Walking in random Delaunay triangulation Nicolas Broutin Olivier - - PowerPoint PPT Presentation
Walking in random Delaunay triangulation Nicolas Broutin Olivier - - PowerPoint PPT Presentation
Walking in random Delaunay triangulation Nicolas Broutin Olivier Devillers Ross Hemsley 1 The problem random points 2 The problem Delaunay triangulation 2 Visibility walk The problem 2 Visibility walk The problem 2 Visibility walk
SLIDE 2
SLIDE 3
2
Delaunay triangulation
The problem
SLIDE 4
2
Visibility walk The problem
SLIDE 5
2
Visibility walk The problem
SLIDE 6
2
Visibility walk The problem
SLIDE 7
2
Visibility walk The problem
SLIDE 8
2
Visibility walk The problem
SLIDE 9
2
Straight walk The problem
SLIDE 10
2
Straight walk The problem
SLIDE 11
2
Vertex walk The problem
SLIDE 12
2
The problem How many visited triangles ?
Average on point distribution Worst case on walk choices Worst case on start and query
SLIDE 13
2
The problem Cone walk Results
P
- |walk| ≥ cst(|length|√n + log6 n)
- ≤ 1
n
|stretch factor| ≤ 3.7
Th.
|worst walk| = O(√n)
SLIDE 14
2
Visibility walk The problem Results
P
- |walk| ≥ cst(|length|√n + log3 n)
- |worst walk| = O(√n)
≤ e−cst·log
3 2 n
Th. Cor.
SLIDE 15
3
The difficulty
SLIDE 16
3
The difficulty
SLIDE 17
3
The difficulty
At a given step in the walk already some knowledge of unexplored part
SLIDE 18
3
The difficulty
At a given step in the walk already some knowledge of unexplored part Delicate dependencies to manage
SLIDE 19
4
Straight walk
[Devroye Lemaire Moreau, Bose Devroye]
SLIDE 20
4
Straight walk
[Devroye Lemaire Moreau, Bose Devroye]
Is edge p1p2 Delaunay and part of the walk ?
SLIDE 21
4
Straight walk
[Devroye Lemaire Moreau, Bose Devroye]
Is edge p1p2 Delaunay and part of the walk ? p1 p2 Half-moon graph give an upper bound
SLIDE 22
4
Straight walk
[Devroye Lemaire Moreau, Bose Devroye]
Is edge p1p2 Delaunay and part of the walk ? p1 p2 Half-moon graph give an upper bound Does not depend too much on other points
SLIDE 23
4
Straight walk
[Devroye Lemaire Moreau, Bose Devroye]
Is edge p1p2 Delaunay and part of the walk ? p1 p2 Half-moon graph give an upper bound Does not depend too much on other points |worst walk| = O(√n)
SLIDE 24
5
Cone walk
[Broutin, Devillers, Hemsley. AofA’14]
SLIDE 25
6
SLIDE 26
6
SLIDE 27
6
SLIDE 28
6
SLIDE 29
6
SLIDE 30
6
SLIDE 31
6
SLIDE 32
6
SLIDE 33
6
SLIDE 34
6
Vertex path in Delaunay
SLIDE 35
7
z q z′ y
If q far enough, cones do not overlap
SLIDE 36
7
z q z′ y
If q far enough, cones do not overlap One step is independant from previous ones
SLIDE 37
8
q y y′ z
Knowledge of previous step may influence ♯ points in disk
SLIDE 38
8
q y y′ z
Knowledge of previous step may influence ♯ points in disk But it can only goes down
SLIDE 39
9
Cone walk
SLIDE 40
9
Cone walk A lot of technical probability
SLIDE 41
9
Cone walk
♯ substeps in a step is expected constant
SLIDE 42
9
Cone walk
♯ steps is proportional to length
SLIDE 43
9
Cone walk
♯ neighbors is ok
SLIDE 44
9
Cone walk
dealing with boundary conditions
SLIDE 45
10
Cone walk Results
P
- |walk| ≥ cst(|length|√n + log6 n)
- ≤ 1
n
|stretch factor| ≤ 3.7
Th.
|worst walk| = O(√n)
SLIDE 46
11
Visibility walk
[Devillers, Hemsley]
SLIDE 47
12
Results
P
- |walk| ≥ cst(|length|√n + log3 n)
- |worst walk| = O(√n)
≤ e−cst·log
3 2 n
Th. Cor.
Visibility walk
SLIDE 48
13
First trick: progress measure by power
SLIDE 49
13
First trick: progress measure by power
Change in circle power
SLIDE 50
13
First trick: progress measure by power
d α ℓ Change in circle power
= 2dℓ sin α
SLIDE 51
13
First trick: progress measure by power
d α ℓ Change in circle power
= 2dℓ sin α
If d and α are not small then there is measurable progress
SLIDE 52
13
First trick: progress measure by power
d α ℓ Change in circle power
= 2dℓ sin α
If d and α are not small then there is measurable progress call this a good edge
SLIDE 53
14
Second trick: make boxes
SLIDE 54
14
Second trick: make boxes
SLIDE 55
14
Second trick: make boxes
definition of good edge Choose grid size
SLIDE 56
14
Second trick: make boxes
definition of good edge Choose grid size P(∃ a bad edge in cell 0) is small
SLIDE 57
14
Second trick: make boxes Few bad cells
SLIDE 58
14
Second trick: make boxes Few bad cells
not independant between neighboring cells
SLIDE 59
15
Third trick: color boxes
SLIDE 60
15
Third trick: color boxes
SLIDE 61
15
Third trick: color boxes
Being bad for cells of same color is independant with very high probability
SLIDE 62
16
Percolation
SLIDE 63
16
Percolation
Walk Bad cells
SLIDE 64
16
Percolation
Walk Bad cells
SLIDE 65
16
Walk Bad cells
look at the worst color
SLIDE 66
16
Walk
Percolation
Bad cells
percolation ⇒ there is a linear number on good cells look at the worst color
SLIDE 67
17
Is there a long walk in Delaunay triangulation ?
SLIDE 68
17
Is there a long walk in Delaunay triangulation ? Long walk in Delaunay triangulation → long walk in lattice → many bad cells in lattice → below percolation threshold
SLIDE 69
17
Is there a long walk in Delaunay triangulation ? Long walk in Delaunay triangulation → long walk in lattice → many bad cells in lattice → below percolation threshold Impossible by good choice of parameters
SLIDE 70
17
Is there a long walk in Delaunay triangulation ? Long walk in Delaunay triangulation → long walk in lattice → many bad cells in lattice → below percolation threshold Impossible by good choice of parameters Pretty bad constants in O
SLIDE 71
