University of Central Missouri: Golf Pro Shop & Caf Designers- Jordan Becker, Alex Hillis, Amanda Hoffsette, Ashley Lawrence Design Problem Statement & Design Objectives To design retail and caf environments that reflect the

slide-1
SLIDE 1

University of Central Missouri:

Golf Pro Shop & Café

Designers- Jordan Becker, Alex Hillis, Amanda Hoffsette, Ashley Lawrence

slide-2
SLIDE 2

Design Problem Statement & Design Objectives

 To design retail and café environments that reflect

the client’s needs for a safe, and comfortable space; as well as the client’s want for a non-institutional

  • look. Other significant points discussed include: a

large amount of storage, including a club repair room; three serviceable offices; a wide variety of merchandise display units; preservation of golf course view provided by a window wall; and flexible dining and lounge spaces.

  • T
  • design an environment that is non-institutional and inviting
  • T
  • design functional spaces that support a comfortable shopping experience and

encourages customer satisfaction.

  • T
  • design a clean and sanitary space that is sustainable and healthy for occupants

and the environment.

slide-3
SLIDE 3

Concept Statement: Trees of Missouri

 The Oak trees of Missouri reveal numerous design relationships that are

used to guide the design of the space. Focusing on the organic, straight, and implied rhythms of the masculine Oak tree to reinforce the essential character of the space, the architectural and interior elements reflect the relationship between the tree rings that reside in the tree that compliment the rippling movement of the space.

 The kiosk and entry way is the clients’ first introduction to the

comfortable golf pro shop environment, and the concept inspired by the Missouri Oak trees that reveals itself through several different designs. The custom carpet design draws on the soft repeating circles of the Oak tree rings and directs the client visually toward the beautiful vantage point of the golf course. Upholstered furniture forms within this space also reflect the repeated circular elements. The room was softened by incorporating a circular drop down ceiling above the kiosk with warm pendent lighting. The combination of rich playful upholstery, soft curvilinear patterns within the custom carpeting and the enhanced by the drop down ceiling provides an inviting, safe and comfortable shopping experience.

slide-4
SLIDE 4

Inspiration

slide-5
SLIDE 5

Programming

Entrance/Golf Pro Shop

  • Square Footage: 1304 sq. ft (or ft2)
  • Occupancy:

 By code: 62  Seating Provided: 5

 2 task chairs for employees  3 individual chairs for customers

  • Client Requirements:

 Kiosk desk with computer, printer and filing for 2 to 3 employees  Visual welcome to the space – merchandise display units

  • Code Requirements:

 Meet applicable fire codes for emergency egress  Meet applicable standards for accessibility

 Turning radius and power assisted door

  • Related Design Solutions:

 Coordinated ceiling and custom carpeting  Seating and Furniture for small short-stay waiting area  Custom kiosk desk

 Shape and textile selection  Lowered transaction counter for accessibility  Lowered work surface  Hides desk clutter from visitor  Provides larger work surface and visual privacy for employee

 Custom Wall Unit

 Provides ample storage space  Design and decorative accessories to soften and humanize entry space

 Bathroom

 Provides private restroom for customers to use as a changing facility for trying on merchandise

slide-6
SLIDE 6

Programming

 Outdoor Patio Space

  • Square Footage:

731 sq. ft (or ft2)

  • Occupancy:

 By code: 48  Seating Provided: 33

 1 task chairs for employees  32 individual chairs for customers

  • Client Requirements:

 Small securable outdoor bar with a small variety of beverages  Visual welcome to the golf course vantage point

  • Code Requirements:

 Meet applicable fire codes for emergency egress  Meet applicable standards for accessibility

 Turning radius and power assisted door

  • Related Design Solutions:

 Seating and Furniture for dining; weather proof  Custom outdoor bar

 Securable storage  Lowered transaction counter for accessibility  Lowered work surface  Hides desk clutter from visitor  Provides larger work surface and visual privacy for employee

slide-7
SLIDE 7

Programming

 Interior Bar & Lounge Space

  • Square Footage:

718 sq. ft (or ft2)

  • Occupancy:

 By code: 47  Seating Provided: 20

 20 individual chairs for customers

  • Client Requirements:

