Using Pathway Tools & Matlab for Flux Balance Analysis Kent Peterson 25 Aug. 2009 Summary Flux Balance Analysis (FBA) Workflow: from Ptools to Matlab, and back again A simple example What next? 2 Lets start at the

slide-1
SLIDE 1

Using Pathway Tools & Matlab for Flux Balance Analysis

Kent Peterson 25 Aug. 2009

slide-2
SLIDE 2

Summary

  • Flux Balance Analysis (FBA)
  • Workflow: from Ptools to Matlab, and back again
  • A simple example
  • What next?

2

slide-3
SLIDE 3

Let’s start at the very beginning ...

Krebs cycle in A. thaliana (from Widipedia)

Bio Chemical Reaction Network

X1 X2 E12 k12

slide-4
SLIDE 4
slide-5
SLIDE 5
slide-6
SLIDE 6

Flux Balance Analysis (FBA)

  • Flux = “rate at which chemicals are transformed or transported”
  • Balanced = “input & output rates are equal” (a.k.a. steady-state)
  • Analysis = “optimize (balanced) flux with constraints”
  • Example: maximize product synthesis per unit feedstock,

while satisfying maintenance (biomass) requirements Cell Feedstock Product Biomass

slide-7
SLIDE 7

Software components

  • Pathway Tools1 (PGDB for organism)
  • SBML2 Toolbox (export metabolic description files)
  • COBRA3 (setup the LP)
  • GLPK4 (solve the LP)
  • Matlab5 (math’s programming & graphics)
  • 1. http://bioinformatics.ai.sri.com/ptools/
  • 2. http://sbml.org/Software/SBMLToolbox
  • 3. Palsson lab @ UCSD, http://gcrg.ucsd.edu/Downloads/Cobra_Toolbox
  • 4. GNU Linear Programming Kit, http://glpkmex.sourceforge.net/
  • 5. http://www.mathworks.com/
slide-8
SLIDE 8

Workflow

  • Load PGDB into PathwayTools
  • Export metabolic network into SBML file
  • Import SBML file into Matlab
  • Compute FBA solution in Matlab
  • Examine network & flux sol’n, using Matlab GUIs
  • Iterate
  • Write FBA sol’n to text file
  • Import sol’n to Pathway Tools Omics Viewer

8

Pathway tools Matlab

Export Import Iterate

slide-9
SLIDE 9

Example

9

Maximize anabolic “biomass” produced from a “feedstock”

slide-10
SLIDE 10

Getting the data from Ptools to Matlab

  • SBML export from Pathway Tools
  • SBML import into Matlab

10

slide-11
SLIDE 11

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 (1) PROTONCCOTHYLUMCYA (2) CDP (3) PHOSPHOENOLPYRUVATE (4) 2PG (5) MET0009 (6) OXYGENMOLECULE (7) E (8) PYRUVATE (9) MET0001 (10) CMP (11) MET0004 (12) MET0002 (13) CTP (14) MET0003 (15) PPI (16) MET0007 (17) MET0008 (18) MET0006 (19) Oxidizedferredoxins (20) MET0005 (21) Reducedferredoxins (22) CARBONDIOXIDE (23) PROTON (24) G3P (25) NADP (26) NADPH (27) DPG (28) DIHYDROXYACETONEPHOSPHATE (29) FRUCTOSE16DIPHOSPHATE (30) ERYTHROSE4P (31) FRUCTOSE6P (32) GAP (33) WATER (34) DSEDOHEPTULOSE17P2 (35) Pi (36) DSEDOHEPTULOSE7P (37) XYLULOSE5PHOSPHATE (38) ATP (39) DRIBULOSE15P2 (40) ADP (41) RIBOSE5P (42) RIBULOSE5P (43) Biomass (1) RIB5PISOM (2) PHOSPHORIBULOKINASE (3) RIBULP3EPIM (4) SEDOHEPTULOSEBISPHOSPHATASE (5) 2TRANSKETO (6) 1TRANSKETO (7) F16BDEPHOS (8) SEDOBISALDOL (9) F16ALDOLASE (10) TRIOSEPISOMERIZATION (11) 1.2.1.13 (12) PHOSGLYPHOS (13) RUBISCO (14) RXN0001 (15) RXN0002 (16) RXN0003 (17) RXN0004 (18) RXN0005 (19) RXN0006 (20) RXN0007 (21) RXN0008 (22) RXN0009 (23) 1.18.1.2 (24) RXN4903650 (25) PSII (26) RXN0010 (27) 3PGAREARR (28) 2PGADEHYDRAT (29) PEPDEPHOS (30) CDPKIN (31) CMPKIN (32) INORGPYROPHOSPHAT (33) 3.6.3.14 (34) BiomassFormation

What a mess!

