innovation through engineering and scientific excellencesince 1985 Robert Bourke, Natalie Waters, and Jordon Moniuszko Water Resource Sustainability Issues on Tropical Islands December, 2015 Estuary Rehabilitation Stream Flow

slide-1
SLIDE 1

…innovation through engineering and scientific excellence…since 1985

Robert Bourke, Natalie Waters, and Jordon Moniuszko

Water Resource Sustainability Issues on Tropical Islands

December, 2015

slide-2
SLIDE 2

Estuary Rehabilitation Stream Flow Restoration to

Kaelepulu Estuary

slide-3
SLIDE 3
slide-4
SLIDE 4

Kailua Bay

1,000 BC

1 Km

slide-5
SLIDE 5

Kawai Nui Swamp Kaelepulu Pond Kailua Bay

1928

1 Km

slide-6
SLIDE 6

Kawai Nui Swamp Kaelepulu Pond Kailua Bay Kaelepulu Pond Kawai Nui Swamp

1928

slide-7
SLIDE 7

1952

1 Km New Channel

slide-8
SLIDE 8

1952 1966

1 Km

slide-9
SLIDE 9

1952 1966

slide-10
SLIDE 10

1952 1966 1990

slide-11
SLIDE 11

1958

slide-12
SLIDE 12
slide-13
SLIDE 13
slide-14
SLIDE 14
slide-15
SLIDE 15
slide-16
SLIDE 16
slide-17
SLIDE 17

ESTUARY CHALLENGES

  • EXCISED FROM

HEADWATER FLOWS

  • DECREASED

STREAM MOUTH EXCHANGE

  • BATHYMETRY

CHANGES

  • URBAN STORM

WATER FLOWS

  • INVASIVE

SPECIES

slide-18
SLIDE 18

ESTUARY CHALLENGES

  • EXCISED FROM

HEADWATER FLOWS

  • DECREASED

STREAM MOUTH EXCHANGE

  • BATHYMETRY

CHANGES

  • URBAN STORM

WATER FLOWS

  • INVASIVE

SPECIES

slide-19
SLIDE 19

ESTUARY IS ONLY EXPOSED TO TIDAL FLOW ON A PERIODIC BASIS MANUAL OPENING OF STREAM MOUTH ON ~MONTHLY SCHEDULE BY C&C HONOLULU

slide-20
SLIDE 20
slide-21
SLIDE 21
slide-22
SLIDE 22

Total Tidal Inflow 0.23 M cuft

slide-23
SLIDE 23

Total Tidal Inflow 21x103m3 Total Tidal Inflow 0.23 M cu ft Total Tidal Inflow 0.75 M cu ft Timing of Stream Mouth Opening to Maximize Initial Outflow Results in an Increase of Total Exchange

slide-24
SLIDE 24

ESTUARY CHALLENGES

  • EXCISED FROM

HEADWATER FLOWS

  • DECREASED

STREAM MOUTH EXCHANGE

  • BATHYMETRY

CHANGES

  • URBAN STORM

WATER FLOWS

  • INVASIVE

SPECIES

slide-25
SLIDE 25

SHOALING OF STREAM CHANNEL AT POND OUTFLOW INHIBITS TIDAL FLOW OF SALT WATER TO THE POND

slide-26
SLIDE 26

ESTUARY CHALLENGES

  • EXCISED FROM

HEADWATER FLOWS

  • DECREASED

STREAM MOUTH EXCHANGE

  • BATHYMETRY

CHANGES

  • URBAN STORM

WATER FLOWS

  • INVASIVE

SPECIES Being addressed through

State TMDL City NPDES

slide-27
SLIDE 27

ESTUARY CHALLENGES

  • EXCISED FROM

HEADWATER FLOWS

  • DECREASED

STREAM MOUTH EXCHANGE

  • BATHYMETRY

CHANGES

  • URBAN STORM

WATER FLOWS

  • INVASIVE

SPECIES

A 2004 ELRA $24K – 319 Grant B 2009 KCC $29K – Hi. Comn. Foundation & Castle Foundation C 2016 (?) C&C $750K State funded

A B C

slide-28
SLIDE 28
slide-29
SLIDE 29

Of the principle problems confronting the estuary:

