55 GANSEVORT STREET, MANHATTAN PROPOSED SIDEWALK CAFE AND AWNING - - PowerPoint PPT Presentation

55 GANSEVORT STREET, MANHATTAN PROPOSED SIDEWALK CAFE AND AWNING ALTERATION

Landmarks Preservation Commission Presentation Page 1

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATION, SIDEWALK CAFÉ, AND SIDEWALK ALTERATION

Proposed Sidewalk Café, with LPC-approved façade restoration. October 2019: Current condition, undergoing renovation.

Insert Rendering showing proposed sidewalk café, awning alteration, and extended diamond plate here

Landmarks Preservation Commission Presentation Page 2

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATION, SIDEWALK CAFÉ, AND SIDEWALK ALTERATION

Insert Rendering showing proposed sidewalk café, awning alteration, and extended diamond plate here (use straight-on view)

Greenwich Village Historic District

W e s t 1 5 t h S t r e e t 4 4 4 3 8 W e s t 1 4 t h S t r e e t 4 4 8 4 4 5 3 5 1 W e s t 1 3 t h S t r e e t 4 3 2 L i t t l e W e s t 1 2 t h S t r e e t 4 3 9 2 1 Gansevoort Street 73 28 Horatio Street 85 115 West Street 521 535 108 816 802 799 838 846 835 831 639 1/2 Washington Street 874 8 7 7 3 2 Hudson Street 685 Ninth Avenue 59 6 reenwich Street

H i g h L i n e

­

8 7 2 4 2 9 4 4 49 8 649 669 3 5 5 22 Gansevoort Market Historic District

Designated: September 9th, 2003

October 2019: Current condition, undergoing renovation Proposed Sidewalk Cafe, with LPC - approved facade restoration Gansevoort Market Historic District Map

Landmarks Preservation Commission Presentation Page 2

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATION, SIDEWALK CAFÉ, AND SIDEWALK ALTERATION

Insert Rendering showing proposed sidewalk café, awning alteration, and extended diamond plate here (use straight-on view)

Landmarks Preservation Commission Presentation Page 2

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATION, SIDEWALK CAFÉ, AND SIDEWALK ALTERATION

Insert Rendering showing proposed sidewalk café, awning alteration, and extended diamond plate here (use straight-on view)

Landmarks Preservation Commission Presentation Page 2

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATION, SIDEWALK CAFÉ, AND SIDEWALK ALTERATION

Insert Rendering showing proposed sidewalk café, awning alteration, and extended diamond plate here (use straight-on view)

Rendered South Elevation

Landmarks Preservation Commission Presentation Page 3

55 GANSEVOORT STREET, MANHATTAN HISTORIC PHOTOS

1936, by Berenice Abbott. (MCNY) 1940’s Tax Photo. (NYC Municipal Archive) 2003 Designation Photo. (NYC Landmarks Preservation Commission)

Landmarks Preservation Commission Presentation Page 4

55 GANSEVOORT STREET, MANHATTAN SIDEWALK AND GROUND FLOOR CONDITIONS PRIOR TO ON-GOING RENOVATION

2015: Sidewalk view, looking west. 2015: Sidewalk view, looking east. 2015: 55 Gansevoort Street, looking west. 2015: Awning and storefronts, looking west. 2015: Awning and storefronts, eastern end of the building.

Landmarks Preservation Commission Presentation Page 4

55 GANSEVOORT STREET, MANHATTAN SIDEWALK AND GROUND FLOOR CONDITIONS PRIOR TO ON-GOING RENOVATION

2015: Sidewalk view, looking west. 2015: Sidewalk view, looking east. 2015: 55 Gansevoort Street, looking west. 2015: Awning and storefronts, looking west. 2015: Awning and storefronts, eastern end of the building.

Landmarks Preservation Commission Presentation Page 5

55 GANSEVOORT STREET, MANHATTAN PREVIOUS AWNING ALTERATION APPROVAL

Ground floor and awnings alterations approved in 2017.

Landmarks Preservation Commission Presentation Page 5

55 GANSEVOORT STREET, MANHATTAN PREVIOUS AWNING ALTERATION APPROVAL

Ground floor and awnings alterations approved in 2017.

Landmarks Preservation Commission Presentation Page 6

55 GANSEVOORT STREET, MANHATTAN PREVIOUS AWNING ALTERATION APPROVAL

Detail of ground floor and awnings alterations approved in 2017.

Landmarks Preservation Commission Presentation Page 6

55 GANSEVOORT STREET, MANHATTAN PREVIOUS AWNING ALTERATION APPROVAL

Detail of ground floor and awnings alterations approved in 2017.

