VE VERRA RRAZA ZANO NO-NAR ARROWS ROWS BR BRIDG DGE M MAS ASTE TER R PL PLAN AN VERRAZANO-NARROWS BRIDGE MASTER PLAN 1 OU OUTLI TLINE NE Introduction Purpose of Study Master Plan Projects Bridge Rehabilitation

slide-1
SLIDE 1

1

VERRAZANO-NARROWS BRIDGE MASTER PLAN

VE VERRA RRAZA ZANO NO-NAR ARROWS ROWS BR BRIDG DGE M MAS ASTE TER R PL PLAN AN

slide-2
SLIDE 2

2

VERRAZANO-NARROWS BRIDGE MASTER PLAN

OU OUTLI TLINE NE

  • Introduction
  • Purpose of Study
  • Master Plan Projects

– Bridge Rehabilitation and Reconstruction – Traffic/Safety and Accessibility

  • Shared–Use Access Study
  • Next Steps
slide-3
SLIDE 3

3

VERRAZANO-NARROWS BRIDGE MASTER PLAN

INT NTRODUCTIO RODUCTION

  • The Verrazano-Narrows Bridge (VNB) is an

iconic, irreplaceable 50-year-old structure and a critical transportation link in the I-278 corridor (Staten Island Expressway/Gowanus Expressway).

  • Many of the Upper Level approach structures

and Belt Parkway ramps are the original construction from 1964.

  • Since 1992 Triborough Bridge and Tunnel

Authority (TBTA) has invested $927 Million in capital improvements.

  • More than $1.5 Billion will be invested over

the next 25 years.

  • Reconstructing the Upper Level Approaches,

Lower Level Suspended Span deck, and the connecting ramps and roadways are the next major elements in the long-term plan to reconstruct the VNB.

VNB within I-278 Corridor

VNB

Brooklyn Queens Staten Island New Jersey Bronx

slide-4
SLIDE 4

4

VERRAZANO-NARROWS BRIDGE MASTER PLAN

INT NTRODUCTION RODUCTION (C (Con

  • ntin

tinued) ued)

  • These reconstruction projects are

required to maintain the facility in a state of good repair and to improve access, safety and meet modern design standards.

  • While planning these necessary

upgrades, TBTA is also assessing the feasibility of possibly providing pedestrian and bicycle access across the bridge.

  • In 2014 TBTA started this Master

Plan Study to assess the best way to address the VNB’s long-term

  • needs. This presentation reflects

progress to date.

Brooklyn Ramps

slide-5
SLIDE 5

5

VERRAZANO-NARROWS BRIDGE MASTER PLAN

PU PURP RPOS OSE OF OF S STU TUDY

GOALS AND OBJECTIVES

  • Extend the lifespan and enhance the functionality of the

Bridge and its approaches

  • Improve traffic safety and operations for customers and

Authority personnel

  • Minimize adverse impacts on customers, environment and

neighboring community

  • Optimize capital and operating investments
  • Optimize sequence of project implementation
slide-6
SLIDE 6

6

VERRAZANO-NARROWS BRIDGE MASTER PLAN

MAS ASTE TER R PL PLAN AN SU SUMMAR ARY

slide-7
SLIDE 7

7

VERRAZANO-NARROWS BRIDGE MASTER PLAN

MAS ASTER TER PL PLAN AN PRO PROJE JECT CTS-STATEN TEN ISL SLAN AND

slide-8
SLIDE 8

8

VERRAZANO-NARROWS BRIDGE MASTER PLAN

MAI AIN N SP SPAN AN

slide-9
SLIDE 9

9

VERRAZANO-NARROWS BRIDGE MASTER PLAN

MAS ASTER TER PL PLAN AN PRO PROJE JECT CTS-BROOKL BROOKLYN YN

slide-10
SLIDE 10

10

VERRAZANO-NARROWS BRIDGE MASTER PLAN

BRO BROOK OKLYN YN RA RAMPS PS – CON ONSTR TRUCTI TION ON STAGI GING NG VI VIDE DEO O PH PHAS ASE 1 1 AN AND 2 D 2

slide-11
SLIDE 11

11

VERRAZANO-NARROWS BRIDGE MASTER PLAN

BRO BROOK OKLYN YN RA RAMPS PS - PH PHAS ASE 3

Fort Hamilton Army Property

Widened Belt Parkway Connector Ramps

slide-12
SLIDE 12

12

VERRAZANO-NARROWS BRIDGE MASTER PLAN

BE BELT T PAR ARKWAY Y EAS ASTBO TBOUND ND MERGE GE

Belt Pkwy Merge Fort Hamilton Match A-A Match A-A EB Lane addition from VNB/Belt Pkwy merge to Bay Pkwy EB Lane addition from VNB/Belt Pkwy merge to Bay Pkwy

