Three Kings Quarry Excellence in Environmental Management Presented by Gordon Laing 1 Quarry Manager (MIQ) Winstone Aggregates Environmental Management Background: Winstone Aggregates has a formal Environmental Policy. Proactive

slide-1
SLIDE 1

1

Three Kings Quarry

Excellence in Environmental Management

Presented by

Gordon Laing

Quarry Manager (MIQ)

slide-2
SLIDE 2

2

Winstone Aggregates Environmental Management

Background:

 Winstone Aggregates has a formal Environmental Policy.  Proactive approach to implementing a high standard of

performance at all quarries.

 Implementation of environment policy led through

Environmental Management System based on ISO 14001.

 Records & procedure manuals at all sites.  Internal site inspections, external audits and monthly

reporting.

slide-3
SLIDE 3

3

Winstone Aggregates

Contribution to the Aggregate and Quarrying Industry

 Winstone Aggregates is an industry leader:

– Promoting the need for quarries and aggregates in the community

 Site environmental management & public

relations efforts:

– Lead by example

 Environmental Management:

– Employment of best practice

 Compliance levels:

– Often exceeded

slide-4
SLIDE 4

4

Three Kings Quarry

slide-5
SLIDE 5

5

Location

Approximately 6km from Central Auckland

2 1 Scale (kms)

Three Kings Quarry (Approximate boundary

  • nly)

Auckland

slide-6
SLIDE 6

6

Surrounding the site

 Mainly residential.  Some business

development.

 Auckland City

Council Reserve to the north-west.

slide-7
SLIDE 7

7

 Environmental management decisions

  • ften based on discussion with local

residents.

 Most residents reasonable, happy to work

together for mutually agreeable results.

Operational Issues

slide-8
SLIDE 8

8

 Another group refuses to accept the existence of any

quarry in Three Kings’ urban setting.

 Campaigns to close the quarry down.  Group creates obstacles to effective environmental

management.

 Disseminates misinformation and causes delays.

Operational Issues

slide-9
SLIDE 9

9

slide-10
SLIDE 10

10

New neighbours

satisfactory outcome all parties

slide-11
SLIDE 11

11

Originality and Innovation in Environmental Management Initiatives

slide-12
SLIDE 12

12

 Community Liaison  Public Relations  Other Initiatives

slide-13
SLIDE 13

13

Community Liaison

 Initiatives began in 1995.  Has evolved into the Three Kings Quarry Site

Liaison Group.

 Quarry Management Plan developed in 2001 in

conjunction with the Site Liaison Group.

 Three Kings Quarry continues to operate in

accordance with this Quarry Management Plan.

slide-14
SLIDE 14

14

 Work with public

relations advisers to develop communications strategy.

 Public open days and

special information

  • pen days have been

held.

Consultation at an open day

Public Relations

slide-15
SLIDE 15

15

Consultation itself is mandatory

Voluntary processes of consultation

– e.g. both mediation and public meetings evolve by agreement into mandatory inclusions in the District Plan or consent conditions.

Environmental management initiatives

– Evolved from consultation and Site Liaison Group meetings. – Became voluntary actions – Included later in District Plan or consent conditions to become mandatory.

Most management initiatives outlined in “Originality and Innovation” section discussed

– Were voluntary – Now mandatory

Environmental Management is both Voluntary and Mandatory

slide-16
SLIDE 16

16

Site visit invitations to:

 Commissioners  Community board representatives  Journalists  Special interest group

– e.g.Resource Management & Law Association

Open & transparent

slide-17
SLIDE 17

17

 Applied to the public relations process:

– has kept it functional.

 Some sectors appreciate the effort applied:

– eg. Auckland City Council confirmed in writing that all previous environmental effects had been mitigated or removed.

Persistence and patience

slide-18
SLIDE 18

18

 Current site information in a folder at the local public

library.

 Current site info on the Winstone Aggregates’ website:

www.winstoneaggregates.co.nz

 Resources and funding for local primary school projects.  Provision of an educational CD (“The Earth Beneath Us”) for

primary schools.

 Provision of information for primary, secondary and tertiary

students.

Other initiatives

slide-19
SLIDE 19

19

Environmental Management Practices deployed at Three Kings Quarry

slide-20
SLIDE 20

20

 Compliance for many years.  Rockbreakers no longer in use.  Quarry gate opened before start of business for

trucks to wait inside the site.

 Ongoing upgrade and maintenance of mobile site

equipment.

 Right to refuse loading of poorly maintained

trucks (e.g. no muffler).

