SLIDE 1
1
2
1 Biology Enzymes 20150828 www.njctl.org 2 Vocabulary Click on - - PowerPoint PPT Presentation
1 Biology Enzymes 20150828 www.njctl.org 2 Vocabulary Click on - - PowerPoint PPT Presentation
1 Biology Enzymes 20150828 www.njctl.org 2 Vocabulary Click on each word below to go to the definition. activation energy enzyme active site feedback inhibition allosteric regulation induced fit catalyst noncompetitive inhibitor
SLIDE 2
SLIDE 3
3
Vocabulary
Click on each word below to go to the definition. activation energy noncompetitive inhibitor active site allosteric regulation catalyst coenzyme cofactor competitive inhibitor enzyme feedback inhibition induced fit
- ptimal pH
- ptimal temperature
substrate
SLIDE 4
4
Enzymes Unit Topics
· Enzymes, Catalytic Cycle · Temperature, pH, Inhibition
Click on the topic to go to that section
· Allosteric Regulation, Feedback Inhibition
SLIDE 5
5
Enzymes, Catalytic Cycle
Return to Table of Contents
SLIDE 6
6
A catalyst is a substance which speeds up chemical reactions without being changed by the reaction. When a catalyst is present, less energy is needed to start a chemical reaction. When a catalyst is present, the speed of a chemical reaction is faster. The catalyst remains unchanged at the end of the reaction.
Catalysts
SLIDE 7
7
Enzymes are catalysts in biological systems. In early cells, enzymes were made of ____________. In modern cells, enzymes are a type of ___________.
Enzymes
SLIDE 8
8
Common Enzymes
Lactase is an enzyme that helps us to digest dairy products. People with lactose intolerance have trouble digesting dairy because they lack this enzyme, but they are able to take a lactaid pill that contains the enzyme lactase.
SLIDE 9
9
Common Enzymes
Amylase is an enzyme found in human saliva. It begins the chemical process of digestion. Typically, you can identify an enzyme by its ase ending.
SLIDE 10
10
Enzyme Substrate Complex
Enzymes help chemical reactions occur by providing a space called an active site for the substrates (reactants), to bind.
Substrate entering active site of enzyme Enzyme/substrate complex Enzyme/products complex Products leaving active site of enzyme
Active site
substrate
Click here to see a video on Enzymes
SLIDE 11
11
Induced Fit
Just as a key can only open a specific lock, each enzyme has its
- wn unique shape, so each enzyme is specific to certain substrates.
As the substrates enter the active site, the enzyme's shape changes just a little in order to create a better fit, called an induced fit.
SLIDE 12
12
Catalytic Cycle of an Enzyme
An enzyme is capable of being used again and again to allow more of the same reactions to occur.
SLIDE 13
13
1 Which of the following acts as a catalyst in the body?
A
Carbohydrates B Nucleic Acids
C
Lipids
D
Enzymes E Water
Answer
D
SLIDE 14
14
2 Another name for protein reactants is _____.
A
products
B substrates C active sites D enzymes
Answer
B
SLIDE 15
15
3 Enzymes bind only to certain substrates.
True False
Answer
TRUE
SLIDE 16
16
4 An enzyme can only be used for one reaction and then it will not work again.
True False
Answer
FALSE
SLIDE 17
17
Activation Energy
Enzymes work by decreasing the minimum amount of energy required for reaction. This is called the activation energy, Ea. Just as a ball cannot get over a hill if it does not roll up the hill with enough energy, a reaction cannot occur unless the molecules possess sufficient energy to get over the activation energy barrier.
SLIDE 18
18
Potential Energy Diagrams
This activation energy is usually needed to break bonds in the substrate. initial energy final energy
SLIDE 19
19
Catalysts
Enzymes increase the rate of a reaction by decreasing the activation energy of the reaction. This graph shows the decomposition of a sugar both with and without a catalyst. Notice that the initial energy of reactants and the final energy of the products are unchanged by the catalyst.
SLIDE 20
20
5 Activation energy is _____.
A
the heat released in a reaction B the energy given off when reactants collide
C
generally very high for a reaction that takes place rapidly
D
an energy barrier between reactants and products
Answer
D
SLIDE 21
21
6 What happens to a catalyst in a reaction?
A
It is unchanged.
