SLIDE 1
AGENDA
Motivation State of the art Monopticon Related research
2
Visualizing, Analyzing and Filtering Zeek Events using a graphical - - PowerPoint PPT Presentation
Visualizing, Analyzing and Filtering Zeek Events using a graphical - - PowerPoint PPT Presentation
Visualizing, Analyzing and Filtering Zeek Events using a graphical frontend and OpenGL Nick Skelsey ZeekWeek 2019 Seattle, WA 11 October, 2019 AGENDA Motivation 1. State of the art 2. Monopticon 3. Related research 4. 2 CONNECTIVITY
SLIDE 2
SLIDE 3
3
> ping google.com > ping 8.8.8.8 > ip a > ping 192.168.1.0 > dhcp -4 iface_name *check cable* *check unpaid bills* *check news for regional disaster*
CONNECTIVITY ISSUES: do not suffer in silence
SLIDE 4
Graphics can have high information density. No certifications required. Develop intuition.
4
MOTIVATION
1. 2. 3.
SLIDE 5
5
IVRE
Lalet, Pierre, Florent Monjalet, and Camille Mougey. "IVRE, a network recon framework." ivre.rocks (2017).
SLIDE 6
RadialNet: An Interactive Network Topology Visualization Tool with Visual Auditing Support, CRITIS 2008 João P. S. Medeiros, Selan R. dos Santos at Federal University of Rio Grande do Norte – UFRN
6
ZENMAP & RADIALNET
SLIDE 7
A GPLv3 application built with C++, zeek and Mangum for POSIX systems.
7
MONOPTICON
SLIDE 8
8
minicps WATER TREATMENT
> ip link add name feth1 type dummy > ip link set dev feth1 up > tcpreplay -v -i feth1 SWaT_plc_test.pcapng
Antonioli, Daniele, and Nils Ole Tippenhauer. "MiniCPS: A toolkit for security research on CPS networks." Proceedings of the First ACM workshop on cyber-physical systems-security and/or privacy. ACM, 2015.
SLIDE 9
9
Bettercap ARP Spoofing
> set arp.spoof.internal true; > set arp.spoof.targets 192.168.1.20,192.168.1.30; > set arp.spoof.full_duplex on; > arp.spoof on;
SLIDE 10
10
OBSERVATIONS
Limit scope: Ethernet and IPv4 Must be modular: Represent the OSI stack as a stack Must be passive: offline packet analysis Must be quick: native or web assembly Should be extensible: zeek and bash scripts
10
1. 2. 3. 4. 5.
SLIDE 11
11
DESIGN
11
SLIDE 12
IEEE 802.1* defines ethernet
38:30:f9:61:97:6f
12
MODELING DEVICES IN A BROADCAST DOMAIN
SLIDE 13
13
MAGNUM.GRAPHICS
SLIDE 14
14
THE GRAPHICS PIPELINE
14
SLIDE 15
15
OBJECT SELECTION
1 2 3
SLIDE 16
16
OBJECT LAYOUT
16
SLIDE 17
17
LIMITATIONS
SLIDE 18
All devices addressable by their MAC. Frames traverse switches based on:
- Destination address
- The type of address
- The switches (routing) tables
- Structure of the spanning tree
- Optimizations like 802.1aq
18
802.1 BROADCAST DOMAINS
Fedyk, D., et al. "IS-IS extensions supporting IEEE 802.1 aq shortest path bridging." Internet Engineering Task Force (IETF), RFC 6329 (2012): 2070-1721.
SLIDE 19
zeek package that passively infers the structure of an IPv4 network over Ethernet
19
AAALM
SLIDE 20
20
INFERRING NETWORK STRUCTURE
SLIDE 21
21
DRAWING A BROADCAST DOMAIN
SLIDE 22
22
Port knocking
SLIDE 23
23
FUTURE WORK
Extensible event monitoring Sane packaging L2 & L3 model to identify network security policy violations. 1. 2. 3.
SLIDE 24
Check out: Monopticon on github or in the AUR aaalm zeek package
24