Noise

slide-21
SLIDE 21

21

Vibration / Airblast

 No Blasting at Three Kings (currently).  Procedure in place in Quarry Management

Plan should blasting be required.

slide-22
SLIDE 22

22

Dust monitoring

 Total Suspended

Particulate samplers:

– Monitor the site – Three locations

 Wind and weather

monitoring:

– Record rain, wind speed and direction

 Backup:

– Minivol monitoring is carried out during summer months

 Reporting:

– Update Site Liaison Group at liaison meetings with quarterly results

slide-23
SLIDE 23

23

Dust suppression

Water sprinkler system:

set up around perimeter of

working site

wets faces and working area

Water cart:

 dampens areas as a back up

to the sprinkler system

slide-24
SLIDE 24

24

Dust supression

Haul roads and stockpiles are wetted to minimise dust.

slide-25
SLIDE 25

25

Emissions

 Time lapse video monitoring  Maintenance procedure for all mobile plant, reduce exhaust

emissions

 Exhaust pipes of site and Winstone transport trucks and

machines not directed downwards

slide-26
SLIDE 26

26

Traffic Management

 Hours of operation

– 7am to 8pm daily – load out 7am to 5pm only.

 Covering of loads

– Notice located next to weighbridge speaker phone

 Clean trailer drawbars

– Drivers asked to do this before leaving site

 Routine checks at gateway

– Any aggregate spills are cleaned up immediately – No questions asked

slide-27
SLIDE 27

27

Caring for the Community

 Installation of a wheel wash

slide-28
SLIDE 28

28

Purpose of dewatering

– Maximise extraction of scoria – Scarce & valuable resource. – Extending life of Three Kings operation preferable to removal of one of few remaining scoria cones.

Ground Water

slide-29
SLIDE 29

29

Ground Water

Comprehensive Monitoring and Contingency Plan:

– to track behaviour of groundwater

Depth measurement:

– Wide network of groundwater monitoring bores

Surface level:

– Network of ground surface monitoring points – Precise level survey network

Regular reporting of data:

– Required under Monitoring and Contigency plan – To Council and – To Site Liaison Group

Drill rig in action preparing groundwater monitoring bores

slide-30
SLIDE 30

30

Partnerships

 Implementation of residential property indemnity scheme  Partnership sought during consenting process to provide

water for Auckland Municipal supply through dewatering

slide-31
SLIDE 31

31

Landscape / Visual

Residential properties looking to the east from Big King Reserve

slide-32
SLIDE 32

32

Landscape / Visual

 Quarry

workings now below street level

slide-33
SLIDE 33

33

Landscape / Visual

View from elevated residential properties to the north-east .

slide-34
SLIDE 34

34

Landscape / Visual

Construction of 2-3m high earth bund

  • n Mt Eden Road frontage
slide-35
SLIDE 35

35

Landscape / Visual

Upgrade of perimeter safety fence

– provides more aesthetic barrier to the Big King reserve.

Boundary Fencing between quarry and reserve

slide-36
SLIDE 36

36

Landscape / Visual

 Demolition and removal of unnecessary unsightly

structures.

 Removal and replacement of workshop to a less

  • btrusive location.

 Clean up and remove surplus machinery and

scrap.

 Planting native vegetation along the northern

boundary.

slide-37
SLIDE 37

37

Exposed faces worked

  • ut in the upper pit are

revegetated Exposed faces not worked in the lower pit are hydroseeded

Landscape / Visual

slide-38
SLIDE 38

38

Landscape / Visual

 Preparation and implementation of site

revegetation management plan

 Hydroseeding and watering of quarry faces not

currently being worked

 Hydroseeding and revegetation of completed

faces.

slide-39
SLIDE 39

39

Three Kings site

1989

slide-40
SLIDE 40

40

Three Kings site

1997

slide-41
SLIDE 41

41

2003

Three Kings site

slide-42
SLIDE 42

42

Three Kings site

2005

slide-43
SLIDE 43

43

Quarry End Use

slide-44
SLIDE 44

44

 Options have been explored with Site Liaison Group and

incorporated into the Quarry Management Plan.

 Currently preferred option:

– Cleanfill to road level. – obtain planning approval for mixed residential / commercial / light-industrial development.

 Conceptual work started and discussed with Site Liaison

Group.

End Uses ?

slide-45
SLIDE 45

45

Majority of the community not aware of quarry’s presence.

Standard of performance at Three Kings is consistent with what many communities now expect of our industry.

Overall Environmental Impact

slide-46
SLIDE 46

46

2 1 Scale (kms)

Conclusion

Three Kings

Quarry

– An excellent example of “sound environmental management for the aggregate and quarrying industry.”

slide-47
SLIDE 47

47

Acknowledgements

Alan Happy

– Resource and Environmental Manager, (FIQ)

Michael Harris

– Engineering Geologist, (AMIQ)

Arsini Hanna

– Northern Region Environmental Co-ordinator (AMIQ)

Christina Renhart

– Project Leader, Projects

slide-48
SLIDE 48

48

Thank you
