1 2 Semantic Web Service Tutorial Michael Stollberg Katia Sycara - - PowerPoint PPT Presentation

1

2 Carnegie Mellon University Katia Sycara Massimo Paolucci Michael Stollberg Matthew Moran Michal Zaremba Mick Kerrigan Emilia Cimpian Stefania Galizia Barry Norton Liliana Cabral John Domingue

Semantic Web Service Tutorial

3

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Agenda

• Part I: Introduction to Semantic Web Services

09.00 – 09.30

• Part II: SWS Description Frameworks

09.30 – 12.00

– OWL-S coffee break 10.15 – 10.45 – WSMO lunch 12.00 – 01.00

• Part III: SWS Techniques and Systems

01.00 – 01.45

– Discovery, Composition, Invocation, Mediation – OWL-S IDE, WSMX, IRS

• Part IV: Hands-On Session

01.45 – 04.00

– Tools presentation coffee break 02.15 – 02.45 – OWL-S IDE, WSMX

4

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

PART I:

Introduction to Semantic Web Services

Michael Stollberg

5

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Contents

• The vision of the Semantic Web
• Ontologies as the basic building block
• Current Web Service Technologies
• Vision and Challenges for Semantic Web Services

6

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Static

– 500 million users – more than 3 billion pages

WWW

URI, HTML, HTTP

The Vision

7

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WWW

URI, HTML, HTTP

Serious Problems in

• information finding,
• information extracting,
• information representing,
• information interpreting and
• and information maintaining.

Semantic Web

RDF, RDF(S), OWL

Static

The Vision

8

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WWW

URI, HTML, HTTP

Bringing the computer back as a device for computation

Semantic Web

RDF, RDF(S), OWL

Dynamic

Web Services

UDDI, WSDL, SOAP

Static

The Vision

9

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WWW

URI, HTML, HTTP

Bringing the web to its full potential

Semantic Web

RDF, RDF(S), OWL

Dynamic

Web Services

UDDI, WSDL, SOAP

Static

Semantic Web Services

The Vision

10

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

The Semantic Web

• the next generation of the WWW
• information has machine-processable and

machine-understandable semantics

• not a separate Web but an augmentation of

the current one

• Ontologies as basic building block

11

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Ontology Definition

formal, explicit specification of a shared conceptualization

commonly accepted understanding conceptual model

• f a domain

(ontological theory) unambiguous terminology definitions machine-readability with computational semantics

12

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Ontology Example

• isA – hierarchy (taxonomy)
• attends

holds

!"#$% $&

13

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Ontology Technology

To make the Semantic Web working we need:

• Ontology Languages:

– expressivity – reasoning support – web compliance

• Ontology Reasoning:

– large scale knowledge handling – fault-tolerant – stable & scalable inference machines

• Ontology Management Techniques:

– editing and browsing – storage and retrieval – versioning and evolution Support

• Ontology Integration Techniques:

–

• ntology mapping, alignment, merging

– semantic interoperability determination

• and … Applications

14

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Web Services

• loosely coupled, reusable components
• encapsulate discrete functionality
• distributed
• programmatically accessible over standard

internet protocols

• add new level of functionality on top of the

current web

15

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

The Promise of Web Services

web-based SOA as new system design paradigm

16

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WSDL

• Web Service Description Language
• W3C effort, WSDL 2 final construction phase

describes interface for consuming a Web Service:

• Interface: operations (in- & output)
• Access (protocol binding)
• Endpoint (location of service)

17

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

UDDI

• Universal Description, Discovery, and Integration Protocol
• OASIS driven standardization effort

Registry for Web Services:

• provider
• service information
• technical access

18

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

SOAP

• Simple Object Access Protocol
• W3C Recommendation

XML data transport:

• sender / receiver
• protocol binding
• communication aspects
• content

19

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Lackings of WS Technology

• current technologies allow usage of Web Services
• but:

– only syntactical information descriptions – syntactic support for discovery, composition and execution => Web Service usability, usage, and integration needs to be inspected manually – no semantically marked up content / services – no support for the Semantic Web

=> current Web Service Technology Stack failed to realize the promise of Web Services

20

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Semantic Web Technology + Web Service Technology

Semantic Web Services

=> Semantic Web Services as integrated solution for realizing the vision of the next generation of the Web

• allow machine supported data interpretation
• ontologies as data model

automated discovery, selection, composition, and web-based execution of services

21

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Semantic Web Services

• define exhaustive description frameworks for

describing Web Services and related aspects (Web Service Description Ontologies)

• support ontologies as underlying data model to

allow machine supported data interpretation (Semantic Web aspect)

• define semantically driven technologies for

automation of the Web Service usage process (Web Service aspect)

22

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Web Service Usage Process

1. Deployment create & publish Web service description 2. Discovery determine usable services for a request 3. Composition combine services to achieve a goal 4. Selection choose most appropriate service among the available ones 5. Mediation solve mismatches (data, protocol, process) that hamper interoperation 6. Execution invoke Web services following programmatic conventions

23

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Web Service Execution Support

• Monitoring

control the execution process

• Compensation

provide transactional support and undo

• r mitigate unwanted effects
• Replacement

facilitate the substitution of services by equivalent ones

• Auditing

verify that service execution occurred in the expected way

24

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

PART II:

Semantic Web Service Ontologies

Katia Sycara Michael Stollberg

25

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Contents

• OWL-S

– Upper Ontology – Service Profile – Process Model – Service Grounding

• WSMO

– WSMO top level notions – Choreography and Orchestration – Mediation

• Differences and Commonalities

26

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

OWL-S

Katia Sycara

27

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

OWL-S Ontology

• OWL-S is an OWL ontology to describe Web services
• OWL-S leverages on OWL to

– Support capability based discovery of Web services – Support automatic composition of Web Services – Support automatic invocation of Web services

Complete do not compete

– OWL-S does not aim to replace the Web services standards rather OWL-S attempts to provide a semantic layer

• OWL-S relies on WSDL for Web service invocation (see Grounding)
• OWL-s Expands UDDI for Web service discovery (OWL-S/UDDI

mapping)

28

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

OWL-S Upper Ontology

• Mapping to WSDL
• communication protocol (RPC, HTTP, …)
• marshalling/serialization
• transformation to and from XSD to OWL
• Control flow of the service
• Black/Grey/Glass Box view
• Protocol Specification
• Abstract Messages
• Capability specification
• General features of the Service
• Quality of Service
• Classification in Service

taxonomies

29

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Service Profiles

Service Profile – Presented by a service. – Represents

what the service provides

– Two main uses:

• 1. Advertisements of Web

Services capabilities

• 2. Request of Web services with a

given set of capabilities

30

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

OWL-S Profile in a Nutshell

• Describes Web service

– What capabilities it provides:

• What transformation the service computes
• Type of service and products

– General features such as

• Agent providing the service
• Security requirements
• Quality guarantees of service
• Primary role: to assist discovery

– Allows capability based search – Allows selection based on requirements of the requester

• Profile does not specify use/invocation

31

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

OWL-S Service Profile

Capability Description

• Preconditions

– Set of conditions that should hold prior to service invocation

• Inputs

– Set of necessary inputs that the requester should provide to invoke the service

• Outputs

– Results that the requester should expect after interaction with the service provider is completed

• Effects

– Set of statements that should hold true if the service is invoked successfully.

• Service type

– What kind of service is provided (eg selling vs distribution)

• Product

– Product associated with the service (eg travel vs books vs auto parts)

32

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

OWL-S Service Profile

Additional Properties

• Security Parameters

– Specify the security capabilities of a Web service (eg support X509 Encryption) – Specify the security requirements of a Web service (eg a client should be able to provide X509 Encryption)

• Quality rating

– What level of service quality does the Web service provide?

• Description with standard business taxonomies

– How would the service be classified in standard taxonomies such as UNSPSC or NAICS?

