Valdez Operations Overview

Alyeska Pipeline Service Company

Prince William Sound Regional Citizens Advisory Council Board Meeting January 24, 2019 Anchorage, Alaska

January 24, 2019

Page 2 of 23

2018*

Tankers Loaded 247 Tankers Escorted 255 Barrels Loaded 178,137,687

Since Startup

Tankers Loaded 22,407 Tankers Escorted 13,710 Barrels Loaded 17,120,939,370

VMT Operations

* As of 12/31/18 January 24, 2019

Page 3 of 23

Health-Safety-Environment

Valdez Operations

Safety 2018

Days Away From Work Cases TAPS Combined Recordable Incident Rate % 0.27

Environment 2018

Spill Volume (Gallons) 217.2862 (12.2862*) Number of Spills 10

* Outside containment

January 24, 2019

Page 4 of 23

Alyeska Organizational Update

January 24, 2019

Page 5 of 23

Alyeska Organizational Update

January 24, 2019

Page 6 of 23

Alyeska Organizational Update

January 24, 2019

Page 7 of 23 January 24, 2019

Alyeska Organizational Update

Operations and Maintenance Division

Page 8 of 23 January 24, 2019

Alyeska Organizational Update

Engineering and Risk Division

Page 9 of 23

Fishing Vessel Availability

End of 4 th quarter 2018

Port Tier 1 Tier 2

Valdez 21 23 Cordova 32 (7RR) 115 Whittier 6 23 Seward 30 Homer 55 Kodiak 39

TOTAL 59 285

*RR = Rapid Response

January 24, 2019

Page 10 of 23 January 24, 2019

SERVS Highlights

2019 Fishing Vessel Training

• Spring Fishing Vessel Training
• Kodiak: March 27 – April 2
• Homer: April 3 – April 9
• Seward: April 10 – April 14
• Cordova: April 15 – April 26
• Valdez: April 27 – May 3
• Fall Fishing Vessel Training
• Whittier: September 18 – September 24
• Cordova: September 25 – October 6

Page 11 of 23

• October 9: Alyeska IMT developed first 12 hours of

documentation for PWS Tanker Exercise

• October 10: Alyeska SERVS completed demonstration

exercises in greater than 20 knot winds (Note: this demonstration completes transition plan exercises)

• October 10‐11: PWS Tanker Exercise with Crowley Alaska

Tankers

• November 5‐6: ADEC unannounced PWS Tanker Exercise
• December 17: ADEC inspection of OSRB‐2
• Total 2018 transition / assurance tug and barge deployments

completed: 215

January 24, 2019

2018 Drills, Exercises and Training

4Q Exercise Highlights

Page 12 of 23

• January 9 & 16: ICS 305 / 307 training for resource ordering

and ICS 204s

• March 4: Non‐mechanical Airborne Dispersant Delivery

System (ADDS) Pack training exercise in Valdez

• March 9: Veterinary technician (Otter Rehab) training in

Anchorage

• March 26: VMT IMT training exercise
• May 8: VMT IMT exercise
• Week of October 7: BP PWS tanker exercise
• Continued increased ECO assurance activities

January 24, 2019

2019 Drills, Exercises and Training

Upcoming 2019 Exercise Highlights

Page 13 of 23

• VMT coordination group quarterly meetings
• VMT contingency plan renewal application
• Submitted for sufficiency review on November 5, 2018
• Public review period: November 23, 2018 – January 7, 2019
• VMT contingency plan routine amendment to address

Qualified Individual (QI) changes effective January 1

• Routine amendment application submitted on January 2, 2019

January 24, 2019

2019 Look Ahead

Contingency Plan Activities

VMT 2018 Projects Highlights

X218 – 2018 Tank Inspection and Maintenance Program

• Completed exterior coating of Tank 94 (Ballast Water Tank)
• Completed API 653 internal inspection of Tank 56 (Diesel Storage Tank)

Z716 – Below Ground Crude Oil Piping Internal Inspection

• Completed 19 pig runs (10 runs “A” header, 9 runs “B” header); < 5

gallons wax removed

• Inspection data revealed the system is good for operation
• Dual off‐take scope execution underway; commissioning in 2019

