OGAWA DEPARDON ARCHITECTS 77 CHAMBERS STREET, 2FL NEW YORK, NY 10007 123 & 125 WEST 87TH STREET NEW YORK, NY 10024 PAGE 1

123 & 125 WEST 87TH STREET

BLOCK 1218 | LOT 124 & 24

OGAWA DEPARDON ARCHITECTS 77 CHAMBERS STREET, 2FL NEW YORK, NY 10007 123 & 125 WEST 87TH STREET NEW YORK, NY 10024 PAGE 2

• 1. SITE PLAN: BUILDINGS HIGHLIGHTED IN RED

OGAWA DEPARDON ARCHITECTS 77 CHAMBERS STREET, 2FL NEW YORK, NY 10007 123 & 125 WEST 87TH STREET NEW YORK, NY 10024 PAGE 3

125 W 87TH ST 123 W 87TH ST

EXISTING FRONT FACADES

OGAWA DEPARDON ARCHITECTS 77 CHAMBERS STREET, 2FL NEW YORK, NY 10007 123 & 125 WEST 87TH STREET NEW YORK, NY 10024 PAGE 4

121 W 87TH ST 119 W 87TH ST 117 W 87TH ST

EXISTING FRONT FACADES OF NEIGHBORS

OGAWA DEPARDON ARCHITECTS 77 CHAMBERS STREET, 2FL NEW YORK, NY 10007 123 & 125 WEST 87TH STREET NEW YORK, NY 10024 PAGE 5

125 W 87TH ST 123 W 87TH ST 121 W 87TH ST 121 W 87TH ST 119 W 87TH ST 117 W 87TH ST

TAX PHOTOS

NOTE: 117 AND 119 HAVE THE SAME NEWEL POSTS AND BALUSERS IN THE ABOVE PHOTOS, EVEN THOUGH PRESENTLY 117 HAS DIFFERENT RAILINGS AND NO POSTS

OGAWA DEPARDON ARCHITECTS 77 CHAMBERS STREET, 2FL NEW YORK, NY 10007 123 & 125 WEST 87TH STREET NEW YORK, NY 10024 PAGE 6

125 W 87TH ST 125 W 87TH ST 123 W 87TH ST 123 W 87TH ST 119 W 87TH ST 119 W 87TH ST

EXISTING AND PROPOSED FACADES AND SCOPE OF WORK

PROPOSED WORK SCOPE SUMMARY (DETAILS IN SUBSEQUENT SLIDES):

• 123 & 125 W 87TH: REPLACE NON-HISTORIC STAIR RAILING WITH NEW CAST CONCRETE NEWEL POST AND BALUSTERS TO MATCH

119 WEST 87TH ST, RAISE BALUSTERS AND NEWEL POST 4” IN HEIGHT FOR RAILING TO BE 28” ABOVE NOSING, PAINT BLACK

• 123 & 125 W 87TH: REPLACE PARLOR DOORS WITH NEW WOOD DOORS WITH FOUR PANELS, SECOND TO TOP IS GLASS AND OTHERS ARE

WOOD, PAINT BLACK

























NEW CAST CONCRETE POST & BALUSTRADE TO MATCH 119 W 87TH ST RESTORE DAMAGED CURB STONES. BROWNSTONE RESURFACING APPROVED UNDER LPC DOCKET #186330 REPLACE WD & GLASS DOOR WITH NEW WD & GLASS DOOR GRILLS REMOVED UNDER LPC DOCKET #186330 NEW WD & TRANSLUCENT GLASS WINDOW TO REPLACE EXISTING WD & GLASS DOOR NEW RAIL & GATE TO MATCH 123 W 87TH ST NEW ADDITION APPROVED UNDER LPC DOCKET #186330 DOB APPLICATION 121189971 REBUILD DAMAGED STAIRS & STOOP

OGAWA DEPARDON ARCHITECTS 77 CHAMBERS STREET, 2FL NEW YORK, NY 10007 123 & 125 WEST 87TH STREET NEW YORK, NY 10024 PAGE 7

125 W 87TH ST 123 W 87TH ST

PHOTO DETAIL OF EXISTING STOOPS AND RAILINGS

REPLACE NON-HISTORIC STAIR RAILINGS AT 123 AND 125 WEST 87TH STREET WITH NEW CAST CONCRETE POST AND BALUSTRADE TO MATCH 119 WEST 87TH ST, RAISE POST AND BALUSTERS 4” FOR RAIL TO BE 28” ABOVE NOSING, PAINT BLACK

125 W 87TH ST 123 W 87TH ST

OGAWA DEPARDON ARCHITECTS 77 CHAMBERS STREET, 2FL NEW YORK, NY 10007 123 & 125 WEST 87TH STREET NEW YORK, NY 10024 PAGE 8

