3-Dimensional Monolithic Nonvolatile Memories and the Future of Solid-State Data Storage

• Dr. Michael A. Vyvoda

Director, Technology Transfer and Operations 3D Technology Group SanDisk Corporation February 8th, 2008

2

Outline

• Flash memory market dynamics: what drives technology advances?
• The floating-gate technology roadmap
• Scaling challenges: what will replace the floating gate?
• Monolithic 3D memory: technical overview and future potential

3

Flash Memory Market Dynamics

4

Strong Demand Drivers of Flash Market Growth

Source: Gartner Dataquest, November 2006

Imaging Video & PC Audio Data Billions

• f MB

Lifestyle Storage

• 2,000

4,000 6,000 8,000 10,000 12,000 14,000 16,000

2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 Other Automotive PC G aming Mobile Phone Camcorder USB Drive Media Player Digital Camera

15.4 Trillion MB 1.4 Billion MB

Media Player Mobile Phone PC USB

• Bits shipped routinely doubles-to-triples year-over-year, fueled by

rapid average-selling-price (ASP) reduction (next page)

• This is enabling exciting new markets such as flash-based MP3 players

and video recording

5

Continual $/ MB Reductions Driving New Markets

SanDisk Retail Selling Price per MB ($/MB) - Log Scale 1999Q1 Q2 Q3 Q4 2000Q1 Q2 Q3 Q4 2001Q1 Q2 Q3 Q4 2002Q1 Q2 Q3 Q4 2003Q1 Q2 Q3 Q4 2004Q1 Q2 Q3 Q4 2005Q1 Q2 Q3 Q4 2006Q1 Q2 Q3 Q4

3-4 Quarter Cyclicality

4 3 % A n n u a l A S P / M B D e c l i n e T r e n d l i n e

Source: SanDisk

2001 Down Cycle 2007 Down Cycle

• Persistent, unrelenting price reductions, enabled by aggressive

technology innovation, driving new markets shown on previous page

• Superimposed boom/bust cycles of more benign/more rapid ASP

decline

ASP/ MB

6

Projected Flash Trends: 2008 - 2011

• 40%-50% annual price reductions sustainable only by top tier players
• Smooth transitions to 5Xnm (2007), 43nm (2008/2009)

Transition points to date have been limited by photolithographic

constraints (more on this later)

• Increasingly more complex NAND (Floating-Gate to Charge-Trap-

Flash) transitions at 32nm, 22nm (2009-2011)

• 3- and 4-bit-per-cell critical for competitiveness in 2009-2011
• 200mm Fabs no longer competitive; 300mm wafers are now the norm

in cutting-edge Fabs

• In next 1-2 years capacities should grow dramatically:

512MB-2GB 4GB-32GB

• In next 3-5 years cumulative price reductions (~ 10X from 2007 to

2011) should become disruptive to DVD, HDD (hard disk drive), stimulate huge demand and create new Flash markets

7

Sub-segment Market Growth

8

USB (“Thumb Drive”) Market Size

50 100 150 200 250 2005 2006 2007 2008 2009 Source: Gartner Nov '06 M Units 2,200 2,300 2,400 2,500 2,600 2,700 2,800 2,900 M $ UFD Units UFD $

• 18% compound-annual-growth-rate (CAGR) in units shipped from

2006 2009, much higher than the semiconductor industry in aggregate

• Dollar growth less strong due to ASP declines

9

Flash MP3 Player Market Size

50 100 150 200 250 300 2003 2004 2005 2006 2007 2008 2009

Source: Gartner Nov ‘06 M Units

• Very strong growth in the 2003 2006 timeframe as MP3 player

manufacturers adopted flash memory

• 16% CAGR 2006 2009, as with USB showing continued strong

growth

10 10 Source: DSC Forecast IDC Sep‘06, Installed Base: SanDisk Estimates

DSC Shipments and Installed Base

• 20

40 60 80 100 120 140 160 180 200 220 240 260 280 300 2005 2006 2007 2008 2009 Installed Base 4 Years shipments

Digital Still Camara (DSC) Market Size

• Roughly 120M DSC units ship per year, with a 260M DSC installed

base (!)