 Transaction Counter located near interior bar, flexible seating  Visual welcome to the dining/ lounge area

  • Code Requirements:

 Meet applicable fire codes for emergency egress  Meet applicable standards for accessibility

 Turning radius and power assisted door

  • Related Design Solutions:

 Coordinated ceiling and custom carpeting  Seating and Furniture for dining; abrasion resistant  Custom indoor bar and bar hutch

 Securable storage  Lowered transaction counter for accessibility  Lowered work surface  Hides desk clutter from visitor  Provides larger work surface and visual privacy for employee

 Faux fireplace lounge

 Comfortable seating  Built in decorative fire place  Custom wall partition- 3Form Ripple

slide-8
SLIDE 8

Programming

 Café Space

  • Square Footage:

583 sq. ft (or ft2)

  • Occupancy:

 By code: 38  Seating Provided: 22

 22 individual chairs for customers

  • Client Requirements:

 Comfortable dining arrangement- chairs and tables  Visual welcome- warm pendent lighting

  • Code Requirements:

 Meet applicable fire codes for emergency egress  Meet applicable standards for accessibility

 Turning radius and power assisted door

  • Related Design Solutions:

 Coordinated ceiling and custom carpeting  Seating and Furniture for dining  Custom drop down ceiling

 Contains recessed down lighting; easy for cleaning  Softens the rectangular dining space  Adds dimension, and visual interest past the walls

slide-9
SLIDE 9

Programming

Golf Pro Shop Manager Office

  • Square Footage:

110 sq. ft (or ft2)

  • Occupancy:

 By code: 2  Seating Provided: 2

 1 task chairs for employees  1 individual chairs for customers

  • Client Requirements:

 Comfortable seating

  • Code Requirements:

 Meet applicable fire codes for emergency egress  Meet applicable standards for accessibility

  • Related Design Solutions:

 Durable carpeting  Institutional work furniture

 Securable filing storage  Ample work surface  Additional storage in bookcase

Golf Pro Shop Assistant Manager Office

  • Square Footage:

110 sq. ft (or ft2)

  • Occupancy:

 By code: 2  Seating Provided: 2

 1 task chairs for employees  1 individual chairs for customers

  • Client Requirements:

 Comfortable seating

  • Code Requirements:

 Meet applicable fire codes for emergency egress  Meet applicable standards for accessibility

  • Related Design Solutions:

 Durable carpeting  Institutional work furniture

 Securable filing storage  Ample work surface  Additional storage in bookcase

slide-10
SLIDE 10

Programming

Restroom Facilities

  • Square Footage: 379 sq. ft
  • Occupancy:

 By code: 6  Seating Provided: 1

 1 individual chairs for customers

  • Client Requirements:

 Clean & safe environment  Up to ADA standards  Appropriate privacy

  • Code Requirements:

 Meet applicable fire codes for emergency egress  Meet applicable standards for accessibility

 Turning radius in restroom  Turning radius in accessible stall

  • Related Design Solutions:

 Coordinated ceiling and flooring- tile

Storage Facilities

  • Square Footage: 237sq. ft.
  • Occupancy:

n/a unoccupied ancillary space

  • Client Requirements:

n/a

  • Code Requirements:

n/a

  • Related Design Solutions:

n/a

slide-11
SLIDE 11

Schematics

slide-12
SLIDE 12

Schematics

slide-13
SLIDE 13

Golf Pro Shop Floor Plan

slide-14
SLIDE 14

Golf Pro Shop Ceiling & Lighting Plan

slide-15
SLIDE 15

Golf Pro Shop Perspective

slide-16
SLIDE 16

Golf Pro Kiosk Perspective

slide-17
SLIDE 17

Café Perspective

slide-18
SLIDE 18

Bar Lounge Perspective

slide-19
SLIDE 19

Custom Furniture Detail: Bar Hutch

slide-20
SLIDE 20

Bar Hutch Perspective

  • Indoor Bar Hutch

Wood: Acacia Hardware: Gatehouse 1-1/4” Satin Nickel Egg Knob 3 Form: Genoa-Mango

slide-21
SLIDE 21

Custom Furniture Detail: Interior Bar

slide-22
SLIDE 22

Interior Bar Perspective

  • Indoor Restaurant

Bar

Linoleum Countertop: (Lowe’s Item #A3238) Wood: Acacia Hardware: Brainerd 3” Greco Roman Pull