This is not a closed set, new properties can be added using existing ontologies

33

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Process Model

• Process Model

– Describes how a service works: internal processes of the service – Specifies service interaction protocol – Specifies abstract messages:

• ntological type of

information transmitted

• Facilitates

– Web service invocation – Composition of Web services – Monitoring of interaction

34

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Viewpoints of Process Model

• Three viewpoints of a Web service

– Glass Box:

• The Web service reveals all its internal structure
• Which parts of the service it performs in-house, which one it

subcontracts, etc

– Black Box:

• The Web service model does not reveal anything about the

internal working of the service

• It just specifies what data it gathers and what data it sends back

– Grey Box:

• The Web service selectively hides some parts of its Process

Model, while it publicizes others

35

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Definition of Process

• A Process represents a transformation (function). It is

characterized by four parameters – Inputs: the inputs that the process requires – Preconditions: the conditions that are required for the process to run correctly – Outputs: the information that results from (and is returned from) the execution of the process – Results: a process may have different outcomes depending on some condition

• Condition: under what condition the result occurs
• Constraints on Outputs
• Effects: real world changes resulting from the execution of the

process

36

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Motivation for Results

• Processes may terminate in exceptional states:

– The credit company may fail to charge the credit card – The book may be out of stock – The deliver of the goods may fail

• Results support modeling of non-deterministic
• utcomes of Web services

– The condition specifies when an outcome is generated – Each outcome is characterized by

• a set of constraints on outputs
• a set of effects

37

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Example of Process

<process:AtomicProcess rdf:ID="LogIn"> <process:hasInput rdf:resource="#AcctName"/> <process:hasInput rdf:resource="#Password"/> <process:hasOutput rdf:resource="#Ack"/> <process:hasPrecondition isMember(AccName)/> <process:hasResult> <process:Result> <process:inCondition> <expr:SWRL-Condition> correctLoginInfo(AccName,Password) </expr:SWRL-Condition> </process:inCondition> <process:withOutput rdf:resource=“#Ack“> <valueType rdr:resource=“#LoginAcceptMsg”> </process:withOutput> <process:hasEffect> <expr:SWRL-Condition> loggedIn(AccName,Password) </expr:SWRL-Condition> </process:hasEffect> </process:Result> </process:hasResult> </process:AtomicProcess>

Inputs / Outputs Result Condition Effect

Output Constraints

Precondition

38

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Ontology of Processes

Process Atomic Simple Composite

Provides abstraction, encapsulation etc. Defines a workflow composed of process performs Invokable bound to grounding

39

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Process Model Organization

• Process Model is described as a tree structure

– Composite processes are internal nodes – Simple and Atomic Processes are the leaves

• Simple processes represent an abstraction

– Placeholders of processes that aren’t specified – Or that may be expressed in many different ways

• Atomic Processes correspond to the basic

actions that the Web service performs

– Hide the details of how the process is implemented – Correspond to WSDL operations

40

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Composite Processes

• Composite Processes specify how processes

work together to compute a complex function

• Composite processes define

1.Control Flow

Specify the temporal relations between the executions of the different sub-processes

2.Data Flow

Specify how the data produced by one process is transferred to another process

41

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Example of Composite Process

Sequence

BookFlight Depart Arrive Flights Airline Airline Flight

Perform Get Flights

Flight

Perform Select Flight

Flights

Control Flow Links

Specify order of execution

Data-Flow Links

Specify transfer of data

Perform statements

Specify the execution of a process

42

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Perform Construct

• Perform provides invocation mechanism

– Specify context of process execution

• input data flow
• hooks for output data flow
• Distinction between definition and

invocation of a process

– Definition specifies the process’ I/P/R – Perform specify when the process is invoked and with what parameters

43

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Control Flow

• Processes can be chained to form a workflow
• OWL-S supports the following control flow constructs

– Sequence/Any-Order: represents a list of processes that are executed in sequence or arbitrary order – Conditionals: if-then-else statements – Loops: while and repeat-until statements – Multithreading and synchronization: split process in multiple threads, and rendezvous (joint) points – Non-deterministic choices: (arbitrarily) select one process of a set

44

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Data Flow

Dataflow allows information that is transferred from process to process. Output→ → → →Input:

The information produced by one process is transferred to another in the same control construct

Input → → → →Input:

The information received by a composite process is transferred to the sub-processes

Output→ → → →Output:

The information produced by a subprocess is transferred to a super-process

45

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Process Model: take home lesson

• Service Model describes

– Set of processes that define the operations performed by the Web service – Control flow describing the temporal flow of processes – Data flow describing the transfer of information between sub-processes

46

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Service Grounding

• Service Grounding

– Provides a specification of service access information. – Service Model + Grounding give everything needed for using the service – Builds upon WSDL to define message structure and physical binding layer

• Specifies:

– communication protocols, transport mechanisms, communication languages, etc.

47

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Rationale of Service Grounding

• Provides a specification of service access

information.

• Service Model + Grounding give everything

needed for using the service

– Service description is for reasoning about the service

• Decide what information to send and what to expect

– Service Grounding is for message passing

• Generate outgoing messages, and get incoming messages
• Mapping XML Schemata to OWL concepts
• Builds upon WSDL to define message structure

and physical binding layer

48

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Mapping OWL-S / WSDL 1.1

• Operations

correspond to Atomic Processes

• Input/Output

messages correspond to Inputs/Outputs

• f processes

49

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Example of Grounding

Sequence

BookFlight Depart Arrive Flights Airline Airline Flight

Perform Get Flights

Flight

Perform Select Flight

Flights Get Flights Op Depart Arrive Flights WSDL Airline Flight

Select Flight op

Flights

50

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Result of using the Grounding

• Invocation mechanism for OWL-S

– Invocation based on WSDL – Different types of invocation supported by WSDL can be used with OWL-S

• Clear separation between service description and

invocation/implementation

– Service description is needed to reason about the service

• Decide how to use it
• Decide how what information to send and what to expect

– Service implementation may be based on SOAP an XSD types – The crucial point is that the information that travels on the wires and the information used in the ontologies is the same

• Allows any web service to be represented using OWL-S

– For example: Amazon.com

51

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Handling stateful vs stateless Web services

• 1. Stateless Web services
• The server does not maintain the state of the

computation

• Dataflow links specify how the client

communicate the state to the service

• 2. Stateful Web services
• The service does maintain the state
• No need of dataflow links since transfer of

information is opaque to the client

52

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Representing Stateful Web services

Sequence

BookFlight Flights Airline Airline Flight

Perform Get Flights

Flight

Perform Select Flight

Flights Get Flights Op Arrive Flights

Server

Flight

Select Flight op

Flights Stateless: no information is transferred between the two operations

Client Server

53

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Representing Stateless Web services

Sequence

BookFlight Flights Airline Airline Flight

Perform Get Flights

Flight

Perform Select Flight

Get Flights Op Arrive Flights

Server

Flight

Select Flight op

Flights

Client

Stateful: information is recorded by the server, no need

• f transfer between the two operations

54

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Conclusion OWL-S section

• OWL-S provides a language for the description of Web

services – Service Profile provides description of capabilities of Web Service

• Allows capability-based discovery

– Process Model provides the description of how to use a Web service

• Allows automatic invocation of Web service

– Service Grounding maps Atomic Processes into WSDL operations

• Allows separation between description and implementation
• Supports description of arbitrary Web services

55

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Web Service Modeling Ontology WSMO

Michael Stollberg

56

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Outline

• WSMO Working Groups
• Top Level Notions

– Ontologies – Web Services – Goals – Mediators

57

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WSMO Working Groups

A Conceptual Model for SWS A Formal Language for WSMO A Rule-based Language for SWS Execution Environment for WSMO

58

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WSMO Top Level Notions

Objectives that a client wants to achieve by using Web Services Provide the formally specified terminology

• f the information

used by all other components Semantic description of Web Services:

• Capability (functional)
• Interfaces (usage)

Connectors between components with mediation facilities for handling heterogeneities

WSMO D2, version 1.2, 13 April 2005 (W3C submission)

59

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Non-Functional Properties

• Dublin Core Metadata Set:

– complete item description – used for resource management

• Versioning Information

– evolution support

• Quality of Service Information

– availability, stability

• Other

– Owner, financial

relevant, non-functional aspects for WSMO elements

60

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Non-Functional Properties List

Dublin Core Metadata

Contributor Coverage Creator Description Format Identifier Language Publisher Relation Rights Source Subject Title Type

Quality of Service

Accuracy NetworkRelatedQoS Performance Reliability Robustness Scalability Security Transactional Trust

Other

Financial Owner TypeOfMatch Version

61

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WSMO Ontologies

Provide the formally specified terminology

• f the information

used by all other components Semantic description of Web Services:

• Capability (functional)
• Interfaces (usage)

Connectors between components with mediation facilities for handling heterogeneities Objectives that a client wants to achieve by using Web Services

62

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

• Ontologies are the ‘data model’ throughout WSMO

– all WSMO element descriptions rely on ontologies – all data interchanged in Web Service usage are ontologies – Semantic information processing & ontology reasoning

• WSMO Ontology Language WSML

– conceptual syntax for describing WSMO elements – logical language for axiomatic expressions (WSML Layering)

• WSMO Ontology Design

– Modularization: import / re-using ontologies, modular approach for

• ntology design

– De-Coupling: heterogeneity handled by OO Mediators

Ontology Usage & Principles

63

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

• Non functional properties (see before)
• Imported Ontologies

importing existing ontologies where no heterogeneities arise

• Used mediators

OO Mediators (ontology import with terminology mismatch handling)

Ontology Elements:

Concepts set of concepts that belong to the ontology, incl. Attributes set of attributes that belong to a concept Relations define interrelations between several concepts Functions special type of relation (unary range = return value) Instances set of instances that belong to the represented ontology Axioms axiomatic expressions in ontology (logical statement)

Ontology Specification

64

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WSMO Web Services

Provide the formally specified terminology

• f the information

used by all other components Semantic description of Web Services:

• Capability (functional)
• Interfaces (usage)

Connectors between components with mediation facilities for handling heterogeneities Objectives that a client wants to achieve by using Web Services

65

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WSMO Web Service Description

Web Service Implementation

(not of interest in Web Service Description)

Choreography --- Service Interfaces --- Capability functional description

WS WS

• Advertising of Web Service
• Support for WS Discovery

client-service interaction interface for consuming WS

• External Visible

Behavior

• Communication

Structure

• ‘Grounding’

realization of functionality by aggregating

• ther Web Services
• functional

decomposition

• WS composition

Non-functional Properties DC + QoS + Version + financial

• complete item description
• quality aspects
• Web Service Management

WS

Orchestration

66

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Capability Specification

• Non functional properties
• Imported Ontologies
• Used mediators

– OO Mediator: importing ontologies with mismatch resolution – WG Mediator: link to a Goal wherefore service is not usable a priori

• Pre-conditions

What a web service expects in order to be able to provide its service. They define conditions over the input.

