1 Citizens Reservoir Quarry Conversion Ryan Taylor, PE Manager Citizens Energy Group February 12, 2019 2 Overview Project Purpose Site Mining History Site Description Project Approach Intake Structure Pumping

slide-1
SLIDE 1

1

slide-2
SLIDE 2

Citizens Reservoir – Quarry Conversion

2

Ryan Taylor, PE – Manager Citizens Energy Group February 12, 2019

slide-3
SLIDE 3

Overview

3

  • Project Purpose
  • Site Mining History
  • Site Description
  • Project Approach
  • Intake Structure
  • Pumping Structure
  • Outlet Structure
slide-4
SLIDE 4

Project Purpose

4

  • Customers

– 325,000 retail – 8 wholesale

  • 10 treatment plants ‐ 257 MGD
  • Average demand ‐ 125 MGD
  • Max demand ‐ 232 MGD (2012)
  • 3 main supply reservoirs
  • 4,400~ miles of main
slide-5
SLIDE 5

Project Purpose

5

  • Raw Water Supply &

Treatment

  • Excess Raw Water

Capacity in Fall Creek

  • Additional Treatment

Capacity at White River Treatment Plant

Geist Reservoir Canal

White River Treatment Plant & Aqueduct Intake Citizens Reservoir Fall Creek Treatment Plant

slide-6
SLIDE 6

6

1941

One Room School House

slide-7
SLIDE 7

7

1956

30 AC

slide-8
SLIDE 8

8

1962

55 AC

slide-9
SLIDE 9

9

1972

190 AC

slide-10
SLIDE 10

10

1987

360 AC

slide-11
SLIDE 11

11

2000

220 AC 190 AC

slide-12
SLIDE 12

12

2018

slide-13
SLIDE 13

13

slide-14
SLIDE 14

Site Description

14

  • 90 Acre Site
  • 8 Acre Site at Elev 790
  • 230 Feet Deep
  • +3 Bgal Capacity
  • Geist Reservoir 6.7 Bgal
  • Residential Development
slide-15
SLIDE 15
slide-16
SLIDE 16
slide-17
SLIDE 17

Design Approach

17

  • Feasibility Study
  • Stakeholder Coordination
  • Basis of Design
  • Water Quality Analysis
  • 30% Design
  • Frequency of Drawdown
slide-18
SLIDE 18

18

Probability of Quarry Drawdown Quarry Drawdown (ft) Corresponding Water Surface Elevation in Quarry (ft) 25 year occurrence (4%) 200 585 20 year occurrence (5%) 145 640 15 year occurrence (6.67%) 125 660 10 year occurrence (10%) 85 700 5 year occurrence (20%) 44 741 4 year occurrence (25%) 30 755 3 year occurrence (33%) 19 766 2 year occurrence (50%) 2 783

slide-19
SLIDE 19

19

slide-20
SLIDE 20

Citizens Reservoir ‐ Intake

20

slide-21
SLIDE 21

21

slide-22
SLIDE 22

22

slide-23
SLIDE 23

Pumping Structure

23

slide-24
SLIDE 24

24

slide-25
SLIDE 25

25

slide-26
SLIDE 26

26

slide-27
SLIDE 27

27

slide-28
SLIDE 28

Outlet Structure

28

slide-29
SLIDE 29

29

slide-30
SLIDE 30

Questions

30

  • Ryan Taylor, PE – Manager Citizens Energy Group