Z735 – Valdez Facilities Bird Deterrent

• ERB proof‐of‐concept laser was not successful; new conceptual design

for ERB roof in progress for 2019 execution

• Installation and repair of deterrents will continue in 2019

Page 14 of 23 January 24, 2019

VMT 2018 Projects Highlights

Z761 – 2018 Ballast Header Inspection and Repair

• Completed internal cleaning, inspection, testing and repair of the 42”

ballast header piping for Berth 5, “A” header, and the Tank 93 branch leg (~7200 ft. of piping)

• Remaining “A” header work to be completed in 2019

Z758 – VMT IWWS Trunk Line Lifecycle Repairs

• HDPE piping sliplined in existing ductile iron pipe (~2000 ft.); 7

manholes replaced or repaired; 1 manhole eliminated

• Installed vapor sensors in MH‐2‐22 (westernmost manhole on PDC

road)

Z748 – VMT Berth Crude Block Valves Replacement

• Installed and commissioned 4 new Chromatic dual off‐set full port ball

valves on Berth 5

• Berth 4 valves to be installed in 2019

Page 15 of 23 January 24, 2019

VMT 2018 Projects Highlights

Z751 – VMT Berth Fisher Control Valves Replacement

• Installed and commissioned 4 Fisher Pressure Indicating Control Valves

(PICVs) on Berth 5

• Berth 4 valves to be installed in 2019

Z738 – Replace Incinerator Waste Gas Shutdown Valves

• Replaced 14 obsolete valves and actuators on the vapor recovery

system

• Achieves Safety Integrity Level (SIL) 2 system rating

Z739 – DAF Vapor System Emergency Shutdown and Ventilation

• Stack and generator concrete pads completed in 2018
• Install and commission equipment and instrumentation in 2019

Page 16 of 23 January 24, 2019

VMT 2019 Projects Summary

X219 – 2019 Tank Inspection and Maintenance Program

• API 653 internal inspection of Tank 8 (Crude Storage Tank)
• Exterior coating of Tank 93 (Ballast Water Tank) and Tank 10 (Crude

Storage Tank)

Page 17 of 23 January 24, 2019

VMT 2019 Projects Summary

Z716 – Below Ground Crude Oil Piping Internal Inspection (Dual Off‐ takes)

• Install 36‐inch dual off‐take piping and valves upstream of the East

Metering facility

• Requires pipeline shutdown for commissioning (June 2019)

Page 18 of 23 January 24, 2019 Dual off‐takes final design rendering 2 ea. 36” valves installed in fall 2018

VMT 2019 Projects Summary

Z762 – 2019 Ballast Header Inspection and Repair

• Clean, inspect and repair the ballast header piping from BWT West

Manifold to the “B” header termination vault

• Shortest section of inspection program piping (~740 ft.)

Page 19 of 23 January 24, 2019 West Manifold

VMT 2019 Projects Summary

Z586 – Berths 4 and 5 EMAC (Electronic Measurement and Control) Replacement

• Replace existing Daniels Metering systems with a new site‐specific

Omni EMAC system for Berths 4 and 5 at the West Metering Facility

• Requires a short shutdown for system conversion on each berth

Page 20 of 23 January 24, 2019 West Metering existing Daniels Metering system

VMT 2019 Projects Summary

Z769 – Replace VMT Pig Receiver Isolation Valves

• Replace the 48‐inch (58‐MOV‐001) and 36‐inch (58‐MOV‐003) scraper

trap isolation valves at the East Metering facility

• Installation planned during the August 2019 pipeline shutdown

Page 21 of 23 January 24, 2019 East Metering pig trap isolation valves

VMT 2019 Projects Summary

Z770 – Ship Loading Vapor Collection Life Cycle Replacement

• Extend life of existing Fenwal systems on Berths 4 and 5
• Bulk purchase replacement infrared detectors, controllers and chassis

Page 22 of 23 January 24, 2019 Berth causeway

• X. Project Management Improvements

23

QUESTIONS?

Page 23 of 23 January 24, 2019
