3D Geometry for Computer Graphics

Lesson 2: PCA & SVD

2

Last week - eigendecomposition

A

We want to learn how the matrix A works:

3

Last week - eigendecomposition

A

If we look at arbitrary vectors, it doesn’t tell us

much.

4

Spectra and diagonalization

A

If A is symmetric, the eigenvectors are

• rthogonal (and there’s always an eigenbasis).

A = UΛU

T

⎟ ⎟ ⎟ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎜ ⎜ ⎜ ⎝ ⎛

n

λ λ λ

• 2

1

Λ= Aui = λi ui

5

Why SVD…

Diagonalizable matrix is essentially a scaling. Most matrices are not diagonalizable – they do other

things along with scaling (such as rotation)

So, to understand how general matrices behave,

• nly eigenvalues are not enough

SVD tells us how general linear transformations

behave, and other things…

6

The plan for today

First we’ll see some applications of PCA –

Principal Component Analysis that uses spectral decomposition.

Then look at the theory. SVD

Basic intuition Formal definition Applications

7

PCA finds an orthogonal basis that best represents given data set. The sum of distances2 from the x’ axis is minimized.

PCA – the general idea

x y x’ y’

8

PCA – the general idea

PCA finds an orthogonal basis that best represents given data set. PCA finds a best approximating plane (again, in terms of Σdistances2)

3D point set in standard basis

x y z

9

Application: finding tight bounding box

An axis-aligned bounding box: agrees with the axes x minX maxX y maxY minY

10

Application: finding tight bounding box

Oriented bounding box: we find better axes!

x’ y’

11

Application: finding tight bounding box

This is not the optimal bounding box

x y z

12

Application: finding tight bounding box

Oriented bounding box: we find better axes!

13

Usage of bounding boxes (bounding volumes)

Serve as very simple “approximation” of the object Fast collision detection, visibility queries Whenever we need to know the dimensions (size) of the object

• The models consist of

thousands of polygons

• To quickly test that they

don’t intersect, the bounding boxes are tested

• Sometimes a hierarchy
• f BB’s is used
• The tighter the BB – the

less “false alarms” we have

Sample

14

Scanned meshes

15

Point clouds

Scanners give us raw point cloud data How to compute normals to shade the surface?

normal

16

Point clouds

Local PCA, take the third vector

17

Notations

Denote our data points by x1, x2, …, xn ∈ Rd

1 1 1 1 2 2 2 2 1 2 1 2

, , ,

n n d d d n

x x x x x x x x x ⎛ ⎞ ⎛ ⎞ ⎛ ⎞ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ = = = ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎝ ⎠ ⎝ ⎠ ⎝ ⎠

1 2 n

x x x …

18

The origin is zero-order approximation of our

data set (a point)

It will be the center of mass: It can be shown that:

The origin of the new axes

1 1 n i n i =

=

∑

m x

2 1

argmin

n i i=

=

∑

x

m x - x

19

Scatter matrix

Denote yi = xi – m, i = 1, 2, …, n

where Y is d×n matrix with yk as columns (k = 1, 2, …, n)

T

S YY =

1 1 1 1 2 1 2 1 1 1 2 2 2 1 2 1 2 2 2 2 1 2 1 2 d n d n d d d d n n n n

y y y y y y y y y y y y S y y y y y y ⎛ ⎞⎛ ⎞ ⎜ ⎟⎜ ⎟ ⎜ ⎟⎜ ⎟ = ⎜ ⎟⎜ ⎟ ⎜ ⎟⎜ ⎟ ⎜ ⎟⎜ ⎟ ⎝ ⎠⎝ ⎠

• Y

YT

20

Variance of projected points

In a way, S measures variance (= scatterness) of the data in different

directions.

