2 Jiang Y, Lee A, Chen J, Ruta V, Cadene M, Chait BT, et al. X-ray structure of a voltage-dependent K+ channel. Nature. 3 2003 05/01;423(6935):33-41. PDZ Domain PDZ Ligand + Periplasm (GGGGS)3 Linkers Voltage Sensor + + + + + + Peptide

slide-1
SLIDE 1
slide-2
SLIDE 2

2

slide-3
SLIDE 3

Jiang Y, Lee A, Chen J, Ruta V, Cadene M, Chait BT, et al. X-ray structure of a voltage-dependent K+ channel. Nature. 2003 05/01;423(6935):33-41.

3

slide-4
SLIDE 4

PDZ Domain PDZ Ligand

+

  • + + +

Periplasm Inner Membrane Cytosol

Voltage Sensor Peptide Polyproline Linkers (GGGGS)3 Linkers Effectors

+ + +

(GGGGS)3 Linkers Effectors 4

slide-5
SLIDE 5

PDZ Domain PDZ Ligand

+

  • + + +

Periplasm Inner Membrane Cytosol

Voltage Sensor Peptide Polyproline Linkers (GGGGS)3 Linkers Effectors

+ + +

(GGGGS)3 Linkers Effectors 5

slide-6
SLIDE 6

+

  • Periplasm

Inner Membrane Cytosol

6

+ + + + + +

slide-7
SLIDE 7

+

  • 7

+ + + + + +

slide-8
SLIDE 8

8

+

slide-9
SLIDE 9

We have made:

  • BBa_K1092006: Voltage Sensor Peptide

Voltage Sensor Peptide RBS 9

180bp

Voltage Sensor Peptide

slide-10
SLIDE 10

We have made:

  • BBa_K1092008:

ssDsbA-PDZ Domain-Voltage Sensor Peptide

  • BBa_K1092024:

T7-RBS-ssDsbA-PDZ Domain-VS-RFP C terminus

10 Voltage Sensor Peptide PDZ Domain

Voltage Sensor Peptide PDZ Domain RFP C terminus RBS

slide-11
SLIDE 11

11

slide-12
SLIDE 12

12

slide-13
SLIDE 13

Acenaphthene Pyrene Acenaphthylene Fluorene Anthracene Benzo[a]pyrene

13

slide-14
SLIDE 14
  • Found in car exhaust, tar, cooking fume...

Pictures from http://chemistry.about.com/od/factsstructures/ig/Chemical-Structures---B/Benzo-a-pyrene.htm

Benzo[a]pyrene (BaP)

14

slide-15
SLIDE 15
  • Benzo[a]pyrene Diol Epoxide

(Carcinogenic!)

Human Body

Pictures from http://en.wikipedia.org/wiki/Benzo(a)pyrene

15

slide-16
SLIDE 16
  • Enzymes: Laccase and dioxygenase

– Inspired by a fungal pathway[1]

  • 1. Hadibarata T, Kristanti RA. Identification of metabolites from benzo[a]pyrene oxidation by ligninolytic enzymes of

Polyporus sp. S133. J Environ Manage. 2012 11/30;111(0):115-9.

Laccase

Catechol 1,2-Dioxygenase

Benzo[a]pyrene BaP-1,6-quinone 1-Hydroxy-2-naphthoic acid

Dangerous Safe 16

slide-17
SLIDE 17
  • BBa_K1092005

– T7 – RBS – Laccase

Laccase RBS

pSB1C3 Laccase (1542bp) Plasmid Restriction Digestion Gel Photo 1.5kbp 1kbp 750bp 500bp 250bp 100bp

Laccase

Benzo[a]pyrene BaP-1,6-Quinone

17

slide-18
SLIDE 18
  • BBa_K1092003

– T7 – RBS - Dioxygenase

Catechol 1,2-Dioxygeanse RBS

pSB1C3 Dioxygen

  • ase

(936bp) Plasmid Restriction Digestion Gel Photo 1kbp 750bp 500bp 250bp 100bp

Catechol 1,2- Dioxygenase BaP-1,6-Quinone 1-Hydroxy-2-naphthoic acid

18

slide-19
SLIDE 19

W T a c c a s e 0.00 0.05 0.10 0.15 0.20

**

Control T7 – Laccase

OD389 Value [1]

n = 3 p ≤ 0.01

  • 1. Method from: Ramesh A, Archibong AE, Niaz MS. Ovarian susceptibility to benzo[a]pyrene: tissue burden of

metabolites and DNA adducts in F-344 rats. Journal of Toxicology and Environmental Health, Part A. 2010 10/28; 2013/10;73(23):1611-25.