Landmarks Preservation Commission Presentation Page 7

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATIONS AND SIDEWALK CAFÉ

(Elevations and Detail drawings on this page)

Landmarks Preservation Commission Presentation Page 7

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATIONS AND SIDEWALK CAFÉ

(Elevations and Detail drawings on this page)

Page 7

Proposed Sidewalk Cafe Elevation Showing East Awning Section Removed

SCALE: 1/8” = 1’-0”

N E W E N G L A N D B I S C U I T W O R K

REMOVE EXISTING SECTION OF AWNING 11'-03

Proposed Sidewalk Cafe Enlarged Elevation

SCALE:1/2” = 1’-0”

2'-0" 6" 2" Landmarks Preservation Commission Presentation Page 7

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATIONS AND SIDEWALK CAFÉ

(Elevations and Detail drawings on this page)

Landmarks Preservation Commission Presentation Page 7

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATIONS AND SIDEWALK CAFÉ

(Elevations and Detail drawings on this page)

Page 8

SCALE:1/2” = 1’-0”

Section Through Sidewalk Cafe

Landmarks Preservation Commission Presentation Page 7

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATIONS AND SIDEWALK CAFÉ

(Elevations and Detail drawings on this page)

Landmarks Preservation Commission Presentation Page 7

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATIONS AND SIDEWALK CAFÉ

(Elevations and Detail drawings on this page)

3" DOWNSPOUT

1 4" MALE FLARE FITTING FOR 1 2" GAS LINE 1 2 " GAS LINE RUNNING ABOVE STEEL WITHIN

AWNING PARALLEL TO BUILDING TINTED TEMPERED GLASS UPLIGHTS BUILT INTO REMOVABLE DECK REMOVABLE DECKING ON PROPOSED DIAMOND PLATE STEEL 1'-10" PLANTER 8'-7" 6" HEDGE 8'-91 4" B.O. LIGHT FIXTURE 3'-0" LANTERN HEIGHT 1'-0" PLANTER 3'-21 2" 1'-8" 1'-10" 1'-5" 2" 4'-73 4" 1'-5" 1'-8" 1'-10" PLANTER 7'-5 1

2 " E.O. DECKING FROM FACADE TO

E.O. 22" x 22" PLANTER 7'-11 1

4 " E.O. DECKING FROM

FACADE TO E.O. 1' PLANTER Page 9

C L

7'-5 1

2 " E.O. DECKING FROM FACADE TO

E.O. 22" x 22" PLANTER 7'-11 1

4 " E.O. DECKING FROM

FACADE TO E.O. 1' PLANTER REMOVABLE DECKING ON PROPOSED DIAMOND PLATE STEEL UPLIGHTS BUILT INTO REMOVABLE DECK Landmarks Preservation Commission Presentation Page 7

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATIONS AND SIDEWALK CAFÉ

(Elevations and Detail drawings on this page)

SCALE:1/2” = 1’-0”

Section at Guesthouse Entry

Landmarks Preservation Commission Presentation Page 7

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATIONS AND SIDEWALK CAFÉ

(Elevations and Detail drawings on this page)

Landmarks Preservation Commission Presentation Page 7

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATIONS AND SIDEWALK CAFÉ

(Elevations and Detail drawings on this page)

Page 10

3" DOWNSPOUT

1 4" MALE FLARE FITTING FOR 1 2" GAS LINE 1 2 " GAS LINE RUNNING ABOVE STEEL WITHIN

AWNING PARALLEL TO BUILDING TINTED TEMPERED GLASS 2'-0" PLANTER 6" HEDGE 8'-91 4" B.O. LIGHT FIXTURE 3'-0" LANTERN HEIGHT 1'-10" PLANTER 6'-91 4" PLANTER

Landmarks Preservation Commission Presentation Page 8

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATIONS AND SIDEWALK CAFÉ

(Previously approved Plan and proposed plan on this page)

Awning plan approved in 2017.

Landmarks Preservation Commission Presentation Page 7

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATIONS AND SIDEWALK CAFÉ

(Elevations and Detail drawings on this page)

Page 11

Proposed Sidewalk Cafe Plan

SCALE:1/8” = 1’-0”

3'-0" 3'-0" 28'-73 4" OVERALL PLANTER 28'-61 2" OVERALL PLANTER

storage

113

LANTERN ABOVE REMOVABLE DECKING

6'-1"

[12'-8" A.F.F.]

