Who’s In Control of Your Control System? Device Fingerprinting for Cyber-Physical Systems

David Formby, Preethi Srinivasan, Andrew Leonard, Jonathan Rogers, Raheem Beyah NDSS 2016

Presented by: Yi Zhang October 18th, 2016

Cyber Physical Systems (CPS)

Cyber

Personal Computers Mobile Phones Embedded Devices

Physical

Motors, pumps, Generators, Valves, Relays…

CPS

Cyber Physical Systems (CPS)

• Home automaPon

– LighPng, locks, thermostat, security system

• Industrial control systems (ICS)

– Power grid, water/sewage, oil/gas, manufacturing, supervisory control and data acquisiPon (SCADA) – Cyber-based compromise can lead to physical harm – Current ICS is filled with vulnerable, legacy devices

Motivation

• ICS are vulnerable to false data

and command injecPons

– push system into unsafe state, cause physical harm – Previous fingerprinPng work not suited for ICS – TradiPonal IDS have limitaPons

Illustration of simple false data injection

• CPS fingerprinPng helps defend against these a\acks

Threat Model and Goals

• Two a\acker models

– Compromised node

• Stuxnet

– Physical access

• Weak physical security
• Goal

– Develop accurate fingerprinPng methods to idenPfy what type of device the responses are originaPng from.

CPS Fingerprinting in ICS

• Data AcquisiPon FuncPons

– Cross Layer Response Time (CLRT) – EsPmate device processing Pme – Black Box Model fingerprints

• Control FuncPons

– Physical fingerprinPng – EsPmate physical operaPon Pme – Black Box Model fingerprints – New class of fingerprinPng - White Box Modeling

Cross-Layer Response Time (CLRT)

• Fingerprints devices from data

acquisiPon traffic

• EsPmates device processing

Pme

– Time between TCP ACK and SCADA response – StaPc and unique distribuPon

• Fast links (100Mbps) with slow devices,

slow and regular traffic

Adversary cannot simply respond faster to beat IED, must match the CLRT fingerprint

• Use a real world dataset before and ader changes in the network
• AddiPonal capture from another substaPon with different network

architecture

• CLRT measurements taken from DNP3 polling requests

CLRT Experiment

CLRT Results

Same hardware, different software

CLRT Results

• Uses FF-ANN
• Time slices as small as 5 mins

– Average accuracy 93%

• Supervised Bayes classifier

performs even be\er

• Unsupervised learning also works

well

CLRT Results

• Network architecture found to have minimal effect

Training Data – Original dataset Testing Data – Upgraded network Training Data – Original dataset Testing Data – Different substation

Physical Fingerprinting

• Fingerprint devices from

control traffic

• EsPmate physical operaPon

Pme

– Time between command packet and event Pmestamp – Requires Pme synchronizaPon

• Black Box and White Box

Methods

Adversary must guess what event timestamp to respond with

Physical Fingerprinting Setup

• Relays – Typically used to open or close higher voltage circuits

with a lower voltage signal. Common device in ICS and analogous to large scale circuit breakers

Relays used in testbed, nearly identical specifications Testbed setup

Physical Fingerprinting Results

No obvious differences between Open operations due to nearly identical ratings. Clear differences in Close

• perations allow for device

fingerprinting.

Physical Fingerprinting Results

White Box Modeling

• Black Box Modeling somePmes

infeasible

– Operate infrequently, no physical access

• Construct physical model and

esPmate parameters

Current in coil Magnetic field Permanent magnet force Equation of motion Coil Force

White Box Modeling Results

Reduced accuracy, but could be refined as true samples become available

• Two classes of adversary

– Weak adversary : compromise one of the low powered devices – Strong adversary: gain physical access to the network

• The adversary is assumed to have gathered accurate samples

Robust Against Forgery

Conclusion

• Novel passive fingerprinPng techniques for ICS

– Data acquisiPon and control – 99% and 92% classificaPon accuracy – Inventory and complemenPng tradiPonal IDS – Resistant to simple mimicry a\acks

• New class of fingerprinPng – White Box Models
• Future work

– Internet of Things, developing white box methods

Discussion

• What is the contribuPon of the paper?
• What are the limitaPons of the paper?
• How is ICS different from other systems?
• How to improve the white box modeling?
