Fully understand RF and it effects.
  • Provide training: Set the frequency of your training

(annually or biannually, project base).

  • Provide proper PPE to your employees.
  • Enforce regulatory bodies’ regulations.
  • ALWAYS keep emergency contacts handy.
slide-9
SLIDE 9

Step 3: Improvement

There is ALWAYS room for improvement

  • Stay informed with technology.
  • Keep track of your portfolio and/or inventory.
  • Review and update your program accordingly.
  • Keep the public informed.
slide-10
SLIDE 10

Feel free to contact me: kevin.ramdas@telecomtrain.ca OR https://www.linkedin.com/in/kevinramdas/

10

Thank you!

slide-11
SLIDE 11
slide-12
SLIDE 12

COMPANY PROPRIETARY

5G and the new challenge!

slide-13
SLIDE 13

COMPANY PROPRIETARY

Summary 1- Company overview 2- Introduction to 5 G challenges 3- EMF measurement in the Telecommunication industry

slide-14
SLIDE 14

COMPANY PROPRIETARY

23 years

(since 1997)

About Wavecontrol: highlights +60 countries

+3000

Delivered instruments

5 continents ISO 17025

accredited calibration lab

ISO 9001

certified company

Continuous

R+D

+5000

ILAC accredited calibrations

slide-15
SLIDE 15

COMPANY PROPRIETARY

17025 Accredited Calibrations

  • LabCal Wavecontrol: ISO 17025 Accredited Calibration Laboratory for probes.
  • All equipment delivered with accredited calibration
  • ILAC calibration accepted Worldwide
slide-16
SLIDE 16

COMPANY PROPRIETARY

5G Challenges

  • Frequency range: 5G will be present in several

new frequency bands:

✓Sub-6GHz (for example 3.5GHz) ✓mm Waves (28, 39 … GHz)

  • Wavecontrol has already increased its probe

frequency range up to 60 GHz so it can cover all the next 5G frequency band allocation.

slide-17
SLIDE 17

COMPANY PROPRIETARY

5G Challenges

  • EMF exposure depends even more on

the traffic due to beam sweeping.

  • No standardized methods is defined to measure

the EMF exposure. Several methods are under considerations​:

✓Force the antenna under 100% traffic inside the desired beam with a user equipment (UE) ✓Determine or extrapolate the maximum exposure with fast RMS detection.

slide-18
SLIDE 18

COMPANY PROPRIETARY

EMF measurement in the Telecommunication industry

Following : IEC 62232, ITU-T K.61, etc.

slide-19
SLIDE 19

COMPANY PROPRIETARY

EMF measurement in the Telecommunication industry

  • Properties of EMF in Telecoms Industry
  • Field regions (near-field and far-field)
  • In near-field, both E and H should be measured
  • In far-field, only one is measured. The other can be evaluated

using the formula.

  • Measured value can be in field intensity (E/H) or power density

(S) units.

Requirements of Measurement instrument

  • Isotropic measurement (preferred)
  • Broadband (easier and cheaper) or Narrowband
  • Minimum sensitivity = 1 V/m
  • Isotropy = < 2 dB, Linearity = less than ± 1/1.5 dB
  • Frequency response:
  • 900 MHz – 3 GHz = ± 1.5 dB
  • Below 900 MHz or Above 3 GHz = ± 3 dB

E/H = Z0 = 377 Ohms (i.e. Impedance of free space)

Standards – IEC 62232 and ITU-T K.61

slide-20
SLIDE 20

COMPANY PROPRIETARY

Measurement Procedures and Conditions

  • Compile all the relevant information of the

measuring site:

  • Sources of EMF around site and their characteristics

(frequency, intensity, the type and orientation of the antenna, degree of inclination. etc) for proper positioning (see figure).

  • Possible perturbation or interference with

measurement

  • Preassessment to locate sensitive areas with maximum

exposure levels (Hotspots).

slide-21
SLIDE 21

COMPANY PROPRIETARY

Averaging:

  • If required, Spatial average should be done at the height of possible human

presence (1.5m , vary between 0 to 2 m)

  • Time averaged according to standard used.
  • 6 mins, 30 mins or as stated otherwise.

Measurement Procedures and Conditions

slide-22
SLIDE 22

COMPANY PROPRIETARY

SMP2 – RF Human Exposure Assessment

  • Move the SMP2 around and look for the maximum value.
  • Place the SMP2 on a tripod at the correct height.
  • Press the LOG button. The SMP2 will start measuring for

the measurement time set.

  • Find your measurement in MENU -> MEASUREMENT LOG.

Measurement Procedures and Conditions

slide-23
SLIDE 23

COMPANY PROPRIETARY

PC Software: SMP2 Reader

  • Remote control and Measurement
  • Using F.O. connection
  • Display
  • SMP2 parameters
  • Real time measurements
  • Google map location (if GPS was ON)
  • Measurements visualization
  • Graph format
  • Table format
  • Import data from SMP2 meter
  • Automatic report generator
slide-24
SLIDE 24

COMPANY PROPRIETARY

  • Automatic generated report with info:
  • Logo (customizable)
  • Used SMP2 + Probe information
  • Last automatic screenshot (if activated)
  • Measurements settings , date and time
  • Results
  • Measurements in graph and table format
  • Location (if GPS was activated)

PC Software: SMP2 Reader

slide-25
SLIDE 25

COMPANY PROPRIETARY

Thank you

HEADQUARTERS Wavecontrol S.L. Carrer de Pallars 65-71 08018 Barcelona (SPAIN)

  • Tel. [+34] 933 208 055

USA OFFICE Wavecontrol, Inc Overlook Corporate Center 150 Clove Road, 11th Floor Little Falls, NJ 07424-2138 (USA)

www.wavecontrol.com info@wavecontrol.com