Let’s look at a line L through the center of mass m, and project our

points xi onto it. The variance of the projected points x’i is:

Original set Small variance Large variance

2 1 1

var( ) || ||

n i n i

L

=

′ = −

∑ x

m

L L L L

21

Variance of projected points

Given a direction v, ||v|| = 1, the projection of xi

• nto L = m + vt is:

|| || , /|| || ,

T i i i i

′ − = < − > = < > = x m v x m v v y v y

v m xi x’i L

22

Variance of projected points

• So,

2 2 2 1 1 1 1 1 2 1 1 1 1 1

var( ) || || ( ) || || || || , ,

n n i i n n n i i T T T n n n n n

L Y Y Y Y YY S S

= =

′ = = = = = = < > = = = < >

∑ ∑

T T T T T

x -m v y v v v v v v v v v v

( ) ( )

2 2 1 1 1 1 1 2 2 2 2 2 2 1 2 1 2 2 1 2 1 1 1 2

( ) || ||

i n n n T d d i n i i d d d d i n

y y y y y y y y v v v v v v Y y y y y

= =

⎛ ⎞ ⎛ ⎞ ⎛ ⎞ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ = = = ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎜ ⎟ ⎝ ⎠ ⎝ ⎠ ⎝ ⎠

∑ ∑

T i

v y v

23

Directions of maximal variance

So, we have: var(L) = <Sv, v> Theorem:

Let f : {v ∈ Rd | ||v|| = 1} → R,

f (v) = <Sv, v>

(and S is a symmetric matrix). Then, the extrema of f are attained at the eigenvectors of S.

So, eigenvectors of S are directions of maximal/minimal

variance!

24

Summary so far

We take the centered data vectors y1, y2, …, yn ∈ Rd Construct the scatter matrix S measures the variance of the data points Eigenvectors of S are directions of maximal variance.

T

S YY =

25

Scatter matrix - eigendecomposition

S is symmetric

⇒ S has eigendecomposition: S = VΛVT S

= v2 v1 vd λ1 λ2 λd v2 v1 vd The eigenvectors form

• rthogonal basis

26

Principal components

Eigenvectors that correspond to big eigenvalues

are the directions in which the data has strong components (= large variance).

If the eigenvalues are more or less the same –

there is no preferable direction.

Note: the eigenvalues are always non-negative.

27

Principal components

• There’s no preferable

direction

S looks like this:

• Any vector is an eigenvector

T

V V λ λ ⎛ ⎞ ⎜ ⎟ ⎝ ⎠

• There is a clear preferable

direction

S looks like this:

• μ is close to zero, much

smaller than λ.

T

V V ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛

μ

λ

28

How to use what we got

For finding oriented bounding box – we simply

compute the bounding box with respect to the axes defined by the eigenvectors. The origin is at the mean point m. v2 v1 v3

29

For approximation

x y v1 v2 x y This line segment approximates the original data set The projected data set approximates the original data set x y

30

For approximation

In general dimension d, the eigenvalues are

sorted in descending order: λ1 ≥ λ2 ≥ … ≥ λd

The eigenvectors are sorted accordingly. To get an approximation of dimension d’ < d, we

take the d’ first eigenvectors and look at the subspace they span (d’ = 1 is a line, d’ = 2 is a plane…)

31

For approximation

To get an approximating set, we project the

• riginal data points onto the chosen subspace:

xi = m + α1v1 + α2v2 +…+ αd’vd’ +…+αdvd

Projection:

xi’ = m + α1v1 + α2v2 +…+ αd’vd’ +0⋅vd’+1+…+ 0⋅ vd

SVD

33

Geometric analysis of linear transformations

We want to know what a linear transformation A does Need some simple and “comprehendible” representation

• f the matrix of A.

Let’s look what A does to some vectors

Since A(αv) = αA(v), it’s enough to look at vectors v of unit length

A

34

The geometry of linear transformations

A linear (non-singular) transform A always takes

hyper-spheres to hyper-ellipses.

A A

35

The geometry of linear transformations

Thus, one good way to understand what A does is to find

which vectors are mapped to the “main axes” of the ellipsoid.