• Assumptions

Conditions on the state of the world that has to hold before the Web Service can be executed

• Post-conditions

describes the result of the Web Service in relation to the input, and conditions on it

• Effects

Conditions on the state of the world that hold after execution of the Web Service (i.e. changes in the state of the world)

67

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Choreography & Orchestration

• VTA example:
• Choreography =

how to interact with the service to consume its functionality

• Orchestration =

how service functionality is achieved by aggregating other Web Services

VTA Service

Date Time Flight, Hotel Error Confirmation

Hotel Service Flight Service

Date, Time Hotel Error Date, Time Flight Error When the service is requested When the service requests

68

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Choreography Interfaces

• External Visible Behavior

– those aspects of the workflow of a Web Service where Interaction is required – described by workflow constructs: sequence, split, loop, parallel

• Communication Structure

– messages sent and received – their order (communicative behavior for service consumption)

• Grounding

– executable communication technology for interaction – choreography related errors (e.g. input wrong, message timeout, etc.)

• Formal Model

– reasoning on Web Service interfaces (service interoperability) – semantically enabled mediation on Web Service interfaces

Interface for consuming Web Service

69

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Orchestration Aspects

• decomposition of

service functionality

• other Web services

consumed via their choreography interfaces

Behavior for Interaction with aggregated Web Services

WS

Web Service Business Logic

1

2 3 4

WS

State in Orchestration Control Flow Data Flow Service Interaction

70

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WSMO Web Service Interfaces

• behavior interfaces of Web services and clients for “peer-2-

peer” interaction

• Choreography and Orchestration as sub-concepts of

Service Interface with common description language

• service interface description aspects:

1. represent the dynamics of information interchange during service consumption and interaction 2. support ontologies as the underlying data model 3. appropriate communication technology for information interchange 4. sound formal model / semantics of service interface specifications in

• rder to allow advanced reasoning on them

5. support higher-level process constructs for more complex reasoning tasks 6. provide graphical representation for editing and maintenance

71

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Service Interface Description

(WSMO) Ontologies as data model:

• every resource description based on ontologies
• every data element interchanged is ontology instance

Formal Model: “ontologized ASMs” as sound formalism Grounding:

• making service interfaces executable
• currently grounding to WSDL

Downwards Translation UML -> Formal Model User Language (UML2 Activity Diagrams) graphical representation for choreography &

• rchestration descriptions

72

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Ontologized Abstract State Machines

• Vocabulary :

– ontology schema(s) used in service interface description – usage for information interchange: in, out, shared, controlled

• States ():

– a stable status in the information space – defined by attribute values of ontology instances

• Guarded Transition GT():

– state transition – general structure: if (condition) then (update)

• condition on current state, update = changes in state transition
• all GT() whose condition is fulfilled fire in parallel

73

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WSMO Goals

Provide the formally specified terminology

• f the information

used by all other components Semantic description of Web Services:

• Capability (functional)
• Interfaces (usage)

Connectors between components with mediation facilities for handling heterogeneities Objectives that a client wants to achieve by using Web Services

74

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Goals

• Goal-driven Approach, derived from AI rational agent approach
• ntological De-coupling of Requester and Provider
• ‘intelligent’ mechanisms detect suitable services for solving the Goal
• service re-use & knowledge-level client side support
• Usage of Goals within Semantic Web Services

– A Requester (human or machine) defines a Goal to be resolved independently and on the knowledge level – SWS techniques / systems automatically determine Web Services to be used for resolving the Goal (discovery, composition, execution, etc.) – Goal Resolution Management is realized in implementations

Client Objective Specification along with all information needed for automated resolution

75

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Goal-driven Architecture

Client

Goal

• objective (desired final state)
• input for service usage
• goal resolution constraints,

preferences, and policies

Goal Resolution Plan

• goal resolution algorithm
• decomposition (optional)
• service usage / invocation

corresponds to / creation of defines

Service Implementation

(not of interest here)

functional behavioral

service detection & composition

Client-Side Service-Side

Domain Knowledge

Ontology Ontology Ontology Ontology service usage

76

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Mediation

• Heterogeneity …

– Mismatches on structural / semantic / conceptual / level – Occur between different components that shall interoperate – Especially in distributed & open environments like the Internet

• Concept of Mediation (Wiederhold, 94):

– Mediators as components that resolve mismatches – Declarative Approach:

• Semantic description of resources
• ‘Intelligent’ mechanisms that resolve mismatches independent of content

– Mediation cannot be fully automated (integration decision)

• Levels of Mediation within Semantic Web Services (WSMF):

(1) Data Level: mediate heterogeneous Data Sources (2) Protocol Level: mediate heterogeneous Communication Patterns (3) Process Level: mediate heterogeneous Business Processes

77

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WSMO Mediators Overview

OO Mediator

O O / G / WS / M 1 .. n 1

GG Mediator

G G 1 .. n 1 ..n

WG Mediator

G xor WS WS xor G 1 .. n 1 ..n Process Level (Communication)

WW Mediator

WS WS 1 1 ..n terminology representation & protocol

• Relation

Mediation data level mediation

• Relation

Mediation Process Level (Communication)

• Relation

Mediation technique used imports / reuses correlation Legend Process Level (Cooperation)

78

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Mediator Usage

79

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

OWL-S and WSMO

Commonalities and Differences

80

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

OWL-S and WSMO

• OWL-S =
• ntology and language to describe Web services
• WSMO =
• ntology and language for core elements of

Semantic Web Service systems

OWL-S profile WSMO capability + non-functional properties OWL-S Grounding ≈ ≈ ≈ ≈ current WSMO Grounding OWL-S Process Model ≈ ≈ ≈ ≈ WSMO Service Interfaces

Main Description Elements Correlation:

81

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Mediation in OWL-S and WSMO

• OWL-S does not have an explicit notion of mediator

– Mediation is a by-product of the orchestration process

• E.g. protocol mismatches are resolved by constructing a plan that

coordinates the activity of the Web services

– …or it results from translation axioms that are available to the Web services

• It is not the mission of OWL-S to generate these axioms
• WSMO regards mediators as key conceptual

elements

– Different kinds of mediators:

• OO Mediators for ensuring semantic interoperability
• GG, WG mediators to link Goals and Web Services
• WW Mediators to establish service interoperability

– Reusable mediators – Mediation techniques under development

82

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Semantic Representation

• OWL-S and WSMO adopt a similar view on the need
• f ontologies and explicit semantics

but they rely on different logics

– OWL-S is based on OWL/SWRL

• OWL represent taxonomical knowledge
• SWRL provides inference rules
• FLOWS as formal model for process model

– WSMO is based on

• WSML a family of languages with a common basis for compatibility

and extensions in the direction of Description Logics and Logic Programming

• Ontologizes Abstract State Machines and formal model for Service

Interface Descriptions

83

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

OWL vs WSML

OWL Lite OWL DL OWL Full WSML Flight WSML DL WSML Core WSML Rule WSML Full

Description Logics full RDF(S) support subset Description Logics Logic Programming First Order Logic

84

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Summary

Grounding (WSDL / SOAP,

• ntology-based)

Service Interfaces (Choreography + Orchestration) Goals and Web Services (capability) WSMO WSDL/SOAP Grounding+ WSDL/SOAP Invocation

How to invoke

BPEL4WS Process Model Consumption & Interaction

How to consume & realize

UDDI API Profile Discovery

What it does

current Web Service technologies OWL-S

85

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

PART III:

Semantic Web Service Techniques and Systems

Michael Stollberg

86

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Contents

• The “Virtual Travel Agency Example”

– Goal and Web service description – discovery – mediation

• SWS tools and systems

– Web Service Execution Environment WSMX – OWL-S Integrated Development Environment – IRS

87

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Challenges

• Web services as loosely coupled components that shall interoperate

dynamically and automatically

• Techniques required for:

– Discovery

• How are Web services found and selected?

