Tau Energy Scale in Tau Energy Scale in 2016 dat 2016 dataset aset Huajie Cheng 2020.11.13 Introduction TES measurement using TauFW Preliminary results using 2016 dataset, in mu-tau events Coarse ES variations applied to real

slide-1
SLIDE 1

Tau Energy Scale in Tau Energy Scale in 2016 dat 2016 dataset aset

2020.11.13 Huajie Cheng

slide-2
SLIDE 2

Introduction

2

◆ TES measurement using TauFW

◼ Preliminary results using 2016 dataset, in mu-tau events ◼ Coarse ES variations applied to real tau

  • 3% → 3% in steps of 1% (0.2% for final measurement)

◼ Compare the impacts in DY and TT processes ◼ Fit independently per DM

  • Only in DY process
  • Use mvis and mτ as observables
  • Fix “r” parameter and scan likelihood profile in TES
  • Fit the NLL profile by asymmetric parabola function
slide-3
SLIDE 3

Mu-tau selections

◆ Baseline

➢ Single muon trigger & SF applied ➢ Muon

  • pT > 23 GeV, |eta| < 2.1 or 2.4
  • |dxy| < 0.045, |dz| < 0.2
  • medium ID, rel. iso < 0.15

➢ Tau

  • pT > 20 GeV, |eta| < 2.3, |dz|<0.2, decay modes 0, 1, 10, 11
  • DeepTau2017v2p1VSjet Tight WP
  • DeepTau2017v2p1VSmu Tight WP
  • DeepTau2017v2p1VSe VVLoose WP

➢ Opposite sign mu-tau pair with ΔR > 0.5 and highest mu and tau pT ➢ Extra-lepton veto

◆ mT < 50 GeV

3

slide-4
SLIDE 4

TES systematic uncertainties

4 Nuisance Parameter Distribution Uncertainty Applied to lumi lnN ±2.5% all, except QCD mu Eff lnN ±2% all, except QCD tau ID shape from recommendation ZTT, TTT DY cross section lnN ±2% DY ttbar cross section lnN ±6% ttbar signle top cross section lnN ±5% single top VV cross section lnN ±5% diboson W+jets normalization lnN ±8% W QCD normalization lnN ±10% QCD jet -> 𝜐 fake rate lnN ±15% ZJ, W, QCD, TTJ, ST jet -> 𝜐 fake ES shape ±5% on jet → 𝜐 energy ZJ, W, TTJ ℓ -> 𝜐 fake rate shape from recommendation ZL, TTL ℓ -> 𝜐 fake ES shape ±2% on ℓ → 𝜐 energy ZL, TTL Z pt reweight shape apply weight ±10% DY

◆ All the shape uncertainties are not yet in place

slide-5
SLIDE 5

Datacard for DM0

◆ Not all syst included, e.g. tid

5

slide-6
SLIDE 6

Likelihood profile scan

6

DM0 DM1 DM10 DM11

◆ Profile the NLL as a function of tes ◆ And the fit with asym parabola function

DM1 DM10 DM11

slide-7
SLIDE 7

Fit result

7

◆ DM1 for m_tau

DM1

slide-8
SLIDE 8

Fit result

8

◆ DM10 for m_tau

DM10

slide-9
SLIDE 9

Fit result

9

◆ DM11 for m_tau

DM11

slide-10
SLIDE 10

Fit result

10

◆ DM0 for m_vis

DM0

slide-11
SLIDE 11

Fit result

11

◆ DM1 for m_vis

DM1

slide-12
SLIDE 12

Fit result

12

◆ DM10 for m_vis

DM10

slide-13
SLIDE 13

Fit result

13

◆ DM11 for m_vis

DM11

slide-14
SLIDE 14

Results

◆ Finally got the TES values w.r.t different DMs

14

Before fit After fit Ref.

◆ Quite ugly due to very coarse variation step and missing uncertainties ◆ Jobs with step=0.2% almost done! ◆ Asked to give a status report next Monday

slide-15
SLIDE 15
slide-16
SLIDE 16

Some distributions

16

  • 3% TES

+3% TES

◆ Here are the plots with all DMs combined, the fit will be performed with each DM separately

slide-17
SLIDE 17

Some distributions

17

Negligible impact from ttbar

◆ Will only apply the TES in ZTT for the measurement

slide-18
SLIDE 18

18

Framework: from nanoAOD to final plots

slide-19
SLIDE 19

Sample list

19

slide-20
SLIDE 20

1 10 100 1000 10000 1 2 3 4 5 6 7 8 9 10 11 12 13 14

Counts in 5 mins (14.16L)

Cases

0.3um 0.5um 1.0um 2.0um 5.0um 10.0um

Air condition monitoring in the clean room

◆ Took 4 samples in each rooms (2 for room 110)

slide-21
SLIDE 21

IV-curve

◆ Finally managed to perform IV measurement remotely by LabView

➢ Change from GPIB to RS232-to-USB cable
