Workshop AA

Energy Savings Champions – Best Practices & Case Studies in Energy Reduction & Energy Efficiency in Award-Winning, Multi-Facility, Large National Corporations

Wednesday, February 19, 2020 11:00 a.m. to 12:15 p.m.

Biographical Information Angie Rybalt, Outreach Manager, Energy Efficiency Programs 700 Morrison Road, Gahanna, OH 43230 614-883-6902 amrybalt@aep.com

• Mrs. Rybalt is the Outreach Manager for the AEP Ohio Energy Efficiency Programs.

Angie’s team is responsible for AEP Ohio Business Incentive program participation across multiple sectors of Solution Providers and customers. Angie spent the first part of her career in financial sales and with the belief that EE is financial sale she naturally shifted to energy efficiency sales. She has supported the AEP Ohio energy efficiency programs for over a decade. Her key strengths are the deep relationships she has made and understanding the sales process surrounding energy efficiency amongst different customer segments.

• Mrs. Rybalt currently serves on the board of the local chapter of Association of Energy

Engineers and has a BA in Business from The Ohio State University. Angie’s true passions are yoga and spending time with her charming and chaotic little family. Katie Flynn, Energy Manager Giant Eagle 261 Kappa Drive, Pittsburgh, PA 15238 412-967-3742 Katie.Flynn@gianteagle.com Katie Flynn joined Giant Eagle as Energy Manager in January 2015. Her responsibilities include monitoring energy usage, engaging team members in sustainability, implementing and communicating demand response programs, and identifying and implementing energy efficiency projects. She received her BS in Engineering from Smith College and her MS in Civil & Environmental Engineering from Carnegie Mellon University. She is a Certified Energy Manager and a LEED AP O&M. Katie teaches a graduate course on Sustainable Buildings at Carnegie Mellon University and has experience with corporate sustainability. Andrew Stroh, CEM, Energy Manager Abercrombie & Fitch Co. 6301 Fitch Path, New Albany OH43054-9269 614-283-6074 Andrew_Stroh@anfcorp.com Andrew Stroh is the Energy Manager for Abercrombie and Fitch Co. and is a Certified Energy Manager (CEM) with the Association of Energy Engineers (AEE). He has specialized in commercial and industrial demand side energy management and reduction for 10 years. His background involves utility program implementation and energy portfolio management for end users in the public and private sectors. Andrew is responsible for utilities and energy procurement at Abercrombie & Fitch Co.

Giant Eagle

Energy Management

AEP Annual Ohio Energy Management Conference February 2/ 19/ 2020

2

Agenda

• Energy Program Overview
• Case Studies
• Current Projects

3

Giant Eagle Overview

1931 $9.2 BILLION

ANNUAL SALES

216

CONVENIENCE

SUPERMARKETS

259

Retail locations in Pa., Ohio, W.Va., Md., Ind.

32,000

TEAM MEMBERS

4

Planning for Energy Cost Reduction Projects

Get into the W eeds

• Understand current consumption

– Energy consumption by site – Focus on major end uses of energy – Utilize sub-metered data – Look at demand profiles and time of use

• Look at your energy expense

– Allocate expense into high level buckets

• Consumption
• Demand
• Capacity

5

Evolving Opportunities

• Fruit that has fallen

– Implement easy to make operational changes that can be implemented through existing control devices

• Setpoints
• Setbacks
• Low hanging fruit

– Projects with a relatively low cost, quick payback, that are easy to implement

• Stretch projects

– Look at holistic savings opportunities by considering non-energy impacts such as maintenance and asset availability – Put multi-year strategy in place

6

Demand Response and Peak Load Shaving

Maxim izing Existing Program s

• Prior to 2016, Giant Eagle participated in

traditional demand response programs by lowering electricity demand in supermarkets

• In 2016, Giant Eagle began to monitor

instantaneous load on PJM and engaged demand response load shed during peak times to lower our capacity tags for the following year

• Increased events required:

– Additional resources devoted to program – Increased communication to supermarkets and internally at corporate – Measurement and verification of performance