– Composition

• How to aggregate Web Services into a complex functionality?

– Conversation

• How to ensure automated interaction of Web Services?

– Invocation

• How to access and invoke Semantic Web Services?

– Mediation and Interoperability

• How are data and protocol mismatches resolved?
• Integrated systems for automated Web service usage :

– Editing and Management – Execution Control of Functional Components – APIs and web-based

88

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Virtual Travel Agency Use Case

• Michael is employed in DERI Austria and wants to book a flight and a hotel for the

HICSS-39 conference

• the start-up company VTA provides tourism and business travel services based on

Semantic Web Service technology => how does the interplay of Michael, VTA, and other Web Services look like?

James

Flight Booking Hotel Booking uses & aggregates Service Provider Service Provider provides Contract Contract VTA

89

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Domain Ontologies

• All terminology used in resource descriptions are based
• n ontologies and all information interchanged should be
• ntology instances
• Domain Ontologies needed for this Use Case:

Trip Reservation Ontology, Location Ontology, Date and Time Ontology, Purchase Ontology, … possibly more

• Ontology Design for the Semantic Web

– “real ontologies, no crappy data models” (Dieter Fensel) – (re-)use existing, widely accepted ontologies – modular ontology design – … is a very difficult and challenging task

• determine agreed conceptualization of domain
• correct formalization (e.g. misuse of is_a / part_of relations)

=> requires expertise in knowledge engineering

90

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Trip Reservation Ontology

• defines the terminology for trips (traveling, accomodation, holiday /

business travel facilities) and reservations

• provided by community of interest (e.g. Austrian Tourism Association)
• main concepts:

– TRIP

• describes a trip (a journey between locations)
• passenger, origin & destination, means of travel, etc.

– RESERVATION

• describes reservations for tickets, accomodation, or complete trips
• customer, trip, price, payment

– RESERVATION REQUEST – RESERVATION OFFER – RESERVATION CONFIRMATION

• uses other ontologies:

– Location Ontology for origin & destination specification – Date and Time Ontology for departure, arrival, duration information – Purchase Ontology for payment related aspects

91

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Goal Description

• “book flight and hotel for the HICSS-39 for Michael”
• goal capability postcondition: get a trip reservation for this

goal _"http://www.wsmo.org/examples/goals/hicss39" importsOntology {_"http://www.wsmo.org/ontologies/tripReservationOntology", …} capability postcondition definedBy ?tripReservation memberOf tr#reservation[ customer hasValue fof#michael, reservationItem hasValue ?tripHICSS] and ?tripHICSS memberOf tr#trip[ passenger hasValue fof#michael,

• rigin hasValue loc#innsbruck,

destination hasValue loc#kauai, meansOfTransport hasValue ?flight, accomodation hasValue ?hotel] and ?flight[airline hasValue tr#staralliance] memberOf tr#flight and ?hotel[name hasValue “Grand Hyatt Kauai Resort”] memberOf tr#hotel .

92

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

VTA Service Description

• book tickets, hotels, amenities, etc.
• capability description (pre-state)

capability VTAcapability sharedVariables {?creditCard, ?initialBalance, ?item, ?passenger} precondition definedBy ?reservationRequest[ reservationItem hasValue ?item, passenger hasValue ?passenger, payment hasValue ?creditcard, ] memberOf tr#reservationRequest and ((?item memberOf tr#trip) or (?item memberOf tr#ticket)) and ?creditCard[balance hasValue ?initialBalance] memberOf po#creditCard . assumption definedBy po#validCreditCard(?creditCard) and (?creditCard[type hasValue po#visa] or ?creditCard[type hasValue po#mastercard]).

93

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

VTA Service Description

• capability description (post-state)

postcondition definedBy ?reservation[ reservationItem hasValue ?item, customer hasValue ?passenger, payment hasValue ?creditcard ] memberOf tr#reservation . assumption definedBy reservationPrice(?reservation, ?tripPrice) and ?finalBalance= (?initialBalance - ?ticketPrice) and ?creditCard[po#balance hasValue ?finalBalance] .

94

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Web Service Discovery

James Objective: „book a flight and a hotel for me for the HICSS-39.“ Service Registry WS Discoverer

has searches

VTA

result set includes

Goal definition

95

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Discovery Techniques

• different techniques available

– trade-off: ease-of-provision <-> accuracy – resource descriptions & matchmaking algorithms Key Word Matching

match natural language key words in resource descriptions

Controlled Vocabulary

• ntology-based key word matching

Semantic Matchmaking

… what Semantic Web Services aim at

Ease of provision Possible Accuracy

96

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Matchmaking Notions & Intentions

Exact Match:

G, WS, O, M ∀ ∀ ∀ ∀x. (G(x) <=> WS(x) )

PlugIn Match:

G, WS, O, M ∀ ∀ ∀ ∀x. (G(x) => WS(x) )

Subsumption Match:

G, WS, O, M ∀ ∀ ∀ ∀x. (G(x) <= WS(x) )

Intersection Match:

G, WS, O, M ∃ ∃ ∃ ∃x. (G(x) ∧ ∧ ∧ ∧ WS(x) )

Non Match:

G, WS, O, M ¬∃ ∃ ∃ ∃x. (G(x) ∧ ∧ ∧ ∧ WS(x) )

= G = WS

X

Keller, U.; Lara, R.; Polleres, A. (Eds): WSMO Web Service Discovery. WSML Working Draft D5.1, 12 Nov 2004.

97

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Discoverer Architecture

• Discovery as central Semantic Web Services technology
• Integrated Discoverer Architectures (under construction):

Resource Repository (UDDI or other) Keyword-/ Classification-based Filtering Controlled Vocabulary Filtering Semantic Matchmaking usable Web Service

efficient narrowing

• f search space

(relevant services to be inspected)

retrieve Service Descriptions invoke Web Service

98

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Choreography Discovery

Requested Interface 1) send request 2) select from offer 3) receive confirmation

Goal

defines

VTA

VTA WS ‘Trip Booking’

Capability Interface (Chor.) 1) get request 2) provide offer 3) receive selection 4) send confirmation Interface (Orch.) 1) flight request 2) hotel request 3) book flight 4) book hotel

Flight WS

Capability Interface (Chor.) 1) get request 2) provide offer 3) receive selection 4) send confirmation Orch. ..

Hotel WS

Capability Interface (Chor.) 1) get request 2) provide offer 3) receive selection 4) send confirmation Orch. ..

provides

Requested Capability book flight & hotel

• both choreography interfaces given (“static”)
• correct & complete consumption of VTA

=> existence of a valid choreography?

• VTA Orchestration & Chor. Interfaces of

aggregated WS given => existence of a valid choreography between VTA and each aggregated WS?

• Choreography Discovery as a central reasoning task in Service Interfaces
• ‘choreographies’ do not have to be described, only existence determination

99

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

internal business logic

• f Web Service

(not of interest in Service Interface Description)

Choreography Discovery

internal business logic

• f Web Service

(not of interest in Service Interface Description)

• a valid choreography exists if:

1) Information Compatibility

• compatible vocabulary
• homogeneous ontologies

2) Communication Compatibility

• start state for interaction
• a termination state can be reached without any additional input

100

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Communication Compatibility Example

S1(Ø) = {Ø} S1(1) = {request(out)} S1(2a) = {offer(in), changeReq(out)} if Ø then request S2(Ø) = {Ø} S2(1) = {request(in), offer(out)} if request then offer if cnd1(offer) then changeReq S1(2b) = {offer(in), order(out)} if cnd2(offer) then order S2(2a) = {changeReq(in),offer(out)} if changeReq then offer S2(2b) = {order(in), conf(out)} if order then conf S1(3) = {offer(in), conf(in)} if conf then Ø Goal Behavior Interface VTA Behavior Interface Start 2(C) 1(C) 3(C) 4(C) Termination existence of a valid Choreography

101

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Orchestration Validation Example

if Ø then (FWS, flightRequest) if request then offer if order then confirmation VTA Web Service Orchestration Start

(VTA, FWS)

Termination

(VTA, FWS)

if flightOffer then (HWS, hotelRequest) if selection then (FWS, flightBookingOrder) if selection, flightBookingConf then (HWS, hotelBookingOrder) Flight WS Behavior Interface if request then offer if order then confirmation Hotel WS Behavior Interface Start

(VTA, HWS)

Termination

(VTA, HWS)

Orchestration is valid if valid choreography exists for interactions between Orchestrator and each aggregated Web Service, done by choreography discovery

102

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Mediation

• Heterogeneity as inherent characteristic of (Semantic) Web:

– heterogeneous terminology – heterogeneous languages / formalisms – heterogeneous communication protocols and business processes