PHOTO DETAIL OF 119 WEST 87TH STREET

REPLACE NON-HISTORIC STAIR RAILINGS AT 123 AND 125 WEST 87TH STREET WITH NEW CAST CONCRETE POST AND BALUSTRADE TO MATCH 119 WEST 87TH ST, RAISE POST AND BALUSTERS 4” FOR RAIL TO BE 28” ABOVE NOSING, PAINT BLACK

OGAWA DEPARDON ARCHITECTS 77 CHAMBERS STREET, 2FL NEW YORK, NY 10007 123 & 125 WEST 87TH STREET NEW YORK, NY 10024 PAGE 9

125 W 87TH ST EXISTING 125 W 87TH ST PROPOSED 123 W 87TH ST EXISTING 123 W 87TH ST PROPOSED

EXISTING RAILINGS AND PROPOSED NEWEL POSTS AND BALUSTERS DRAWING

























OGAWA DEPARDON ARCHITECTS 77 CHAMBERS STREET, 2FL NEW YORK, NY 10007 123 & 125 WEST 87TH STREET NEW YORK, NY 10024 PAGE 10

ENLARGED DRAWING OF PROPOSED NEWEL POST AND BALUSTERS

























INCREASE NEWEL POST BASE BY 4" IN HEIGHT







INCREASE SQUARE TOP OF BALUSTER BY 1.5" IN HEIGHT INCREASE SQUARE BASE OF BALUSTER BY 2.5" IN HEIGHT NEW CAST CONCRETE POST & BALUSTRADE TO MATCH 119 W 87TH ST, RAISE 4" IN HEIGHT OVERALL







ACTUAL HEIGHT OF POST AND RAILING AT 119 WEST 87TH STREET PROPOSED INCREASED HEIGHT OF POST AND RAILING COMPARED TO 119 WEST 87TH STREET

OGAWA DEPARDON ARCHITECTS 77 CHAMBERS STREET, 2FL NEW YORK, NY 10007 123 & 125 WEST 87TH STREET NEW YORK, NY 10024 PAGE 11

CAST CONCRETE QUALITY SAMPLE & CLOSE UP OF 119 WEST 87TH NEWEL POST & BALUSTER

WE ARE PROPOSING CAST CONRETE INSTEAD OF CAST IRON / ALUMINUM DUE TO SIGNIFICANT COST SAVINGS CAST IRON : ESTIMATED AT $110,000 PER HOUSE CAST ALUMINUM: ESTIMATED AT $80,000 FOR MATERIAL & FABRICATION PER HOUSE, NOT INCLUDING ENGINEERING CAST CONCRETE : $35,000 PER HOUSE

OGAWA DEPARDON ARCHITECTS 77 CHAMBERS STREET, 2FL NEW YORK, NY 10007 123 & 125 WEST 87TH STREET NEW YORK, NY 10024 PAGE 12

125 W 87TH ST 123 W 87TH ST 118 W 87TH ST 124 W 87TH ST

EXISTING PARLOR DOORS

DOORS WERE PHOTOGRAPHED ON JUNE 20, 2019. WE ARE PROPOSING DOORS SIMILAR TO OTHER HOMES ON THE SAME BLOCK.

OGAWA DEPARDON ARCHITECTS 77 CHAMBERS STREET, 2FL NEW YORK, NY 10007 123 & 125 WEST 87TH STREET NEW YORK, NY 10024 PAGE 13

DISTRICT DESIGNATION PHOTOS OF 125 AND 123 WEST 87TH STREET

123 WEST 87TH STREET SHOWS REPLACEMENT OUTER DOORS

OGAWA DEPARDON ARCHITECTS 77 CHAMBERS STREET, 2FL NEW YORK, NY 10007 123 & 125 WEST 87TH STREET NEW YORK, NY 10024 PAGE 14

EXISTING AND PROPOSED PARLOR DOOR DRAWINGS

BECAUSE THE EXISTING PARLOR DOORS ARE ONLY ONE LAYER, WE ARE PROPOSING A DOOR WITH MORE WOOD AND LESS GLASS FOR SECURITY, SIMILAR TO THE ONES AT 118 AND 124 WEST 87TH STREET, PAINT BLACK























 125 W 87TH ST EXISTING 125 W 87TH ST PROPOSED 123 W 87TH ST EXISTING 123 W 87TH ST PROPOSED

OGAWA DEPARDON ARCHITECTS 77 CHAMBERS STREET, 2FL NEW YORK, NY 10007 123 & 125 WEST 87TH STREET NEW YORK, NY 10024 PAGE 15

PROPOSED PARLOR DOOR DETAILS