slide-23
SLIDE 23

Custom Furniture Detail: Outdoor Bar

slide-24
SLIDE 24

Outdoor Bar Perspective

  • Outdoor Bar

Wood: Acacia Countertop: Concrete/ Linoleum (#A3238) Hardware: Brainerd 3-3/4” Fusilli Pull

slide-25
SLIDE 25

Custom Furniture Detail: Golf Pro Shop Kiosk Desk

slide-26
SLIDE 26

Kiosk Perspective

  • Golf Pro Shop Kiosk

Wood: Acacia Countertop: Acacia Hardware: Gatehouse Aged Bronze Casual Pull 3Form Color: Genoa-Papaya

slide-27
SLIDE 27

Lighting

  • Corbett Lighting

113-44 Vertigo 4 Light Ceiling Pendant Height: 32.75 in Width: 30.00 in Lamping: 4 – Med Base 60W Lamp Type: Incandescent

  • Corbett Lighting

113-11 Vertigo 1 Light Wall Sconce Height: 10.00 in Width: 9.75 in Extension: 5.00 in Lamping: 1 – med based T

  • rpedo

60W Lamp Type: Incandescent

slide-28
SLIDE 28

Lighting

  • Louie Lighting

(Pendant) Item #G1067-6 Height: 31.5 in Diameter: 19.7 in Lamping: Standard Lamp and wattage: 6 – compact fluorescent E-27 13W bulb

  • ie
  • Kenroy Lighting

44301BS Medici Mini Pendant, Brushed Steel Height: 9.00 in Diameter: 4 in Cord Length: 120 in Lamping: 1 – 60 watt bulb

slide-29
SLIDE 29

Lighting

  • Corbett Lighting

113-43 Vertigo 3 Light Ceiling Pendant Height: 18.50 in Width: 18.00 in Lamping: 2 – Med Base 60 watts ea Lamp Type: Incandescent

slide-30
SLIDE 30

Furnishings

  • 3 Tier Oval Display

Table

Wood: Western Redwood Length: 60.00 in Depth: 42.00 in Height: 42.00 in

  • Reclaimed Wood

Fixture (450300)

Wood: Western Redwood Width: 30.00 in Depth: 30.00 in Height: 65.00 in

slide-31
SLIDE 31

Furnishings

  • Reclaimed Wood

Fixture (450100)

Wood: Western Redwood Width: 30.00 in Depth: 33.00 in Height: 65.00 in

  • FOCA Chair

(Store Seating)

Width: 56.00 in Depth: 39.00 in Height: 35.00 in

slide-32
SLIDE 32

Furnishings

  • Armen Living Igloo

Barstool (211562)

Height: 30.00 in Width: 20.00 in Depth: 20.00 in

  • Hardwood

Pedestal Dining Table

Material: Wood Height: 29.50 in Diameter: 59.00 in

slide-33
SLIDE 33

Furnishings

  • Delano Embossed

Chair

(spn-43302) Length: 22.00 in Width: 21.00 in Height: 30.50 in

slide-34
SLIDE 34

Furnishings

  • Bentley Sofa

(Lounge Sofa)

Width: 60.00 in Depth: 38.00 in Height: 34.00 in

  • Bentley Chair

(Lounge Chair).

Width: 43.00 in Depth: 40.00 in Height: 36.00 in

slide-35
SLIDE 35

Furnishings

  • Reclaimed Wood

Fixture (450200)

Wood: Redwood Width: 52.00 in Depth: 30.00 in Height: 65.00 in

  • Outdoor Patio Furniture

Style: Valencia Table w/ 6 stacking chairs Color: Charcoal/ Black Size: 150.00 cm Diam.

slide-36
SLIDE 36

Flooring- Carpeting: Tandus

Sound Stage Disc Jockey New Release Preview

slide-37
SLIDE 37

Other Materials: Color Accents

Torchlight

Y

  • O/Y/82

SW 6374

Sherman Williams

slide-38
SLIDE 38

Other Materials- Color Accents

Ceiling Colors

Wheat Penny Colony Bluff SW 7723 SW 7705
