X Disparity Determination in Stereo Vision

Lu Sang, Michael Haberl, Raphael Ullmann 22.07.2017

Lu Sang, Michael Haberl, Raphael Ullmann

slide-2
SLIDE 2

Overview

Problem Description Algorithms Results

Lu Sang, Michael Haberl, Raphael Ullmann

slide-3
SLIDE 3

Overview

Problem Description Algorithms Results

Lu Sang, Michael Haberl, Raphael Ullmann

slide-4
SLIDE 4

Problem Description

Lu Sang, Michael Haberl, Raphael Ullmann

slide-5
SLIDE 5

Problem Description

Lu Sang, Michael Haberl, Raphael Ullmann

slide-6
SLIDE 6

Problem Description

  • What is the distance to an object?
  • How to determine the distance by 2D images?

1https://upload.wikimedia.org/wikipedia/commons/4/49/Roboterhand.mit.Gluehbirne.png Lu Sang, Michael Haberl, Raphael Ullmann

slide-7
SLIDE 7

Problem Description

  • What is the distance to an object?
  • How to determine the distance by 2D images?

Applications

  • Autonomous driving
  • Robotics
  • Object recognition

1

1https://upload.wikimedia.org/wikipedia/commons/4/49/Roboterhand.mit.Gluehbirne.png Lu Sang, Michael Haberl, Raphael Ullmann

slide-8
SLIDE 8

Stereo Cameras

Lu Sang, Michael Haberl, Raphael Ullmann

slide-9
SLIDE 9

Corresponding Pixels

Figure: Left Picture [1] Figure: Right Picture

Lu Sang, Michael Haberl, Raphael Ullmann

slide-10
SLIDE 10

Corresponding Pixels

Figure: Left Picture [1] Figure: Right Picture

Lu Sang, Michael Haberl, Raphael Ullmann

slide-11
SLIDE 11

Corresponding Pixels

Figure: Left Picture [1] Figure: Right Picture

1 Calculate for the pixels in the left image costs in the right


Lu Sang, Michael Haberl, Raphael Ullmann

slide-12
SLIDE 12

Corresponding Pixels

Figure: Left Picture [1] Figure: Right Picture

1 Calculate for the pixels in the left image costs in the right


2 Pixel with minimal cost is the corresponding pixel

Lu Sang, Michael Haberl, Raphael Ullmann

slide-13
SLIDE 13

Disparity

Lu Sang, Michael Haberl, Raphael Ullmann

slide-14
SLIDE 14

Disparity

Disparity

Pixel distance of related pixels.

Lu Sang, Michael Haberl, Raphael Ullmann

slide-15
SLIDE 15

Getting distance from Disparity

Lu Sang, Michael Haberl, Raphael Ullmann

slide-16
SLIDE 16

Getting distance from Disparity

Lu Sang, Michael Haberl, Raphael Ullmann

slide-17
SLIDE 17

Getting distance from Disparity

Lu Sang, Michael Haberl, Raphael Ullmann

slide-18
SLIDE 18

Getting distance from Disparity

Lu Sang, Michael Haberl, Raphael Ullmann

slide-19
SLIDE 19

Distance

z ✏ f ☎ b d

  • Distance z
  • Focal length of the camera f
  • Disparity d

Lu Sang, Michael Haberl, Raphael Ullmann

slide-20
SLIDE 20

Overview

Problem Description Algorithms Results

Lu Sang, Michael Haberl, Raphael Ullmann

slide-21
SLIDE 21

Overview

Pre-processing Cost Calculation Pyramid Scheme Force Local Consistency Penalty Terms Median Filter

Lu Sang, Michael Haberl, Raphael Ullmann

slide-22
SLIDE 22

Overview

Pre-processing Cost Calculation Pyramid Scheme Force Local Consistency Penalty Terms Median Filter