19

slide-20
SLIDE 20

40 80 120 0.0 0.1 0.2 0.3

EV T7-Dioxygenase

Time / min

Normalized OD298

n = 3 p ≤ 0.05

  • 1. Method from: Huang Y, Xun R, Chen G, Xun L. Maintenance role of a glutathionyl-hydroquinone lyase (PcpF) in

pentachlorophenol degradation by Sphingobium chlorophenolicum ATCC 39723. Journal of Bacteriology. 2008 December 01;190(23):7595-600.

[1] 20 Control T7-Dioxygenase

slide-21
SLIDE 21
  • Repressor: QsrR

– Quinone-mediated transcriptional repressor[1]

  • 1. Ji Q, Zhang L, Jones MB, Sun F, Deng X, Liang H, et al. Molecular mechanism of quinone signaling mediated through S-

quinonization of a YodB family repressor QsrR. Proceedings of the National Academy of Sciences. 2013 March 26;110(13):5010-5.

Cys-5 QsrR

QsrR Binding Site

Downstream Genes (Regulated by QsrR) Quinone Cys-5 QsrR

mRNA

21

BaP-1,6-quinone

slide-22
SLIDE 22
  • Biobricks

– BBa_K1092001: T7–RBS–QsrR – BBa_K1092014: Constitutive Promoter (BBa_J23100)–RBS– QsrR Bind Site–Dioxygenase

Catechol 1,2- Dioxygenase QsrR Binding Site RBS QsrR RBS

pSB1C3 QsrR (339bp)

Plasmid Restriction Digestion Gel Photo

1kbp 750bp 500bp 250bp 100bp

22

slide-23
SLIDE 23

QsrR Binding Site RBS PDZ Domain Voltage Sensor Peptide Dioxygenase

23

RBS PDZ Ligand Voltage Sensor Peptide Laccase

Laccase

Catechol 1,2-Dioxygenase

Benzo[a]pyrene BaP-1,6-quinone 1-Hydroxy-2-naphthoic acid

slide-24
SLIDE 24

+

  • Arai R, Ueda H, Kitayama A, Kamiya N, Nagamune T. Design of the linkers which effectively separate domains of a

bifunctional fusion protein. Protein Engineering. 2001 August 01;14(8):529-32.

24

+ + + + + +

Laccase Dioxygenase

slide-25
SLIDE 25

Arai R, Ueda H, Kitayama A, Kamiya N, Nagamune T. Design of the linkers which effectively separate domains of a bifunctional fusion protein. Protein Engineering. 2001 August 01;14(8):529-32.

25

+

  • Laccase

Dioxygenase

slide-26
SLIDE 26

BBa_K1092000 QsrR BBa_K1092001 T7-RBS-QsrR BBa_K1092002 Dioxygenase BBa_K1092003 T7-RBS-Dioxygenase BBa_K1092004 Laccase BBa_K1092005 T7-RBS-Laccase BBa_K1092006 Voltage Sensor Peptide BBa_K1092007 ssDsbA-PDZ Ligand-Voltage Sensor Peptide BBa_K1092008 ssDsbA-PDZ Domain-Voltage Sensor Peptide BBa_K1092013 T7-RBS-Voltage Sensor Peptide BBa_K1092014 T7-QsrR Binding Site-RBS-Dioxygenase BBa_K1092024 pSB1C3-T7-RBS-ssDsbA-PDZ Domain-Voltage Switch-RFP C terminus BBa_K1092105 RFP N terminus BBa_K1092106 RFP C terminus 26

slide-27
SLIDE 27

QsrR Binding Site RBS PDZ Domain Voltage Sensor Peptide Dioxygenase RBS PDZ Ligand Voltage Sensor Peptide Laccase

27

slide-28
SLIDE 28

28

slide-29
SLIDE 29
  • Biomolecular Fluorescent

Complementation (BiFC).

  • Fluorescent proteins were splited at loop

regions at DNA level, and coexpressed. A few fluorescent signals are found.

  • Fluorescent signals are enhanced when

linked to interacting proteins pair.

  • Used widely to study protein-protein

interaction.

  • No documented reversible BiFC up until

now.

Kodama, Y. & Hu, C.-D. BioTechniques. 53, 285–98 (2012).

29

slide-30
SLIDE 30

Promoter RBS PDZ domain PDZ ligand Voltage sensor peptide Voltage sensor peptide RFP-N terminus RFP-C terminus Terminator

1 s 1 s 1 s

30

  • +
slide-31
SLIDE 31
  • BiFC
  • Target protein to the corresponding membrane

(e.g. ER, Golgi)

  • The system works on its own base on the native

membrane potential

31

RBS PDZ domain PDZ ligand Voltage sensor peptide Voltage sensor peptide RFP-N terminus RFP-C terminus Terminator Promoter Signaling peptide

slide-32
SLIDE 32

32

slide-33
SLIDE 33

Adapted from: Huang, L. J. et al. The Journal of cell biology 145, 951–9 (1999).

