VOLUME #1 Special Provisions and Affected Vol. 2 Specifications

2014

Standards Engineer’s First Roller

2

Incorporation of Accessibility Design Standards into Volume 1

3

F-3512 TACTILE WALKING SURFACE INDICATORS (TWSI’S)

New SP outlining the installation requirements for TWSI’s.



TWSI’s shall one of the approved cast-in-place, cast or ductile iron products described in MS-13.1 and listed in MS-22.15.



Multiple plates shall be bolted together with Stainless Steel bolts and nuts.

4

F-3512 TACTILE WALKING SURFACE INDICATORS (TWSI’S)

From the Accessibility Standard (Part of detail drawing SC7 shown)



TWSI’s shall be set back 150 to 200mm from the back of curb.



TWSI’s shall be 610 to 650 in depth and a minimum width of 1500mm.



For curb ramps and single transition areas, TWSI’s shall extend the full width of the curb ramp/area.



All TWSI’s shall have 6mm wide x 6mm deep drain grooves at corners between the TWSI and the curb. Panel joints may be adapted for use if touching.

5

F-3512 TACTILE WALKING SURFACE INDICATORS (TWSI’S)



Unless indicated otherwise on the contract drawings for blended transition areas (dropped corners?) serving two crossing directions provide .3m gap between the TWSI sets.



Plates shall be parallel with the curb radius (i.e. not necessarily perpendicular to the direction of pedestrian travel). This will require the use of radius TWSI plates in some instances.



Radius TWSI’s are available in various radii. Careful consideration of radius design is required as the TWSI radius shall follow as close as possible the back of curb radius.

Note Natural uncoated finish for concrete

6

F-3512 TACTILE WALKING SURFACE INDICATORS (TWSI’S)



Tops of TWSI’s shall be aligned and level with the adjacent concrete surface and installation in wet concrete shall be effective in permanently securing the TWSI in place once dry.



Measurement will be the area of TWSI’s in m².



F-3510 and F-3511 (Sidewalk Construction Specs) also updated to include TWSI’s.



4 Approved suppliers on approved list. MS-22.15 shown below.

7

F-4070 MH’s, CB’s Ditch Inlets and Chambers



Self-level Catch Basin frames now approved but limited to one supplier at the moment.



Requirements are described in MS-13.1 and the approved supplier is listed in MS-22.15. Conditions of the approval have since been satisfied.

Adapter plate required for square CB’s.

8

F-4080 Adjusting or Rebuilding MH’s CB’s …..

 Same as F-4070, self level surface inlet Catch

Basin Frames and Covers now approved.

 From Page 5:

9

F-4080 Adjusting or Rebuilding MH’s CB’s …..

 Lip of concrete that was previously

allowed, to be prevented to reduce chances

• f being lifted by frost heave.

(Page 6)

Before Now

10

F-4081 Self Level Maintenance Hole Frame and Cover

Installation on Existing/Retrofit structures

 Structure to be minimum 250mm below surface

depending on manufacturer. 150 to 230mm

• typical. East Jordan 250mm high so more room

needed.

 Section 7 modified to stress the importance of

putting generous quantities of asphalt under the raised lip so it sits about 25 to 38mm higher than the surrounding asphalt before rolling. Also using better pushing tools than the sharp end of a shovel is suggested.

11

F-4081 Self Level Maintenance Hole Frame and Cover

12

F-4081 Self Level Maintenance Hole Frame and Cover

 Section 8 now requires compacting to start

from the outside and work towards the centre to ensure compaction of the material under the lip.

13

F-4081 Self Level Maintenance Hole Frame and Cover

• New section 9 to stress that the

upper frame is not to rest on the guide frame otherwise will loosen and rock causing noise complaints, possible damage to the frames and possible ejection

• f the cover, possibly leading to

an accident.

• Picture - 311 forces replaced
• riginal SL F&C with regular

F&C after a noise complaint.

• Changed back to SL before

completion.

14

F-4100 PIPE SEWERS

 Page 4 – Cored Tees approved for years but not

mentioned in F-4100 and now they are.