• WSMO identifies Mediators as top level element, i.e. central

aspect of Semantic Web Services

– levels of mediation: data, protocol, processes – WSMO Mediator types

• Approach: declarative, generic mismatch resolution

– classification of possible & resolvable mismatches – mediation definition language & mediation patterns – execution environment for mappings

103

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Data Level (OO) Mediation

• Related Aspects / Techniques:

– Ontology Integration (Mapping, Merging, Alignment) – Data Lifting & Lowering – Transformation between Languages / Formalisms

• Data Level Mismatch Classification

– Conceptualization Mismatches

• same domain concepts, but different conceptualization
• different levels of abstraction
• different ontological structure

=> resolution only incl. human intervention

– Explication Mismatches

• mismatches between:

T (Term used) D (definition of concepts), C (real world concept)

=> automated resolution partially possible

104

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Ontology Mapping Language

• Language Neutral Mapping Language

– mapping definitions on meta-layer (i.e. on generic ontological contructs) – independent of ontology specification langauge – “Grounding” to specific langauges for execution (WSML, OWL, F-Logic)

• Main Features:

– Mapping Document (sources, mappings, mediation service) – direction of mapping (uni- / bidirectional) – mapping between Ontology Constructs:

• classMapping, attributeMapping, relationMapping (between similar constructs)
• classAtrributeMapping, classRelationMapping, classInstanceMapping
• instanceMapping (explicit ontology instance transformation)

– Conditions / logical expressions for data type mismatch handling, restriction of mapping validity, and complex mapping definitions

– Mapping operators:

• =, <, <=, >, >=, and, or, not
• inverse, symmetric, transitive, reflexive
• join, split

105

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Ontology O2

Mapping Language Example

Human

• name

Adult Child Person

• name
• age

1234 memberOf Person

• name =James
• age = 22

classMapping(unidirectional o2:Person o1.Adult attributeValueCondition(o2.Person.age >= 18)) this allows to transform the instance 1234 of ontology O2 into a valid instance of ‘adult’ in ontology O1 Ontology O1

106

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

internal business logic

• f Web Service

(not of interest in Service Interface Description)

internal business logic

• f Web Service

(not of interest in Service Interface Description)

Protocol & Process Level Mediation

• if a choreography does not exist, then find an

appropriate WW Mediator that

– resolves possible mismatches to establish Information Compatibility (OO Mediator usage) – resolves process / protocol level mismatches in to establish Communication Compatibility

WW Mediator

107

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Process Mediation – Addressed Mismatches

108

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Unsolvable Mismatches

Business Partner1 Business Partner2 A PM

?

Business Partner1 Business Partner2 A PM

?

B A B Business Partner1 Business Partner2 PM

?

A Ack

109

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

itinerary[origin, destination, date] time price

• rigin

destination itinerary[origin, destination] date itinerary [route, date, time, price] R E Q U E S T S E R V I C E

Processes Mediator

Process Mediation Example

110

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

time price date R E Q U E S T S E R V I C E

Processes Mediator

Process Mediation Example

itinerary[origin, destination, date]

• rigin

destination itinerary[origin, destination] itinerary [route, date, time, price]

111

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

time price date R E Q U E S T S E R V I C E

Processes Mediator

Process Mediation Example

itinerary[origin, destination, date]

• rigin

destination itinerary[origin, destination] itinerary [route, date, time, price]

112

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

time price date R E Q U E S T S E R V I C E

Processes Mediator

itinerary[origin, destination, date]

• rigin

destination itinerary[origin, destination] itinerary [route, date, time, price]

Process Mediation Example

113

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

time price date R E Q U E S T S E R V I C E

Processes Mediator

itinerary[origin, destination, date]

• rigin

destination itinerary[origin, destination] itinerary [route, date, time, price]

Process Mediation Example

114

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

SWS Tools and Systems

1. OWL-S Integrated Development IDE

– OWL-S tool suite – WS implementation, deployment, discovery, invocation, and verification

2. The Web Service Execution Environment WSMX

– Integrated Semantic Web Service system – WSMO reference implementation – The Web Service Modelling Toolkit (WSMT)

3. Internet Reasoning Service IRS

– Infrastructure for Semantic Web services – Server acts as broker, as well as publisher – Client allows goal-based invocation

Carnegie Mellon University

115

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

OWL-S IDE (CMU)

Integration of WS implementation, deployment, discovery, invocation and verification

116

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Integrated WS Development cycle

• OWL-S IDE aims at automating WS-

Development and invocation cycle

– Based on Eclipse to support WS programmers – (Semi) Automated generation of WSDL and OWL-S descriptions – Consistency checking – Automated publication with UDDI – Integrated Semantic discovery in UDDI – Automated generation of client code

117

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WS Development and invocation

• Web Service Development

– Implement Web service – Produce WSDL and OWL-S WS description – Deploy Web service

• Advertise to available UDDI
• Make service available for invocation
• Web Service invocation on client side

– Find Web service in UDDI – Translate internal data representation to WS data representation – Invoke Web service consistently with specification of OWL-S Process Model

All descriptions should fit together

• therwise interaction with Web service fails

118

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Overview OWL-S IDE

• '(()

'(())*

• .(

• .

. .

• Java Code

Generated OWL-S

• Embed guided generation of WSDL and

schematic OWL-S directly from Java exploiting Java2WSDL and WSDL2OWL-S tools OWL-S VM provides an execution environment for OWL-S Web services Automatic publication, inquiry and capability- based discovery with Semantic UDDI

OWL-S Editor integrated with Eclipse

OWL-S API provide easy processing in Java Integrated editing of all OWL-S modules

119

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

OWL-S IDE Components

• WSDL2OWL-S

map WSDL descriptions into OWL-S descriptions

• OWL-S API

transform OWL-S code in an equivalent set of Java classes for easy processing

• OWL-S Virtual Machine

control interaction with Web service consistently with Process Model and Grounding

• OWL-S/UDDI translator

translate OWL-S Profiles in UDDI statements

• Semantic UDDI

integrate UDDI Registry and OWL reasoning to facilitate discovery

• f Web services

120

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WSMX Motivation

• Provide middleware ‘glue’ for Semantic Web Services

– Allow service providers focus on their business

• Provide a reference implementation for WSMO

– Eat our own cake

• Provide an environment for goal based service

discovery and invocation

– Run-time binding of service requester and provider

• Provide a flexible Service Oriented Architecture

– Add, update, remove components at run-time as needed

• Keep open-source to encourage participation

– Developers are free to use in their own code

• Define formal execution semantics

– Unambiguous model of system behaviour

121

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WSMX Usage - P2P SWS Computing

• complete the functionality for all the boxes

122

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Design Principles

Strong Decoupling & Strong Mediation

autonomous components with mediators for interoperability

Interface vs. Implementation

distinguish interface (= description) from implementation (=program)

Peer to Peer

interaction between equal partners (in terms of control)

WSMO Design Principles == WSMX Design Principles == SOA Design Principles

123

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WSMX Architecture

Messaging Messaging

Application Management Application Management Service Oriented Architectures Service Oriented Architectures

124

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

System Entry Points

Legend

Adapter any Data format Communication Manager (Requester Side) Parser Service Requester WSML Choreography Engine Communication Manager (Provider Side) Service Provider SOAP Data Mediator Communication Manager (Requester Side Parser Service Repository Matchmaker Selector Data Mediator Editor Communication Manager (Requester Side Parser Service Provider

receiveMessage receiveGoal storeEntity

Adapter any Data format Service Requester WSML WSML Service Repository WSMX components External entities Execution Flow Usage

125

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Web Services Modelling Toolkit

126

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Web Services Modelling Toolkit

• Allow description of goals,

services and mediation in WSMO

• Allows WSMO domain ontologies

to be built

• Communicates goals and service

definitions to execution environments

127

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WSMX @ Sourceforge.net

128

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

WSMX Wrap Up

• Conceptual model is WSMO
• End to end functionality for executing SWS
• Has a formal execution semantics
• Real implementation
• Open source code base at SourceForge
• Event-driven component architecture
• Growing functionality - developers welcome

129

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

IRS-III: A framework and platform for building Semantic Web Services

Stefania Galizia and Barry Norton

130

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

The Internet Reasoning Service is an infrastructure for publishing, locating, executing and composing Semantic Web Services

131

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Design Principles

• Ontological separation of User and Web Service

Contexts

• Capability Based Invocation
• Ease of Use
• One Click Publishing
• Agnostic to Service Implementation Platform
• Connected to External Environment
• Open
• Complete Descriptions
• Inspectable
• Interoperable with SWS Frameworks and Platforms

132

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Features of IRS-III (1/2)

• Based on Soap messaging standard
• Provides Java API for client applications
• Provides built-in brokering and service

discovery support

• Provides capability-centred service

invocation

133

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Features of IRS-III (2/2)

• Publishing support for variety of platforms

– Java, Lisp, Web Applications, Java Web Services

• Enables publication of ‘standard code’

