1 LOGO LAB 4&5 PCM Modulator & Demodulator Block diagram of PCM modulation LPF is used to remove the noise in the audio signal 3 PCM modulation is a kind of source coding. is commonly used in audio and telephone transmission Source

slide-1
SLIDE 1

1

slide-2
SLIDE 2

LOGO

LAB 4&5 PCM Modulator & Demodulator

slide-3
SLIDE 3

3

Block diagram of PCM modulation

LPF is used to remove the noise in the audio signal

slide-4
SLIDE 4

4

PCM modulation is a kind of source coding. is commonly used in audio and telephone transmission Source coding means the conversion from analog signal to digital signal.

slide-5
SLIDE 5

PCM in Wired Telephony

Voice circuit bandwidth is 3400 Hz. Sampling rate is 8 KHz (Ts=125 s). Each sample is quantized to one of 256 levels. Each quantized sample is coded into a 8-bit word. The 8-bit words are transmitted serially (one bit at a time) over a digital transmission channel. The bit rate is:

8 *8,000 64,000 sec sec bit sample bit sample  

slide-6
SLIDE 6

6

The bits are regenerated at digital repeaters. The received words are decoded back to quantized samples, and filtered to reconstruct the analog signal.

slide-7
SLIDE 7

7

slide-8
SLIDE 8

Parallel transmission

slide-9
SLIDE 9

Serial transmission

slide-10
SLIDE 10

Example of PCM: Voice & Audio

Telephone voice  F = 4 kHz → 8000 samples/sec  8 bits/sample  Rs=8 x 8000 = 64 kbps CD Audio  F= 22 kHz → 44000 samples/sec  16 bits/sample  Rs=16 x 44000= 704 kbps per audio channel

 High quality than telephone communication

slide-11
SLIDE 11

11

Quantization

Uniform Non- Uniform

slide-12
SLIDE 12

12

 A system (with uniform quantization) would be wasteful for speech signals

  • Many of the quantizing steps would rarely be used.
  • The SNR is worse for low level signals than for high

level signals.

Uniform Quantization

slide-13
SLIDE 13

13

slide-14
SLIDE 14

Nonuniform quantization

Example: Voice analog signal Peak value(1V) is less appears while weak value(0.1V, 20dB down) around 0 is more appears (nonuniform amplitude distribution) Thus nonuniform quantization is used Implementation of nonuniform quantization

Compression (Nonlinear) filter

PCM with Uniform Quantization

Analog Input PCM

  • utput
slide-15
SLIDE 15

15

?

slide-16
SLIDE 16

16

Compression(Nonlinear) filter

slide-17
SLIDE 17

17

slide-18
SLIDE 18

18

slide-19
SLIDE 19

19

  • can provide fine quantization for the weak signals.
  • For telephone users with loud voices & quiet voices,

quantisation noise will have same power(same q).

  • If SQNR made acceptable for quiet voices it may be

better than necessary for loud voices.

  • Can be used to make the SNR a constant for all signals

within the input range.

Nonuniform quantization

slide-20
SLIDE 20

Quantization

Uniform Nonuniform

The more steps (levels) the less quantization noise. Nonuniform quantization (e.g. -law) allows a larger dynamic range (important for speech).

slide-21
SLIDE 21

21

Nonuniform quantization

slide-22
SLIDE 22

22

slide-23
SLIDE 23

23

In uniform we assign as many reconstruction levels for larger amplitudes as for smaller amplitudes, which are more probable to occur.

slide-24
SLIDE 24

24

the histogram of the same speech signal after mu-law companding.

slide-25
SLIDE 25

25

Non-uniform Uniform

slide-26
SLIDE 26

26

Com- pressor ADC with uniform quantiser Expander Transmit

  • r store

Uniform DAC Compressor: Compression filter in transmitter Expander: Inverse Compression filter in receiver

Companding= compression + expansion

Companding

slide-27
SLIDE 27

A-law µ-law

Compression characteristic

slide-28
SLIDE 28

28

DCS5-1 on ETEK DCS-6000-03

slide-29
SLIDE 29

29

Circuit diagram of PCM modulation

slide-30
SLIDE 30

30

  • CW6694 is used as PCM modulator and PCM demodulator.
  • The sampler, quantizer and encoder are built in the IC
  • FS0(pin5) and FS1(pin7) are the data format selection of PCM encoder.

pin5 pin7

slide-31
SLIDE 31

31

slide-32
SLIDE 32

32

Buffer U1

is used to transfer a voltage from a first circuit, having a high output impedance level, to a second circuit with a low input impedance level.

slide-33
SLIDE 33

33

slide-34
SLIDE 34

34

  • Lab#5 PCM Modulator
slide-35
SLIDE 35

35

  • PAM, PWM, and PPM modulations belong to analog modulation

and the PCM modulation belongs to the digital modulation

  • PAM, PWM, and PPM modulations are similar to AM, FM, and PM

modulations, respectively.

Pulse wave modulation can be classified as :

  • pulse amplitude modulation (PAM)
  • pulse width modulation (PWM)
  • pulse position modulation (PPM)
  • pulse code modulation (PCM).
slide-36
SLIDE 36

36

slide-37
SLIDE 37

37

Block diagram of PCM demodulation

slide-38
SLIDE 38

38

slide-39
SLIDE 39

LOGO

39

slide-40
SLIDE 40

40

slide-41
SLIDE 41

41

1 2

c

f RC  

slide-42
SLIDE 42

42

1600 Hz

c

f 

slide-43
SLIDE 43

43

Frequency Response of a 1st-order Low Pass Filter

1st-order Low Pass Filter

slide-44
SLIDE 44

44 1 1

1 1 1600 2 2 (100)(1 )

c

f Hz R C      

2 1

10 1 1 2 10

  • i

V R k Gain V R k      

1st order LPF

slide-45
SLIDE 45

45

slide-46
SLIDE 46

46

Frequency 1.0Hz 100Hz 10KHz 1.0MHz V(U1:OUT) V(U1:-) 0V 1.0V 2.0V

slide-47
SLIDE 47

47

Second-order Low Pass Filter

slide-48
SLIDE 48

48

Frequency Response of a 2nd-order Low Pass Filter

slide-49
SLIDE 49

49 1 1 2 2 1 2 1 2

1 2 1 (if & ) 2

c c

f R C R C R R C C f RC       

4 3

1

  • i

V R Gain V R   

slide-50
SLIDE 50

50

The High Pass Filter Circuit

slide-51
SLIDE 51

51

Frequency Response of a 1st Order High Pass Filter.

slide-52
SLIDE 52

52

Second-order High Pass Filter

slide-53
SLIDE 53

53

slide-54
SLIDE 54

54

Inverting Integrator Configuration

slide-55
SLIDE 55

55

The RC Differentiator Circuit

slide-56
SLIDE 56

56

Inverting Differentiator Configuration