1 4" FLARE FITTING

FOR 1

2" GAS LINE

RUNNING PARALLEL TO BUILDING WITHIN AWNING 1

2" GAS LINE

3" DOWNSPOUT EXISTING AWNING EXTENT 1

2" GAS LINE

3" DOWNSPOUT STANDPIPE/ HOSE BIBB

61'-101 4" OVERALL 9'-0"

1:12 22" x 24" 22" x 54" UP 1:12 U P 1 : 1 2 U P 1 : 1 2 IN-DECK LIGHTING UP 1:20 EXISTING DIAMOND PLATE L I N E PROPOSED DIAMOND PLATE LINE

4'-7 3

4 "

6'-0" 3'-0" 18'-0" 113 4" 3'-03 4" 1'-0" 1'-10" 1'-5" 3'-3" 1'-6" 3'-111 2" 1'-71 2"

CAFE

5'-21

5'-81

Landmarks Preservation Commission Presentation Page 8

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATIONS AND SIDEWALK CAFÉ

(Previously approved Plan and proposed plan on this page)

Awning plan approved in 2017.

Landmarks Preservation Commission Presentation Page 7

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATIONS AND SIDEWALK CAFÉ

(Elevations and Detail drawings on this page)

Page 12 Landmarks Preservation Commission Presentation Page 8

55 GANSEVOORT STREET, MANHATTAN PROPOSED AWNING ALTERATIONS AND SIDEWALK CAFÉ

(Previously approved Plan and proposed plan on this page)

Awning plan approved in 2017.

Proposed Sidewalk Cafe with New Awning Layout

SCALE:1/8” = 1’-0”

storage

113 6'-1"

[12'-8" A.F.F.]

3'-0"

1 4" FLARE FITTING

FOR 1

2" GAS LINE

RUNNING PARALLEL TO BUILDING WITHIN AWNING 1

2" GAS LINE

3" DOWNSPOUT EXISTING AWNING EXTENT 1

2" GAS LINE

3" DOWNSPOUT STANDPIPE/ HOSE BIBB

EXISTING D I A M O N D P L A T E LINE PROPOSED D I A M O N D P L A T E LINE

5'-81 4" TYP. 18'-0" 1'-6" 5'-6"

2'-21 2" 2'-21 2" 2'-21 2"

108'-73

4" AWNING

12'-21

2" AWNING

Landmarks Preservation Commission Presentation Page 9

55 GANSEVOORT STREET, MANHATTAN PROPOSED MATERIALITY AND FIXTURES

(Details and material sample images on this page)

PAINTED WOOD PLANTER REMOVABLE DECKING BOXWOOD HEDGING LANTERNS Page 13

Landmarks Preservation Commission Presentation Page 10

55 GANSEVOORT STREET, MANHATTAN DISTRICT CONTEXT: AWNINGS

414 West 14th Street, looking east. 415 West 13th Street, gutter and leader at awning. 46 Gansevoort Street. 835 Washington Street sidewalk café 46 Gansevoort Street, close up of flat glass awning. 414 West 14th Street, looking west.

Landmarks Preservation Commission Presentation Page 10

55 GANSEVOORT STREET, MANHATTAN DISTRICT CONTEXT: AWNINGS

414 West 14th Street, looking east. 415 West 13th Street, gutter and leader at awning. 46 Gansevoort Street. 835 Washington Street sidewalk café 46 Gansevoort Street, close up of flat glass awning. 414 West 14th Street, looking west.

Page 14

Landmarks Preservation Commission Presentation Page 11

55 GANSEVOORT STREET, MANHATTAN HISTORIC CONTEXT FOR MATERIALITY OF SIDEWALK CAFÉ

1936: South side of Gansevoort Street, from Ninth Avenue to Washington Street, looking west, showing wood crates piled up in front of buildings. (P.L. Sperr, NYPL) 1936: North side of Little West 12th Street, looking west from Ninth Avenue. (P.L. Sperr, NYPL) 1936: North side of Little West 12th Street, looking west from Ninth Avenue. (NYPL)

Landmarks Preservation Commission Presentation Page 11

55 GANSEVOORT STREET, MANHATTAN HISTORIC CONTEXT FOR MATERIALITY OF SIDEWALK CAFÉ

1936: South side of Gansevoort Street, from Ninth Avenue to Washington Street, looking west, showing wood crates piled up in front of buildings. (P.L. Sperr, NYPL) 1936: North side of Little West 12th Street, looking west from Ninth Avenue. (P.L. Sperr, NYPL) 1936: North side of Little West 12th Street, looking west from Ninth Avenue. (NYPL)

Page 15

Landmarks Preservation Commission Presentation Page 12

55 GANSEVOORT STREET, MANHATTAN HISTORIC CONTEXT FOR MATERIALITY OF SIDEWALK CAFÉ

Circa 1900 New England Biscuit Works wood box with this building’s address

• n the label. (Peu-Duvallon)

