Warm Welcome Matrix SETU VTEP Single Span VoIP to T1/E1 PRI Gateway

Introduction VoIP to T1/E1 PRI Gateway � Dedicated VoIP-ISDN PRI Gateway � Plug-n-Play device � VoIP access device for an existing PBX � PRI trunking for an IP-PBX

SETU VTEP - At a Glance SETU VTEP Sync In Network Clock Synchronization Sync Out ISDN - PRI ISDN - PRI TE/NT TE/NT ISDN WAN Port USB Port DC Power Jack Network Interfaces

Network Connectivity VoIP Connectivity 32 VoIP Channels 32 SIP Accounts VoIP Proxy Calls (SIP Accounts) VoIP Proxy Calls (SIP Accounts) ISDN PRI Connectivity Peer-to-Peer Calls (500 Entries) 1 ISDN PRI Software Configurable T1 and E1 PRI Programmable TE/NT

Target Customers END USERS BUSINESS VERTICALS � � System Integrators Corporate Offices � � Internet Telephony Service Providers Factories and Ware Houses � � Internet Service Providers Banks � IT and Technology Companies � Logistics Companies � Government Institutions � Hotels � Call Centers � Organizations with Remote Offices

APPLICATIONS APPLICATIONS Confidential

VoIP Access Device for Existing PBX T1/E1 PRI VoIP Access SETU VTEP ISDN ISDN ISDN PBX ISDN PBX Terminals Existing Infrastructure � VoIP access for legacy phone systems with T1/E1 PRI interface � Programmable TE/NT modes , so no configuration changes in the PBX � Retain existing PBX infrastructure and terminals � ISDN terminals can place calls directly over WAN network � Compatible with all legacy ISDN PBX

T1/E1 PRI Gateway for an IP-PBX ISDN PRI VoIP SETU VTEP IP- Phones IP- Phones IP-PBX IP-PBX IP based System � ISDN PRI trunking for IP based system � Deployable in all SIP based VoIP networks � Provide connectivity to traditional and wide spread ISDN PRI network

Peer-to-peer Calling Peer-to-Peer Call � VoIP without involving SIP proxy server � 500 Direct dial access codes � Dynamic DNS support ; no need of static IP address � Enables SOHO and SMEs to interconnect multiple sites without significant investment of telephony infrastructure at all sites

Virtual Trunking Accessibility Local PSTN Trunk Call Placed Accessibility over VoIP network

Virtual Trunking Accessibility � Connect multiple branch offices over cost-effective IP network � Virtually access trunk connectivity of remote location � Avoid heavy inter-network call charges � SETU VTEP can be registered to central IP-PBX � Leverage central IP-PBX resources and features remotely via SETU VTEP

DDI Routing over IP � Extends ISDN DDI service over IP from one location to other � Receive DDI calls directly on remote branch extensions � Route a callback over ISDN trunk–either from local branch or remote branch

KEY DIFFERENTIATORS KEY DIFFERENTIATORS Confidential

Compact Footprint � Compact and dedicated VoIP-ISDN PRI Gateway � Out-n-Out Gateway � 32 VoIP Channels � 1 ISDN PRI T1/E1 Channel ISDN PRI � Various mounting options � � Wall-Mount Wall-Mount � Table-Top � 19” Rack Mount VoIP SETU VTEP

Network Clock Synchronization � Dedicated Sync-In and Sync-Out port � Common clock source shared between PBX and SETU VTEP � No interoperability issues � No clock slips ~ no dropped calls: � Superior voice quality ISDN PRI Sync In Sync Out Master Clock NT TE Extns ISDN PBX SETU VTEP

Administrative and Configuration Ease � Fast and easy installation � No high level expertise required � Web–based remote management � Intuitive user interface � Quick access wizard for easy configuration Click Next to Configure Step- wise