15

F-4100 PIPE SEWERS

 Gap at top of PVC sewer pipes when using Kor-

n-seal connectors has been resulting in cracks/breakage during cleaning operations.

 Obvert to be cut back 50mm to reduce stress on

• bvert when using Kor-n-seal. See page 5.

16

F-4451 WATERMAIN CLEANING AND STRUCTURAL LINING

 Many clarifications made to ensure

that the end result will be a structural lining with a sleeve/jacket not just a spray coating. Old spec was inconsistent.

17

F-4491 COMMISSIONING OF WATERMAINS

 Page 3 Nozzles

are no longer to be installed on hydrant laterals.

 Nozzle removed

from hydrant lateral on associated drawing W46.

18

F-4493 TRACING WIRE FOR WATERMAINS …..



From page 2 of 4493.



W36 revised to show extension of wire for PEX.



OK to use the same wire as specified tracing wire is superior to wire specified in OBC and OK’d by John Buck.

19

VOLUME #2: Material Specifications, and Affected Detail Drawings

Failed 1963 pilot using snow as a road surface

20

MATERIAL SPECIFICATIONS

 The primary purpose of the material

specifications is to outline the technical requirements for products prior to approval.

 After approval, products are listed in

the appropriate list of approved products.Water MW-19.15; Sewer (TWSI’s) MS-22.15.

SALESMEN’S JUMP FOR JOY

21

SEWER MATERIAL SPECIFICATIONS

VOLUME 2 Cont’d Approved PVC sewer pipes at Lansdowne

22

MS-13.1 MAINTENANCE HOLES CB’S, ICD’S AND TWSI’S

 Double OPSD

705.020 Alternate “B” CB’s added.

23

MS-13.1 MAINTENANCE HOLES CB’S, ICD’S AND TWSI’S

 Inspection Staff

voiced concerns with removing covers using lift pockets.

 Requested

return of larger sniffer holes.

24

MS-13.1 MAINTENANCE HOLES CB’S, ICD’S AND TWSI’S



For Storm and Sanitary covers (S24, S24.1) sniffer hole to be increased to 25mm and to come with approved removable plug.



Suppliers have 1 year to clear old stock.

25

MS-13.1 MAINTENANCE HOLES CB’S, ICD’S AND TWSI’S

 Insertion type

plugs now for replacement

• nly. Slider type

now standard.

 New types

suitable for retrofitting CB’s with no sump (no room below outlet) added in categories 8, 9, 10 and 11.

26

MS-13.1 MAINTENANCE HOLES CB’S, ICD’S AND TWSI’S

 Approved list showing

changes in red

27

MS-13.1 MAINTENANCE HOLES CB’S, ICD’S AND TWSI’S

 New categories 8 to 11

typically used for retrofit purposes only

28

MS-22.15 APPROVED SEWER PRODUCTS LISTING

29

MS-22.15 APPROVED SEWER PRODUCTS LISTING Cont’d

Press-Seal RFS Nitrile added for Maintenance Holes.

30

MS-22.15 APPROVED SEWER PRODUCTS LISTING Cont’d

 Star and PCHG

now approved for Sanitary and Storm covers.

31

MS-22.15 APPROVED SEWER PRODUCTS LISTING Cont’d

 East Jordan, Star and

PCHG were all added for Self Level Frames.

 Also approved for

Valve Chambers.

32

MS-22.15 APPROVED SEWER PRODUCTS LISTING Cont’d

 Internal Drop Tees

added to the list.



IPEX product approved.

 Associated drawing

S12 updated to show correct flap configuration.

33

MS-22.15 APPROVED SEWER PRODUCTS LISTING Cont’d

 Name changed for Rehau to Next

Polymer – Supplier of PSM PVC Sewer and C900 and C905 Watermain pipe.

 From MW-19.15

34

MS-22.15 APPROVED SEWER PRODUCTS LISTING Cont’d

 For retrofit applications

connecting sewer services in contaminated soils nitrile versions of Mission and Fernco found only an e-mail away in the UK .

