Kathleen “Kat” Gordon School Board Member District 5 Monday, April 17, 2017

• Dr. Barbara Jenkins, Superintendent Mr. John Morris, Chief Facilities Officer

School Board District 5 100% Design/Construction Kick-Off Community Meeting Pine Hills Elementary School

Orange County Public Schools

Pine Hills Elementary 100% Design/Construction Update

Agenda

April 17, 2017, Pine Hills ES media center, 6:00 pm

• Opening Remarks & Introduction of Public Officials – Kathleen “Kat” Gordon
• Acknowledgements & Introductions of Project Team – Jessma Lambert
• Project Update –

Architect: BRPH Architects/Engineers, Inc. Construction Manager: Pirtle Construction

• Transportation for Swing School Update
• Questions and Answers
• Adjournment

2

Orange County Public Schools

Existing Site

Existing Counts: Maximum Observed Queuing: 69 Vehicles Existing Parking: 73 Vehicles

FERNDELL DRIVE ACADEMY STREET HASTINGS STREET

10 VEHICLES QUEUED NORTH BOUND ON HASTINGS STREET

24 15

20 VEHICLES QUEUED ON FERNDELL DRIVE

3

Orange County Public Schools

Site Plan

Student Capacity: 837 1st Floor: 63,121 SF Covered Play: 2,224 SF 2nd Floor: 31,208 SF Provided: Percent Stacking: 19.3% Total Queuing: 162 Cars Total Parking: 128 Cars Bus: 3 Existing: Queuing: 69 Cars Parking: 73 Cars Bus: 1 Required: Queuing: 82-120 (Max) Cars Parking: 82 (Staff)+10 (Visitor)=92 Bus: 2

4

Orange County Public Schools

Traffic Study

Recommendations

Queuing Provide 82 vehicles stacking based on projected student capacity Queuing for 162 vehicles provided (69 vehicles existing) Parking Provide 92 parking spaces based on projected student capacity Parking for 128 vehicles provided (73 spaces existing) Buses Provide bus loop to accommodate 2 buses Bus loop accommodates more than 17 buses (1 bus at existing school)

5

Orange County Public Schools

Example Classrooms

Example Interactive Display

6

Orange County Public Schools

Skills Lab Art Music

Example Specialty Classrooms

7

Orange County Public Schools

Example Lobby & Cafeteria

8

Orange County Public Schools

Example Media Center

9

Orange County Public Schools

Example Elevations

North East South

10

Orange County Public Schools

Example of BRPH Prototype

11

Orange County Public Schools

Pine Hills Elementary is designed to meet Green Globes sustainable building standards Sustainable Features Include: Site

• Native/low water plants – reduce water consumption
• Low Impact Design (LID) stormwater design

Building

• 10% more energy efficient than ASHRAE 90.1 standard
• High Efficiency Chillers (8% energy reduction)
• Light colored roof to reduce heat gain and improves energy

performance

• Energy Star rated equipment
• Water saving toilets, faucets, and fixtures
• Nearly all general classrooms have exterior windows
• Thermal efficient windows/glazing
• Fully automated building controls system

Sustainability

12

Orange County Public Schools

School Year Open Conway ES 2008 Wetherbee ES 2011 Rock Springs ES 2013 Spring Lake ES 2014 Ocoee ES 2014 Pineloch ES 2014 Lake Weston ES 2015 Tangelo Park ES 2016 Rock Lake ES (currently under construction) 2017 Oak Hill ES (currently under construction) 2017

BRPH Prototype

13

Orange County Public Schools

Construction Logistics

14

Orange County Public Schools

Schedule

August 2016 February 2017 June 2018 August 2018

Design Construction (12 Months) Move-In

June 2017

Permitting & Bidding 15

Orange County Public Schools

• Will provide transportation service to Clarcona ES,

the swing school site.

• Bus routes will be created in June.
• Bus routes to be approved by the School Board at

the end of July.

• Bus stop information will be available week before

school begins.

• Will have display bus at Open House to share

information with first time bus riders.

Transportation Services

16

Orange County Public Schools

General Steps in Developing Routes

• Determine stop locations within DOE criteria.
• Determine number of students per stop based
• n the student’s address listed in the District’s

database.

• Create route to match capacity of bus.

17

Transportation Services

Orange County Public Schools

General Criteria for Safe Bus Stops

• Distance from student’s residence (6A-3.001 states no more than 1 ½

miles).

• Intersection controls.
• Location of sex offenders (criteria provided by Florida DOJ).
• Safe area for students to wait.
• Ride time.
• Most efficient number of stops.
• Right side pickup locations.
• Number of eligible students.
• Site distance to proposed location stops (curves, hills, etc.).
• Minimum distance between stops.

18

Transportation Services

Questions?

Facilities contact person for School Board District 5 Jessma Lambert Facilities Director, Construction Planning 407-317-3700

Thank you to Orange County taxpayers for the ½ penny sales tax, which makes this construction possible.