– Provides clever wrappers – One-click publishing of web services

• Integrated with standard Web Services world

– Semantic web service to IRS – ‘Ordinary’ web service

134

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

IRS-3 Server

Domain Models Web Service Specifications + Registry of Implementors Goal Specifications + SOAP Binding

IRS Publisher S O A P IRS Client

SOAP

IRS Publisher IRS Publisher IRS Publisher

• IRS-III Framework

135

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

LispWeb Server

IRS-III Architecture

IRS-III Server

WS Publisher Registry OCML WSMO Library OWL(-S) Handler OWL(-S) Browser Invocation Client Publishing Clients

SOAP Handler

S O A P

Publishing Platforms

Web Service Java Code Web Application

SOAP

Browser Handler Publisher Handler Invocation Handler

J a v a A P I

WSMX

136

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Publishing Platform Architecture

IRS-III Publishing Platform HTTP Server SOAP Handler Service Registrar Service Invoker WS Service Registry IRS-III Server

• Web Service 1

Web Service 2 Web Service 3

137

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

IRS-III/WSMO differences

• Underlying language OCML
• Goals have inputs and outputs
• IRS-III broker finds applicable web services via

mediators

– Used mediator within WS capability – Mediator source = goal

• Web services have inputs and outputs

‘inherited’ from goal descriptions

• Web service selected via assumption (in

capability)

138

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

IRS-III Demo

(including Import from WSMX Toolset)

Stefania Galizia and Barry Norton

139

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

SWS Creation & Usage Steps

• Create a goal description

– (e.g. exchange-rate-goal) – Add input and output roles – Include role type and soap binding

• Create a wg-mediator description

– Source = goal – Possibly add a mediation service

• Create a web service description

– Used-mediator of WS capability = wg-mediator above

• Specify Operation <-> Lisp function mapping in

Choreography Grounding

• Publish against web service description
• Invoke web service by ‘achieve goal’

140

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Multiple WS for goal

• Each WS has a mediator for used-

mediator slot of capability

– Some WS may share a mediator

• Define a kappa expression for

assumption slot of WS capability

• Kappa expression format

– (kappa (?goal) <ocml relations>)

• Getting the value of an input role

– (wsmo-role-value ?goal <role-name>)

141

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Defining a Mediation Service

• Define a wg-mediator
• Source = goal
• Mediation-service = goal for mediation

service

• Mediation goal

– Mediation goal input roles are a subset of goal input roles

• Define mediator and WS as normal

142

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Valid Relations

• Classes are unary relations

– e.g. (country ?x)

• Slots are binary relations

– e.g. (is-capital-of ?x ?y)

• Standard relations in base (OCML toplevel)
• ntology

=, ==, <, >, member

143

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

European Currency Assumption

(kappa (?goal) (member (wsmo-role-value ?goal 'has_source_currency) '(euro pound)))

144

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Goal Based Invocation

Invocation

Instantiate Goal Description Exchange-rate-goal Has-source-currency: us-dollars Has-target-currency: pound Web Service Discovery European-exchange-rate-ws Non-european-exchange-rate-ws European-bank-exchange-rate-ws Solve Goal Goal -> WG Mediator -> WS/Capability/Used-mediator Web service selection European-exchange-rate Mediate input values ‘$’ -> us-dollar WS -> Capability -> Assumption expression Mediation Invoke selected web service European-exchange-rate Invocation

145

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Hands-On Session (with IRS III)

Barry Norton and Stefania Galizia

146

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

European Travel Scenario

147

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

European Travel Demo

148

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

IRS-III Hands On Task

• Develop an application for the European Travel scenario based on
• SWS. The application should support a person booking a train ticket

between 2 European cities at a specific time and date

• Create Goal, Web service and Mediator WSMO descriptions in IRS-III

(european-travel-service-descriptions) for available services. Your descriptions should choose a specific service depending on the start and end locations and the type of traveller. Use the assumption slot to do this

• Publish available lisp functions against your descriptions
• Invoke the web services
• Solution to be shown at the end of this session

149

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Tutorial Setup

IRS Server (3000)

Domain Models Web Service WSMO Descriptions + Registry of Implementors Goal WSMO Descriptions + SOAP Binding

Travel Services (3001) IRS Lisp Publisher IRS-III Knowledge Model Browser & Editor WSMX

Mediator WSMO Descriptions

150

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Travel Related Knowledge Models

151

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Key Classes, Relations, Instances

Is-in-country <city> <country> e.g. (is-in-country berlin germany) -> true (student <person>) -> true, for john matt michal (business-person <person>) -> true, for liliana michael

152

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Goals

1- Get train timetable

– Inputs: origin and destination cities (city), date (date-and-time, e.g. (18 4 2004)) – Output: timetable (string)

2- Book train

– Inputs: passenger name (person), origin and destination cities, departure time-date (list-date- and-time, e.g. (20 33 16 15 9 2004)) – Output: booking information (string)

153

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Services

• 1 service available for goal 1

– No constraints

• 6 services available for goal 2

– As a provider write the constraints applicable to the services to satisfy the goal (assumption logical expressions)

• 1 wg-mediator mediation-service

– Used to convert time in list format to time in universal format

154

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Service constraints

• Services 2-5

– Services for (origin and destination) cities in determined countries

• Service 4-5

– Need a mediation service to map goal time-date to service time-date

• Services 6-7

– Services for students or business people in Europe

155

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Available Functions (1/3)

1- get-train-times

paris london (18 4 2004) "Timetable of trains from PARIS to LONDON on 18, 4, 2004 5:18 …23:36"

2- book-english-train-journey

christoph milton-keynes london (20 33 16 15 9 2004) "British Rail: CHRISTOPH is booked on the 66 going from MILTON-KEYNES to LONDON at 16:49, 15, SEPTEMBER 2004. The price is 169 Euros."

3- book-french-train-journey

sinuhe paris lyon (3 4 6 18 8 2004) "SNCF: SINUHE is booked on the 511 going from PARIS to LYON at 6:12, 18, AUGUST 2004. The price is 27 Euros."

156

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Available Functions (2/3)

4- book-german-train-journey

christoph berlin frankfurt 3304251200 "First Class Booking German Rail (Die Bahn): CHRISTOPH is booked on the 323 going from BERLIN to FRANKFURT at 17:11, 15, SEPTEMBER

• 2004. The price is 35 Euros."

5- book-austrian-train-journey

sinuhe vienna innsbruck 3304251200 "Austrian Rail (OBB): SINUHE is booked on the 367 going from VIENNA to INNSBRUCK at 16:47, 15, SEPTEMBER 2004. The price is 36 Euros. "

157

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Available Functions (3/3)

6- book-student-european-train-journey

john london nice (3 4 6 18 8 2004) "European Student Rail Travel: JOHN is booked on the 916 going from LONDON to NICE at 6:44, 18, AUGUST 2004. The price is 94 Euros. "

7- book-business-european-train-journey

liliana paris innsbruck (3 4 6 18 8 2004) "Business Europe: LILIANA is booked on the 461 going from PARIS to INNSBRUCK at 6:12, 18, AUGUST 2004. The price is 325 Euros."

8- mediate-time (lisp function) or JavaMediateTime/mediate (java)

(9 30 17 20 9 2004) 3304686609

158

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Example: Goal

In IRS-III

• r

In WSMT

159

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Example: Mediator

In IRS-III

• r

In WSMT

160

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Example: Service

In IRS-III

• r

In WSMT

161

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Example: Publishing

162

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Tips

• Order matters for input roles

– Input roles in goal must match order of arguments to function

• Need to specify both input roles and output role
• Be careful with soap binding

– sexpr as default – String for one line output – Use xml for multiple line output

• Input roles for web services inherited from goal
• Slot names can not be the same as class names
• Goal <-> web service linking mediator in the capability

used mediators

163

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Closing, Outlook, References, Acknowledgements

164

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Tutorial Wrap-up

• The targets of the presented tutorial were to:

– understand aims & challenges within Semantic Web Services – understand OWL-S and WSMO:

• design principles & paradigms
• ontology elements
• .. an overview of ‘hot topics’ within the Semantic Web

and Semantic Web Services

• .. OWL-S and WSMO Tools and System Presentation
• .. do-it-yourself Hands-On Session

=> you should now be able to correctly assess emerging technologies & products for Semantic Web Services and utilize these for your future work

165

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

OWL-S and WSMO

• North-American and European initiatives with

converging aims

• Offer a SWS platforms to be used by B2C and

B2B applications

• Provide a backbone for advanced integration and

automation of industrial and business processes

• Are the most developed SWS technologies up to

now available to be used in commercial and industrial applications

• Developments towards refining and

interconnecting them

166

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Future work – OWL-S

• OWL-S is close to conclusion, but a few issues

still need to be addressed

– An exception mechanism is still missing – There is a need of an exec instruction for loading and executing Process Models dynamically – A new Grounding for WSDL 2 should be developed