• ~ 240M Flash cards sold per year with market size < $4.5B in 2007

11 11

Video Consuming More Memory

• Video Capture becoming a large driver of bit growth

IDC predicts that 4800 PBs will be consumed by Video in 20091 Today 20% of all PBs used in Video is used for archival storage and

will grow to > 40% through 20091

Camera phones are a large component of this

500,000,000 1,000,000,000 1,500,000,000 2,000,000,000 2,500,000,000 3,000,000,000 3,500,000,000 4,000,000,000 4,500,000,000 5,000,000,000 Captured GigaBytes 2006 2007 2008 2009 Consumer DVC DSC CamPhone

DVC CAGR 34.6% DSC CAGR 25.8% CamPhone CAGR 42%

Source1: IDC Dec. 06

12 12

Projected SSD Penetration in Notebooks by 2010

• Solid-state-drive (SSD) adoption driven by price elasticity and

MLC adoption (must reasonably compete with rotating-media)

• SSD penetration in ~ 20% of the notebook market = 32M units
• 1300 PB of NAND flash to be used in SSDs or 11% of NAND
• utput
• TAM > $3B in 2010 $100/system ASP

5 10 15 20 25 30 35 2006 2007 2008 2009 2010

U n its (M illio n s )

200 400 600 800 1000 1200 1400

M e g a b y te s (B illio n s )

Units MB

Source: Gartner, December, 2006 Notebook market in 2010 is estimated at 153M units

13 13

Finally: Mobile Phones as the Market Leader

1400 1200 1000 800 600 400 200

2005 2010 2009 2008 2007 2006

Worldwide Handset Sales (MU)

Source: Strategy Analytics, December 2006

Shipments of Slotted Phones (MU)

• 500M phones with Flash-card slots shipped in 2007, projected to

almost double by 2010

14 14

Conclusions – Market Dynamics

• The solid-state data storage market, dominated by Flash

memory, has grown and will continue to grow very rapidly in the foreseeable future

• This growth has been driven entirely by the effects of price

elasticity: lower prices lead to nonlinear growth in bits shipped, due to the appearance of new markets for memory

• The markets for Flash memory are now very diverse, ranging

from music to video to still images to hard-disk replacements

15 15

NAND Technology Roadmap

16 16

NAND Memory Product Roadmap

1G 16G 4G 2G 8G 2007 2005 2006 2009 2008 2010 32G

Source: SanDisk

64G 96G 128G

32nm 32nm 43nm 43nm 56nm 70nm Released 56nm

Product Memory Capacity

• Near-yearly technology-node transitions are responsible for the price

declines and bit-growth described in the previous slides

50% year-over-year price declines matched by YOY cost declines

17 17

New Process Node Transition Every Year

0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%

2004 2005 2006 2007 2008

43nm 56nm 70nm 90nm 130nm

Technology Transition for Total Captive Wafer Production – % of GB

Source: SanDisk

18 18

Going Beyond 2 Bits/ Cell (“MLC”)

4 bits/cell 16 levels

1 1 1 1 1

1 bit/cell 2 levels (“SLC”)

1

2 bits/cell 4 levels (“MLC”)

00 01 10 11 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

3 bits/cell 8 levels (“x3”)

1 1 1 1 1 1 1 1 1 1 1 1

System Expertise Increasingly Important

• Very advanced controller chips required to move above 2-bit/cell

Signal processing and other algorithm innovations to maintain high write

speeds and data retention

Wear-leveling algorithms to increase endurance

19 19

Multi-bit-per-cell I mplementation

0.01 0.01 0.0001 0.0001 Effective Cell Size 0.1 0.1 0.001 0.001

Jan Jan-

• ‘

‘04 04 Jan Jan-

• ‘

‘05 05 Jan Jan-

• ‘

‘06 06 Jan Jan-

• ‘

‘07 07 Jan Jan-

• ‘

‘08 08 Jan Jan-

• ‘

‘09 09 Jan Jan-

• ‘

‘10 10 Jan Jan-

• ‘

‘11 11 Jan Jan-

• ‘

‘12 12

90 nm 90 nm 70 nm 70 nm 56 nm 56 nm 43 nm 43 nm 32 nm 32 nm 2x nm 2x nm

Binary MLC (2b/ cell) MLC (3b/ cell) MLC (4b/ cell)

I mmersion Litho ~ 56-nm Super SA-STI New Structure New Materials

2G 4G 8G 8G 16G 4G 8G 16G 16G 32G 64G 32G 64G 64G

Source: SanDisk

• 2-bit-per-cell (MLC) has been mainstream for several years now,

among the top-tier suppliers

• 3-bit-per-cell (x3) on SanDisk’s 56nm technology will ramp in mid-’08

20 20

Photolithography as a Technology Enabler

70nm 56nm 43nm 32nm 2xnm 2005 2006 2007 2008 2009 2010

Further Aggressive shrink with immersion & hyper NA Dry ArF

λ=193nm

NA < 1.0 EUV Immersion ArF λ=193nm Hyper NA >> 1.0 Immersion ArF λ=193nm NA >> 1.0 Wet ArF l= 193nm NA > 1.0

Source: SanDisk

• For the past several years, brute-force physical scaling as lead the

way to technology-node transitions

• Immersion lithography as a key enabler for 56nm and onwards

21 21

Scaling Challenges and Alternate Devices

22 22

Scaling Challenges

• Physical limitations

How do we print, etch and fill lines/spaces below 3xnm? To continue on the Moore’s Law trajectory of cost reduction,

innovation is needed

• Cell-to-cell coupling

Vt shift due to coupling from

adjacent cells exacerbated at tighter geometries

• Electron-loss tolerance

(from floating gate)

Reduced allowance for

electron loss to avoid large Vt shift

Source: Kim and Jeong, 2007 IEDM

23 23

Seagate Nanochip IBM(?)