1936 photo by Berenice Abbott, cropped to show boxes being unloaded into 55 Gansevoort Street, and wood fruit barrels at building to the east. (MCNY) Circa 1900 New England Biscuit Works wood box with this building’s address on the label. (Peu-Duvallon) Close up of circa 1900 New England Biscuit Works wood box with this building’s address on the label. (Peu-Duvallon) Letterhead from 1900 correspondence from the E.S. Burnham Company, one of the first tenants at 55 Gansevoort Street. (Peu-Duvallon)

Landmarks Preservation Commission Presentation Page 12

55 GANSEVOORT STREET, MANHATTAN HISTORIC CONTEXT FOR MATERIALITY OF SIDEWALK CAFÉ

Circa 1900 New England Biscuit Works wood box with this building’s address

• n the label. (Peu-Duvallon)

1936 photo by Berenice Abbott, cropped to show boxes being unloaded into 55 Gansevoort Street, and wood fruit barrels at building to the east. (MCNY) Circa 1900 New England Biscuit Works wood box with this building’s address on the label. (Peu-Duvallon) Close up of circa 1900 New England Biscuit Works wood box with this building’s address on the label. (Peu-Duvallon) Letterhead from 1900 correspondence from the E.S. Burnham Company, one of the first tenants at 55 Gansevoort Street. (Peu-Duvallon)

Page 16 1936 photo by Berenice Abbott, cropped to show boxes being unloaded into 55 Gansevoort Street, and wood fruit barrels at building to the east. (MCNY) Circa 1900 New England Biscuit Works wood box with this building’s address

• n the label. (Peu-Duvallon)

Letterhead from 1900 correspondence from the E.S. Burnham Company, one of the first tenants at 55 Gansevoort Street. (Peu-Duvallon) Circa 1900 New England Biscuit Works wood box with this building’s address on the label. (Peu-Duvallon) Close up of circa 1900 New England Biscuit Works wood box with this building’s address on the label. (Peu-Duvallon)

Landmarks Preservation Commission Presentation Page 13

55 GANSEVOORT STREET, MANHATTAN DISTRICT CONTEXT: WOOD ELEMENTS

410 West 13th Street wood awning. 5 Ninth Avenue, wood door surround and windows. 52 Gansevoort Street sidewalk café. INSERT MAPS on EACH PAGE TO LOCATE PRECEDENTS 10 Little West 12th Street wood storefronts

Landmarks Preservation Commission Presentation Page 12

55 GANSEVOORT STREET, MANHATTAN HISTORIC CONTEXT FOR MATERIALITY OF SIDEWALK CAFÉ

Circa 1900 New England Biscuit Works wood box with this building’s address

• n the label. (Peu-Duvallon)

1936 photo by Berenice Abbott, cropped to show boxes being unloaded into 55 Gansevoort Street, and wood fruit barrels at building to the east. (MCNY) Circa 1900 New England Biscuit Works wood box with this building’s address on the label. (Peu-Duvallon) Close up of circa 1900 New England Biscuit Works wood box with this building’s address on the label. (Peu-Duvallon) Letterhead from 1900 correspondence from the E.S. Burnham Company, one of the first tenants at 55 Gansevoort Street. (Peu-Duvallon)

Page 17

410 West 13th Street wood awning. 5 Ninth Avenue, wood door surround and windows. 10 Little West 12thStreet wood storefronts

44 NINTH AVE 675 HUDSON ST 1 LITTLE WEST 12TH ST 7 NINTH AVE 420 WEST 13TH ST 835 WASHINGTON ST 52 GANSEVOORT ST 5 NINTH AVE 10 LITTLE WEST 12TH 410 WEST 13TH ST RH GH

District Context Map

Landmarks Preservation Commission Presentation Page 14

55 GANSEVOORT STREET, MANHATTAN DISTRICT CONTEXT: SIDEWALK CAFÉS

52 Gansevoort Street sidewalk café. 420 West 13th Street sidewalk café, looking west. 420 West 13th Street sidewalk café, looking east. 52 Gansevoort Street sidewalk café. 835 Washington Street sidewalk café 835 Washington Street sidewalk café

Landmarks Preservation Commission Presentation Page 12

55 GANSEVOORT STREET, MANHATTAN HISTORIC CONTEXT FOR MATERIALITY OF SIDEWALK CAFÉ

Circa 1900 New England Biscuit Works wood box with this building’s address

• n the label. (Peu-Duvallon)

