SLIDE 1
Section1.4
Equations of Lines and Modeling
Section1.4 Equations of Lines and Modeling FindingtheEquationof - - PowerPoint PPT Presentation
Section1.4 Equations of Lines and Modeling FindingtheEquationof - - PowerPoint PPT Presentation
Section1.4 Equations of Lines and Modeling FindingtheEquationof Line Point-Slope Form If you know the slope and any point on a line, you can write the equation in point-slope form: y y 1 = m ( x x 1 ) Point-Slope Form If you know the
SLIDE 2
SLIDE 3
Point-Slope Form
If you know the slope and any point on a line, you can write the equation in point-slope form: y − y1 = m(x − x1)
SLIDE 4
Point-Slope Form
If you know the slope and any point on a line, you can write the equation in point-slope form: y − y1 = m(x − x1) m is the slope of the line rise
run
SLIDE 5
Point-Slope Form
If you know the slope and any point on a line, you can write the equation in point-slope form: y − y1 = m(x − x1) m is the slope of the line rise
run
- (x1, y1) is the point
SLIDE 6
Examples
- 1. Determine the
slope-intercept form of the equation for the following graph:
−2 −1 1 2 3 4 5 6 7 −4 −3 −2 −1 1
SLIDE 7
Examples
- 1. Determine the
slope-intercept form of the equation for the following graph:
−2 −1 1 2 3 4 5 6 7 −4 −3 −2 −1 1
y = 1
2x − 3
SLIDE 8
Examples
- 1. Determine the
slope-intercept form of the equation for the following graph:
−2 −1 1 2 3 4 5 6 7 −4 −3 −2 −1 1
y = 1
2x − 3
- 2. Determine the slope-intercept
form of the line which has a slope of −4 and a y-intercept
- f
- 0, 2
3
- .
SLIDE 9
Examples
- 1. Determine the
slope-intercept form of the equation for the following graph:
−2 −1 1 2 3 4 5 6 7 −4 −3 −2 −1 1
y = 1
2x − 3
- 2. Determine the slope-intercept
form of the line which has a slope of −4 and a y-intercept
- f
- 0, 2
3
- .
y = −4x + 2
3
SLIDE 10
Examples
- 1. Determine the
slope-intercept form of the equation for the following graph:
−2 −1 1 2 3 4 5 6 7 −4 −3 −2 −1 1
y = 1
2x − 3
- 2. Determine the slope-intercept
form of the line which has a slope of −4 and a y-intercept
- f
- 0, 2
3
- .
y = −4x + 2
3
- 3. Find the standard form of a line
with a slope of 3
4 and which
passes through the point (−1, 4).
SLIDE 11
Examples
- 1. Determine the
slope-intercept form of the equation for the following graph:
−2 −1 1 2 3 4 5 6 7 −4 −3 −2 −1 1
y = 1
2x − 3
- 2. Determine the slope-intercept
form of the line which has a slope of −4 and a y-intercept
- f
- 0, 2
3
- .
y = −4x + 2
3
- 3. Find the standard form of a line
with a slope of 3
4 and which
passes through the point (−1, 4). −3x + 4y = 19
- r
3x − 4y = −19
SLIDE 12
Examples (continued)
- 4. Find the slope-intercept form of a line which passes through the
points (−3, 1) and (4, 2).
SLIDE 13
Examples (continued)
- 4. Find the slope-intercept form of a line which passes through the
points (−3, 1) and (4, 2). y = 1
7x + 10 7
SLIDE 14
Examples (continued)
- 4. Find the slope-intercept form of a line which passes through the
points (−3, 1) and (4, 2). y = 1
7x + 10 7
- 5. Find the formula for the linear function g(x), where g(2) = 1 and
g(−1) = 5.
SLIDE 15
Examples (continued)
- 4. Find the slope-intercept form of a line which passes through the
points (−3, 1) and (4, 2). y = 1
7x + 10 7
- 5. Find the formula for the linear function g(x), where g(2) = 1 and
g(−1) = 5. g(x) = − 4
3x + 11 3
SLIDE 16
ParallelandPerpendicular Lines
SLIDE 17
Parallel Lines
Parallel lines are lines which run in the same direction and never cross. Two lines with defined slope are parallel when they have the same slope. m1 = m2
SLIDE 18
Parallel Lines
Parallel lines are lines which run in the same direction and never cross. Two lines with defined slope are parallel when they have the same slope. m1 = m2 Two vertical lines (which don’t have a slope) are parallel.