Not sure Good. Tip size and scan precision

• nly

dependent Not Known. Potentially very high Not known. Storage media dependent Not compatible. Very small (nm) Tip size and scan precision dependent Probe Probe Storage Storage

In development cell level (many companies)

Has potential. Not proved. Good No data Potential

• small. Scales

poorly Potential

• good. But

no sufficient data Small~ 4F² RRAM RRAM

SanDisk Toshiba Samsung Macronix Toshiba Freescale 4Mb Samsung IBM 16Mb Fujitsu Ramtron 1Mb In Development Intel, IBM, Samsung 512Mb Quimonda Spansion 1Gb (ORNAND) In Developmen t Samsung SanDisk / Toshiba, Macronix SanDisk Toshiba Samsung Hynix, Micron

Company No Data Has potential. No No Has potential. Not proved on products. 2 bits proved. 4 bits ?? Possible with improved material

• Yes. In

producti

• n.

MLC Capability Good Good Poor. Write current increases with scaling Poor Questionable. Endurance is affected by the volume of the PCM material Down to 5x nm Good down to 2xnm. Possible 1xnm(?) Good down to 2x nm Scalability No Data Comparable w/ NAND (?) Theoretica lly infinite

108 - 1012 ~ 105 104 104 104-105

Endurance No Data Very Small Very High 5-10 ma Scales poorly Small ~ 1µa High ~ mA Medium 10 – 100µa Very Small Very Small W/E Current per cell Good Good Poor Poor Etching difficult Good Compatible with back end process Good Good Good CMOS Integration Very small 4F2 /n Small~ 4F² Large ~ 30F² Large ~ 20F² Small ~ 6F² Medium ~ 10F² Small ~ 4F² Small ~ 4F² Cell Size 3D Diode 3D Diode 3D NAND 3D NAND MRAM MRAM FeRAM FeRAM PCM PCM Mirror Bit Mirror Bit SONOS SONOS FG FG NAND NAND NONVOLATILE MEMORY TECHNOLOGIES COMPARISON NONVOLATILE MEMORY TECHNOLOGIES COMPARISON

Seagate Nanochip IBM(?)

Not sure Good. Tip size and scan precision

• nly

dependent Not Known. Potentially very high Not known. Storage media dependent Not compatible. Very small (nm) Tip size and scan precision dependent Probe Probe Storage Storage

In development cell level (many companies)

Has potential. Not proved. Good No data Potential

• small. Scales

poorly Potential

• good. But

no sufficient data Small~ 4F² RRAM RRAM

SanDisk Toshiba Samsung Macronix Toshiba Freescale 4Mb Samsung IBM 16Mb Fujitsu Ramtron 1Mb In Development Intel, IBM, Samsung 512Mb Quimonda Spansion 1Gb (ORNAND) In Developmen t Samsung SanDisk / Toshiba, Macronix SanDisk Toshiba Samsung Hynix, Micron

Company No Data Has potential. No No Has potential. Not proved on products. 2 bits proved. 4 bits ?? Possible with improved material

• Yes. In

producti

• n.

MLC Capability Good Good Poor. Write current increases with scaling Poor Questionable. Endurance is affected by the volume of the PCM material Down to 5x nm Good down to 2xnm. Possible 1xnm(?) Good down to 2x nm Scalability No Data Comparable w/ NAND (?) Theoretica lly infinite

108 - 1012 ~ 105 104 104 104-105

Endurance No Data Very Small Very High 5-10 ma Scales poorly Small ~ 1µa High ~ mA Medium 10 – 100µa Very Small Very Small W/E Current per cell Good Good Poor Poor Etching difficult Good Compatible with back end process Good Good Good CMOS Integration Very small 4F2 /n Small~ 4F² Large ~ 30F² Large ~ 20F² Small ~ 6F² Medium ~ 10F² Small ~ 4F² Small ~ 4F² Cell Size 3D Diode 3D Diode 3D NAND 3D NAND MRAM MRAM FeRAM FeRAM PCM PCM Mirror Bit Mirror Bit SONOS SONOS FG FG NAND NAND NONVOLATILE MEMORY TECHNOLOGIES COMPARISON NONVOLATILE MEMORY TECHNOLOGIES COMPARISON