33 +

+

slide-34
SLIDE 34

Voltage Switch

Reversible BiFC Degrade Cellular Content

Bacterial Screen Biosafety Control

Study Protein Complements

Much More

34

slide-35
SLIDE 35

35

slide-36
SLIDE 36

Others* = Australia, Austria, Belgium, Canada, China, Denmark, England, Finland, France, Germany, Hong Kong, India, Indonesia, South Korea, Malaysia, Mexico, Russia, Singapore, South Africa, Taiwan, Thailand, The Netherlands, Ukraine, USA, Vietnam

36

CUHK Human Practice International Macau (60 students) Lab Workshop Synthetic Biology Talk Survey Others* (110 students) Survey Local High School (135+234students) Lab Workshop Synthetic Biology Talk Survey Open Day Undergraduate Students (110 students) Poster Exhibition Survey

slide-37
SLIDE 37

37

slide-38
SLIDE 38

Interesting 30% Useful 31% Interesting and Useful 23%

Neither good

  • r bad

11% Dangerous 5%

38

slide-39
SLIDE 39

0% 10% 20% 30% 40% 50% 60% 70%

iGEM

  • nly

Synthetic Biology

  • nly

Both Neither

Percentage of Respondents High School Students (Hong Kong) High School Students (Macau) University Students (Hong Kong) University Students (International)

39

slide-40
SLIDE 40

3.71 3.84 1 2 3 4 5 Believers Non Believers 3.37 3.62 1 2 3 4 5 Believers Non Believers Mean Degree of Acceptability 40

slide-41
SLIDE 41

41

slide-42
SLIDE 42

42

slide-43
SLIDE 43

43

slide-44
SLIDE 44

iGEM only 11% Synthetic Biology 9%

Both 66%

Neither 14%

44

slide-45
SLIDE 45

Yes 95%

No 5% 45

slide-46
SLIDE 46
  • Comics convey message about iGEM and

synthetic biology well

  • Views on synthetic biology directly relates to

religion’s view

  • Many agree that synthetic biology will be an

integral part of knowledge-based economy

  • Future Plan:

– Wider outreach and full detailed comics in English and Chinese languages

46

slide-47
SLIDE 47
  • Research Group of Prof.

CHAN King Ming

  • Research Group of Prof.

CHAN Ting Fung

  • Research Group of Prof. NGO

Chi Ki, Jacky

  • Prof. KONG Siu Kai
  • Prof. GE Wei
  • Prof. JIANG Liwen
  • Jacky Loo
  • Qin Hao
  • Sunny
  • Nelson So
  • School of Life Sciences, CUHK
  • School of Biomedical

Engineering, CUHK

  • University Safety Office,

CUHK

  • Shanghai Jiao Tong

University

47

slide-48
SLIDE 48

Arai R, Ueda H, Kitayama A, Kamiya N, Nagamune T. Design of the linkers which effectively separate domains of a bifunctional fusion protein. Protein Engineering. 2001 August 01;14(8):529-32. Hadibarata T, Kristanti RA. Identification of metabolites from benzo[a]pyrene oxidation by ligninolytic enzymes of Polyporus sp. S133. J Environ Manage. 2012 11/30;111(0):115-9. Huang Y, Xun R, Chen G, Xun L. Maintenance role of a glutathionyl-hydroquinone lyase (PcpF) in pentachlorophenol degradation by Sphingobium chlorophenolicum ATCC

  • 39723. Journal of Bacteriology. 2008 December 01;190(23):7595-600.

Ji Q, Zhang L, Jones MB, Sun F, Deng X, Liang H, et al. Molecular mechanism of quinone signaling mediated through S-quinonization of a YodB family repressor QsrR. Proceedings of the National Academy of Sciences. 2013 March 26;110(13):5010-5. Jiang Y, Lee A, Chen J, Ruta V, Cadene M, Chait BT, et al. X-ray structure of a voltage- dependent K+ channel. Nature. 2003 05/01;423(6935):33-41. Kodama Y and Hu CD. Bimolecular fluorescence complementation (BiFC): A 5-year update and future perspectives. BioTechniques. 2012 November; 53(5): 285-298. Ramesh A, Archibong AE, Niaz MS. Ovarian susceptibility to benzo[a]pyrene: tissue burden of metabolites and DNA adducts in F-344 rats. Journal of Toxicology and Environmental Health, Part A. 2010 10/28; 2013/10;73(23):1611-25.

48

slide-49
SLIDE 49

49
