ICU2005 2005/09/06, Zurich, Switzerland Ultra Wideband Double-Directional Channel Measurements in an Office Environment 1 Jun-ichi Takada 2 Fumio Ohkubo 1 Katsuyuki Haneda Takehiko Kobayashi 3 1, 3: UWB Technology Institute, National


slide-1
SLIDE 1

ICU2005

2005/09/06, Zurich, Switzerland

Ultra Wideband Double-Directional Channel Measurements in an Office Environment

Jun-ichi Takada Fumio Ohkubo Katsuyuki Haneda Takehiko Kobayashi

1 1 2 3 1, 3: UWB Technology Institute, National Institute

  • f Information and Communication Technology

1: Tokyo Institute of Technology 3: Tokyo Denki University 2: NTT Advanced Technology Corporation

slide-2
SLIDE 2

Overview of our activities

  • Channel modeling based on measured data
slide-3
SLIDE 3

Table of contents

  • Background
  • UWB double-directional measurement

– Concept – Double-directional measurement procedure – Parameterization of double-directional channels

  • Experiment in a meeting room
  • Experiment in an office
  • Observation of the results
  • Summary and future works
  • Acknowledgement
slide-4
SLIDE 4

Background

  • Impact of double-directional channel sounding

activities with UWB signal

1. For UWB systems: – Improvement of the current UWB channel models – Focus is to include spatial channel information 2. For MIMO transmission: – Detailed investigation of the relation between MIMO capacity and physical phenomena – Possibility to cover wide frequency range Final goal: Antenna-independent channel models which are applicable both for UWB and MIMO systems with all operating frequencies

slide-5
SLIDE 5

Double-directional channel

  • Estimating both DOD and DOA enables us to

separate antenna effects from channel model (M. Steinbauer et., al, 2001)

DOD DOA

Tx Rx Propagation Antenna + Propagation = Channel

slide-6
SLIDE 6

UWB double-directional measurements

  • Measurement strategy

– MISO/SIMO configurations = double directional meas.

SIMO

Tx Rx

MISO

Rx Tx DOD / DTOA estimation Connecting DOA and DOD information using DTOA DOA / DTOA estimation

slide-7
SLIDE 7

UWB channel sounding system

Synthetic array

  • Vector Network Analyzer & spatial scanner

GPIB

  • Data acquisition

VNA PC

  • 3-D (x-y-z)

scanner and UWB antenna

  • frequency

sweeping from

3.1 to 10.6 GHz

UWB antenna

  • Omni-directional

monopole antenna

  • flat group delay

characteristics

  • Measurement control

via GPIB Preamp (30dB)

slide-8
SLIDE 8

Specifications of experiment

  • Arrays

– Spatial sampling: points in directions – Element spacing: 48 mm – Frequency range: 3.1 to 10.6 GHz Achieved 10 deg resolution of DOD / DOA azimuth angle, and 0.13 ns resolution of DTOA

  • Others

– DOD / DOA / DTOA estimation algorithm: SAGE – Polarization: vertical-vertical – SNR at the receiver: at least 20 dB – Calibration: function of the VNA and back-to-back (antenna calibration)

10 10 7 × ×

xyz

slide-9
SLIDE 9

Experiment in a meeting room

Tx1 Tx2 20 cm Rx Tx

(1.0 m high) (2.0 m high) Side wall: metal Ceiling: plaster board

Tx-Rx distance: 4.6m

slide-10
SLIDE 10

Experiment in a meeting room

  • The 10 strongest waves

revealed that

  • 1. Many reflected paths from

the ceiling were detected

  • 2. Multi-reflected waves

were detected due to metal side walls

  • 3. Path constitution was

symmetric w.r.t. Tx-Rx line

# 3 # 8 # 1 # 1 , # 2 , # 5 , # 6 , # 9 # 4 # 7 T x 1 R x 1

長机

T x 1 R x 1 # 1 # 1 , # 2 # 5 , # 6 # 9 天井裏

Plaster board Metal ceiling

Desk

slide-11
SLIDE 11

Experiment in a meeting room

  • Reflection from ceiling

– Many metal pipes inside the plaster board – Metal parts of room lights

長机

T x 1 R x 1 # 1 # 1 , # 2 # 5 , # 6 # 9 天井裏

Plaster board Metal ceiling

Desk

slide-12
SLIDE 12

Experiment in an office

Rx Tx

(1.0 m high) (2.0 m high)

Tx-Rx distance: 7.5m Plaster board LOS is assured

slide-13
SLIDE 13

Experiment in an office

  • Detected waves

revealed that

  • 1. Reflections from office

desks, equipment and floor are few

  • 2. Reflections from

windows and far wall are few

  • 3. The 10 strongest

waves are first-order reflections on metal furniture or direct path

# 2 # 4 # 5 , # 7 # 6 # 1 , # 3 , # 8 , # 9 R x 2 T x 2 # 1

W i n d

  • w
slide-14
SLIDE 14

Observations of the results

  • Initial findings from the experiment
  • 1. Reflection occurs on metal wall, furniture, and pipes

inside the ceiling

  • 2. Reflection from ceiling is much stronger than those

from the floor

  • 3. Reflections from windows are few
  • 4. Office environment reveals complicated propagation

phenomena than residential environment due to metal structures of buildings

  • 5. Specular reflection contains stronger power than non-

specular scattering

  • 6. Higher-order specular reflection still have strong

power in the meeting room due to metal walls

slide-15
SLIDE 15

Summary and future works

  • UWB double-directional channel sounding in the

meeting room and office

– Channel sounding procedure – Initial findings from measurements

  • Future works
  • 1. Quantitative analyses of channel behavior
  • Cluster analyses
  • Reflection coefficients
  • 2. Channel modeling based on the results
  • 3. Modeling of the residual components
  • 4. Improvement of the SAGE algorithm
  • To avoid spurious paths, search strategy and reduction of

sidelobes should be considered.

slide-16
SLIDE 16

Acknowledgement

  • The authors would like to thank the

members of NICT UWB Consortium and UWB Technology Institute in NICT:

– Prof. Dr. Kiyomichi Araki – Mr. Iwao Nishiyama – Dr. Honggang Zhang – Mr. Naoto Takahashi – Dr. Makoto Yoshikawa – Dr. Akira Akeyama – Dr. Osamu Sasaki – Dr. Yuko Rikuta – Mr. Takahiro Miyamoto

slide-17
SLIDE 17

Specifications of experiment

  • Signal processing of measured data

– SAGE (Space-Alternating Generalized Expectation- Maximization) algorithm – Derivation of DOD, / DOA, DTOA and frequency spectrum of each path

Measured data

  • DOD
  • DTOA
  • Frequency spectrum
  • DOA

Fourier pair What we want SAGE Spatial transfer function distributions

  • Maximum-likelihood based estimation (parametric channel estimation)
  • Widely used in conventional wideband channel sounding, and we modified it to

to UWB signals

Features of the SAGE

slide-18
SLIDE 18

Observations of the results

  • Problems
  • 1. There are many weak paths that cannot be identified in

the real environment

  • 2. Even the 10 strongest waves, they contain only 20 to

30 % of total received power

  • 100
  • 95
  • 90
  • 85
  • 80

45 90 135 180 225 270 315 360 Azimuth angle [deg] 10 20 30 40 50 60 70

  • 100
  • 95
  • 90
  • 85

45 90 135 180 225 270 315 360 Azimuth angle [deg] 10 20 30 40 50 60 70

Before extracting 100 waves After extracting 100 waves In the meeting room