Lu Sang, Michael Haberl, Raphael Ullmann

slide-23
SLIDE 23

Pre-processing: Undistortion

Original Picture Undistorted Picture

Lu Sang, Michael Haberl, Raphael Ullmann

slide-24
SLIDE 24

Pre-processing: Undistortion

Original Picture Undistorted Picture

Lu Sang, Michael Haberl, Raphael Ullmann

slide-25
SLIDE 25

Pre-processing: Rectification

Lu Sang, Michael Haberl, Raphael Ullmann

slide-26
SLIDE 26

Pre-processing: Rectification

Lu Sang, Michael Haberl, Raphael Ullmann

slide-27
SLIDE 27

Pre-processing: Rectification

Lu Sang, Michael Haberl, Raphael Ullmann

slide-28
SLIDE 28

Pre-processing: Rectification

Left Picture Right Picture

Lu Sang, Michael Haberl, Raphael Ullmann

slide-29
SLIDE 29

Pre-processing: Rectification

Left Picture Right Picture

Lu Sang, Michael Haberl, Raphael Ullmann

slide-30
SLIDE 30

Modelling: Energy Function

Energy Function

argmind C♣p, dq S♣p, dq

  • Cost C♣p, dq for every pixel p and disparities d ✏ 1, ..., D
  • Regularization S♣p, dq
  • E.g. penalty for deviation of neighbouring pixels

Lu Sang, Michael Haberl, Raphael Ullmann

slide-31
SLIDE 31

Overview

Pre-processing Cost Calculation Pyramid Scheme Force Local Consistency Penalty Terms Median Filter

Lu Sang, Michael Haberl, Raphael Ullmann

slide-32
SLIDE 32

Cost Calculation: Comparing Windows

Lu Sang, Michael Haberl, Raphael Ullmann

slide-33
SLIDE 33

Cost Calculation: Comparing Windows

Lu Sang, Michael Haberl, Raphael Ullmann

slide-34
SLIDE 34

Cost Calculation: Cross Correlation

❞ ✏ ñ ✏ ✁ ❞ ✏ ñ ✏ ✁ r✁ s

Lu Sang, Michael Haberl, Raphael Ullmann

slide-35
SLIDE 35

Cost Calculation: Cross Correlation

❞ ✏ ñ ✏ ✁ ❞ ✏ ñ ✏ ✁ r✁ s

Lu Sang, Michael Haberl, Raphael Ullmann

slide-36
SLIDE 36

Cost Calculation: Cross Correlation

❞ ✏ ñ ✏ ✁ ❞ ✏ ñ ✏ ✁ r✁ s

Lu Sang, Michael Haberl, Raphael Ullmann

slide-37
SLIDE 37

Cost Calculation: Cross Correlation

❞ ✏ Total sum = 2 ñ Costs ✏ ✁2 ❞ ✏ ñ ✏ ✁ r✁ s

Lu Sang, Michael Haberl, Raphael Ullmann

slide-38
SLIDE 38

Cost Calculation: Cross Correlation

❞ ✏ Total sum = 2 ñ Costs ✏ ✁2 ❞ ✏ ñ ✏ ✁ r✁ s

Lu Sang, Michael Haberl, Raphael Ullmann

slide-39
SLIDE 39

Cost Calculation: Cross Correlation

❞ ✏ Total sum = 2 ñ Costs ✏ ✁2 ❞ ✏ ñ ✏ ✁ r✁ s

Lu Sang, Michael Haberl, Raphael Ullmann

slide-40
SLIDE 40

Cost Calculation: Cross Correlation

❞ ✏ Total sum = 2 ñ Costs ✏ ✁2 ❞ ✏ Total sum = 4 ñ Costs ✏ ✁4 r✁ s

Lu Sang, Michael Haberl, Raphael Ullmann

slide-41
SLIDE 41

Cost Calculation: Cross Correlation

❞ ✏ Total sum = 2 ñ Costs ✏ ✁2 ❞ ✏ Total sum = 4 ñ Costs ✏ ✁4 Normalization and Zero Mean: Values in r✁1, 1s

