Varden Vertical Ag Structures Structures up to 12 tall Utilizing - - PowerPoint PPT Presentation

Components for A-Frame Varden Vertical Ag Structures Structures up to 12 tall Utilizing Varden Sleeves Example Pic Example Pic Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com Lighting and Air Circulation Options For Any


slide-1
SLIDE 1

Varden Vertical Ag Structures

Components for A-Frame Structures up to 12’ tall Utilizing Varden Sleeves

slide-2
SLIDE 2

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

Example Pic Example Pic

slide-3
SLIDE 3

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

Lighting and Air Circulation Options For Any Operation

slide-4
SLIDE 4

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

slide-5
SLIDE 5

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

slide-6
SLIDE 6

Introducing the Varden Sleeve:

  • Made to attach easily to our proven

welded wire support panels

  • Functions as an AirTray for use with

100mm dia. Ellepots in various depths

  • Integrates with automated processes

from seeding to finished plants

  • Mimics the same growing conditions

and features provided by propagation in various sizes of AirTrays

  • Facilitates high density plant counts to

increase growing area efficiency

  • Allow for precise moisture control and

dry-down while creating optimal root health

  • Interacts seamlessly with Varden

Support Structures and allows easy movement and reconfigure of density based on plant stage and top-growth size Wire Mounting Clips Drip Line Receptors Rigid Body Made of Recycled Polypropylene Air Space Side and Bottom Ventilation

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

slide-7
SLIDE 7

The Varden A-Frame System Utilizing Sleeves:

  • Uprights come in 3’ long

sections for ease in shipment and handling

  • Create frame heights in 3’

increments up to 12’

  • Successive sections can be

added by extending on either side in 4’ wide increments

  • Room for irrigation,

lighting, heat and air movement are accommodated

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

slide-8
SLIDE 8

4’ long

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

slide-9
SLIDE 9

6” Long

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

slide-10
SLIDE 10

3’ Long

(Slotted for both 6” and 8” Wire and Key Elevations)

slide-11
SLIDE 11

6”

(Fasteners included)

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

slide-12
SLIDE 12

4”

(Levelling bolt with foot included)

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

slide-13
SLIDE 13

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

slide-14
SLIDE 14

Easily set the right distance between uprights during install and then tension the finished structure once all parts are installed

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

slide-15
SLIDE 15

(Easily set standard 80-degree angle of the frame)

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

slide-16
SLIDE 16

(Each panel at 4’ wide x 3’ tall)

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

slide-17
SLIDE 17
  • Start plants in most dense

configuration and spread them out as foliage canopy increases and to ensure good light and air penetration

  • Rooted Ellepots can be pulled from

the Varden Sleeves or Sleeves can be un-hooked and moved without disruption

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

136

slide-18
SLIDE 18

Many paper durations and media blends available

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

slide-19
SLIDE 19

Supply line easily fits between the right and left Twist-Lok Keys on the frame

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

slide-20
SLIDE 20

Drip lines can be blank tubing with inserted emitters where desired or can come with built in emitters at 6”, 12” and 18”

  • spacings. Lines snapped into

receptors can be easily lifted out to move or replace the sleeve.

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

slide-21
SLIDE 21

The ability to dry down the root zone is critical for many species and Varden Sleeves with Ellepots offers maximum control

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

slide-22
SLIDE 22

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com

slide-23
SLIDE 23

Price Pe Per Comp mplet ete 12’ x ’ x 4’ Section:

  • Each A-Frame provides 96 sf of

plantable area on 5’ x 4’ (20 sf ) of floor space. Couple sections together to create rows of any length.

  • Includes all parts listed to

assemble one 12’ x 4’ wide A-Frame section, irrigation lines, Varden Sleeves and 100mm Ellepots at 100%

  • coverage. (272 Sleeves)
  • All components ship densely on

standard 40” x 48” wood pallets.

  • End-user price per section without

delivery is $1,500.00. ($15.63/sf plantable) or ($75.00/sf floor) Click above to see how Blackmore Company and Ellepot have been improving the growing industry with innovation and automation

Verdtech, Inc. | Saint Louis, MO. | 314-279-8905 | www.verdtech.com 5’ 4’ 12’
