Work Management System (WMS) aka Computerized Maintenance Management System (CMMS) Michael Rodriguez Systems Engineering Project Community Workshop August 14 th 2018 #lsst2018 #lsst2018 LSST Project and Community Workshop 2018 Tucson

slide-1
SLIDE 1

1

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

Work Management System (WMS)

aka Computerized Maintenance Management System (CMMS)

Michael Rodriguez Systems Engineering

Project Community Workshop August 14th 2018

slide-2
SLIDE 2

2

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

What is a WMS/CMMS?

  • There 1,440 minutes in a day. For the next 12ish years, each minute inside

the dome should be allocated for and assigned to someone, on at least a weekly basis.

  • Account for time to stage large equipment, adjust environmental

conditions for tests, order parts, etc.

  • There will inevitably be a backlog so we will never run out of tasks to

fill the schedule.

  • Coordination of schedules for Planned Maintenance (Astronomers, Operators,

Engineers, Safety, Maintenance Technicians, Contractors)

  • Interface to Issue Management System for handling Unplanned Maintenance.
  • Interface to Inventory Management system for parts and materials ordering.
  • Monitor trends, generate daily reports and ad-hoc alarms as needed.
slide-3
SLIDE 3

3

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

Needs for a Work Management System

  • Commissioning and Operations work on weekly and daily timescales needs to be planned.
  • Multiple Inputs:
  • Planned Work
  • Integration
  • Verification/Commissioning
  • Engineering
  • Maintenance
  • Calibration
  • Observing
  • Unplanned Work
  • Repairs
  • Issue Resolution
  • Priorities will change sometimes from day-to-day based on real time events.
  • A common, agile tool is needed to manage all of these inputs and plan work in a coherent

and safe manner.

slide-4
SLIDE 4

4

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

Inputs and Outputs

slide-5
SLIDE 5

5

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

What is the project deliverable?

LSE-30 OS-REQ-0077 04 Maintenance Activity Support Specification: In support of all maintenance activity, both predictive and preventive, the LSST Observatory shall implement the following systems:

  • Comprehensive problem reporting, tracking, and management system
  • Work order driven preventive maintenance support system (usually known as CMMS for

Computerized Maintenance Management System).

  • Warehouse inventory and property control
  • Document control center
  • Analysis tools for supporting predictive maintenance.

Message box example for short highlighted messages.

slide-6
SLIDE 6

6

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

One Subsystem…

LSE-61 TLS-REQ-0136 Telescope and Site Activity Support, Tracking and Reporting The Telescope and Site shall implement the following systems: Specification same as LSE-30, plus: The Telescope and Site shall maintain a permanent record of the description and time required to recover from all maintenance events. A set of automatic reports based on engineering telemetry shall be generated on a daily basis. NOTE: This requirement corresponds mostly to the OCS domain. T&S shall provide the necessary information to OCS for the maintenance management.

slide-7
SLIDE 7

7

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

What is a Work Order?

Work Order = Task + Resources

  • Tasks include: replacing coolant, updating software, cleaning

glass, etc.

  • Resources include: skilled people, procedures, facilities,

consumables, parts, tools, power equipment, etc.

slide-8
SLIDE 8

8

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

Work Order Components

slide-9
SLIDE 9

9

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

One Sample Task Implementation

slide-10
SLIDE 10

10

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

Varieties of CMMS Implementation

SAP-like Excel + Excellence

  • Large amount of effort and resources
  • Typically team of 30+ members for a year
  • r more
  • Large cost
  • Significant ongoing maintenance cost
  • Significant cost of implementing change
  • Large training effort involved
  • Heavily dependent on individual people,

representing a single point of failure and long ramp up for replacements or supplements.

  • Little or no integration of tools, requiring other

SMEs for different types of tools.

LSST (AURA)-Hybrid

  • Reduced initial cost due to use of existing tools

and processes.