Lu Sang, Michael Haberl, Raphael Ullmann

slide-42
SLIDE 42

Cost Calculation: Result

Lu Sang, Michael Haberl, Raphael Ullmann

slide-43
SLIDE 43

Cost Calculation: Result

Lu Sang, Michael Haberl, Raphael Ullmann

slide-44
SLIDE 44

Cost Calculation: Result

  • Error Rate of NCC: 33.09%

Lu Sang, Michael Haberl, Raphael Ullmann

slide-45
SLIDE 45

Test Data

Figure: Left Image Figure: Right Image

Lu Sang, Michael Haberl, Raphael Ullmann

slide-46
SLIDE 46

Test Data

  • Middlebury Dataset
  • Ground Truth
  • Leaderboard

Lu Sang, Michael Haberl, Raphael Ullmann

slide-47
SLIDE 47

Algorithm Defect

Lu Sang, Michael Haberl, Raphael Ullmann

slide-48
SLIDE 48

Overview

Pre-processing Cost Calculation Pyramid Scheme Force Local Consistency Penalty Terms Median Filter

Lu Sang, Michael Haberl, Raphael Ullmann

slide-49
SLIDE 49

Pyramid Scheme

Lu Sang, Michael Haberl, Raphael Ullmann

slide-50
SLIDE 50

Pyramid Scheme

Lu Sang, Michael Haberl, Raphael Ullmann

slide-51
SLIDE 51

Pyramid Scheme

Lu Sang, Michael Haberl, Raphael Ullmann

slide-52
SLIDE 52

Pyramid Scheme: Results

Figure: Results of NCC Figure: Results of Pyramid Scheme

  • Error Rate of NCC: 33.09%
  • Error Rate of Pyramid Scheme: 28.1%

Lu Sang, Michael Haberl, Raphael Ullmann

slide-53
SLIDE 53

Overview

Pre-processing Cost Calculation Pyramid Scheme Force Local Consistency Penalty Terms Median Filter

Lu Sang, Michael Haberl, Raphael Ullmann

slide-54
SLIDE 54

Force Local Consistency

  • Interpret Cross Correlation as confidence indicator
  • Use only pixels with high confidence
  • Replace low confidence by values with high confidence in the

window

Lu Sang, Michael Haberl, Raphael Ullmann

slide-55
SLIDE 55

Force Local Consistency: Confidence Map

Figure: Results of NCC Figure: Confidence Map

  • Black point: trustworthy pixel with correct disparity

(C♣pq ➙ T).

  • Red point: unreliable pixel with violated disparity (C♣pq ➔ T).

Lu Sang, Michael Haberl, Raphael Ullmann

slide-56
SLIDE 56

Force Local Consistency C♣pq

Correct Disparity ➙ T Violated Disparity C♣p✶q Closest p✶ not unique Unique p✶ unique maxp✶PW C♣p✶q Original Disparity C♣p✶q P W all violated ➔ T

1 Mark all violated pixels.

Lu Sang, Michael Haberl, Raphael Ullmann

slide-57
SLIDE 57

Force Local Consistency C♣pq

Correct Disparity ➙ T Violated Disparity C♣p✶q Closest p✶ not unique Unique p✶ unique maxp✶PW C♣p✶q Original Disparity C♣p✶q P W all violated ➔ T

1 Mark all violated pixels. 2 Find the pixel with max NCC coefficient.

Lu Sang, Michael Haberl, Raphael Ullmann

slide-58
SLIDE 58

Force Local Consistency C♣pq

Correct Disparity ➙ T Violated Disparity C♣p✶q Closest p✶ not unique Unique p✶ unique maxp✶PW C♣p✶q Original Disparity C♣p✶q P W all violated ➔ T

1 Mark all violated pixels. 2 Find the pixel with max NCC coefficient. 3 Replace the disparity value by using the disparity of new pixel.

