SLIDE 1
QUALITY OF LIGHT MATTERS IN VERTICAL FARMING
V a l
- y
a P r e s e n t a t i
- n
Vertical Farming
2017
1 Confidential
- | Vertical Farming Presentation
QUALITY OF LIGHT MATTERS IN VERTICAL FARMING V a l o y a P r - - PowerPoint PPT Presentation
QUALITY OF LIGHT MATTERS IN VERTICAL FARMING V a l o y a P r - - PowerPoint PPT Presentation
QUALITY OF LIGHT MATTERS IN VERTICAL FARMING V a l o y a P r e s e n t a t i o n Vertical Farming 2017 | Vertical Farming Presentation 1 Confidential Wavelength (nm) | Vertical Farming Presentation 2
SLIDE 2
SLIDE 3
2 Confidential | Vertical Farming Presentation
Wavelength (nm)
SLIDE 4
3 Confidential
- | Vertical Farming Presentation
SLIDE 5
SLIDE 6
5
Cultivate plants according to your needs
SLIDE 7
SLIDE 8
SLIDE 9
- Baby leaf lettuce grown under Valoya AP673L has 58% higher
biomass in average compared to baby leaf lettuce grown under a RB LED source.
SLIDE 10
- Plants grown under Valoya AP673L were significantly larger in size compared to a RB light source. Picture was taken 18 days after sowing.
SLIDE 11
- 10
Not only the spectrum, but also the light intensity shapes the plant and affects the morphology. The ‘Multiblond’ lettuces were grown under Valoya AP67 spectrum with 50, 75, 100 and 125 umol light intensity, respectively.
SLIDE 12
- 11
A= Red oak leaf lettuce was grown first week under 50 umol, after which it was grown under 50, 75, 100 or 125 umol for 21 days. B= first week under 50, 75, 100, or 125 umol and then 21 days under 50 umol. Light intensity affects plant morphology and secondary metabolite activity, such as anthocyanin production.
A B
SLIDE 13
- Plants are sensitive to photoperiod.
- Some plants flower in short day, some in long day. Most leafy vegetables are day
neutral and can be cultivated in long day conditions.
- One should consider both the photoperiod and DLI when thinking about the
lighting hours
- DLI = µmol/m/s x (3600 x photoperiod)/ 1000 000
- Treatments:
- PAR 125, photoperiod 18, DLI 8.1
- PAR 185, photoperiod 12, DLI 8.1
SLIDE 14
13 13
33 meters under ground – Central London
| Multilayer Growing Confidential
SLIDE 15
14 14
Tree seedling propagation in Sweden
- Nordic trees at Holmen Skog Nursery in
Sweden
- Multi-tier environment will increase
number of crops per year from 4 to 7.
- Valoya developed a tailor-made
spectrum for spruce seedlings. The new spectrum provides fast growth and rooting.
| Multilayer Growing Confidential
SLIDE 16
Strawberries in Urban Environment
Agricool (FR) uses Valoya AP67 spectrum in their cooltainers for strawberry cultivation. Cooltainers are used in cities, such as Paris, to produce local food for its citizens. Valoya AP67 spectrum promotes vegetative and generative growth and enhances truss elongation of strawberry. Due to the quality of the spectrum, bumble bees can navigate in this no-natural light environment enabling efficient pollination of the flowers.
SLIDE 17
16
Valoya Products
Valoya C-Series Valoya B-Series Valoya R-Series Valoya L-Series Valoya Bulb
| Powerpoint Presentation Title
SLIDE 18
17
Thank you!
Confidential | Presentation 2016