  • Pollutant flows from urban storm drains
  • Poor salt wedge penetration into pond
  • Poor exchange at stream mouth
  • Invasive Species (mangrove)
  • Lack of sufficient water flow

Improving water flow was deemed likely to provide the greatest benefit with the least effort.

slide-30
SLIDE 30

2.0 1.0 22.5 1.0

NOTE: All volumes given in millions of cubic feet

Estuary Area – 526,300m2 135 acres Volume – 750,000m3 = 26.5 Mft3 Volume of 8-inch (0.2m) tidal inflow – 106,000m3 = 3.7 Mft3

slide-31
SLIDE 31

CLASSICAL SALT WEDGE AND EXCHANGE CURRENTS IN AN ESTUARY

slide-32
SLIDE 32

Lanikai Bridge (Kbay Tide) Water Height Ft. MLLW

1 2 3

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 Feet MLLW

Lanikai Bridge Water Turbidity

10 20 30 40 50

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 Turbidity NTU

Lanikai Bridge Water Salinity

10 20 30 40 50

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 Salinity PPT

Kaelepulu Rain per Hr

0.2 0.4 0.6 0.8 1 1.2 1.4

1 2 3 4 5 6 7 8 9 10 11 12 13 14

Days, Beginning Dec. 18, 2010

Rain Inch/Hr.

A B C D

DEPTH

TURBIDITY SALINITY RAIN

6 M cu ft

slide-33
SLIDE 33

PHYSICAL WATER QUALITY TRANSECTS OF ESTUARY CONDUCTED BEFORE AND AFTER EACH STREAM MOUTH OPENING EVENT T, Salinity, pH, NTU, Chl-a, PC, DO% @ 15 cm 30 cm 60 cm 120 cm 180 cm

slide-34
SLIDE 34

Beach Pond Channel

slide-35
SLIDE 35

Beach Pond Channel Shallows

slide-36
SLIDE 36

9/15/13 Salinity Kawainui Pre Opening 9/15/13 Salinity Kaelepulu

slide-37
SLIDE 37

9/26/13 Salinity Kawainui Post opening 9/26/13 Salinity Kaelepulu

slide-38
SLIDE 38

11/16/13 Salinity Kawainui – Pre opening 11/16/13 Salinity Kaelepulu

slide-39
SLIDE 39

9/15/13 Oxygen Kawainui Pre Opening 9/15/13 Oxygen Kaelepulu

slide-40
SLIDE 40

9/26/13 Oxygen Kawainui Post opening 9/26/13 Oxygen Kaelepulu

slide-41
SLIDE 41

11/16/13 Dissolved Oxygen Kawainui – Pre opening 11/16/13 Dissolved Oxygen Kaelepulu

slide-42
SLIDE 42

Salinity for 10 Sampling Events

Other Parameters Tracked:

  • Temperature
  • Dissolved Oxygen
  • pH
  • Turbidity
  • PC
  • CHL-A
  • Volume Exchange
slide-43
SLIDE 43

% Exchange = (SF-SI) / (35-SI)

slide-44
SLIDE 44

% Exchange = (SF-SI) / (35-SI)

slide-45
SLIDE 45

PROPOSAL TO TEST FLOW RESTORATION BY INSTALING TEMPORARY SIPHON OVER LEVEE ~ 6 L/s

slide-46
SLIDE 46

2 ft3/sec  5.2 M ft3/Month  ~1 ft Rise (- Evaporation)

slide-47
SLIDE 47

2 ft3/sec  5.2 M ft3/Month  0.9 ft Rise (- Evaporation)

slide-48
SLIDE 48

Construction of Four 6-inch PVC Siphons over Levee

slide-49
SLIDE 49
slide-50
SLIDE 50

TEST TRIAL IS HYPOTHESIZED TO DEMONSTRATE THAT THE FLOW RESTORATION WILL

  • Increase monthly water exchange in the Kawainui

Stream Channel thereby improving water quality

  • Increase volume and period of exchange with the
  • cean by enhanced opening head and flow

dynamics

slide-51
SLIDE 51

Experiment Duration Control Portion of Experiment Marsh Water Surface Rate of Fall = 0.20 inch/da Marsh Water Surface Rate of Fall = 0.2 to 0.34 inch/da