• Additional issues that OWL-S does not address

– Security and Policies are not directly expressed in OWL-S yet – There are no facilities for Contracting and agreement – There are no facilities for Web service management

167

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Future work – OWL-S (2)

• Standardization

– The OWL-S coalition is planning to submit a W3C note to draw attention and create momentum for W3C standardization activities on Semantic Web services – Members of the OWL-S coalition are already active in standardization committee such as UDDI, WSDL 2 and WS Coordination

• The Future of OWL-S

– OWL-S is nearing its completion and it will converge in the results of the SWSI working group or future standardization activities – The OWL-S coalition plans to remain in existence to maintain and further develop the language if needed

168

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Future work - WSMO

• Further develop and consolidate concepts

and implementation aspects of WSMO, WSML and WSMX

– Choreography and orchestration – Business process execution – Web services composition – Process and protocol mediation

• Open to new ideas, contributions and

suggestions

169

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Future Work WSMO (2)

• Standardization …
• WSMO & WSMX – applied in several case

studies within EU funded projects

• WSMO Studio development
• WSMX v2 to be release in November

170

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Future Work IRS

• IRS III further integration with WSMX toolset
• n-going
• IRS-III to be applied in:

– Business Processes Modelling (w/ SAP in DIP, and new EU project SUPER) – Geographical Information Systems (DIP project) – Biomed Modelling (new EU project Living Human Digital Library) – eLearning (new EU project LUISA)

171

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Future Work IRS (2)

• IRS orchestration and choreography to be

extended to three-level model:

– Graphical language: UML Activity Diagrams – Workflow language: Cashew – Executable language: Ontologized Abstract State Machines

• extends OWL-S
• aligns with Workflow

Patterns

• expresses

choreography, as well as

• rchestration

172

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Beyond OWL-S and WSMO

• Although OWL-S and WSMO are the main initiatives on

Semantic Web services, they are not the only activities

• Semantic Web Services Interest Group

– Interest group founded at W3C to discuss issues related to Semantic Web Services (http://www.w3.org/2002/ws/swsig/)

• SWSI: International initiative to push toward a

standardization of SWS (http://www.swsi.org)

• WSDL-S: Semantic Annotation of WSDL interfaces
• Semantic Web services are entering standardization

– W3C working groups currently starting – OASIS working groups currently starting => eventually major influence on next generation Web technology

173

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

References OWL-S

• The main repository of papers on OWL-S is at

http://www.daml.org/services/owl-s/pub-archive.html that contains many papers produced by the coalition as well as from the community at large

• The main source of information on OWL-S is the Web

site http://www.daml.org/services/owl-s

• The rest of this section will report what we believe to be

the most influential papers on OWL-S as well as paper referred in this tutorial

174

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

References OWL-S

• Fundamental

David Martin, Massimo Paolucci, Sheila McIlraith, Mark Burstein, Drew McDermott, Deborah McGuinness, Bijan Parsia, Terry Payne, Marta Sabou, Monika Solanki, Naveen Srinivasan, Katia Sycara, "Bringing Semantics to Web Services: The OWL-S Approach", Proceedings of the First International Workshop on Semantic Web Services and Web Process Composition (SWSWPC 2004), July 6-9, 2004, San Diego, California, USA.

The DAML Services Coalition (alphabetically Anupriya Ankolenkar, Mark Burstein, Jerry R. Hobbs, Ora Lassila, David L. Martin, Drew McDermott, Sheila A. McIlraith, Srini Narayanan, Massimo Paolucci, Terry R. Payne and Katia Sycara), "DAML-S: Web Service Description for the Semantic Web", Proceedings of the First International Semantic Web Conference (ISWC), Sardinia (Italy), June, 2002. DAML Services Coalition (alphabetically A. Ankolekar, M. Burstein, J. Hobbs, O. Lassila, D. Martin, S. McIlraith, S. Narayanan, M. Paolucci, T. Payne, K. Sycara, H. Zeng), "DAML-S: Semantic Markup for Web Services", in Proceedings of the International Semantic Web Working Symposium (SWWS), July 30-August 1, 2001.

175

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

References OWL-S

• Discovery

Lei Li and Ian Horrocks. A software framework for matchmaking based on semantic web technology. In Proc. of the Twelfth International World Wide Web Conference (WWW 2003), 2003

• B. Benatallah, M. Hacid, C. Rey, F. Toumani Towards Semantic Reasoning for

Web Services Discovery,. In Proc. of the International Semantic Web Conference (ISWC 2003), 2003 Daniel J. Mandell and Sheila A. McIlraith. Adapting BPEL4WS for the Semantic Web: The Bottom-Up Approach to Web Service Interoperation. In Proceedings of the Second International Semantic Web Conference (ISWC2003), Massimo Paolucci, Takahiro Kawamura, Terry R. Payne, Katia Sycara; Importing the Semantic Web in UDDI. In Proceedings of Web Services, E-business and Semantic Web Workshop, 2002 Massimo Paolucci, Takahiro Kawamura, Terry R. Payne, Katia Sycara; "Semantic Matching of Web Services Capabilities." In Proceedings of the 1st International Semantic Web Conference (ISWC2002), 2002

176

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

References OWL-S

• Composition and Invocation

Evren Sirin, Bijan Parsia, Dan Wu, James Hendler, and Dana Nau. HTN planning for web service composition using SHOP2. In Journal of Web Semantics, To appear, 2004 Katia Sycara, Massimo Paolucci, Anupriya Ankolekar and Naveen Srinivasan, "Automated Discovery, Interaction and Composition of Semantic Web services," Journal of Web Semantics, Volume 1, Issue 1, September 2003, pp. 27-46 Massimo Paolucci, Anupriya Ankolekar, Naveen Srinivasan and Katia Sycara, "The DAML-S Virtual Machine," In Proceedings of the Second International Semantic Web Conference (ISWC), 2003, Srini Narayanan and Sheila McIlraith ``Analysis and Simulation of Web Services" Computer Networks, 42 (2003), 675-693, Elsevier Science, 2003

177

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

References OWL-S

• Formal Models and Verification

Anupriya Ankolekar, Massimo Paolucci, and Katia Sycara Spinning the OWL-S Process Model -- Toward the Verification of the OWL-S Process Models In Proceedings of Workshop on Semantic Web Services: Preparing to Meet the World of Business Applications (ISWC 2004) Narayanan, S. and McIlraith, S. ``Simulation, Verification and Automated Composition of Web Services''. IN the Proceedings of the Eleventh International World Wide Web Conference (WWW-11), May, 2002 Anupriya Ankolekar, Frank Huch and Katia Sycara. "Concurrent Semantics for the Web Services Specification Language DAML-S." In Proceedings of the Fifth International Conference on Coordination Models and Languages, York, UK, April 8- 11, 2002. Anupriya Ankolekar, Frank Huch, Katia Sycara. "Concurrent Execution Semantics for DAML-S with Subtypes." In The First International Semantic Web Conference (ISWC), 2002.

178

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

References OWL-S

• Policies and Security

Ronald Ashri, Grit Denker, Darren Marvin, Mike Surridge,Terry Payne, Semantic Web Service Interaction Protocols: An Ontological Approach, 3rd International Semantic Web Conference (ISWC2004), Hiroshima, Japan Lalana Kagal, Grit Denker, Tim Finin, Massimo Paolucci, Naveen Srinivasan and Katia Sycara, "An Approach to Confidentiality and Integrity for OWL-S", forthcoming in Proceedings of AAAI 2004 Spring Symposium. Grit Denker, Lalana Kagal, Tim Finin, Massimo Paolucci, Naveen Srinivasan and Katia Sycara, "Security For DAML Web Services: Annotation and Matchmaking" In Proceedings of the Second International Semantic Web Conference (ISWC 2003), Sandial Island, Fl, USA, October 2003, pp 335-350.

179

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

References OWL-S

• Applications

Schlenoff, C., Barbera, A., Washington, R., “Experiences in Developing an Intelligent Ground Vehicle (IGV) Ontology in Protégé” In Proceedings of the 7th International Protege Conference, Bethesda, MD, July 6 - 8, 2004. Aabhas V Paliwal, Nabil Adam, Christof Bornhövd, and Joachim Schaper Semantic Discovery and Composition of Web Services for RFID Applications in Border Control In Proceedings of Workshop on Semantic

Web Services: Preparing to Meet the World of Business Applications (ISWC 2004) Mithun Sheshagiri, Norman Sadeh and Fabien Gandon, Using Semantic Web Services for Context-Aware Mobile Applications, Proceedings

• f MobiSys2004 Workshop on Context Awareness, Boston, June 2004

Zhexuan Song, Yannis Labrou and Ryusuke Masuoka, "Dynamic Service Discovery and Management in Task Computing," pp. 310 - 318, MobiQuitous 2004, August 22-26, 2004, Boston, USA

180

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

References WSMO

• The central location where WSMO work and papers can

be found is WSMO Working Group: http://www.wsmo.org

• WSMO languages – WSML Working Group:

http://www.wsml.org

• WSMO implementation

– WSMX working group : http://www.wsmx.org – WSMX open source can be found at: https://sourceforge.net/projects/wsmx/

181

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

References WSMO

• [WSMO Specification]: Roman, D.; Lausen, H.; Keller, U. (eds.): Web Service

Modeling Ontology, WSMO Working Draft D2, final version 1.2, 13 April 2005.

