CONSTRUCTION MISSION AND VALUES The purpose of our work is success of partners. Constantly expanding our network of branches we are trying to be even closer to them. Our product range expands every year and is not limited only to components for production of windows. We keep abreast of the latest technical developments. Employees of our company are regularly trained and transfer knowledge to customers and partners. We provide only high quality products that have established themselves on the Russian market of PVC systems. In the daily competition we improve the quality of work and production. ABOUT US The German company ARtec is specializing in the production of PVC profiles and distribution of components for production of windows and doors and exists in the window market since 1995. During this time the company has established itself as a reliable manufacturer of quality profiles and a comprehensive supplier of window hardware, related materials and accessories. Our company has 30 branches: 16 in Russia, 9 in Ukraine and 5 in Kazakhstan. There is a representative office in Belarus. For the present we are one of the few companies with such a wide network of branches in Russia and CIS countries. This allows us to organize an individual approach to customers and to implement a prompt resolution of any issues. The presence of our employees in the regions contributes to the effective and successful cooperation because we understand the needs of partners given the characteristics of the particular region

ARtec — A RELIABLE MANUFACTUERER AND SUPPLIER

The program of cooperation with partners of the company ARtec includes a whole range of

• ffers and services:

1.Full range of profiles and accessories for production and installation of windows and doors.

• 2. Goods delivery in any point of Russia and CIS.
• 3. Technical maintenance in launching the new production and re-equipment of the existing

production.

• 4. Technical support of our customers in production issues.
• 5. Assistance in the design of products for individual orders.
• 6. Training of the personnel responsible for promotion of products, installation and service.
• 7. Provision of software for the production.
• 8. Marketing assistance.

In Russia the company owns its factory, which produces profiles on modern equipment with the use of technological innovations in the industry. Components used for the preparation of the blend for manufacturing of the profiles are mainly of European origin so the quality of products consistently meets the requirements of the standards and often exceeds them. The development of profile systems, production management as well as control of technological process and quality are carried out by German experts at the factory in Tver. We offer our partners original systems of PVC profiles ARtec for production of windows and doors, hardware, materials for the production of insulating glass as well as accessories for mosquito nets.

ARtec EXTRATHERM/EFFECTIV Premium-class systems

Modern energy saving systems, that meet the highest requirements for heat and sound insulation Advantages:

• The height of the surfacing with no analogues on

the Russian market is 25 mm and eliminates fogging

• f the edge zones of insulating glass.
• The mounting width of 70 mm and optimal

arrangement of 5 chambers provide a high level R0=0,8 m²°С/W.

• 13 mm hardware groove provides more secure

protection against burglary (Drawing 1).

• The gasket forms an additional air chamber that

allows to absorb shocks when closing the sash and eliminates sticking in the winter (Drawing 2).

• Universal static, coupling and bay profiles are

applicable both for 60 mm and 70 mm systems.

• There is a possibility of concealed and open

condensate drainage system (Drawing 3).

• Available for order are profile systems with pre-

inserted TPE grey gasket.

• The standard product range includes color profiles

in the mass of brown and caramel for further lamination according to RENOLIT and LG catalogues. Main characteristics:

• The thickness 2,5 mm (B class) –

for EXRTRATHERM system.

• The thickness 3 mm (A class) –

for EFFECTIV system.

• Construction depth 70 mm.
• 5 air chambers.
• Possibility of installation

Insulating glass with thickness till 42 mm.

• Resistance to heat transfer

R0 = 0,8 m²°С/W.

• Resistance to wind load, to water

and air permeability till A class according to GOST 23166.

• Sound insulation till В class

according to GOST 23166.

• Range of application from -60°С

to +75°С.

• Service life 60 years.

ARtec EVOLUTION/CLASSIC Classic window systems

For use in individual and mass construction.

Advantages:

• 13 mm Hardware groove provides more secure

protection against burglary (Drawing 1).

• The gasket forms an additional air chamber that

allows to absorb shocks when closing the sash and eliminates sticking in the winter (Drawing 2).

• Simplified technology of mullion attachment reduces

the production time.

• Universal static, coupling and bay profiles are

applicable both for 60 mm and 70 mm systems.

• There is a possibility of concealed and open

condensate drainage system (Drawing 3).

• Available for order are profile systems with pre-

inserted TPE grey gasket.

