What is Arduino Italian Company, Since 2005 Mini-Computer Support DIY Well-known for Hardware Why Arduino Low Cost Open Source Easy to Use Technology is No Professional

SLIDE 1

深圳市创客工场科技有限公司

SLIDE 2

Italian Company,

Since 2005

Mini-Computer
Support DIY
Well-known for Hardware

What is Arduino

SLIDE 3

Low Cost

Why Arduino

Open Source
Easy to Use

Affordable for general public Technology is accessible for everyone No Professional background required

SLIDE 4

Good Compatibility

Based on Arduino

Same Brain (MCU Chip) to Control Same Software to Program Compatible to Other Famous Brands

SLIDE 5

MCU Chip Atmega 328p mCore Orion mBot

MCU Chip on Makeblock Board

Arduino Uno

Starter Robot Kit Music Robot Kit

XY Plotter

SLIDE 6

MCU Chip Atmega 2560 Me Auriga Mega Pi mBot Ranger

MCU Chip on Makeblock Board

Arduino Mega

Ultimate 2.0 mGiraffe 3D Printer

SLIDE 7

Makeblock Platform (3 Parts)

SLIDE 8

Platform-Machinery

Structure and Actuator

Aluminum, Anodizing, Solid ,Thread Groove Multifunction Component with Practical Design Industrial Standard, High Compatibility Over 200 types, Allow Infinite Combination

SLIDE 9

Platform-Machinery

Beam

Type Length(mm) Hole Number Beam0824-016 16 2 Beam0824-032 32 4 Beam0824-048 48 6 Beam0824-064 64 8 Beam0824-080 80 10 Beam0824-096 96 12 Beam0824-112 112 14 Beam0824-128 128 16 Beam0824-144 144 18 Beam0824-160 160 20 Beam0824-176 176 22 Beam0824-192 192 24 Beam0824-496 496 30 Short Beam 0824 Pack 64,80,96,112,128 8,10,12,14,16 Medium Beam 0824 Pack 144,160,176,192 18,20,22,24

Character:

◆ Holes on 16mm Increments ◆ M4 Thread Holes on Both Ends

Name : Beam 08 24 - 016 Height Width Length

SLIDE 10

Platform-Machinery

Power Output (Different Demand)
1. Simplicity
3. Run Fast
4. Joint Rotation
2. Accuracy
DC Motor
Servo Motor
Encoder Motor
Step Motor

SLIDE 11

Platform-Electronic

Over 30 Practical Sensors

Ultrasonic Sensor 7-Segment Display RGB LED Dual DC Motor Driver 4 Button Step Motor Driver

◆Sensing ◆Driver ◆Display ◆Input

Joystick Line Follower

SLIDE 12

Platform-Electronic

Great Compatibility

◆ Most of electronic modules are equipped with M4 holes, mounting to Makeblock mechanical structural parts ◆ The modules have holes for DIY Dupont wire, and they are ideal ports for users that want to connect the modules to other development board.

SLIDE 13

Platform-Electronic

RJ 25 Port

Highlight Structure

◆ 6 pins integrated in 1 port, support most of our sensors ◆ 3 various length: 20cm, 35cm, 50cm No more complex Dupont wiring Color identification, more accurate and funny Rapid construction, suitable for teaching

SLIDE 14

Platform-Software

PC Software

1. Arduino IDE 2. mBlock

◆ Support the program software designed by Arduino company, Makeblock also provides some practical demo codes for users ◆ Based on Scratch 2.0 software, simply combine different graphs and then finish the program. User can also design the animation.

SLIDE 15

Platform-Software

Mobile Devices App— IOS & Android

◆ Portable: Users are able to design the program on iPad or other tablet ◆ Convenient: The robots can be controlled by smart phones or tablets through App

※ apps are available from App Store and Google Play

SLIDE 16

Summary

The reasons why Makeblock is based on Arduino
Several Makeblock control boards and its

corresponding products

Understand the 3 sections of Makeblock platform