• [WSMO Primer]: Feier, C. (ed.): WSMO Primer, WSMO Working Draft D3.1, 18

February 2005.

• [WSMO Choreography and Orchestration] Roman, D.; Scicluna, J., Feier, C.

(eds.): Ontology-based Choreography and Orchestration of WSMO Services, WSMO Working Draft D14, 01 March 2005.

• [WSMO Use Case] Stollberg, M.; Lausen, H.; Polleres, A.; Lara, R. (ed.): WSMO

Use Case Modeling and Testing, WSMO Working Drafts D3.2; D3.3.; D3.4; D3.5, 05 November 2004.

• [WSML] de Bruijn, J. (Ed.): The WSML Specification, WSML Working Draft D16,

03 February 2005.

182

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

References WSMO

• [Arroyo et al. 2004] Arroyo, S., Lara, R., Gomez, J. M., Berka, D., Ding, Y.

and Fensel, D: "Semantic Aspects of Web Services" in Practical Handbook of Internet Computing. Munindar P. Singh, editor. Chapman Hall and CRC Press, Baton Rouge. 2004.

• [Berners-Lee et al. 2001] Tim Berners-Lee, James Hendler, and Ora

Lassila, “The Semantic Web”. Scientific American, 284(5):34-43, 2001.

• [Chen et al., 1993] Chen, W., Kifer, M., and Warren, D. S. (1993). HILOG:

A foundation for higher-order logic programming. Journal of Logic Programming, 15(3):187-230.

• Domingue, J. Cabral, L., Hakimpour, F., Sell D., and Motta, E., (2004)

IRS-III: A Platform and Infrastructure for Creating WSMO-based Semantic Web Services WSMO Implementation Workshop (WIW), Frankfurt, Germany, September,2004

• [Fensel, 2001] Dieter Fensel, “Ontologies: Silver Bullet for Knowledge

Management and Electronic Commerce”, Springer-Verlag, Berlin, 2001.

183

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

References WSMO

• [Gruber, 1993] Thomas R. Gruber, “A Translation Approach to Portable

Ontology Specifications”, Knowledge Acquisition, 5:199-220, 1993.

• [Grosof et al., 2003] Grosof, B. N., Horrocks, I., Volz, R., and Decker,
• S. (2003). Description logic programs: Combining logic programs with

description logic. In Proc. Intl. Conf. on the World Wide Web (WWW- 2003), Budapest, Hungary.

• [Kifer et al., 1995] Kifer, M., Lausen, G., and Wu, J. (1995). Logical

foundations of object-oriented and frame-based languages. JACM, 42(4):741-843.

• [Pan and Horrocks, 2004] Pan, J. Z. and Horrocks, I. (2004). OWL-E:

Extending OWL with expressive datatype expressions. IMG Technical Report IMG/2004/KR-SW-01/v1.0, Victoria University of Manchester. Available from http://dl-web.man.ac.uk/Doc/IMGTR-OWL-E.pdf.

• [Stencil Group] -

www.stencilgroup.com/ideas_scope_200106wsdefined.html

184

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

References Discovery

• B. Benatallah, M. Hacid, C. Rey, F. Toumani Towards Semantic Reasoning for

Web Services Discovery,. In Proc. of the International Semantic Web Conference (ISWC 2003), 2003 Herzog, R.; Lausen, H.; Roman, D.; Zugmann, P.: WSMO Registry. WSMO Working Draft D10 v0.1, 26 April 2004. Keller, U.; Lara, R.; Polleres, A. (Eds): WSMO Web Service Discovery. WSML Working Draft D5.1, 12 Nov 2004. Keller, U.; Lara, R.; Lausen, H.; Polleres, A.; Fensel, D.: Automatic Location of

• Services. In Proc. of the 2nd European Semantic Web Symposium (ESWS2005),

Heraklion, Crete, 2005.

• M. Kifer, R. Lara, A. Polleres, C. Zhao, U. Keller, H. Lausen and D. Fensel: A Logical

Framework for Web Service Discovery. Proc. 1st. Intl. Workshop SWS'2004 at ISWC 2004,Hiroshima, Japan, November 8, 2004, CEUR Workshop Proceedings, ISSN 1613-0073 Lara, R., Lausen, H.; Toma, I.: (Eds): WSMX Discovery. WSMX Working Draft D10 v0.2, 07 March 2005. Lei Li and Ian Horrocks. A software framework for matchmaking based on semantic web technology. In Proc. of the Twelfth International World Wide Web Conference (WWW 2003), 2003.

185

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

References Discovery

Lei Li and Ian Horrocks. A software framework for matchmaking based on semantic web technology. In Proc. of the Twelfth International World Wide Web Conference (WWW 2003), 2003 Daniel J. Mandell and Sheila A. McIlraith. Adapting BPEL4WS for the Semantic Web: The Bottom-Up Approach to Web Service Interoperation. In Proceedings of the Second International Semantic Web Conference (ISWC2003), Massimo Paolucci, Takahiro Kawamura, Terry R. Payne, Katia Sycara; Importing the Semantic Web in UDDI. In Proceedings of Web Services, E-business and Semantic Web Workshop, 2002 Massimo Paolucci, Takahiro Kawamura, Terry R. Payne, Katia Sycara; "Semantic Matching of Web Services Capabilities." In Proceedings of the 1st International Semantic Web Conference (ISWC2002), 2002 Preist, C.: A Conceptual Architecture for Semantic Web Services. In Proceedings

• f the 3rd International Semantic Web Conference (ISWC 2004), 2004, pp. 395 -

409. Stollberg, M.; Keller, U.; Fensel. D.: Partner and Service Discovery for Collaboration

• n the Semantic Web. Proc. 3rd Intl. Conference on Web Services (ICWS 2005),

Orlando, Florida, July 2005.

186

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

References IRS III

• J. Domingue, L. Cabral, F. Hakimpour, D. Sell and E. Motta: IRS-III: A Platform and

Infrastructure for Creating WSMO-based Semantic Web Services. Proceedings of the Workshop on WSMO Implementations (WIW 2004) Frankfurt, Germany, September 29-30, 2004, CEUR Workshop Proceedings, ISSN 1613-0073, online http://CEUR- WS.org/Vol-113/paper3.pdf.

• J. Domingue and S. Galizia: Towards a Choreography for IRS-III.

Proceedings of the Workshop on WSMO Implementations (WIW 2004) Frankfurt, Germany, September 29-30, 2004, CEUR Workshop Proceedings, ISSN 1613-0073,

• nline http://CEUR-WS.org/Vol-113/paper7.pdf.

Cabral, L., Domingue, J., Motta, E., Payne, T. and Hakimpour, F. (2004). Approaches to Semantic Web Services: An Overview and Comparisons. In proceedings of the First European Semantic Web Symposium (ESWS2004); 10-12 May 2004, Heraklion, Crete, Greece. Motta, E., Domingue, J., Cabral, L. and Gaspari, M. (2003) IRS-II: A Framework and Infrastructure for Semantic Web Services. In proceedings of the 2nd International Semantic Web Conference (ISWC2003) 20-23 October 2003, Sundial Resort, Sanibel Island, Florida, USA. These papers and software downloads can be found at: http://kmi.open.ac.uk/projects/irs

187

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Acknowledgements

We would like to acknowledge the contribution of the past and present members of the OWL-S coalition for their hard work in the development of the language. Furthermore, we would like to thank the community at large for contributing to tools and ideas. Furthermore, we would like to thank to all the members of the WSMO, WSML, and WSMX working groups for their advice and input into this tutorial. Special thanks to Sheila McIlraith, Craig Schlenoff, Daniel Elenius and Naveen Srinivasan for providing slides and suggestions on this tutorial. Slide design by Roberta Hart-Hilber, DERI Austria

188

Semantic Web Services, HICSS 39, Kauai (Hawaii), 04 January 2006

Acknowledgements

The development of OWL-S has been funded almost exclusively by the DAML DARPA program. The WSMO working groups are funded by the European Commission under the projects DIP, Knowledge Web, SEKT, SWWS, and ASG; by Science Foundation Ireland under the DERI-Lion project; and by the Vienna city government under the FIT-IT Programme in the projects RW2 and TCP. IRS development is funded by the European Commission under the DIP project, and formerly IBROW, and by the UK EPSRC under the AKT project, and formerly MIAKT.
