5245-02-02, 72 WIS 23 WIS 11– Mineral Point County Shop Road to Minerva Street Lafayette County Public Involvement Meeting #3 October 11, 2018 5:30 p.m. to 7:30 p.m.

2

Project Team

 WisDOT Project Development Supervisor

• Bill Strobel, PE

 WisDOT Project Manager

• Matt Dapp, PE

 WisDOT Design Team

• James Rinzel

 WisDOT Real Estate Team

• Teresa Klein
• Kema Williams

3

Project Team

 Structure Design

• Michael Baker International

 Plat Development and Survey

• JT Engineering

 Municipal Design

• Delta 3 Engineering
• Vierbicher
• KL Engineering

4

Overview

 Project Location  Existing Facility  Project Needs  Project Improvements  Project Impacts  Project Schedule  Open House

5 County Shop Rd Minerva Street

Project Location

6

Existing Facility

 1.49-mile roadway section  Two-lane urban roadway

• Residential area south of the bridge

 Concrete replaced in 1966  Asphalt replaced in 1984  6,900 vehicles per day

• Business area north of the bridge

 Asphalt replaced in 1989  2,700 – 10,000 vehicles per day

• Parking lanes

 Variable Land Terrain  66 foot right-of-way width

(typical)

7

Project Needs

 Pavement Deterioration  Structure Deterioration  Substandard Roadway Features

• Intersection Geometry
• ADA Concerns
• Crosswalk Locations

 Utility Replacements

• Water
• Sanitary
• Lighting
• Storm Sewer

8

Project Improvements

 Roadway Sections  Superstructure Replacement  Intersection Improvements

• OSOW Accommodations

 ADA Upgrades  Utility Replacements

9

Roadway Sections

Proposed Section County Shop Road to Center Hill Road

10

Roadway Sections

Proposed Section Center Hill Road to Pecatonica River Bridge

11

Retaining Walls

 Modular Block Retaining Wall

12

Roadway Sections

Proposed Section Pecatonica River Bridge to Cornelia Street

13

Roadway Sections

Proposed Section Cornelia Street to Harriet Street

14

Roadway Sections

Proposed Section Harriet Street to Mary Street

15

Roadway Sections

Proposed Section Mary Street to Lucy Street

16

Roadway Sections

Proposed Section Lucy Street to Minerva Street

17

Superstructure Replacement

 Replace Bridge Deck

• Built 1968, Concrete Overlay 1993

 Install Concrete Parapet with Metal Railing  Repair Substructure  Include 6 ft Sidewalk  Lighting on Structure

 Center Hill Road/Union Grove Lane Re-alignment

• Improved intersection angle with WIS 23
• Improved vehicle visibility

18

Intersection Improvements

Proposed Location Proposed Location

 Huntington Court Re-alignments (Minor)

• Improved intersection angle with WIS 23
• Pedestrian accommodations

19

Intersection Improvements

Proposed Location Proposed Location

 Harriet Street Intersection Widenings

• Improved truck turning movements
• Wider paved shoulders and corners

20

Intersection Improvements

Proposed Widening Proposed Widening

 Washington Street Cul-de-Sac at Lucy Street

• Improve intersection layout

21

Intersection Improvements

Cul-de-Sac Location

22

ADA Upgrades

ADA Curb Ramps

23

Crosswalk Locations

ADA Curb Ramps Crosswalks Crosswalks

24

Utility Replacement

 Water Utilities

• Replace watermain and services from Center Hill Road to

Lucy Street

 Sanitary Utilities

• Replace sanitary main sections south of Alice Street and

from Harriet Street to Lucy Street

• Install sanitary main connections at Huntington Court,

Ravine Street and County F

• Replace services from Center Hill Road to River Street and

from Harriet Street to Lucy Street

 Lighting

• Replace lighting from bridge to Harriet Street

25

Utility Replacement

 Storm Sewer Utilities

• Replace storm sewer main and laterals from Center Hill

Road to Lucy Street

• Install check valves at structure for flooding

26

Project Impacts

 Detours  Access over Pecatonica River  Roadway Shift  Real Estate

27

Detour

 WIS 23 Detour (30.3 miles)

WIS 81 – 10.3 miles WIS 126 – 5.7 miles US 151 – 14.3 miles

28

Detour

 WIS 81 Detour (25.9 miles)

WIS 23 – 6.1 miles WIS 11 – 6.0 miles WIS 78 – 13.8 miles

 Access maintained for emergency services and

local residents/businesses

 One lane open over bridge during construction

29

Access over Pecatonica River

Temporary Signals

 Access maintained for emergency services and

local residents/businesses

 One lane open over bridge during construction

30

Access over Pecatonica River

Temporary Signals

31

Roadway Shift

 Existing Land Terrain

• Steep west of WIS 23
• Flat east of WIS 23

Proposed Centerline Existing Centerline

32

Real Estate

 WisDOT Representatives

• Teresa Klein
• Kema Williams

 Real Estate Acquisitions

• 85 Total Properties
• FEE (permanent acquisitions)
• TLE (temporary limited easements)
• Appraisal Staking – Fall 2018

 Potential Property Impacts

• Carriage Walk Removal
• Tree Removal
• Access Removal

 Real Estate Acquisition

• 2019 - 2020

33

Project Schedule

 Public Involvement Meeting #1

May 2016

 Archeological Survey

May 2016

 Historical Survey

May 2016

 Hydrology Study

May 2016

 Soil Testing

Summer 2016

 Public Involvement Meeting #2

November 2016

 Project Plat

July 2018

 Environmental Report Submittal

January 2018

 Public Involvement Meeting #3

October 11, 2018

 Real Estate Acquisitions

2019 – 2020

 Utility Coordination

January 2019

 Public Involvement Meeting #4

TBD – Prior to Construction

 Agency Coordination (DNR, etc.)

Ongoing

 Final Plans Due

May 2020

 Construction

Spring – Fall 2021

34

Input ‘Dot’ Exercise

STEP 1 – Place number on the map. STEP 2 – Write number and comment

• n form and submit in

comment box.

12