Typical Loads Event Loads

7

Retro-commissioning

Optim izing Efficiency of Existing System s

• Validate system setpoints are in line with

internal standards

• Identify and correct where equipment is

not operating properly – Broken lighting contactors – Bypassed VFDs – Inefficient compressor

• Measured and verified savings of 10%

energy reduction on major building systems

• Filled in information gaps

– Large HVAC units without VFDs

8

LED Lighting

Significant Reduction Over Tim e

• Implemented Over Five Years

– Started with backrooms and stock areas – Convivence Stores – Salesfloor, Cases and Exterior

• Energy Efficiency Win

– Reduce a major end use of energy by more than 40% – Implemented along with dimming and

• ther controls
• Auxiliary Benefits

– Lowered maintenance costs – Fewer outages – Improve aesthetic

9

Current Projects

Better I nsight and Control

• Centralized system information platform

– Pulling in major system settings and data into holistic platform – Creating insight across entire portfolio in real-time

• Advanced HVAC control

– Reactive, dynamic controls – More sophisticated control strategy

10

Questions?

11

Incorporating Energy Best Practices at the A&F Co. Global Home Office

February 18th‐19th

Energy Management/Procurement

12

About Abercrombie & Fitch Co.

Global Home Office Energy/Utilities are approximately 10% of total utility spend for A&F Global Home Office is a campus with over 2.5 million square feet of space including Distribution Centers, Office Space, Labs, and a Data Center 16 buildings spread over 500 acres

13

AGENDA

Capital Project Best Practices

• AEP Incentives
• Lighting
• Exterior LEDs
• Interior LEDs
• Lighting Controls/Schedules
• Data Center
• Server Virtualization
• Hot Aisle Containment
• Air Side Economizing (Heat loads when not occupied)
• VFD Compressors

Operational Best Practices

• Scheduling/Setpoints
• Retrocommissioning
• Culture of Operational Savings
• Modeling/Measurement
• Team Meetings
• Cross Functional Collaboration
• Financial Threshold/Consumption Checks

14

Capital Project Best Practices

15

Capital Project Best Practices

AEP Incentives

• Efficient Products
• Bid4Efficiency
• Network Lighting Controls
• Process Efficiency
• Data Center
• New Construction & Major Renovation
• Combined Heat & Power
• Incentive NOW
• E‐Motor Rewind
• Energy Efficient Financing
• Express Program
• Continuous Energy Improvement
• Automated Benchmarking

16

2019 2018 Fall 2016‐Spring 2017 End of 2015/Early 2016 Parking lot lights and some exterior fixtures were changed to LEDs. DC2 redesign included lighting at 0.5 watts per square foot (0.4 watts/square foot below code)

Parking Lot Lights and DC 2 Redesign

Winter 2015/2016 Interior desk spaces in the HO, campus stores, and some exterior lights

• n buildings

Campus LEDs

Some decorative lighting

Specialty Fixtures

Conversion of DC High Bays, Office Spaces, and installation of advanced lighting controls We are at 0.5 watts per square foot in high bay areas and economics to LEDs did not make sense when we did the HO

DC Evaluation

Capital Projects Best Practices

LED Lighting

Note: All lights are scheduled via schedules in EMS or Occ sensors

17

2018 2017 2016 End of 2015/Early 2016 Parking lot lights and some exterior fixtures were changed to LEDs

~92% Virtualized & Virtual Desktop rollouts

2015 Raised operating setpoints inside data center expanding the hours of using outside air temp

Hot Aisle Containment & Air Side Economizer

Continued replacement

• f antiquated

equipment

Over 94% Virtualized ~ 95% Virtualized & replaced battery backup

Capital Projects Best Practices

Data Center

18

2018 2017 2018 DC2 shuttered for extended period and had compressors salvaged and taken to DC1