Lu Sang, Michael Haberl, Raphael Ullmann

slide-59
SLIDE 59

Force Local Consistency: Results

Figure: Results of NCC Figure: Results of FLC

  • Error Rate of NCC: 33.09%
  • Error Rate of FLC: 26.90%

Lu Sang, Michael Haberl, Raphael Ullmann

slide-60
SLIDE 60

Overview

Pre-processing Cost Calculation Pyramid Scheme Force Local Consistency Penalty Terms Median Filter

Lu Sang, Michael Haberl, Raphael Ullmann

slide-61
SLIDE 61

Local Penalty

Local Penalty

1 Smoothness check 2 Search four directions 3 Punish on NCC coefficient 4 Iterate

Lu Sang, Michael Haberl, Raphael Ullmann

slide-62
SLIDE 62

Overview

Pre-processing Cost Calculation Pyramid Scheme Force Local Consistency Penalty Terms Median Filter

Lu Sang, Michael Haberl, Raphael Ullmann

slide-63
SLIDE 63

Post Processing: Median Filter

ñ

Lu Sang, Michael Haberl, Raphael Ullmann

slide-64
SLIDE 64

Final Results

Figure: Results of FLC Figure: After Post-processing

  • Error Rate of FLC: 26.90%
  • Error Rate of FLC + Median filter: 21.10%

Lu Sang, Michael Haberl, Raphael Ullmann

slide-65
SLIDE 65

Overview

Problem Description Algorithms Results

Lu Sang, Michael Haberl, Raphael Ullmann

slide-66
SLIDE 66

Results: Average Error Rates

38.78% 37.37% 32.55% 32.88% 38.78% 36.04% 31.12% 31.60% 0.0% 10.0% 20.0% 30.0% 40.0% NCC Pyramid Scheme +Median Filter +Local Penalty NCC FLC +Median Filter +Local Penalty

Lu Sang, Michael Haberl, Raphael Ullmann

slide-67
SLIDE 67

Own Pictures

Figure: Left Image Figure: Pyramid Scheme + Median Filter

Lu Sang, Michael Haberl, Raphael Ullmann

slide-68
SLIDE 68

Own Pictures

Figure: Left Image Figure: Pyramid Scheme + Median Filter

Lu Sang, Michael Haberl, Raphael Ullmann

slide-69
SLIDE 69

Summary

Pre-processing Cost Calculation Pyramid Scheme Force Local Consistency Penalty Terms Median Filter

Lu Sang, Michael Haberl, Raphael Ullmann

slide-70
SLIDE 70

Failed Approaches

  • Disparity Calculation:
  • Cost Aggregation
  • Gradient Guided Weighted Match
  • Neural Network
  • Disparity Refinement
  • Local Interpolation
  • Cubic Plane Interpolation
  • Segment Penalty
  • Post-processing
  • Bilateral Filter
  • Gradient Guided Mask Filter

Lu Sang, Michael Haberl, Raphael Ullmann

slide-71
SLIDE 71

Failed Approaches

  • Disparity Calculation:
  • Cost Aggregation
  • Gradient Guided Weighted Match
  • Neural Network
  • Disparity Refinement
  • Local Interpolation
  • Cubic Plane Interpolation
  • Segment Penalty
  • Post-processing
  • Bilateral Filter
  • Gradient Guided Mask Filter

Figure: Disparity Image using Neural Networks

Lu Sang, Michael Haberl, Raphael Ullmann

slide-72
SLIDE 72

Thanks!

Disparity Determination

Cross Correlation Force Con- sistency Pyramid Scheme Local Penalty Refinement Median Filter More to Think and Try Neural Network

Segmentation Based FC

Low Texture Surface Failed Approaches Local In- terpolation

Segmentation

Bilateral Filter

Lu Sang, Michael Haberl, Raphael Ullmann

slide-73
SLIDE 73

Sources

[1] D. Scharstein, H. Hirschmüller, Y. Kitajima, G. Krathwohl, N. Nesic, X. Wang, and P. Westling. High-resolution stereo datasets with subpixel-accurate ground truth. In German Conference on Pattern Recognition (GCPR 2014), Münster, Germany, September 2014

Lu Sang, Michael Haberl, Raphael Ullmann
