WalB: A Fast and Low Latency Backup System for Block Devices

Open Source Summit Japan 2017 Kota Uchida June 1, 2017

1

2

About me

▌Kota Uchida ▌SRE team at Cybozu, Inc. ▌A WalB developer

3

About Cybozu

▌A large cloud service vendor in Japan. ▌Largest market shares in field of collaborative software. ▌We serve web applications on our own cloud platform.  kintone: a low-code business app platform  and more

#customer companies： #accesses / day： write IOs / day：

19,000+ 19,000+ 190 millions 190 millions 24.5 24.5 TiB TiB

4

5

Service Level Objective

▌24/7 nonstop service ▌99.99% availability (4 min / month) ▌Daily backup (retention period is 14 days) ▌Disaster recover: copy data to a remote site once a day

Architecture of our platform

6

Application Server L7LB Storage Server dm-snap Storage Server dm-snap Backup Server Remote Site Database Server Diff Diff Diff Diff

The scope of this talk

RAID 1 Blob Server

Mapping Info

Snapshot Management with dm-snap

7

A B

Original Volume Area Snapshot Area

Logical Structure Physical Structure (1) CoW

Latest Image

Write A’ Write B’

Snapshot Image

(2) Write B’ B B’ A A’ A’ 1 2 3 4

Backup using dm-snap

8 Snapshot1

(2) Full-scan a new snapshot Logical Structure

Snapshot0

B’ A’ (3) Generate a diff image by comparing two snapshots B (1) Full-scan an old snapshot B’ A’ A

Full-scan at night

9

Daytime Backup processing time

• ’clock

UX degradation during a full-scan

10

Full-scanning

11

We have no more “nights”

▌Until now: Full scan is allowed only when access rate is low, i.e., at night. ▌From now on: We have to handle accesses from multiple timezones. ▌We must be able to backup any time without UX degradation.

12

New Solution

▌We need a new solution with:  No IO spikes  Short backup time ▌We compared dm-thin with WalB

13

What is dm-thin?

▌dm-thin provides thin-provisioning volume management to  share same data among volumes  reduce disk usage using snapshots ▌In the mainline Linux kernel

Snapshot Management with dm-thin

Logical Structure Physical Structure A Latest Tree Latest Image A

Snapshot Management with dm-thin

15

Logical Structure Physical Structure A Snapshot Tree Latest Tree A Snapshot Latest Image A

Snapshot Management with dm-thin

16

A A’ Snapshot Tree Latest Tree (1) CoW (1) CoW Write A’ Physical Structure (2) Write (2) Update A’ A Snapshot Latest Image Logical Structure

17

A B B’ Snapshot0 Snapshot1 A’ A’ B’ A B Snapshot0 Snapshot1 Generate a diff image using dm-thin metadata Logical Structure Physical Structure

Backup using dm-thin

18

What is WalB?

▌A real-time and incremental backup system  developed at Cybozu Labs ▌Can backup block devices without IO spikes

dm-snap full scanning WalB no spikes

Special Block Devices for WalB

19

WalB device Data device Log device

Read Write

Any application (File system, DBMS, etc.) Linear mapped Ring buffer

Write IO Logging and Backup with WalB

20

A B Data Device Log Device 1 2 3 4 Time series of write I/Os Time

Write IO Logging and Backup with WalB

21

B A B Write A’ Data Device Log Device A’ 1 2 3 4 1 A’ Time series of write I/Os Time Scan the log device and generate a diff image

Write IO Logging and Backup with WalB

22

B A B B’ Write A’ Write B’ Data Device Log Device A’ A’ 4 1 1 2 3 4 A’ A’ B’ Time series of write I/Os Scan the log device and generate a diff image Time 1

23

Performance test

▌Compared dm-snap, dm-thin, and WalB ▌Executed a workload during a backup  The workload & the backup will affect each other ▌Measured the following metrics:  Latencies of the workload  Backup time

24

Environment & Settings

▌Test environment:  CPU：2.40 GHz x 12 cores  MEM：192 GiB  HDD：4 TB HDD, RAID 6 (8D2P)  NIC：10 Gbps x 2  Kernel：4.11 (latest upstream) ▌Test settings:  100 GiB volumes  Workload: 4 KiB Random writes for a 5 GiB range

25

Measuring the Backup Time (dm-snap, dm-thin)

▌dm-snap：take a snapshot & scan full image ▌dm-thin：get a structure of snapshot trees & find modified blocks & read these blocks

5 GiB 95 GiB (unchanged) 4 KiB Random Writes dm-snap : scan full image dm-thin : scan changed chunks (tree traversal)

26

Measuring the Backup Time (WalB)

▌WalB：scan logs from a log device & send them to a backup server continuously

5 GiB 95 GiB (unchanged) 4 KiB Random Writes WalB : scan logs Log Device Write IO logs WalB Device Backup Server Diff Diff Network

Write I/O latency

dm-thin dm-snap WalB no-backup 27

IO spikes due to CoW, worse than dm-snap! Small overhead large due to CoW

Backup time

28

1146 2260 1.2

slower than dm-snap so fast!

29

Conclusion

▌dm-snap & dm-thin  High I/O latency during a backup  Long backup time ▌WalB  Stable and low I/O latency (no spikes)  Short backup time WalB satisfies our requirements for production use.

30

Try WalB!

▌Project page  https://walb-linux.github.io/ ▌Tutorial  https://github.com/walb-linux/walb- tools/tree/master/misc/vagrant/  Vagrantfile for Ubuntu 16.04 and CentOS 7