Localization � Multiple language support � English � French � German � Italian � Portuguese � Spanish � Call Progress Tones and Detection � Country wise Call Progress Tones and Rings � Customize Tones as per Requirement � Country- Specific Date -Time Format , ISDN PRI Variants and CLIP variants � Day Light Saving Time

Key Benefits � Substantial communication cost reduction � Extended existing PBX capacity and capability � High on SOHO and SME wish list � Early Return on Investment � No need to replace legacy communication infrastructure � Cost-effective migration to IP telephony with lower CAPEX � Cost-effective migration to IP telephony with lower CAPEX � Fast and Easy Installation � Multi-site and Multi-branch connectivity for growing organizations � Enhanced administrative and configuration ease

Key Features Key Features

Allowed and Denied List � Allow or deny specific numbers from being dialed � Avoid misuse and restrict unproductive calls � Separate Lists for VoIP and ISDN PRI ports Automatic Number translation Automatic Number translation � Automatically translates the number to match with numbering plan of the destination network � User can dial without worrying about the network through which the call will be routed � Supported on VoIP and ISDN PRI ports

Call Detail Record � Monitor and Keep Record of Incoming and Outgoing Calls � Filters like Call Duration, Calling Number, Type of Port etc. helps in Call Analysis � Store details of 2000 calls � Back-up options in csv and text format Direct Dial-in Routing � Route Incoming Calls on SIP and ISDN PRI trunks to specific extension � Extend DDI Routing capability over IP among Remote locations � Avoid Operator Intervention � A boon for PBX without DDI functionality

Digest Authentication � Used to authenticate an incoming caller on SIP port � Restrict calls between a group of users � Automated authentication mechanism.; no need to manually enter passwords each time before placing calls � Ensure secured communication Enhanced Voice Quality � Toll quality voice with all industry standard codecs support � G.711 A-Law,µ-Law, G.723, G.729AB, GSM-FR codecs to ensure superior voice quality

Fax over IP � Send and receive real-time fax using cost-effective IP network � T.38 Fax and Pass-Through � No need of dedicated analog lines Return Call to Original Caller � Equipment intelligence stores details of called number along with extension number, � Equipment intelligence stores details of called number along with extension number, in case the called number is busy or unanswered � On call back from the called number, SETU VTEP automatically routes call to the same extension from where the call was attempted – No more lost business opportunities � SETU VTEP supports RCOC in both – VoIP and T1/E1 PRI Trunks

TR-069 Auto-Configuration � TR-069 is a Secure Remote Management Protocol � It is used for Auto-configuration and Remote management of the device at customer premises from an Auto-Configuration Server � It supports a variety of functionalities: � Dynamic Service Provisioning � Firmware Management � Firmware Management � Status and Performance Monitoring � Remote Diagnostics

Feature List � � Access Codes Least Cost Routing � � Allowed and Denied Numbers TR-069 Auto-Configuration � � Auto Provisioning for Mass Deployments NAT and STUN Support � � Automatic Number Translation PCAP Trace � � Call Detail Records (CDR) Peer-to-Peer Calling � � � � Call Progress Tone and Rings Call Progress Tone and Rings Return Call to Original Caller Return Call to Original Caller � � Daylight Saving Mode SNMP Monitoring � � Digest Authentication TLS and SRTP Support � � Emergency Number Dialing VLAN Tagging � � Fax over IP Web based Management

Matrix GATEWAY PRODUCT RANGE SETU VGFX Multi-port SIP based VoIP to GSM-FXO and FXS Gateway SETU VGB Multi-port SIP based VoIP to ISDN BRI Gateway SETU VFXTH Medium Density Multi-port SIP based VoIP to FXO-FXS Gateway SETU VFX Low Density Multi-port SIP based VoIP to FXO-FXS Gateway SIMADO GFX Multi-port GSM to FXS Gateway SIMADO GBR SIMADO GBR Multi-port GSM to BRI Gateway Multi-port GSM to BRI Gateway
