Welcome to Disnflex

May 2010

 Plant  Equipment  Team  Applications

3

10 years exclusive license agreement Menzolit will support Disnflex in following ways providing formulations giving know how on production process control advising quality control sharing R&D results Disnflex is authorized to use Menzolit logo for all products made in Disnflex

Menzolit and Disnflex

Menzolit over the Changing Times

Establishment of Menzolit . . Establishment of Menzolit S.a.r.l., France . . Establishment of Menzolit C.V. S.A.S., France Trademark Licence Agreement with Cray Valley, Korea Takeover of the C. V. S.A.S. , France Takeover by Plastal Group Technology Transfer Agreement with FBMix, Brasil Establishment of Menzolit Compounds (Shanghai) Co Ltd Takeover by Senata Group Exclusive License Agreement with Disnflex, China Cooperation with Rodgers Engineering Corp., USA Takeover of DSM Compounds Merger to Menzolit-Fibron GmbH 1995 1997 1998 1999 2000 2000 2001/02 2005 2006 2007 2008 2009 2010 Separation from Menzolit-Fibron GmbH (Mouldings)

International presence and cooperation of Menzolit

UK-Eastwood Products: SMC, BMC PRC- Shanghai Cooperation with: Disnflex Exclusive licensing for Asian market Products: SMC, BMC Cooperation with F.B. Mix Licensing: Technical know-how Brazil I-Turate Products: SMC, BMC E-Granollers Products: SMC Germany Head Office

Production facility cooperation Headquarters

5 10/05/2010

Plant

 Registered capital : 15 million RMB  Total investment : 22 million RMB  Location:

Jinshan, Shanghai

 Plant area:

3200 square meters

Plant Layout

Plant Tour

Plant Tour

Equipment

Compounding equipments based on our proprietary process technology

Two BMC lines – Annual capacity 6000 tons( three shifts )

• - 3 steps process
• pre-blending
• mixing
• extruding for each batch

Equipment

Compounding equipments based on our proprietary process technology

One SMC line – Annual capacity 10000 tons ( three shifts )

• - A + B on line metering system for thickening
• - Metal detector
• - Constant flow at pump

Lab equipment

Color measurement Reactivity measurement Thickening measurement Moisture content measurement Mechanical Testing

A glimpse on the future



• - X ray sheet weight measurement for SMC machine



• - Full process automation

automatic filler handling Resin dispensing system Automatic data collection

Team

General Manager Thomas He Sales Director Thomas He Area Sales Manager Xiaojianzhong Area Sales Manager Eric Yan Assistant GM Lucy Song Production Manager Alan King Production Supervisor Zhang Chunqiang Equip. Maintenance Open Supply Chain Manager Amanda Li Customer Service Rachel Liu Purchasor Amanda Li Ware house Supervisor Zhang Chunqiang Financial & Administrative Manager Erin Ding Cashier Grace Lu Quality Manager Eric Yan QC Gu Jiping Technical Director Jon Hu Lab Manager Jon Hu Lab Technician Zhang Wei

Proven, experienced and well trained professionals

Quality

 We commit to obtain ISO 9001 approval by year 2010  We commit to obtain TS 16949 approval by year 2015

What we can offer

 Full range of products for various applications in

SMC&BMC

a)

Electrical ( appliance, circuit breakers, electrical contactor )

b) Automotive ( external body panels, engine components, head lamp

reflectors, structural parts )

c)

Railway

d) Sanitary e)

Energy

All European SMC/ BMC engine components are based on Menzolit material

Oil pans Daimler heavy truck engine . Moulded by Peguform, material Menzolit SMC 1400

Valve covers made of BMC

Valve cover for GM Vortec V6 engine, moulded by Joh Rubber in Canada: Developed in cooperation with Menzolit.

Engine components made of BMC

Trottle body in BMC moulded in injection moulding for (BOSCH) Moulder Cristophery, Material Tetradur Vlave cover for Perkins diesel engine. Injectio0n moulded in UK. Material Menzolit BMC 1400

SMC & BMC Reduce Noise

Experimental valve cover. Moulded by Joh Rubber (Canada), Material Menzolit BMC 1400 Valve cover for Volvo heavy truck. Moulded by Menzolit-Fibron, material Menzolit SMC 1400 Noise panels for VW Polo . Moulded by Menzolit-Fibron, material Menzolit SMC 0200 Micro filter housing . Moulded by Peguform. Menzolit SMC 0300

SMC/BMC in electrical applications

Other applications SMC, BMC in passenger cars

 Perfect surface  Paintable  Parts integration  Light weight  Low system cost

SMC in commercial vehicles

 Paintable  Weathering resistance  Low moulding pressure  Low tooling cost  Low system cost  Parts integration  Low weight  No corrosion  Noise reduction  Temperature resistant  Resistant to oil, fuel & all engine chemicals

SMC in rail way applications

 Very high fire retardancy  No toxic smoke  Very low smoke  Low moulding pressure  „Vandal“ resistant  Stiffness  Strength  Low weight

The product. The material. The solution.



The product: composite materials based on resin, mineral filler and reinforcing fibres.



The material: SMC Sheet Moulding Compound BMC Bulk Moulding Compound HPC High performance Compound MMC Mineral moulding Compound AdvancedSMC Continuous carbon fibre reinforced compound CarbonSMC Chopped Carbon Fibre reinforced compound



The solution: Our technology for your specific application.

25



Experienced and well trained team to provide world class service

a)

Faster response

b)

Proven professionals

c)

Dedicated to compounding

What we can offer

DISNFLEX COMPOSITES ( SHANGHAI ) CO., LTD.

TEL: ++ 86 21 67256099 FAX: ++ 86 21 67256096 EMAIL: webmaster@disnflex.com WEBSITE: www.disnflex.com ADDRESS: No. 48, PingYe Road, MeiBao Industrial park, Jinshan District, Shanghai 201507, China
