1. Presentation Transcription in Point Form: Introduction - a. This is Alternative Energy Solutions Presentation i. Passive, AC Magnetic Induction Charging System for the purpose of (re)generative harvesting of Magnetic Field for usable KW. ii.


slide-1
SLIDE 1

Updated: 22nd July, 2017 | www.epicasia.com.sg 1. Presentation Transcription in Point Form: Introduction - a. This is Alternative Energy Solutions Presentation

  • i. Passive, AC Magnetic Induction Charging System for the purpose of (re)generative

harvesting of Magnetic Field for usable KW.

  • ii. Of a Technology which averages 6% - 9% KWH Reduction for applications in Hotels

(International References), and more for Printing Press, Construction Operations, and Cold Room Facilities.

  • iii. New Technology only applicable for AC Systems:
  • Total Energy Content of DC Systems:
  • (1) Work Done against resistance
  • + (2) Work Done in Running Load
  • Total Energy Content of AC Systems:
  • (1) Work Done against resistance
  • + (2) Work Done in running Load
  • + (3) Work Done against inductance which is stored in magnetic field.
  • i. The only way to extract/harvest this magnetic field energy is via

electromagnetic induction

  • ii. Technology is widely available commercially but limited in

applications (wireless charging) 2. Energy Efficiency initiatives described with-in a Supply and Demand relationship. a. Design: Quality of Equipment (usually phase 1 of retrofit upgrades of old buildings)

  • i. Changing of older chillers to newer chillers
  • ii. Retrofitting single glazing façade to double glazing façade, low-E Glass, or Window Films.
  • iii. F-Lamps to LED lights

b. Operational: Usage of Equipment (usually phase 2 of retrofit upgrades of old buildings)

  • i. Motion Sensors
  • ii. VFDs
  • iii. Other Demand Response software

c. Supply: Quality of Supply (phase 3)

  • i. Voltage Optimization products for variable stepping down of voltage (UK and TW)
  • ii. Smart-Grid: Load Shifting
  • iii. PV Panels
  • iv. Other sources of Energy and Waste Recovery Technology.

d. Summary: These solutions help to scale down true demand of facility: Before After

Demand in KW 10 units 8 units Utility Supply in KW 10 units 8 units

3. Alternative Energy (AE) defined empirically a. Non AE: Supply = Demand: Energetically Closed System. Singular Source of Supply. b. AE: Supply from Grid < Totality of Real Power Demand, --- Criteria (*): Energetically Open System: Non- Singular Source of Supply. For example: Before After Remark

Demand in KW 10 units

10 units

Singular Energy Source Utility Supply in KW 10 units

8 units

Multiple Energy Source

c. can be achieved by the following,

  • i. Running Genset
  • ii. Solar Panels
  • iii. Others? ->
  • Regenerative Drives (i.e. KONE/Schindler Lifts that convert braking momentum to

Electricity). Source = Residual Momentum

  • Regenerative Harvesting: Source = 50/60 Hz of supply
  • NTU Case study: Chiller Unit. Two Point Coupling Measurement.
slide-2
SLIDE 2

Updated: 22nd July, 2017 | www.epicasia.com.sg

  • Method: Time-Interval-Sampling
  • Figure shows drop in Line Demand when module(s) is activated, while

Load Demand in KW and RLA is preserved at the same level.

  • Further, note that Voltage does not decrease when modules are
  • activated. Due to phase balancing, voltages tend to increase by 1Volt.
  • Degree of KW Reduction depends on number of modules installed, but

does not equate to magnitude of saving.

  • i. Example: NTU
  • ii. Example: Trump Tower
  • Time-Interval-Sampling only serves to show product works, but not how it

will work when fully implemented.

  • Performance Guarantee can be worked out during project proper.

4. NTU Showcasing has successfully shown that product fulfils (*) Criteria that defines Alternative Energy. This result is non-ambiguous and replicable with the right metering in place. a. For installation on chiller units with its own display panel, it is possible to verify that the Line Demand drop is in tandem with

  • i. preservation of Chiller RLA, and that the AE solution
  • ii. Does not stave the compressor and lead to an increase in set temperature.

b. This chart is important because

  • i. It describes an AE not in marketing language
  • ii. But in empirically verifiable terms
  • Replicable anytime:
  • Same Meter Model: FLUKE AMPROBE DM-II PRO ENERGY DATA LOGGER
  • Same Specifications
  • Same Configuration