11

Metabolite Reaction Product flux Substrate flux

slide-12
SLIDE 12

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 (1) PROTONCCOTHYLUMCYA (2) CDP (3) PHOSPHOENOLPYRUVATE (4) 2PG (5) MET0009 (6) OXYGENMOLECULE (7) E (8) PYRUVATE (9) MET0001 (10) CMP (11) MET0004 (12) MET0002 (13) CTP (14) MET0003 (15) PPI (16) MET0007 (17) MET0008 (18) MET0006 (19) Oxidizedferredoxins (20) MET0005 (21) Reducedferredoxins (22) CARBONDIOXIDE (23) PROTON (24) G3P (25) NADP (26) NADPH (27) DPG (28) DIHYDROXYACETONEPHOSPHATE (29) FRUCTOSE16DIPHOSPHATE (30) ERYTHROSE4P (31) FRUCTOSE6P (32) GAP (33) WATER (34) DSEDOHEPTULOSE17P2 (35) Pi (36) DSEDOHEPTULOSE7P (37) XYLULOSE5PHOSPHATE (38) ATP (39) DRIBULOSE15P2 (40) ADP (41) RIBOSE5P (42) RIBULOSE5P (43) Biomass (1) RIB5PISOM (2) PHOSPHORIBULOKINASE (3) RIBULP3EPIM (4) SEDOHEPTULOSEBISPHOSPHATASE (5) 2TRANSKETO (6) 1TRANSKETO (7) F16BDEPHOS (8) SEDOBISALDOL (9) F16ALDOLASE (10) TRIOSEPISOMERIZATION (11) 1.2.1.13 (12) PHOSGLYPHOS (13) RUBISCO (14) RXN0001 (15) RXN0002 (16) RXN0003 (17) RXN0004 (18) RXN0005 (19) RXN0006 (20) RXN0007 (21) RXN0008 (22) RXN0009 (23) 1.18.1.2 (24) RXN4903650 (25) PSII (26) RXN0010 (27) 3PGAREARR (28) 2PGADEHYDRAT (29) PEPDEPHOS (30) CDPKIN (31) CMPKIN (32) INORGPYROPHOSPHAT (33) 3.6.3.14 (34) BiomassFormation

Matlab tools (1): Met/Rxn graph

12

Calvin cycle

Metabolite Reaction Product flux Substrate flux

slide-13
SLIDE 13

Matlab tools (2): Met/Rxn browser

13

slide-14
SLIDE 14

Final product: an FBA solution

14

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 (1) PROTONCCOTHYLUMCYA (2) CDP (3) PHOSPHOENOLPYRUVATE (4) 2PG (5) MET0009 (6) OXYGENMOLECULE (7) E (8) PYRUVATE (9) MET0001 (10) CMP (11) MET0004 (12) MET0002 (13) CTP (14) MET0003 (15) PPI (16) MET0007 (17) MET0008 (18) MET0006 (19) Oxidizedferredoxins (20) MET0005 (21) Reducedferredoxins (22) CARBONDIOXIDE (23) PROTON (24) G3P (25) NADP (26) NADPH (27) DPG (28) DIHYDROXYACETONEPHOSPHATE (29) FRUCTOSE16DIPHOSPHATE (30) ERYTHROSE4P (31) FRUCTOSE6P (32) GAP (33) WATER (34) DSEDOHEPTULOSE17P2 (35) Pi (36) DSEDOHEPTULOSE7P (37) XYLULOSE5PHOSPHATE (38) ATP (39) DRIBULOSE15P2 (40) ADP (41) RIBOSE5P (42) RIBULOSE5P (43) Biomass (1) RIB5PISOM (2) PHOSPHORIBULOKINASE (3) RIBULP3EPIM (4) SEDOHEPTULOSEBISPHOSPHATASE (5) 2TRANSKETO (6) 1TRANSKETO (7) F16BDEPHOS (8) SEDOBISALDOL (9) F16ALDOLASE (10) TRIOSEPISOMERIZATION (11) 1.2.1.13 (12) PHOSGLYPHOS (13) RUBISCO (14) RXN0001 (15) RXN0002 (16) RXN0003 (17) RXN0004 (18) RXN0005 (19) RXN0006 (20) RXN0007 (21) RXN0008 (22) RXN0009 (23) 1.18.1.2 (24) RXN4903650 (25) PSII (26) RXN0010 (27) 3PGAREARR (28) 2PGADEHYDRAT (29) PEPDEPHOS (30) CDPKIN (31) CMPKIN (32) INORGPYROPHOSPHAT (33) 3.6.3.14 (34) BiomassFormation

slide-15
SLIDE 15

Import to Omics Viewer

15

slide-16
SLIDE 16

Recap

  • What have we accomplished?

– From stoichiometry (structure) of reaction network ...

  • Steady-state flux “subspace”,
  • Conserved “motifs”,

– From flux constraints ...

  • Unique steady-state operating point (solution of LP)
  • We used “biomass” optimization, but there are many

variations on the theme (e.g., MOMA, ROOM)

  • What is not represented?

– Quantity (Concentrations) – Thermodynamics (chemical potentials) – Dynamics (approach to steady-state, stability,...) – Spatial inhomogeneities – Regulation (neither metabolic nor transcriptional)

16

v ∈ N(S) ˙ x ∈ N(ST )

slide-17
SLIDE 17

Network dynamics (1): Linearized

17

slide-18
SLIDE 18

Network dynamics (2): Nonlinear

18

slide-19
SLIDE 19

A network model can (should?) include:

  • Structure (connections, stoichiometric weights)
  • Flux (chemical flow)
  • Concentration (chemical potential)
  • Kinetics (flux/potential constitutive model)
  • Regulatory “feedback”

Ref: Krappmann, Lipscomb, Braus (2000) PNAS 97(25): 13585.

slide-20
SLIDE 20

Example of “Metabolic Control” from EcoCyc

T r a n s c r i p t i

  • n

a l c

  • n

t r

  • l

Modulatory control
