Formal Verification of a Geometry Algorithm Yves Bertot October - - PowerPoint PPT Presentation

Formal Verification of a Geometry Algorithm

Yves Bertot October 2018

1 / 38

Outline

◮ Triangulation algorithm ◮ Abstract presentation and successive refinements ◮ Symmetries of the triangle and the convex hull

2 / 38

Triangulations and formal proofs

◮ Bigger context: robot motion

◮ Vorono¨

ı diagrams and Delaunay triangulation

◮ Dufourd&Bertot10 starts from an existing triangulation ◮ Dufourd&Bertot10 uses a specific data-structure

◮ darts: edge extremities ◮ two darts to make an edge, α0 ◮ darts around a point are connected, α1 ◮ A third permutation (α0 ◦ α1)−1 enumerates facets

◮ Astonishingly handy for implementation in C-like languages

◮ α0 and α1 are just pointers 3 / 38

Drawing with darts

α1 d0 α0 d1 d2 d5 d3 d4

◮ d0, d1, d2 and d3, d4, d5 form triangles ◮ unnamed darts form the outer boundary

4 / 38

A more abstract approach to triangulations

◮ Fix a finite set of points ◮ Each point has a pair of coordinates

◮ all operations on coordinates are deemed exact ◮ Only ring operations are necessary

◮ Describe a triangulation as a set of triangles ◮ Describe each triangle as a three-point set ◮ The formalized set theory we use has all basic set operations

◮ set difference, singletons, cardinal, union, intersection ◮ all sets are naturally finite and all operations are decidable 5 / 38

Crucial geometry property

◮ Given a segment [a, b], does c lie to the left or to the right? ◮ Knuth (1992) proposes to abstract this question as a single

predicate ccw (counter-clockwise)

◮ 5 basic properties (called Knuth axioms)

• 1. ccw(a, b, c) = ccw(b, c, a)
• 2. ccw(a, b, c) ⇒ ¬ccw(b, a, c)
• 3. card{a, b, c} = 3 ⇒ ccw(a, b, c) ∨ ccw(b, a, c)
• 4. ccw(a, b, d) ∧ ccw(b, c, d) ∧ ccw(c, a, d) ⇒ ccw(a, b, c)
• 5. ccw(a, b, c) ∧ ccw(a, b, d) ∧ ccw(a, b, e) ∧ ccw(a, c, d) ∧

ccw(a, d, e) ⇒ ccw(a, c, e)

◮ Axiom 3 is a property of the data: no three points aligned

6 / 38

Illustration of Axiom 4

a b d c

7 / 38

Illustration of Axiom 5

e d c a b

8 / 38

Implementing and proving ccw

◮ To every triangle we can associate an orientedsurface ◮ ccw just says that this oriented surface is positive ◮ the oriented surface is computed by a determinant ◮ ccw(a, b, c) =

 0 <

• 1

xa ya 1 xb yb 1 xc yc

• 



9 / 38

Discussion on numerical issues

◮ The assumption of exact numerical computations is

reasonable

◮ Operations for computing the counter-clockwise operation rely

• n polynomials with degree 2

◮ Limiting the precision for the inputs and using double precision

numbers is enough

◮ alternatively using 32-bit integers for inputs and 64 bit integers

for results

◮ In Coq itself, all computations are exact by default ◮ We have to use a discrete number ring to be algorithmically

relevant

10 / 38

Derived predicates

◮ Whether point d is inside a triangle abc can be described

using ccw

◮ The convex hull of a set A of points can be described using

ccw

◮ a sequence s0, . . . , sn such that, for every i and x different

from si, si+1, ccw(si, si+1, x) and similarly for ccw(sn, s0)

◮ it can also be described by giving s0 and the function f that

maps si to si+1 and sn to s0

11 / 38

Convex hull illustration s1 s6 s5 s4 s3 s2 s0 f f f

12 / 38

A naive triangulation algorithm

◮ Add points one by one ◮ When you have three points make the first triangle ◮ When the new point is in an existing triangle

◮ remove that one ◮ add 3 new triangles made with the edges of the old triangle

and the new point

◮ Otherwise, find the boundary edges that are separating

◮ For each such separating boundary edge, make a new triangle

by adding the new point

13 / 38

Naive algorithm illustration

14 / 38

Naive algorithm illustration

15 / 38

Naive algorithm illustration

16 / 38

Naive algorithm illustration

17 / 38

Mathematical formulation

◮ Blue step: find t ∈ T such that p is inside t ◮ T\{t} ∪ {t\q ∪ {p} | q ∈ t} ◮ Red step: ◮ T ∪ t∈T



     

q ∈ t, boundary(t\q) separated(t\q, p, q) {p} ∪ (t\q)

18 / 38

Proving properties of this algorithm

◮ First main specification

◮ All elements of the triangulation have 3 points ◮ The union of all triangles is the input set ◮ The whole convex hull is covered by triangles

◮ Need Geometry proofs ◮ Re-use Knuth’s approach to the convex Hull

19 / 38

Examples of proofs

◮ A point inside a triangle left of a segment is also left of the

segment Lemma inside_triangle_left_of_edge a b c d e f : general_position ([set a; b; c; d; e; f]) -> ccw a b c -> ccw a b d -> ccw a b e -> ccw c d f -> ccw c f e -> ccw f d e -> ccw a b f.

