1 Santa Fe County Project Team Ed Moreno, County Commissioner Tony Flores, Deputy County Manager Mike Kelley, P.E. Public Works Director Robert Martinez - Public Works Deputy Director Diego Gomez, P.E. Projects Engineer

SLIDE 1

SLIDE 2

Santa Fe County Project Team

 Ed Moreno, County Commissioner  Tony Flores, Deputy County Manager  Mike Kelley, P.E. – Public Works Director  Robert Martinez - Public Works Deputy Director  Diego Gomez, P.E. – Projects Engineer  Steven “Justin” Reese - Project Manager III  Terry Lease – Real Property Specialist  Penny Ellis Green – Growth Management Director  Vicki Lucero – Building & Development Manager

SLIDE 3

Commissioner Ed Moreno

SLIDE 4

Alignment/Corridor Study

Phase A, B, C- Completed

Phase A - Alternative Identification and Screening Phase B – Detailed Alternative Analysis Phase C – Environmental Documentation Phase D- Preliminary Design

SLIDE 5

Phase A

Alternate Identification and Screening

A1 - Existing Conditions and Constraints A2 - Agency Coordination and Public Involvement A3 - Establish Purpose and Need A4 - Development of Study Alternative A-5 – Initial Screening of Alternatives

SLIDE 6

Phase A Alternatives

SLIDE 7

Phase B

Detailed Alternative Analysis

B1 - Detailed Evaluation of Alternatives B2 - Engineering Refinement of Preferred Alternative B3 – Alternative Analysis Report

SLIDE 8

Phase B Preferred Alternatives

NE Connector No Build

SLIDE 9

SLIDE 10

Phase B Recommendations

NE Connector SE PNM Utility Easement

SLIDE 11

SLIDE 12

Phase C

Environmental Documentation

C1 - Prepare Resource Reports and Agency Consultation C2 – Prepare Environmental Documentation C3 – Final Environmental Certification C4 – Environmental Re-evaluation

SLIDE 13

Phase C Clearance Map

SLIDE 14

SLIDE 15

SLIDE 16

Conceptual Design

SLIDE 17

Existing Easements and ROW

SLIDE 18

Existing 124 Foot Easement Plat book 250 page 21

SLIDE 19

Existing 124 Foot Easement Plat book 250 page 21

SLIDE 20

Existing 124 Foot Easement Plat book 677 page 46

SLIDE 21

Existing 68 Foot ROW Along College Drive Plat Book 778 page 49

SLIDE 22

Existing 68 Foot ROW Along College Drive Plat Book 778 page 49

SLIDE 23

Project Timeline

Engineering Design - Start December 2018 Engineering Design - Complete December 2019 Construction Start – March 2020 Construction Complete – October 2021 100% County Funded 2012 GOB and 2016 GOB

SLIDE 24

Project Considerations

Environmental Commitments Project Cost Right of Way Required Topography/ Drainage Structures Required Traffic Flow/Connectivity Intersection Improvements

SLIDE 25

Prior Developer Commitments

SLIDE 26

St. Francis South

Santa Fe County Land Use Case S10-5364 Recorded 1/17/2017

Note 8. A revised an updated TIA reflecting current road conditions shall be submitted with the Preliminary design Plat/Development Plat for Phase 2 and shall include timing of improvements and complete road design for build-out of the development. Note 9. The road design for the right turn deceleration lane on rabbit road must be submitted with the Final Plat/Development Plan for Phase

SLIDE 27

Elevation Multi Family Community

CDRC Case #APP13-5382 and CRDC Case #V/DP 13-5381 Recorded 1/13/2016

Note 4. The Applicant shall construct College Drive, to CCDO standard, from its current terminus at Burnt Water to the western boundary to the future Southeast Connector right-of- way, Ordinance No. 2000-12, section 6.E.3.b Note 6. Construction may begin but Elevation is not permitted

ccupancy until the Southwest Connector is completed.

SLIDE 28

Saleh Master Plan

CRDC CASE # V/MP 14-5490 Recorded 10/22/2015 The design of a left turn lane and right turn deceleration lane

n Richards Avenue shall be submitted with the Preliminary

Development Plan application, as per article V, Section 7.2

SLIDE 29

Questions And Answers
