Intel 48-core SCC processor Tilera 100-core processor

3

• Introduction
• Parallel program structure and behavior

– Case study of fluidanimate – Thread criticality problem – Communication impact on thread criticality

• Thread-criticality support in on-chip network

– Bypass flow control – Priority-based arbitration

• Methodology & results
• Conclusion

4

• fluidanimate in PARSEC
• Particle-based fluid simulation

which solves Navier-Stokes equations

• Particles are spatially sorted in a

uniform grid and each thread covers subgrids in entire simulation domain.

• Each thread executes

AdvanceFrameMT() function.

• 8 sub-functions with 8 barriers
• Provided input sets process 5

frames.

5

void AdvanceFrameMT(int i) { ClearParticlesMT(i); pthread_barrier_wait(&barrier); RebuildGridMT(i); pthread_barrier_wait(&barrier); InitDensitiesAndForcesMT(i); pthread_barrier_wait(&barrier); ComputeDensitiesMT(i); pthread_barrier_wait(&barrier); ComputeDensities2MT(i); pthread_barrier_wait(&barrier); ComputeForcesMT(i); pthread_barrier_wait(&barrier); ProcessCollisionsMT(i); pthread_barrier_wait(&barrier); AdvanceParticlesMT(i); pthread_barrier_wait(&barrier); }

void AdvanceFrameMT(int i) { ClearParticlesMT(i); pthread_barrier_wait(&barrier); RebuildGridMT(i); pthread_barrier_wait(&barrier); InitDensitiesAndForcesMT(i); pthread_barrier_wait(&barrier); ComputeDensitiesMT(i); pthread_barrier_wait(&barrier); ComputeDensities2MT(i); pthread_barrier_wait(&barrier); ComputeForcesMT(i); pthread_barrier_wait(&barrier); ProcessCollisionsMT(i); pthread_barrier_wait(&barrier); AdvanceParticlesMT(i); pthread_barrier_wait(&barrier); } Execution time N threads … … … … Barrier 0 Barrier 1 Barrier 2 Barrier 7 ... … … (one thread per core)

6

7

ComputeDensitiesMT ComputeForcesMT Barrier 3

Execution time (108 cycles) thread

Barrier 5

If we accelerate half number of threads, execution time of ComputeForcesMT can be reduced by 29%.

• Variation of executed instructions

– Different execution paths in the same control flow graph ⇒ Different computation time

• Variation of memory accesses

– Different cache behavior on L2 cache – Thread criticality predictor based on per-core L2 hits and misses (Bhattacharjee et al., ISCA ’09)

• Larger total L1 miss penalties ==> higher thread criticality

⇒ Different memory stall time

8

• Large portion of cache miss penalty is communication

latency incurred by on-chip network.

– L2 cache is distributed and interconnected with multiple banks.

• L2 cache access latency in 8x8 mesh network

– 3-cycle hop latency, 6-cycle bank access latency, 12 hops for round trip (uniform random) – 36 cycles (86%) are communication latency in total latency of 42 cycles.

• Our work aims at reducing communication latency of

high-criticality threads to accelerate their execution.

9

• Low latency support

– Express virtual channel (ISCA ‘07)

• Router pipeline skipping by flow control

– Single-cycle router (ISCA ‘04)

• All dependent operations through speculation are handled in single cycle.
• Quality of service support

– Globally synchronized frames (ISCA ‘09)

• Per-flow bandwidth guarantee within a time window

– Application-aware prioritization (MICRO ‘09)

• High system throughput across many single-threaded applications by

exploiting different stall cycles per packet in each application

10

• Bypass flow control

– Reduce per-hop latency for critical threads. – Preserve internal router state to skip router pipelines. – Find a state that maximizes bypassing opportunities.

• Priority-based arbitration

– Reduce stall time caused by router resource arbitration for critical threads. – Assign high priority to critical threads and low priority to non- critical threads. – Allocate VCs and switch ports based on priority-based arbitration.

11

• Router preserves a bypass (default) state between input

ports and output ports.

• When a packet follows the same path in a bypass state of

router, it bypasses router pipeline and directly goes to link.

• Bypass state corresponds to preserved router resources.

– Bypass VC

• Preserved VC for bypass

– State-preserving switch crossbar

• Preserved switch input/output ports for bypass

12

13

VC allocator Switch allocator

IN OUT 1 1 2 2 3 3

Routing

Port state table

…

Input 0 Input 3 Output 0 Output 3

… … …

State-preserving crossbar switch Bypass VC Crossbar switch

14

Crossbar switch

IN OUT 1 1 2 2 3 3

Port state table

Output 0 Output 3 … Input 0 Input 3 … Input 0 Input 3 Output 0 Output 3

//

2x4 decoder

State is preserved when switch allocation does not occur at previous cycle.

• Each router has switch usage counters.

– Each counter is incremented on a packet basis only for critical threads. – Each counter tracks usage of one input port and one output port of switch.

• n2 counters for n × n switch
• Trade-off more (monitoring) resources for improved performance
• These counters are used to update port state table

periodically.

• Each port state table represents switch usage patterns for

critical threads during previous time interval.

15

• When multiple packets request the same resource,

arbitration is necessary.

– VC arbitration, switch arbitration, speculative-switch arbitration

• Higher-priority packets win arbitration over lower-priority

packets.

– This priority is the same as level of thread criticality.

• Aging for starvation freedom

16

• 64-core system modeled by SIMICS

– 8x8 mesh network – 2-stage pipeline router + 1-cycle link

• 3-cycle hop latency (no bypass)
• 1-cycle hop latency (bypass)

– 6-cycle bank access for 16MB L2 cache

• PARSEC benchmarks
• Thread criticality predictor based on accumulated L1 miss

penalty

– Switch usage counters are updated only for top four critical threads.

17

18

19

20

21

• Each thread can have different performance due to

different memory behavior.

• Accelerating slowest (critical) threads reduces execution

time of parallel applications.

• On-chip network is designed to support thread criticality

through bypass flow control and priority-based arbitration techniques.