◮ Many cases, but also many symmetries

20 / 38

Illustration a b c d e f

21 / 38

Symmetries in this figure

◮ The statement does not say which of c, d, or e is the the

leftmost point with respect to a

◮ If we assume c to be the leftmost, it does not say whether

(ccw a d e) holds or not.

◮ There are 6 cases in the proof, each case require 3 uses of

Knuth’s 5th axiom

22 / 38

Illustration a b c d e f

23 / 38

Key points concerning the convex hull

◮ In the red case, red edges are grouped together ◮ There are only two points adjacent to a blue and a red edge ◮ This requires a proof by induction (80 lines of dense Coq

script)

Lemma partition_red_blue a: a \in cover s’ -> ccw (f a) a p -> exists b, exists i, b \in cover s’ /\ (0 < i < size (orbit f b))%N /\ (forall j, (j < i)%N -> ccw (iter j.+1 f b) (iter j f b) p) /\ (forall j, (i <= j < size (orbit f b))%N -> ccw (iter j f b) (iter j.+1 f b) p).

24 / 38

A critique of the mathematical algorithm

◮ Complexity is terrible ◮ Generic operations on sets of sets ◮ Refinements

◮ Caching data ◮ Sparse representation for sets 25 / 38

Refinements

• 1. Return the convex hull with the triangulation
• 2. Take as input a list of points (instead of a subset)
• 3. Output a list of triangles (instead of a subset)

26 / 38

Convex Hull refinement

◮ Refine the output type from {set P} to

{set P} * (P → P) * P

◮ The first component is the same as for the previous algorithm ◮ The second component is a function circulating the convex hull ◮ The third component is a point on the convex hull

◮ The convex hull does not change in the blue case ◮ In the red case some computation must be done

◮ Detect and suppress red edges, keep blue edges ◮ Add two new edges from and two purple points 27 / 38

Convex hull computation in the red case

28 / 38

Defining the new convex hull in the red case

◮ I chose to use the datatype of “finite functions” ◮ Just define the new convex hull as a variation over the old one ◮ Proofs about this new path

◮ values for all blue points are the same as the old path function ◮ Also true for the last purple point ◮ The new path constitutes the new convex hull

Definition new_path (f : {ffun P -> P}) (a b np : P) := finfun [fun x => f x with a |-> np, np |-> b].

29 / 38

Proofs about the new convex hull

◮ The new path is a cycle ◮ The orbit of the new point describes the new boundary edges

◮ 400 lines of proof

◮ The new path has the convex hull property

◮ 120 lines of proof 30 / 38

Correctness statement for the first refinement

Lemma naive_naive2 n (s : {set P}) : (3 <= #|s| <= n)%N -> general_position s -> exists chf b, naive2 n s = (naive n s, chf, b) /\ convex_hull_path coords s (boundary_edge (naive n s)) chf /\ b \in cover (boundary_edge (naive n s)).

31 / 38

Input refinement

◮ Input points from a list instead of a set ◮ Move from a mathematical concept to a computer science one ◮ Simple recursion scheme for lists (none for sets) ◮ Need to replace a non-deterministic choice with a

deterministic one

◮ All proofs about the initial algorithm need to be abstract wrt

the pick function

◮ Lists that are equal up to permutation may lead to different

triangulations

◮ Introduce a function pick seq set that chooses elements in a

set according to the order given by a list, when applicable

32 / 38

Code for the second refinement

Definition pick_seq_set (s : seq P) (s’ : {set P}) :

• ption P :=

if (find (mem s’) s < size s)%N then Some (nth p0 s (find (mem s’) s)) else pick_set s’. Definition naive2’ s n s’ := triangulation_algorithm.naive2 coords p0 (pick_seq_set s) pick_triangle n s’. Lemma naive2_naive3 (s : seq P) : (3 <= size s)%N -> uniq s -> naive3 s = naive2’ s (size s) [set y in s].

◮ This proof is short: 25 lines

33 / 38

abstractions in the refinement ladder

◮ naive and naive2 are shown to return the same triangulation

when using the same pick set function

◮ naive2 and naive3 are shown to return the same triangulation

when naive2 is using pick seq set

34 / 38

Third refinement: lists of triangles

◮ Instead of returning a set of sets, return a list of lists ◮ Need to show that lists have no duplicates

◮ Each list representing a triangle has cardinal 3 ◮ The list of triangles has no duplicates as sets

◮ This proof requires an extra result about the naive algorithm

◮ For a point inside the convex hull, there is exactly one triangle

from the triangulation that contains it (270 lines of proofs)

◮ Proving the refinement itself takes another 300 lines of proofs

35 / 38

Lemma naive3_naive4 l : (3 <= size l)%N -> uniq l -> general_position [set x in l] -> let ’(tr, f, b) := naive4 coords p0 l in naive3 l = ([set t in [seq [set x in t’] | t’ <- tr]], f, b) /\ uniq [seq [set y in x] | x <- tr].

36 / 38

More refinements

◮ Work in progress: finding the right triangles can be improved

using Delaunay

◮ The convex hull path can also be refined

◮ into a cycle of pointers in C-like implementations ◮ into a list for a function implentation (run inside Coq)

◮ The general position condition could be refined, too.

◮ lazy verification of the constraints 37 / 38

Conclusion

◮ Advertising the power of interactive theorem proving ◮ Refinement is a big thing in the B method ◮ Libraries are important ◮ The set abstraction provided by Mathematical components is

a big help

◮ Logical properties (specifications) as a support for

collaboration