SLIDE 19
Perpendicular Lines
Perpendicular lines are lines which cross at exactly a 90◦ angle. Two lines with defined slope are perpendicular when their slopes are negative reciprocals of each other. m1 = − 1
m2
SLIDE 20
Perpendicular Lines
Perpendicular lines are lines which cross at exactly a 90◦ angle. Two lines with defined slope are perpendicular when their slopes are negative reciprocals of each other. m1 = − 1
m2
Vertical lines (which don’t have a slope) are perpendicular to horizontal lines.
SLIDE 21
Examples
- 1. Are the following pairs of lines parallel, perpendicular, or neither?
SLIDE 22
Examples
- 1. Are the following pairs of lines parallel, perpendicular, or neither?
(a) y = 26
3 x − 11;
y = − 3
26x + 15
SLIDE 23
Examples
- 1. Are the following pairs of lines parallel, perpendicular, or neither?
(a) y = 26
3 x − 11;
y = − 3
26x + 15
Perpendicular
SLIDE 24
Examples
- 1. Are the following pairs of lines parallel, perpendicular, or neither?
(a) y = 26
3 x − 11;
y = − 3
26x + 15
Perpendicular (b) x + 2y = 5; 2x + 4y = 17
SLIDE 25
Examples
- 1. Are the following pairs of lines parallel, perpendicular, or neither?
(a) y = 26
3 x − 11;
y = − 3
26x + 15
Perpendicular (b) x + 2y = 5; 2x + 4y = 17 Parallel
SLIDE 26
Examples
- 1. Are the following pairs of lines parallel, perpendicular, or neither?
(a) y = 26
3 x − 11;
y = − 3
26x + 15
Perpendicular (b) x + 2y = 5; 2x + 4y = 17 Parallel (c) x = 3; y = 6
SLIDE 27
Examples
- 1. Are the following pairs of lines parallel, perpendicular, or neither?
(a) y = 26
3 x − 11;
y = − 3
26x + 15
Perpendicular (b) x + 2y = 5; 2x + 4y = 17 Parallel (c) x = 3; y = 6 Perpendicular
SLIDE 28
Examples
- 1. Are the following pairs of lines parallel, perpendicular, or neither?
(a) y = 26
3 x − 11;
y = − 3
26x + 15
Perpendicular (b) x + 2y = 5; 2x + 4y = 17 Parallel (c) x = 3; y = 6 Perpendicular (d) y = −3x + 1; y = − 1
3x + 1
SLIDE 29
Examples
- 1. Are the following pairs of lines parallel, perpendicular, or neither?
(a) y = 26
3 x − 11;
y = − 3
26x + 15
Perpendicular (b) x + 2y = 5; 2x + 4y = 17 Parallel (c) x = 3; y = 6 Perpendicular (d) y = −3x + 1; y = − 1
3x + 1
Neither
SLIDE 30
Examples (continued)
- 2. Find the equation of the line which is parallel to 2x − y = 6 which
passes through the point (−1, 3).
SLIDE 31
Examples (continued)
- 2. Find the equation of the line which is parallel to 2x − y = 6 which
passes through the point (−1, 3). y = 2x + 5
SLIDE 32
Examples (continued)
- 2. Find the equation of the line which is parallel to 2x − y = 6 which
passes through the point (−1, 3). y = 2x + 5
- 3. Find the equation of the line which is perpendicular to
−3x + 2y = 1 which passes through the point (3, 5).
SLIDE 33
Examples (continued)
- 2. Find the equation of the line which is parallel to 2x − y = 6 which
passes through the point (−1, 3). y = 2x + 5
- 3. Find the equation of the line which is perpendicular to
−3x + 2y = 1 which passes through the point (3, 5). y = − 2
3x + 7
SLIDE 34
Examples (continued)
- 2. Find the equation of the line which is parallel to 2x − y = 6 which
passes through the point (−1, 3). y = 2x + 5
- 3. Find the equation of the line which is perpendicular to
−3x + 2y = 1 which passes through the point (3, 5). y = − 2
3x + 7
- 4. Find a so that the line which passes through (a, 4) and (−1, 3) is
parallel to line y = −3x + 6.
SLIDE 35
Examples (continued)
- 2. Find the equation of the line which is parallel to 2x − y = 6 which
passes through the point (−1, 3). y = 2x + 5
- 3. Find the equation of the line which is perpendicular to
−3x + 2y = 1 which passes through the point (3, 5). y = − 2
3x + 7
- 4. Find a so that the line which passes through (a, 4) and (−1, 3) is
parallel to line y = −3x + 6. a = − 4
3