  • Reduced ongoing maintenance costs due to use
  • f existing tools and contracts.
  • Challenges include the population of data and

integration of systems.

slide-11
SLIDE 11

11

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

Subsystem View

slide-12
SLIDE 12

12

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

A Common Tool for the Life of LSST

Plan of the Day Workflow for Operations Workflow Inputs for Commissioning Daily Tasks

System Level Verification Plans Technical Optimization of System Operations Scientifically Motivated Performance Characterization Emergent Technical Issues

Scheduled Maintenance

In-situ Issue Resolution

  • LSST will develop a single tool that meets the Work Management

needs during Commissioning and Operations.

slide-13
SLIDE 13

13

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

Challenges

  • Deliverable description (capability of system)
  • Development, verification and control of the BOM, as well as

the many maintenance and safety procedures.

  • Population and control of parts lists
  • Procurement pipeline and supply chain
  • Some parts and materials take longer to reach Chile
  • Some materials have restrictions
slide-14
SLIDE 14

14

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

Road Map

  • Clarify project expectations.
  • What is the deliverable? Processes, Tools, Procedures, Infrastructure,

etc.

  • Specification/Requirements development and approval.
  • Tool design and review, procurement, planning, resource allocation
  • Implementation, population and verification
  • Plan for maintenance of the system (updates, process implementation an

changes in tool).

slide-15
SLIDE 15

15

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018 A Recommended Implementation with Existing Tools

slide-16
SLIDE 16

16

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

Verification in WMS

slide-17
SLIDE 17

17

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

Verification in WMS – MagicDraw MBSE Tool

  • Source of all project-controlled

requirements (specifications & ICDs)

  • Source of all Verification Plans
  • Source of data for Verification Matrices
slide-18
SLIDE 18

18

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

Verification in WMS – Syndeia Inter-Tool Element Transformations

  • Auto-generates Verification Tickets in JIRA from MagicDraw VerificationPlan elements

and attributes

  • Two-way synchronization
  • Feeds verification results to MagicDraw to generate final verification matrices (VM-F)
  • Verification is a component of Maintenance and has parallel and interlinking processes.
slide-19
SLIDE 19

19

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

Maintenance in WMS

  • Map Maintenance Plans to Maintenance Tasks (test

cases)

  • Generate Maintenance Steps (scripts) for each Task

(Plan)

  • Sequence Tasks into Maintenance Worklists
  • Execute Worklists
  • Address failures with issue tickets
  • Sync results back to MagicDraw
slide-20
SLIDE 20

20

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

JIRA Workflow for Maintenance Tickets

  • System Maintenance Team (SysMT)

responsible for upfront planning

  • Generation of Maintenance Plans
  • Mapping to Acceptance and

Closeout Events (Tasks)

  • Definition of Closeout Events

CCT SysMT SysMT SysMT + Systems Scientist

  • Tickets get assigned to individuals

responsible for the work. SysMT executes the Closeout Events and Analyzes Results

  • SysMT works with the Systems Scientist

and Shift Lead to Schedule activities

  • SysMT Reviews the results and makes the

determination on the sufficiency of the results to close out the Closeout Event

  • SysMT tracks closeout progress
slide-21
SLIDE 21

21

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

Prototype Tool

  • <<Insert Video>>
slide-22
SLIDE 22

22

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

Considerations During Implementation

  • Cross agency (observatories) cooperation. Similar activities, process, maintenance

procedures, safety, quality processes and engineering tools are currently independently developed and “uniquely” implemented.

  • Effort (and other resources) expended to develop and refine working processes and tools

may be shared.

  • Preserve this organizational (AURA-wide) legacy for ongoing and future projects
  • Mandatory Organizational Processes and Tools to be developed, purchased…or shared.
  • Management/Planning/Scheduling/Budgeting
  • Maintenance, Repairs and Issues
  • Quality, Manufacturing and Procurement Processes, Safety Policies and Implementation
  • Configuration Management (Mission critical documentation, Drawings, Software, etc.
  • Resource Coordination (specialized equipment staging, calibrations, etc.)
slide-23
SLIDE 23

23

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

Additional Information

Confluence Pages: https://confluence.lsstcorp.org/display/LSSTCOM/Work+Management+System https://confluence.lsstcorp.org/pages/viewpage.action?pageId=9928805 Specification: LSE-TBD Maintenance Express: http://expresstechnology.com/express-maintenance-software/

slide-24
SLIDE 24

24

LSST Project and Community Workshop 2018 • Tucson • August 13 - 17

#lsst2018

Systems Engineering