5. Such observations have been made independently by third parties such as CSA Group. 6. Other Third Part Verifications available: a. CSA: Product Functions as source of KW b. CE: Line Demand Reduction c. Eaton Cutler-Hammer: Line Demand Reduction d. UL and GSA: Line Demand Reduction e. Mitsubishi EDM: Power Quality Improvement f. AT&T Seakay: Surge Protection g. TUV-SUD America: Product Safety h. Project References (Satisfied Clients) Line Demand Reduction 7. Theory of Operation a. The product is not a Power Factor Correction Capacitor. It is a Passive, Magnetic Induction charging module with added PFC improvement function. This can easily be proven empirically. Point #4. b. It is helpful for clients and professional engineers to recall/be aware that

  • i. Commercially Available: products with similar theory of application are already widely

available on the market. In other words, the theory is not new, but more and more widely and diversely applied. Regen Modules takes the concept, and adapts it for buildings, and C&I

  • customers. (Same theory, new in application)
  • ii. Graduate Research Publications: Induction of magnetic sources has been a hot academic

topic with accelerated research publication rate since 2008. c. Starting Question: In comparison to commercially available products which operates by the same

  • theory. How does the following products operate?
  • i. Electric Tooth Brush
  • ii. Faraday’s Torchlight
  • iii. iPhones with wireless charging
  • iv. Electric Vehicles (EVs)
slide-3
SLIDE 3

Updated: 22nd July, 2017 | www.epicasia.com.sg

  • v. MIT’s Witricity Project

d. All these products are able to function due to inductive charging or Resonance Charging,

  • i. Components: Transmitting and receiver coils are placed in close proximity, and are therefore

magnetically-coupled: where magnetic flux of one inductor passes through another inductor.

  • ii. Transmitting Coils/Plates emit magnetic field when AC is passes through.
  • iii. Voltage and current is being induced at 50/60hz frequency, depending on source AC.

e. Reiteration of Key Points:

  • i. Similarities:
  • Widely understood and accepted Theory of Operation
  • Inductive charging is able to achieve Cordless/Cable-less Power Transmission
  • What we have done is to take such a configuration and fitted both the

transmission reception Coils inside a module of such dimensions: 16” x 13” 8” (Zero-Floor Space)

  • ii. Differences:

Existing Inductive Charging Regen TSRX Modules **Operating Brand for Asia Market

1 Designed to feed a specific load which the receiving induction plate is affixed to; be it EV, or toothbrush, etc. Non-Specific: distributes the induced Active Current to whichever Distribution Panel it is connected to. Minimums feeder amps per module required to ensure magnetic saturation for good performance. 2 Inductive Charging of receiver plates are connected to battery, therefore offers storage capability. No storage required: Instantaneous charging up (conversion of magnetic field to Electricity) and simultaneous releasing of active current for facility’s consumption. ‘ 3 Receiver plate is connected to a target load which consumes electricity. Receiver plate is not a load (Regen Modules do NOT consume electricity). Connected in parallel (only). Induces – charges up – and distributes. 4 None. Additional PQ Benefits:

  • High Quality Surge Protection Device;
  • Passive Harmonic Filter;
  • Power Factor Improvement;
  • Phase Balancing for 3-phase

applications;

  • iii. Differences compared with Capacitors

Power Factor Correction Capacitors Regen TSRX Modules

Energy Storage

electrical potential energy Magnetic field of inductors

Lifespan (Project Life Cycle)

2 ~ 5 (depends heavily on presence of harmonic distortion in circuit) More than 20 Years

Real Demand Reduction?

NO. Average of 4KWH/HR per Module for 400V/50HZ.

  • iv. Special Note.
  • Additional Notes to pointer 3b(iii).

There are other products commercially available which are able to ‘regenerate’ and return electricity to the grid. Examples are

  • Regenerative Lifts (Schindler Lifts)
  • Active Front Ends (AFEs)
slide-4
SLIDE 4

Updated: 22nd July, 2017 | www.epicasia.com.sg

Existing Regenerative Technologies Regenerative Harvesting Technology

Example-1

Active Front End Technology “Regenerative Braking for Energy Savings and Elimination of Braking Resistors”

http://literature.rockwellautomation.com/idc/groups/literature/documents/ pp/20y-pp001_-en-p.pdf

«Regenerative feedback into the line supply (braking

  • peration)»

http://w3.siemens.no/home/no/no/sector/industry/marine/pages/active_fro nt_end.aspx

REGEN TSRX Modules from

Example-2

Regenerative Breaking Technology for Lifts (Elevators) “The Schindler AC Regeneration Module is a high performance line regeneration unit for elevator