B It is incorporated into the products. C It is incorporated into the reactants. D It evaporates away.
Answer
A
SLIDE 22
22
7 Why does a catalyst cause a reaction to proceed faster?
A
Only because there are more collisions per second. B Only because collision occur with greater energy.
C
Only because the activation energy is lowered.
D
There are more frequent collisions and they are of greater energy.
Answer
C
SLIDE 23
23
8 If a catalyst is used in a reaction _____.
A
the energy of activation increases B different reaction products are obtained
C
the reaction rate increases
D it evaporates away
Answer
C
SLIDE 24
24
Temperature, pH, Inhibition
Return to Table of Contents
SLIDE 25
25
Enzymes Have Optimal Environments
Since enzymes are proteins and proteins are sensitive to their environments, enzymes are also sensitive to their environments. Factors Affecting Enzyme Activity Temperature pH
SLIDE 26
26
Effect of Temperature on Enzymes
In general, increasing the temperature of a system increases the reaction rate because the substrates are able to move faster and have more collisions with the active sites of the enzymes. This is true only up to certain temperatures for each type of enzyme! We call this temperature the
- ptimal temperature.
The optimal temperature is different for each type of enzyme.
SLIDE 27
27
Past the optimal temperature, the enzyme begins to denature or lose its shape, which changes the shape of the active site.
Effect of Temperature on Enzymes
SLIDE 28
28
Optimal Temperature and Fever
The optimal temperature for most bacterial enzymes is less than 98o F, so by raising body temperature above that, the immune system attempts to denature the bacteria's enzymes and stop the infection. Fever is the elevation of body temperature above normal (In humans 98.6o F). Typically, fevers develop in response to bacterial or viral infection.
SLIDE 29
29
Common Enzymes
Laundry detergents contain enzymes that help break up and remove stains from your clothing. Why might you want to use a different laundry detergent when you wash clothes in hot water instead of in cold water?
SLIDE 30
30
Effect of pH on Enzymes
pH level can also cause a denaturing of the enzyme.
Most biological solutions have pH values between 68.
Increasingly Acidic
SLIDE 31
31
(optimal pH = 4.2) The optimal pH for most enzymes is between 68, but again the optimal pH is different for each type of enzyme.
Effect of pH on Enzymes
SLIDE 32
32
9 What is the optimal temperature for this enzyme?
Answer
about 40o
SLIDE 33
33
10 What is the optimal pH of this enzyme?
Answer
8
SLIDE 34
34
11 Which enzyme has a lower optimal temperature?
Answer
A
SLIDE 35
35
12 At which temperature do both enzymes have an equal rate of reaction?
Answer
about 45o
SLIDE 36
36
13 Which description best explains the temperature effects shown in the graph?
A
Each enzyme will function at room temperature. B Both enzymes are inactive at the freezing point.
C
Each enzyme has its own optimal temperature range.
D
Both enzymes have the same optimal temperature range.
Answer
C
SLIDE 37
37
14 Based on this information which environment can you conclude as being more acidic? A Stomach B Liver
Liver Enzyme Stomach Enzyme Answer
A
SLIDE 38
38
15 Which enzyme would you choose to use in a basic environment?
A B C Answer
C
SLIDE 39
39
16 The active site of an enzyme
- I. is the part where a substrate can fit
- II. can be used again and again
- III. is not affected by environmental factors
A
I only B II only C III only D I and II E I and III
Answer
D
SLIDE 40
40
Cofactors
Sometimes enzymes need a helper to bind at the active site to make the enzyme active. These helpers are called cofactors. If the cofactors are organic molecules, then they are called
- coenzymes. Vitamins are a type of coenzyme.
Enzyme coenzyme substrate
SLIDE 41
41
Enzyme Inhibitors
Certain chemicals work to stop or inhibit the enzymes. These chemicals are called enzyme inhibitors. Types of Inhibitors
· Competitive Inhibitors · Noncompetitive Inhibitors
click here for an animation about inhibition
SLIDE 42
42
Competitive inhibitors are similar in shape to the substrates. They are able to block the substrates from binding to the active site by binding to the active site themselves.