A A

36

Geometric analysis of linear transformations

If we are lucky: A = V Λ VT, V orthogonal (true

if A is symmetric)

The eigenvectors of A are the axes of the ellipse

A

37

Symmetric matrix: eigen decomposition

In this case A is just a scaling matrix. The eigen

decomposition of A tells us which orthogonal axes it scales, and by how much:

[ ] [ ]

1 2 1 2 1 2 T n n n

A λ λ λ ⎡ ⎤ ⎢ ⎥ ⎢ ⎥ = ⎢ ⎥ ⎢ ⎥ ⎢ ⎥ ⎣ ⎦ v v v v v v … …

• A

1 1 λ2 λ1

i i i

A v v λ =

38

General linear transformations: SVD

In general A will also contain rotations, not just scales: A

[ ] [ ]

1 2 1 2 1 2 T n n n

A σ σ σ ⎡ ⎤ ⎢ ⎥ ⎢ ⎥ = ⎢ ⎥ ⎢ ⎥ ⎢ ⎥ ⎣ ⎦ u u u v v v … …

• 1

1 σ2 σ1

T

A U V = ∑

39

General linear transformations: SVD

A

[ ] [ ]

1 2 1 2 1 2 n n n

A σ σ σ ⎡ ⎤ ⎢ ⎥ ⎢ ⎥ = ⎢ ⎥ ⎢ ⎥ ⎢ ⎥ ⎣ ⎦ v v v u u u … …

• 1

1 σ2 σ1

AV U = ∑

,

i i

A σ σ = ≥

i i

v u

• rthonormal
• rthonormal

40

SVD more formally

SVD exists for any matrix Formal definition:

For square matrices A ∈ Rn×n, there exist orthogonal matrices

U, V ∈ Rn×n and a diagonal matrix Σ, such that all the diagonal values σi of Σ are non-negative and

T

A U V = Σ

=

A U Σ

T

V

41

SVD more formally

The diagonal values of Σ (σ1, …, σn) are called the singular values. It

is accustomed to sort them: σ1 ≥ σ2≥ … ≥ σn

The columns of U (u1, …, un) are called the left singular vectors.

They are the axes of the ellipsoid.

The columns of V (v1, …, vn) are called the right singular vectors.

They are the preimages of the axes of the ellipsoid.

T

A U V = Σ

=

A U Σ

T

V

42

Reduced SVD

For rectangular matrices, we have two forms of

• SVD. The reduced SVD looks like this:

The columns of U are orthonormal Cheaper form for computation and storage

A U Σ

T

V

=

43

Full SVD

We can complete U to a full orthogonal matrix

and pad Σ by zeros accordingly

A U Σ

T

V

=

44

Some history

SVD was discovered by the following people:

• E. Beltrami

(1835 − 1900)

• M. Jordan

(1838 − 1922)

• J. Sylvester

(1814 − 1897)

• H. Weyl

(1885-1955)

• E. Schmidt

(1876-1959)

45

SVD is the “working horse” of linear algebra

There are numerical algorithms to compute

• SVD. Once you have it, you have many things:

Matrix inverse → can solve square linear systems Numerical rank of a matrix Can solve least-squares systems PCA Many more…

46

Matrix inverse and solving linear systems

Matrix inverse: So, to solve

( ) ( )

1

1 1 1 1 1 1 1

n

T T T T

A U V A U V V U V U

σ σ − − − − −

= ∑ = ∑ = ∑ = ⎡ ⎤ ⎢ ⎥ = ⎢ ⎥ ⎢ ⎥ ⎣ ⎦

• 1

T

A V U

−

= = ∑ x b x b

47

Matrix rank

The rank of A is the number of non-zero singular

values

A U Σ

T

V

= m n σ1σ2 σn

48

Numerical rank

If there are very small singular values, then A is

close to being singular. We can set a threshold t, so that numeric_rank(A) = #{σi| σi > t}

If rank(A) < n then A is singular. It maps the entire

space Rn onto some subspace, like a plane (so A is some sort of projection).

49

Back to PCA

We wanted to find principal components x y x’ y’

50

PCA

Move the center of mass to the origin

pi’ = pi − m

x y x’ y’

51

PCA

Constructed the matrix X of the data points. The principal axes are eigenvectors of S = XXT

1 2

| | | | | |

n

X ⎡ ⎤ ⎢ ⎥ ′ ′ ′ = ⎢ ⎥ ⎢ ⎥ ⎣ ⎦ p p p

• 1

T T d

XX S U U λ λ ⎡ ⎤ ⎢ ⎥ = = ⎢ ⎥ ⎢ ⎥ ⎣ ⎦

52

PCA

We can compute the principal components by SVD of X: Thus, the left singular vectors of X are the principal

components! We sort them by the size of the singular values of X.