35

WATER MATERIAL SPECIFICATIONS

Volume 2 Cont’d

Lead Water Pipes in Bath England

36

MW-18.1 WATERMAIN PIPE

SECTION ADDED FOR PAVEMENT INSULATION FOR WATERMAINS AND SEWERS

Insulation for use in roads over pipe trenches shall:



be type Extruded Polystyrene Foam Insulation Boards (XPS) in 600 x 2400 x 50mm size;



meet the requirements of OPSS 1605;



Grade A (275 kPa compressive strength shall meet ASTM C578 Type VI;



Grade B (400 kPa compressive strength shall meet ASTM C578 Type VII.

37

MW-19.15 APPROVED WATER DISTRIBUTION PRODUCTS LISTING

38

MW-19.15 APPROVED WATER DISTRIBUTION PRODUCTS LISTING

 PCHG and Star now

approved for supply

• f valve chamber

covers.

39

SEWER DETAIL DRAWINGS

VOLUME 2 Cont’d

http://www. l http://www. 53632

40

SEWER DETAIL DRAWINGS Drawing S11

 Note 6 revised to

acknowledge the accepted use of “Cored T’s”.

41

Half Way Point

Straddling the border between Kentucky and Virginia

42

WATER DETAIL DRAWINGS

VOLUME 2 Cont’d

43

WATER DETAIL DRAWINGS Drawing W10, W12, W13

Gate valve over access opening to be covered with a blind flange to keep out dirt.

44

WATER DETAIL DRAWINGS Drawing W31.1

 Stand pipe moved

away from valve box to prevent interference when using Key operator.

 Water hammer

arrester moved.

 Sediment drain valves

added.

45

WATER DETAIL DRAWINGS Drawing W31.2

 Sediment drain

valve added.

 Single

backwater preventer changed to dual type.

46

WATER DETAIL DRAWINGS Drawing W32

 Dimension

added to indicate meter installation to be .5 to 1m above floor.

47

WATER DETAIL DRAWINGS Drawing W37.2

 Note 3 - 6m

maximum distance between the hydrant and the end of the large diameter main.

48

WATER DETAIL DRAWINGS Drawing W42 and W44

 Table revised to

indicate zinc anodes for valves up to 250mm not 300. At 300 valves are in chambers.

49

WATER DETAIL DRAWINGS Drawing W46

 Nozzle no longer

to be installed

• n hydrant

leads.

 Drawing and

table revised.

50

Sidewalk, Curb and Pathway Drawings

Power Shovels from Santa, X-Mass 1962

51

Accessibility Standard Applied to Sidewalk Drawings

Accessibility for Ontarians with Disabilities Act, 2005 Exceptions, General 80.31 Exceptions to the requirements that apply to exterior paths of travel are permitted where obligated organizations, other than small organizations, can demonstrate one or more of the following:



• 6. - It is not practicable to comply with the requirements, or some of them, because

existing physical or site constraints prohibit modification or addition of elements, spaces or features, such as where increasing the width of the exterior path would narrow the width of the adjacent highway or locating an accessible pedestrian signal pole within 1,500 mm of the curb edge is not feasible because of existing underground

• utilities. O. Reg. 413/12, s. 6.

(Therefore no expectation exists in the Act to expropriate land or narrow the road surface to generate more room for curb ramps. Also the Ottawa Accessibility Standard mentions “blended transitions” for traffic calming locations but currently has no drawing example to show what that should look like.)

52

Sidewalk Curb and Pathway Drawings SC7



Updated to reflect accessibility standard.



No more grooves.



For retrofit for applications.



Curb ramp suitable for any application.



Curb ramp slope defined as 2 to 5%, maximum 8%.



“Blended Transitions” not well defined in ADS. Only recommended where traffic calming??? Sample drawing to be developed.

53

Sidewalk Curb and Pathway Drawings SC1.1, SC1.2, SC1.3, SC1.4, SC2, SC3 etc.



Dropped curbs now called depressed curbs for consistency in the document.