Competitive inhibitor
Competitive Inhibitors
SLIDE 43
43
Competitive Inhibitors: How They Are Stopped
To stop competitive inhibition, the concentration of the substrates needs to be increased so that they outnumber the inhibitors. This way, the substrates are more likely to bind to the active site before an inhibitor does.
SLIDE 44
44
Noncompetitive Inhibitors: How they work
Noncompetitive inhibitors bind to a separate part of the enzyme and cause the enzyme to change shape. When the enzyme changes shape, the substrate is no longer able to bind to the active site because the active site also changes shape. This type of inhibition is sometimes irreversible.
SLIDE 45
45
17 Organic molecules that aid in the action of the enzyme are called ____.
A
products B coenzymes C substrates D helpers
Answer
B
SLIDE 46
46
18 Which type of inhibitor binds at the active site? A Competitive Inhibitor B Noncompetitive Inhibitor
Answer
A
SLIDE 47
47
19 Noncompetitive inhibitors are similar in shape to the substrates that bind at the active site of an enzyme.
True False
Answer
FALSE
SLIDE 48
48
20 If an enzyme has been inhibited noncompetitively, _______.
A
the enzyme is able to increase its activity B increasing substrate concentration will increase inhibition
C
the active site will be occupied by the inhibitor molecule
D
the active site will change shape
Answer
D
SLIDE 49
49
21 Noncompetitive inhibition is sometimes irreversible.
True False
Answer
TRUE
SLIDE 50
50
Allosteric Regulation, Feedback Inhibition
Return to Table of Contents
SLIDE 51
51
Allosteric Regulation
In most natural processes it is necessary to regulate enzyme
- activity. This regulation can either be to inhibit or to stimulate
activity. Allosteric regulation is a type of noncompetitive inhibition that is reversible.
SLIDE 52
52
Allosteric Activation and Inhibition
Enzymes that undergo allosteric regulation are usually made of multiple subunits or polypeptide chains. All of the subunits together form a complex that can be in an active or inactive position. Where the subunits connect, there is an allosteric site, or a site that allows an activator or inhibitor molecule to bind.
SLIDE 53
53
Allosteric Inhibitors
SLIDE 54
54
If an inhibitor binds to the enzyme, the subunits are stabilized in an inactive form. This means the enzymes changes shape and the active sites are not open for substrates to bind to. Allosteric Activators bind to the enzyme, stabilizing the subunits in an active form. This means the enzymes change shape and the active sites are available for substrates to bind to.
Allosteric Activators
SLIDE 55
55
Both activators and inhibitors can be present in the surrounding environment at the same time! However, only one can bind to the complex at a time.
Allosteric Regulation
SLIDE 56
56
Feedback Inhibition
In certain processes the products from one enzyme act as the substrates for a second enzyme and and the second enzyme's products are a substrate for a third enzyme etc. When this happens, the products from the last enzyme in the path can allosterically inhibit the first enzyme in the path until it is necessary for more of the products to be made again and then the inhibitor leaves. This is called feedback inhibition. Click here to see a video of Feedback Inhibition
SLIDE 57
57
enzyme 2 enzyme 1
End Product Intermediate A Initial Substrate Intermediate B
enzyme 3
End Product +
X
Feedback Inhibition
SLIDE 58
58
22 An allosteric site on an enzyme is A not made of protein B involved in feedback inhibition C the same as the active site D where the products leave the enzyme
Answer
B
SLIDE 59
59
23 Which of the following is not part of allosteric regulation? A
- ther substrate molecules compete for the
active site B regulatory molecules bind to a site separate from the active site C inhibitors and activators may compete with one another D a naturally occuring molecule stabilizes an active conformation
Answer
A
SLIDE 60
60
24 Allosteric regulation is similar to noncompetitive inhibition except that it is _____. A always reversible B sometimes irreversible
Answer
A
SLIDE 61
61
25 In allosteric regulation the sites where the inhibitors and activators are able to bind are called _____.
A
Active Site B Substrates
C
Allosteric Site
D Cofactors
Answer
C
SLIDE 62
62
26 In allosteric regulation both an inhibitor and an activator can bind to one substrate complex at the same time.
True False
Answer
FALSE
SLIDE 63
63
27 Feedback inhibition is a type of _____.
A
competitive inhibition B product
C
allosteric regulation
D enzyme
Answer
C
SLIDE 64
64