DC2 Now Operating with Old DC1 Compressors

2015 By end of the year all 3 compressors were swapped out

One compressor fails and we install one with a VFD

Capital Projects Best Practices

VFD Compressors

19

Operational Project Best Practices

20

2018 2017 2016 Setbacks reduced from 20 minutes to 7 minutes

EMS Setpoints on DC Conveyors

2015 Lighting Schedules updated for HO & DC spaces, exterior daytime coding was updated

Campus LEDs

Increased cooling setpoint and became more aggressive on nighttime setback schedules for HVAC looking more at recovery time and other factors

Cooling Setpoints Raised in DCs

Holiday setbacks more aggressive and investigation into the freeze protection setpoints/scheduling

Chiller Loop Setpoints Raised & More Aggressive Scheduling

Operational Projects Best Practices

Scheduling/Setpoints

21

2019 2018 2017 2016 Setbacks reduced from 20 minutes to 7 minutes

EMS Setpoints on DC Conveyors

2015 Lighting Schedules updated for HO & DC spaces, exterior daytime coding was updated

Campus LEDs

Increased cooling setpoint and became more aggressive on nighttime setback schedules for HVAC looking more at recovery time and other factors

Cooling Setpoints Raised in DCs

Holiday setbacks more aggressive and investigation into the HW loop setpoints/scheduling

Chiller Loop Setpoints Raised & More Aggressive Scheduling

Operational Projects Best Practices

Scheduling/Setpoints

Retrocommissioning

22

1) End of 2018/Ongoing Reduce or eliminate “Chimney Effect” on HO VAV and HW Radiant Loop system along with implementing 45 degree hot water resets 2) Spring 2019/Ongoing ‐ Remove user locked setpoints from VAV. Dead band decreased. Setpoints now broadcasted from AHU now. This also eliminated hunting and conflict between VAVs in open areas. Status: HO (Phase 1) Done DC’s Started, est. 80% done 3) May 2019 ‐ Chilled water set points raised from 42 deg to 44 deg at both DC’s

Operational Project Best Practices

2019 Retrocommissioning Initiatives

23

4) Spring 2019 ‐ Chilled water set point raised from 44deg to 50deg for building with data center/IT at the HO. 5) June 2019 – Match staged cooling of chillers to building demand based on schedule to eliminate whole plant running 6) Dec 2019 – Change boilers to Lead / Lag configuration. Both ran constantly previously. 7) Dec 2019 – Aggressive Scheduling of DC2 AHUs

Operational Project Best Practices

2019 Retrocommissioning Initiatives

24

Operational Projects Best Practices

Culture of Operational Savings

• Find Statistically Significant Energy

Drivers

• Provide validated measured savings

to finance

• Catch all for overlapping savings on

larger meters

• Can be done in Excel but AEP

Program provides access to better statistical tools

Modeling/Measurement (AEP CEI)

CUSUM Chart

25

• Too easy to get lost in the day to day
• There will always be fires to put out
• Stay on target for critical dates like peak periods

and holidays

• You won’t catch every operational savings
• Identify cascading and interconnected savings
• Go together, you will need buy in for some projects

Team Meetings/Group Emails

• Maximize areas of expertise and highlight those

doing the work as high as you can

• There are legitimate reasons projects don’t work
• Energy has a legitimate use
• Be able to pass on things to the next person

Cross Functional Collaboration

Operational Project Best Practices

Culture of Operational Savings

26

0% 20% 40% 60% 80% 100% 120%

400,000 800,000 1,200,000 1,600,000 2,000,000

01‐2016 02‐2016 03‐2016 04‐2016 05‐2016 06‐2016 07‐2016 08‐2016 09‐2016 10‐2016 11‐2016 12‐2016 01‐2017 02‐2017 03‐2017 04‐2017 05‐2017 06‐2017 07‐2017 08‐2017 09‐2017 10‐2017 11‐2017 12‐2017 01‐2018 02‐2018 03‐2018 04‐2018

Gallons

HO Water & Sewage Consumption

YOY %

Operational Project Best Practices

Financial/Consumption Threshold Checks

27

$3M+ 105 Million kWh

Energy Efficiency

Total HO and DC Savings Since 2010

28

Questions?