• The standard product range includes color profiles in

the mass of brown and caramel for further lamination according to RENOLIT and LG catalogues. Main characteristics:

• The thickness 2,5 mm (B

class) – for EVOLUTION system.

• The thickness 3 mm (A class) –

for CLASSIC system.

• Construction depth 60 mm.
• 3 air chambers.
• Possibility of installation of

insulating glass with thickness till 34 mm.

• Resistance to heat transfer

R0 = 0,64 m²°С/W.

• Resistance to wind load, to

water and air permeability till A class according to GOST 23166.

• Sound insulation till В class

according to GOST 23166.

• Service life 60 years.

ARtec ADVANCE ECO/SOLAR ECO Window systems with increased light

• pening

For use in individual and mass construction.

Advantages:

• Increased light opening due to the improved profile

geometry.

• 13 mm hardware groove provides more secure

protection against burglary.

• The gasket forms an additional air chamber that

allows to absorb shocks when closing the sash and eliminates sticking in the winter.

• Universal static, coupling and bay profiles are

applicable both for 60 mm and 70 mm systems.

• There is a possibility of concealed and open

condensate drainage system.

• Available for order are profile systems with pre-

inserted TPE grey gasket.

• The profiles are produced according to COEX

technology which fully meets the requirements of European environmental standards. Main characteristics:

• The thickness 2,5 mm (B

class) – for ADVANCE ECO system.

• The thickness 3 mm (A class) –

for SOLAR ECO system.

• Construction depth 60 mm.
• 3 air chambers.
• Possibility of installation

Insulating glass with thickness till 34 mm.

• Resistance to heat transfer

R0 = 0,65 m²°С/W.

• Resistance to wind load, to

water and air permeability till A class according to GOST 23166.

• Sound insulation till В class

according to GOST 23166.

• Service life 60 years.

Advantages:

• A high level of sound insulation.
• 13 mm hardware groove provides more

secure protection against burglary (Drawing 1).

• The use of amplifiers of welding joints allows

to produce door constructions of bigger size and weight.

• There are sash profiles for doors, which open

inwards and outwards.

• The standard product range includes color

profiles in the mass of brown and caramel for further lamination according to RENOLIT and LG catalogues. Main characteristics:

• The thickness 3 mm (A class)
• Construction depth 60 mm.
• The height of frame 78 mm
• The height of sash 108 mm.
• Two circuits of gaskets.
• 3 air chambers in the frame.
• Locks with dornmass 35 mm.
• Resistance to heat transfer

R0 = 0,63 m²°С/W.

• Service life 60 years.

ARtec TS 60 Reliable door system.

For production of entrance and interior doors

ARtec CONZEPT Conceptual system of the future

Innovative system that allows to produce windows of the future.

Advantages:

• The mounting width of 82 mm and optimal

arrangement of 7 air chambers provide the highest level of thermal insulation.

• The height of the surfacing of 24 mm eliminates

fogging of the edge.

• The possibility of using a special non-metallic

reinforcement as well as reinforcement with thermal break to obtain the highest level of thermal insulation.

• 13 mm hardware groove provides more secure

protection against burglary.

• Additional central gasket ensures no blowing and

forms a supplementary air chamber providing higher resistance to heat transfer (Drawing 1). Main characteristics:

• Construction depth 82 mm.
• 7 air chambers.
• 3 gasket levels.
• Center span 13 mm.
• Possibility of installation

Insulating glass with thickness till 52 mm.

• The coefficient of sound

insulation up to 47 Db.

• Resistance to heat transfer

R0 > 1 m²°С/W.

ARtec – RELIABLE MANUFACTURER AND SUPPLIER

When developing our products we are thinking about tomorrow. Due to introduction of modern technologies profile systems ARtec meet the most stringent industry requirements. We are always attentive to the needs of our customers and anticipate their expectations. The company ARtec is focused on business development in the present and future. As a modern and growing company we are constantly working to improve product quality, to expand the range and to develop new profiles. All our profile systems have high sound insulation, energy saving as well as resistance to water and air permeability. Ecological safety and high quality of profile systems ARtec are confirmed by corresponding certificates. Traditional German thoroughness and reliability combined with the dynamism and the efficiency of our work makes cooperation with the company ARtec promising and profitable. We will be glad to see you among our partners.