Depressed curbs for Pedestrian curb ramps reduced to 0 to 6mm, from previous max 25mm.



For vehicle private entrances no change, 0 to 25mm.



SC1.1 Dimensioning corrected.

54

Sidewalk Curb and Pathway Drawings SC1.2

 SC1.2 concrete

support dimension corrected from 300 to 250mm.

55

Sidewalk Curb and Pathway Drawings SC1.4

 Missing dowels

now shown.

56

Sidewalk Curb and Pathway Drawings SC1.4, SC2, SC3

 Typical Sidewalks

and granular shown incorrectly as 150mm. Should have stayed at

• 100mm. Tech Bulletin

in the works to correct.

 Maximum slope of

curb ramps increased from 4 to 5% to match Accessibility

• Standard. Also in

note 3.

57

Sidewalk Curb and Pathway Drawings SC6

 Updated to reflect

accessibility standard as much as possible.

 For retrofit

applications.

58

Sidewalk Curb and Pathway Drawings SC7.1

 Crossing

grooves were replaced with curb ramps.

59

Sidewalk Curb and Pathway Drawings SC7.2

 Crossing

grooves were replaced with curb ramps.

 Note TWSI’s

are a constant distance from the curbs.

60

Sidewalk Curb and Pathway Drawings SC9

 Note added to

require approval

• f the General

Manager before using paving stones for sidewalks.

61

Sidewalk Curb and Pathway Drawings SC9.1, SC9.2, SC9.3

 Note added to

require approval

• f the General

Manager before using paving stones for sidewalks.

 Curb ramp slope

defined as 2 to 5%, maximum 8%.

62

Sidewalk Curb and Pathway Drawings SC10.1

 New drawing to

show curb ramps through medians.

 On CD but

missing from hardcopy updates.

63

Sidewalk Curb and Pathway Drawings SC11

 Drawing

updated to show new accessible dimensions for the concrete pads for bus shelters.

 Sidewalk width

reduced to 1.8m.

64

Sidewalk Curb and Pathway Drawings SC12

 Drawing

updated to show new accessible dimensions for the concrete pad for bus shelters.

 Sidewalk width

increased to 1.8m from 1.5m.

65

Sidewalk Curb and Pathway Drawings SC13

 Revised

sidewalk width from 2m to 1.8m as per ISDTB 2013-02.

66

Sidewalk Curb and Pathway Drawings SC15

 Major revisions

to show accessible curb ramps.

67

Sidewalk Curb and Pathway Drawings SC16

 Major revisions

to show accessible curb ramps.

68

Sidewalk Curb and Pathway Drawings SC19

 Revised to show

accessible curb ramps.

69

Road Drawings

Experimenting with converting altitude to velocity for transportation

70

Road Detail Drawings R3

 Note 6 added to

require the approval of the General Manger before using paving stones for crosswalks.

 Accessible curb

ramps added.

71

Road Detail Drawings R7 and R8

 Curb ramps

added for accessibility.

72

Traffic Detail Drawings

Failed 1963 ring road pilot.

73

Traffic Drawing T3

 New cover

design introduced in ISDTB 2013-02.

74

Traffic Drawing T6

 New cover

design introduced in ISDTB 2013-02.

75

Fencing and Landscaping Detail Drawings

76

Fence Drawing F6

 Dimensions

revised and some increased.

 Opening

increased from 4 to 4.5m.

77

Fence Drawing F6.1

 New drawing

for Emergency Access Lanes.

78

Fence Drawings F7 to F11

 As part of the

document reorganization, F7 to F11 were rolled into the Fencing section from the former Parks and Pathways section.

79

Fence Drawing F9

 Note 4 added to

require 38mm mesh with 6 gauge vinyl coated wire when adjacent to private residential property to meet the pool enclosure bylaw.

80

Landscaping Drawing L7

 Note 6 added to

ensure vertical joints are staggered.

81

Please Review the Specifications Drawings for

• ther Changes and Additions

Best of luck with your 2014 contracts!!!!