slide-13
SLIDE 13

13

VERRAZANO-NARROWS BRIDGE MASTER PLAN

GOWAN GOWANUS S EXPR PRESS SSWAY/ Y/UP UPPER PER LEVEL VEL AN AND L D LOWE OWER R LEVE VEL L MERGE GE

Existing Conditions – UL and LL Merge and 92nd Street Entrance Ramp

EB Gowanus Expressway Dahlgren Place 92nd Street Bus/HOV Lane

Eastbound View - Gowanus Expressway

To VNB

slide-14
SLIDE 14

14

VERRAZANO-NARROWS BRIDGE MASTER PLAN

LOWE OWER R LEVE VEL L SU SUSP SPEND NDED D SP SPAN AN DE DECK RE REPL PLACEME MENT NT

  • First reconstruction of the LL suspended span

deck since it opened for traffic in 1969

  • Replacing concrete deck with a lighter deck will

decrease the weight of the Bridge

  • Wind and seismic improvements
  • Challenging construction staging due to

constraints with center median and columns

  • Reconstructing Brooklyn approach ramps

provides greater operational flexibility and minimizes traffic impacts when replacing the deck Because much advance planning and study are required, TBTA is starting preliminary design in the 2015-2019 Capital Program.

slide-15
SLIDE 15

15

VERRAZANO-NARROWS BRIDGE MASTER PLAN

OPP PPOR ORTUNI TUNITY Y FOR R SH SHAR ARED-USE USE ACCESS SS

  • The Lower Level Suspended Deck Replacement project creates

the opportunity to lighten bridge and possibly accommodate a shared-use path

  • Approximately 12,000 tons need to be removed to

accommodate paths on both sides of the bridge

  • Similar to Upper Level Deck Replacement which lightened

bridge to accommodate a Bus/HOV lane

slide-16
SLIDE 16

16

VERRAZANO-NARROWS BRIDGE MASTER PLAN

SH SHAR ARED-US USE E ACCESS SS STU TUDY

  • The VNB was not originally designed for bicycle/pedestrian

access

  • Retrofitting a long-span suspension bridge to accommodate

a shared use path is rare

  • Modifications must not:

– diminish bridge safety and structural integrity – increase the weight of the bridge – reduce traffic capacity

  • Requires significant engineering and testing of wind effects

Feasi asibili bility ty Consi sider erati ations

  • ns
slide-17
SLIDE 17

17

VERRAZANO-NARROWS BRIDGE MASTER PLAN

CON ONCEPTU PTUAL AL VI VIEW W

Shared ared Use Pa Paths hs Outboa tboard of Lower r Lev evel l

slide-18
SLIDE 18

18

VERRAZANO-NARROWS BRIDGE MASTER PLAN

CONC NCEPTU EPTUAL AL VIEW

Shared ared Use Pa Paths hs Outboa tboard of Lower r Lev evel-Brook

  • okly

lyn Appr proach

  • ach

View from JPJ Park Bike/Pedestrian Path Connections to Shore Park Path

slide-19
SLIDE 19

19

VERRAZANO-NARROWS BRIDGE MASTER PLAN

CONC NCEPTU EPTUAL AL VIEW

Shared ed Use Pa Paths Outboard of Lower Leve evel-St Staten aten Island d Approach ach

slide-20
SLIDE 20

20

VERRAZANO-NARROWS BRIDGE MASTER PLAN

CON ONCEPTU PTUAL AL VI VIEW

Fort Wadsworth

View from JPJ Park

STA STATEN TEN ISL ISLAND SID SIDE

Shared ared Use Pa Paths hs Outboa tboard of Uppe per r Lev evel el

slide-21
SLIDE 21

21

VERRAZANO-NARROWS BRIDGE MASTER PLAN

PO POSS SSIBLE IBLE NEW EW PE PEDES ESTR TRIAN/BICY IAN/BICYCLE CLE CROS ROSSI SING NG

Conce nceptu tual l View

slide-22
SLIDE 22

22

VERRAZANO-NARROWS BRIDGE MASTER PLAN

MTA A Ne New Yor

  • rk

k Cit ity y Transit sit Init itiativ iative

Bike e & Ride e Pilot t Program

slide-23
SLIDE 23

23

VERRAZANO-NARROWS BRIDGE MASTER PLAN

NE NEXT T STE TEPS PS

St State te of Good d Re Repai pair r and nd Oper erationa tional l Impr prov

  • vem

ement ents

  • Complete Master Plan
  • Proceed with design and construction of

Phase 1

  • Continue preliminary design of Phases 2

and 3

  • Commence preliminary design of LL deck

replacement

  • Engage outside agencies for off-property,

safety and traffic flow improvements

  • Provide further updates as projects develop

further

Shared ared-Us Use Pa Path h Stu Study dy

  • Engage Stakeholders: Fall/Winter 2015
  • Conduct Focus Groups and Survey: Fall/Winter 2015
  • Incorporate Feedback from Stakeholders

Master ter Plan an