WATER SURFACE ELEVATION OF KAWAINUI MARSH SOURCE WATER

slide-52
SLIDE 52

WATER SURFACE ELEVATION OF KAWAINUI STREAM SHOWING STREAM MOUTH OPENING PERIODS

0.5 1 1.5 2 2.5 3

J F M A M J J A S O

Water Surface Elevation, Feet MLLW

Months, 2015

Kaelepulu Water Surface Elevation, 2015 Feet MLLW Syphons ON

slide-53
SLIDE 53

WATER SURFACE ELEVATION OF KAWAINUI STREAM WAS ABOVE FLOOD THREAT LEVEL ON THREE OCCASIONS

0.5 1 1.5 2 2.5 3

J F M A M J J A S O

Water Surface Elevation, Feet MLLW

Months, 2015

Kaelepulu Water Surface Elevation, 2015 Feet MLLW

Periodsof Increased Flood Threat due to High Water Surface Elevation

Stream Mouth Openings

Syphons ON

slide-54
SLIDE 54

WATER SURFACE ELEVATION OF KAWAINUI MARSH SOURCE WATER

slide-55
SLIDE 55

WATER SURFACE ELEVATION OF KAWAINUI MARSH SOURCE WATER

~ 3M cu ft Water Transferred Each Month

slide-56
SLIDE 56
slide-57
SLIDE 57
slide-58
SLIDE 58
slide-59
SLIDE 59

3M cu ft

slide-60
SLIDE 60

FRESH WATER INFLOW SPREADS RAPIDLY ALONG THE SURFACE OF KAWAINUI STREAM AND DOWNSTREAM TOWARDS THE BEACH. VERTICAL MIXING OCCURS MORE SLOWLY MAINTAINING STRATIFICATION THROUGHOUT THE MONTH.

slide-61
SLIDE 61

FRESH WATER INFLOW APPEARS TO FLOW RAPIDLY ALONG THE SURFACE AND EITHER EVAPORATE OR SLOWLY MIX WITH LOWER WATER LAYERS AND MAINTAINING STRATIFICATION

slide-62
SLIDE 62

SYPHON INFLOW RESULTED IN GREATER STRATIFICATION OF THE ENTIRE STREAM

slide-63
SLIDE 63

DISSOLVED OXYGEN

REMAINED WELL BELOW 20% SATURATION IN THE KAWAINUI STREAM THROUGHOUT THE PERIOD OF INFLOW. D.O. WAS NOT DISTINGUISHABLE FROM CONTROL (NO SYPHON FLOW) CONDITIONS ABUNDANT MANGROVE ALONG THIS STREAM REACH ARE LIKELY RESPONSIBLE FOR THE LOW D.O.

slide-64
SLIDE 64

MANGROVE STANDS LINE THE CHANNEL WHERE DISSOLVED OXYGEN LEVELS ARE LOW

ABUNDANT MANGROVE ALONG THIS STREAM REACH ARE LIKELY RESPONSIBLE FOR THE LOW D.O.

slide-65
SLIDE 65

3 1

slide-66
SLIDE 66

Dr ain

Kawainui Marsh Kawainui

High Tide 2.0 ft

Low Tide 0.0 ft

Overflow Weir 2.0 ft Oneawa Canal Kawainui Stream 12” Pipe through Levee Level Control Drain pipe through levee from Kawainui Marsh to Kawainui Stream Level Control Drain pipe through levee from Kawainui Stream to Oneawa Canal

slide-67
SLIDE 67

QUESTIONS ?

slide-68
SLIDE 68

TRACE- CONTAMINANT STUDY BY USGS 41 SAMPLE SITES WITHIN ESTUARY 71 POLLUTANT TRACERS CAFFEINE FOUND AT 3 SITES

slide-69
SLIDE 69

TRACE- CONTAMINANT STUDY BY USGS 41 SAMPLE SITES WITHIN ESTUARY 71 POLLUTANT TRACERS CAFFEINE FOUND AT 3 SITES

slide-70
SLIDE 70

TRACE- CONTAMINANT STUDY BY USGS 41 SAMPLE SITES WITHIN ESTUARY 71 POLLUTANT TRACERS CAFFEINE FOUND AT 3 SITES
