SLIDE 1

Wyandotte Geothermal

SLIDE 2

Overview of Wyandotte Municipal Services

Provides Electric, Water, Cable, Internet, & VOIP Phone Service s

 Water Utility

 Formed in 1889  Approx 10,000 customers

 Electric Utility

 Formed in 1892  Approx 12,000 customers

 Cable Utility

 Formed in 1981  Approx 8,500 customers

SLIDE 3

Overview on Geo-Exchange Technology

 1946 First successful Ground Source Heat Pump

installed in Portland, OR

 Primarily open loop systems until 1979, now almost

all are closed loop

 As of 2004, an estimated 12 GW of thermal capacity

installed world wide

 Each year about 80,000 units are installed in the US

SLIDE 4

How Geo-Exchange Works

During the winter, the fluid collects heat

from the earth and carries it through the system and into the building.

During the summer, the system reverses

itself to cool the building by pulling heat from the building, carrying it through the system and placing it in the ground.

This process creates free hot water in the

summer and delivers substantial hot water savings in the winter.

SLIDE 5

Why Does WMS Promote Geothermal

 Energy Efficiency  Improves system load factor  Is a dispatchable renewable energy source  Lowers customers energy costs  Economic development

SLIDE 6

Energy Efficiency

The GSHP is one of the most efficient residential heating and cooling systems available today, with heating efficiencies 50 to 70% higher than other heating systems and cooling efficiencies 20 to 40% higher than available air conditioners. That directly translates into savings for you on your utility bills.

Source “International Ground Source Heat Pump Association”

SLIDE 7

Improves System Load Factor

SLIDE 8

Lowers Energy Costs

 The average customer will save $580 dollars per

year

 After approximately 22 years they will “break

even” and begin to save even more money

 WMS will also be saving on power generation

SLIDE 9

SLIDE 10

SLIDE 11

Annual Cost to Heat and Cool vs. Size of Home

$0.00 $1,000.00 $2,000.00 $3,000.00 $4,000.00 $5,000.00 700 890 950 1,000 1,000 1,100 1,100 1,200 1,250 1,400 1,500 1,500 1,600 1,650 1,700 1,800 1,800 2,200 2,200 2,300

Annual Cost to Heat and Cool Size of home (Sq FT) Conventional Geo

SLIDE 12

$0.00 $500.00 $1,000.00 $1,500.00 $2,000.00 $2,500.00 Conventional Annual Cost to Heat/Cool in dollars Annual Gas Total Annual Electric total $0.00 $500.00 $1,000.00 $1,500.00 $2,000.00 Geothermal Annual Cost to Heat/Cool in dollars Annual Geo Costs Total

Geothermal vs. Conventional

SLIDE 13

Different Types of Energy

SLIDE 14

Lowers Customers Energy Costs

 Current Incentives in Wyandotte

 30% Federal Tax Credit  1.99% Unsecured Loans Available  WMS working on new incentive program

 Also Offering Other Programs

 Home Energy Audits  Suite of Other Rebates & Incentives

under the Energy Smart Programs

SLIDE 15

What an Installation Looks Like

SLIDE 16

Drilling Experience

 Urban Area

 Average lot width varies 40 ft. to 70 ft.

 Landscaped yards

 Trees, sidewalks, driveways, curbs, porches, etc.

 Artesian Wells

 Rotten egg odors

 Fractured Limestone

SLIDE 17

SLIDE 18

SLIDE 19

Current Status in Wyandotte

 Over 60 Geothermal Units in Operation

 25 new residential installations  19 retrofit residential installations  3 commercial installations  2 new multi-family developments (20 units)  3 Private home owners subscribed