1936 photo by Berenice Abbott, cropped to show boxes being unloaded into 55 Gansevoort Street, and wood fruit barrels at building to the east. (MCNY) Circa 1900 New England Biscuit Works wood box with this building’s address on the label. (Peu-Duvallon) Close up of circa 1900 New England Biscuit Works wood box with this building’s address on the label. (Peu-Duvallon) Letterhead from 1900 correspondence from the E.S. Burnham Company, one of the first tenants at 55 Gansevoort Street. (Peu-Duvallon)

Page 18 52 Gansevoort Street sidewalk café. 835 Washington Street sidewalk café 420 West 13th Street sidewalk café, looking east. 52 Gansevoort Street sidewalk café. 835 Washington Street sidewalk café 420 West 13th Street sidewalk café, looking west.

Landmarks Preservation Commission Presentation Page 15

55 GANSEVOORT STREET, MANHATTAN DISTRICT CONTEXT PHOTOS: SIDEWALK CAFÉS

7 Ninth Avenue sidewalk café. 1 Little West 12th Street sidewalk café. 7 Ninth Avenue sidewalk café. 1 Little West 12th Street sidewalk café. 44 Ninth Avenue sidewalk café. 675 Hudson Street at 14th Street sidewalk café.

Landmarks Preservation Commission Presentation Page 12

55 GANSEVOORT STREET, MANHATTAN HISTORIC CONTEXT FOR MATERIALITY OF SIDEWALK CAFÉ

Circa 1900 New England Biscuit Works wood box with this building’s address

• n the label. (Peu-Duvallon)

1936 photo by Berenice Abbott, cropped to show boxes being unloaded into 55 Gansevoort Street, and wood fruit barrels at building to the east. (MCNY) Circa 1900 New England Biscuit Works wood box with this building’s address on the label. (Peu-Duvallon) Close up of circa 1900 New England Biscuit Works wood box with this building’s address on the label. (Peu-Duvallon) Letterhead from 1900 correspondence from the E.S. Burnham Company, one of the first tenants at 55 Gansevoort Street. (Peu-Duvallon)

Page 19

7 Ninth Avenue sidewalk café. 7 Ninth Avenue sidewalk café. 1 Little West 12th Street sidewalk café. 1 Little West 12th Street sidewalk café. 675 Hudson Street at 14thStreet sidewalk café. 44 Ninth Avenue sidewalk café.

Landmarks Preservation Commission Presentation Page 16

55 GANSEVOORT STREET, MANHATTAN PROPOSED SIDEWALK CAFÉ RENDERINGS

Insert Proposed Sidewalk Café rendering here, looking west. Insert Proposed Sidewalk Café rendering here, looking east.

Landmarks Preservation Commission Presentation Page 12

55 GANSEVOORT STREET, MANHATTAN HISTORIC CONTEXT FOR MATERIALITY OF SIDEWALK CAFÉ

Circa 1900 New England Biscuit Works wood box with this building’s address

• n the label. (Peu-Duvallon)

1936 photo by Berenice Abbott, cropped to show boxes being unloaded into 55 Gansevoort Street, and wood fruit barrels at building to the east. (MCNY) Circa 1900 New England Biscuit Works wood box with this building’s address on the label. (Peu-Duvallon) Close up of circa 1900 New England Biscuit Works wood box with this building’s address on the label. (Peu-Duvallon) Letterhead from 1900 correspondence from the E.S. Burnham Company, one of the first tenants at 55 Gansevoort Street. (Peu-Duvallon)

Page 22

Proposed Sidewalk Cafe Looking East

Landmarks Preservation Commission Presentation Page 17

55 GANSEVOORT STREET, MANHATTAN PROPOSED SIDEWALK CAFÉ DETAILS

Insert Proposed Sidewalk Café renderings here

Landmarks Preservation Commission Presentation Page 12

55 GANSEVOORT STREET, MANHATTAN HISTORIC CONTEXT FOR MATERIALITY OF SIDEWALK CAFÉ

Circa 1900 New England Biscuit Works wood box with this building’s address

• n the label. (Peu-Duvallon)

1936 photo by Berenice Abbott, cropped to show boxes being unloaded into 55 Gansevoort Street, and wood fruit barrels at building to the east. (MCNY) Circa 1900 New England Biscuit Works wood box with this building’s address on the label. (Peu-Duvallon) Close up of circa 1900 New England Biscuit Works wood box with this building’s address on the label. (Peu-Duvallon) Letterhead from 1900 correspondence from the E.S. Burnham Company, one of the first tenants at 55 Gansevoort Street. (Peu-Duvallon)

Page 23

Proposed Sidewalk Cafe Looking West