(CTF)

24 24

NVM Technology – Next Five Years

• Floating Gate (FG) NAND

Likely scalable to ~ 20nm x3 will likely become mainstream by 2009 x4: SanDisk plans to lead through system/controller solutions,

initially targeting A/V markets (starting 2008, growing impact in later years)

• Charge Trapping (CTF) NAND

Advocated by Samsung and Hynix for below 40nm (~ 2009) Planar structure has scaling advantages, unknown difficulties/risks x3, x4 implementation may be more challenging for CTF

• NROM (Quadbit)

Competitive with NOR, probably not a serious threat to high-density

NAND

• PCM, MRAM, Nanotubes, Milipede

Not a serious threat to high-density NAND in the next five years

25 25

NVM Technology – Next Five Years (Cont’d)

• 3D Read/Write

Long-term potential to disrupt/displace NAND, HDD R/W switching actively researched: expected productization in the

next several years (more on this later…)

26 26

SanDisk 3D Technology Overview

27 27

• SanDisk 3D has brought to high volume an NVM where arrays of

memory cells are stacked above control logic circuitry in the 3rd dimension

Stacking 3D memory directly over CMOS allows for high array

efficiency and very small die size

• The technology uses no new materials, processes or Fab

equipment

Control logic circuitry composed of typical CMOS Memory construction using typical backend processing tools Each memory layer is a repeat of layers below CMOS node can lag memory node (“hybrid scaling”) Example: 0.13um-generation CMOS with 80nm-generation

memory

• The technology is inherently scalable

Multiple technology generations proven using the same cell

architecture

Lithography-driven scaling allows for rapid cost reduction

SanDisk 3D Technology Summary

28 28

• The 3D cell consists of a vertical diode in series with a memory

element

• State-change element is…

Irreversibly altered in the case of OTP memory Reversibly altered in the case of re-writeable (R/W) memory

SanDisk 3D Memory Cell

State change element (e.g., antifuse) Steering element (e.g., diode) Input Terminal Output Terminal

Steering Elem ent State C hange Elem ent

O utput2 O utput1

O n w iring1 layer

Input2 Input1

O n w iring1 layer

Input2

O n w iring2 layer O n w iring2 layer

Cell Array

29 29

SanDisk 3D OTP Memory Cell

n+ Si metal p+ Si metal n- Si Anti-fuse Programmed Cell Unprogrammed Cell

30 30

OTP Memory Cell I -V Curve

1.E-14 1.E-13 1.E-12 1.E-11 1.E-10 1.E-09 1.E-08 1.E-07 1.E-06 1.E-05 1.E-04 1.E-03

• 8
• 6
• 4
• 2

2 4 6 8 10

V I [A]

Vread Vprog Memory Cell Window

• > 4 orders cell window at 2V read voltage

Unprogrammed cell Programmed cell

31 31

OTP Memory Cell Read Window

Programmed Unprogrammed

• 4
• 5
• 6
• 7
• 8
• 9
• 10

99 95 90 80 70 60 50 40 30 20 10 5 1

Log(IF2) Percent Current at 2V for programmed and unprogrammed cells

Programmed cell Unprogrammed cell

• Wide [> 4 orders] read margin when considering distributions of

millions of cells

32 32

SanDisk 3D Physical Cross Section

• Memory array is composed of repeating layers of poly-Si memory cells built

directly above CMOS

LV + HV CMOS logic 2 levels of tungsten routing 4 layers of memory cells + tungsten interconnect Al top metal

33 33

SanDisk 3D Array Architecture

SIDE VIEW 3D VIEW TOP VIEW

WL WL WL BL BL BL BL

34 34

SanDisk 3D R/ W Cell Development Update

• OTP and R/W cell developments are tightly coupled and share

most of the process module and design architecture ideas

Recall that the identity and behavior of the switching element

defines OTP or R/W capabilities

• Several parallel research activities are being pursued, exploring

several types of switching behavior

• We have produced several distinctly different cells, each capable
• f being integrated into the existing 3D architecture
• We have developed a test vehicle to test out some of the ideas

being generated that allows us to rapidly collect statistics on large number of cells

• We are seeing very encouraging results from our development

efforts – please stay tuned for results in the near future…

35 35

Overall Concluding Remarks

• The flash memory marketplace is one of the most vibrant and

exciting in the semiconductor industry, not to mention one of the most competitive

• The dominant flash cell architecture, the conventional floating

gate, will see significant, if not unsurpassable, scaling challenges below the 2x nm technology node

• In order to continue the pace of price reductions that consumers

demand, significant innovation is needed, both at the device and system level

• Many candidate device architectures are in development; we are

strong believers that 3D is a viable candidate