  • applications. When applied to an existing ACVF brake

resistor drive, it saves energy by taking the excess regenerative energy from the motor and returning it to the AC power source. Additionally, the brake resistors generate less heat, reducing the need to cool the machine room, providing further savings”

https://www.schindler.com/content/nz/internet/en/modernisation/_jcr_cont ent/rightPar/downloadlist/downloadList/95_1371091339980.download.asset .95_1371091339980/Regenerative_Drive-May2010.pdf

http://literature.rockwellautomation.com/idc/groups/li terature/documents/pp/20y-pp001_-en-p.pdf

Energy Conversion

Mechanical Energy from Braking  Electricity 50/60HZ Magnetic Fluctuation from supply  Electricity

Type of Product

Waste Recovery Waste Recovery

Application

Facilities with Elevators and Motors Entire Facilities

8. International Case Studies a. Hotels b. Constructions c. Printing Press 9. Hotel Samples: a. Hyatt Regency Dehli b. Marriott/Pacific Star, Guam c. Holiday Inn, Guam d. Etc

  • 10. Product Pre-launching Activities (for Indonesia Market)

a. Showcase demonstrations at the following locations, all readings taken from PLN Meter.

  • i. Wirausaha Gedung (PLN)
  • ii. Double Tree Hilton Cikini (PLN)
  • iii. WISMA BNI (Fluke Amprobe only). Facility is too big for showcase modules to have any effect
  • n main PLN Meter. Readings were taken at specific feeder which feeds target chiller.
  • 11. Topic of Presentation: BEYOND SOLAR.

We make the following comparisons Existing Solar PVs Regen TSRX Modules

1 Output for 5 Hours per day maximum, without storage upgrade Same duration as facility. Excellence Product for 24/7 Facilities. 2 Maintenance required for Inverters and surface cleaning for modules. Negligible Maintenance Required. See notes: #13c. 3 N/A Additional PQ Benefits:

slide-5
SLIDE 5

Updated: 22nd July, 2017 | www.epicasia.com.sg

  • High Quality Surge Protection Device;
  • Passive Harmonic Filter;
  • Power Factor Improvement;
  • Phase Balancing for 3-phase applications;
  • 12. Savings Estimation:

a. Quick rule of thumb is given by the formula: Savings = Kc/6 ------------------- Savings Estimation EQN

  • i. Qc = Kc * P
  • Qc

= Reactive Compensation Required

  • Kc

= Coefficient of improvement (Starting and Ending Power Factor)

  • P

= Power in KW.

  • ii. And it must fulfil: total amps at main > 120n -------------- Condition for Magnetic Saturation
  • 13. Payback Calculation

a. Hotels/Resorts -> Less than 4 Years b. Product Lifespan > 15 Years. c. Negligible Maintenance (why?)

  • i. No Mechanical Components  Anything that moves physically has shorter lifespan due to

mechanical friction

  • ii. No PCB/Electronics  these components are susceptible to damage due to high current
  • iii. Surge Events  No danger of damage due to over-voltage  Product itself is a high quality

surge protection device, specifically catered to mitigate such events

  • iv. Service maintenance duration (warranty given) equivalent to project payback.

d. Assumptions:

  • i. 400V/50Hz
  • ii. 24/7 Operations
  • iii. Tariff = 0.075 USD/KWH
  • 14. Excellent Compatibility for facilities which cannot afford to see a reduction in set-running load (equipment with

fixed output) a. Electric Arc Furnaces b. Arc Welding c. Microwave Emitters for CVD Processes d. Hydraulic Motors/Pumps e. Drill Rigs f. Computing Facilities (Data Centres) g. Medical Equipment (MRI Machines) h. F&B Cold Rooms

  • 15. What is required for us to draw up a savings proposal:

a. Single Line b. 12 Months Electrical Bill c. Power Readings at Main Incoming (LVDP) d. Type of Capacitor Bank

  • 16. Interesting Common Question: “Does the product Steal Electricity from the Utility?”

a. At least one of the following conditions will have to be technically fulfilled in order for any persons/products to steal electricity

slide-6
SLIDE 6

Updated: 22nd July, 2017 | www.epicasia.com.sg

  • Condition #1: Modifications to electrical distribution system upstream of the

Revenue Meter in order to channel electricity to the client while effectively bypassing the billing meter.

  • Condition #2: Hacking or corrupting the billing meter.

b. Regen TSRX Modules are

  • i. Installed downstream of the facility (AFTER) the Billing Meter
  • ii. Has no scripting/programming capabilities to corrupt the billing meter in any conceivable

way.