2

( )

T T T T T T T T T

X U V XX U V U V V U U U V U = Σ = Σ Σ = = = Σ Σ Σ

53

Shape matching

We have two objects in correspondence Want to find the rigid transformation that aligns

them

54

Shape matching

When the objects are aligned, the lengths of the

connecting lines are small.

55

Shape matching – formalization

Align two point sets Find a translation vector t and rotation matrix R

so that:

{ } { }

1 1

, , and , , .

n n

P Q = = p p q q … …

2 1

( ) is minimized

n i i i

R

=

− +

∑ p

t q

56

Shape matching – solution

Turns out we can solve the translation and rotation

separately.

Theorem: if (R, t) is the optimal transformation, then the

points {pi} and {Rqi + t} have the same centers of mass.

1

1

n i i

n

=

=

∑

p p

1

1

n i i

n

=

= ∑ q q

( )

1 1

1 1

n i i n i i

R R n R R n

= =

= + ⇓ ⎛ ⎞ = + = + ⎜ ⎟ ⎝ ⎠ = −

∑ ∑

p q p q q t t p t t q

57

Finding the rotation R

To find the optimal R, we bring the centroids of both point

sets to the origin:

We want to find R that minimizes

i i i i

′ ′ = − = − p p p q q q

2 1 n i i i

R

=

′ ′ −

∑ p

q

58

Finding the rotation R

( ) ( )

( )

2 1 1 1 n n T i i i i i i i i n T T T T T T i i i i i i i i i

R R R R R R R

= = =

′ ′ ′ ′ ′ ′ − = − − = ′ ′ ′ ′ ′ ′ ′ ′ = − − +

∑ ∑ ∑

p q p q p q p p p q q p q q

I

These terms do not depend on R, so we can ignore them in the minimization

59

Finding the rotation R

( ) ( ) ( ) ( ) ( )

1 1 1 1

min max . max 2 max

n n T T T T i i i i i i i i i i i i T T T T i i i i i i i n n T T T T T T i i i i i i

R R R R R R R R R

= = = =

′ ′ ′ ′ ′ ′ ′ ′ − − = + ′ ′ ′ ′ ′ ′ = = ′ ′ ′ ′ ⇒ =

∑ ∑ ∑ ∑

p q q p p q q p q p q p p q p q p q

this is a scalar

60

Finding the rotation R

( )

1 1 1 1 n n n T T T i i i i i i i i i n T i i i

Trace Trace H R R R

= = = =

⎛ ⎞ ⎛ ⎞ ′ ′ ′ ′ ′ ′ = = ⎜ ⎟ ⎜ ⎟ ⎝ ⎠ ⎝ ⎠ ′ ′ =

∑ ∑ ∑ ∑

p q q p q p q p

3 ×1 1 ×3 = 3 ×3 =

1

( )

n ii i

Trace A A

=

= ∑

61

So, we want to find R that maximizes Theorem: if M is symmetric positive definite (all

eigenvalues of M are positive) and B is any orthogonal matrix then

So, let’s find R so that RH is symmetric positive definite.

Then we know for sure that Trace(RH) is maximal.

Finding the rotation R

( )

Trace RH

( )

( ) Trace M Trace BM ≥

62

This is easy! Compute SVD of H: Define R: Check RH: T

H U V

Finding the rotation R

= Σ

T

R VU =

( )( )

T T T

VU U V R V V H = Σ = Σ

This is a symmetric matrix, Its eigenvalues are σi ≥ 0 So RH is positive!

63

Summary of rigid alignment:

Translate the input points to the centroids: Compute the “covariance matrix” Compute the SVD of H: The optimal rotation is The translation vector is i i i i

′ ′ = = − − q p p q p q

1 n T i i i

H

=

′ ′ = ∑ q p

T

H U V = Σ

T

R VU =

R = − t p q

64

Complexity

Numerical SVD is an expensive operation We always need to pay attention to the

dimensions of the matrix we’re applying SVD to.

65

Small somewhat related example

The End
