Design of low cost cleaning robot using obstacle avoiding system without microchip SHAO YURUI Trilobite by Electrolux First commercial cleaning robot 2001 1899 2013 2002 Drawing of an Roomba by iRobot Neato electrical floor cleaner

slide-1
SLIDE 1

Design of low cost cleaning robot using obstacle avoiding system without microchip

SHAO YURUI

slide-2
SLIDE 2

1899 Drawing of an electrical floor cleaner Trilobite by Electrolux First commercial cleaning robot 2001 2002 Roomba by iRobot The standard of cleaning machine 2013… Neato Dyson 360eye Xiaomi….. Joined the market

Images adapted from Wikipedia and Leiohone https://www.leiphone.com/news/201605/Sk3uvM8OedJr4btL.html https://ainerds.com/the-evolution-of-the-robovac-why-the-robot-vacuum-of-today-is-different/

slide-3
SLIDE 3

Images adapted from Ezbuy https://ezbuy.sg/category?keywords=cleaning%20robot&sortCondition=3&ezspm=1.10000000.2.0.0

S$675.88 S$313.06 S$397.32 S$312.28

slide-4
SLIDE 4

Icon adapted from Clker http://www.clker.com/clipart-generic-microchip.html

Operation system

slide-5
SLIDE 5

Objective

To create an obstacle avoiding system without any microchip nor sensors, that is able to cover an area not free of obstacles, as efficiently as normal commercial design.

slide-6
SLIDE 6

Material and Design

Obstacle avoiding system without any microchip nor sensors

slide-7
SLIDE 7

Material and Design

A extremely simple circuit design with only two switches. The switch controls the wheel of the opposite side

slide-8
SLIDE 8

Material and Design

A extremely simple circuit design with only two switches. The switch controls the wheel of the opposite side

slide-9
SLIDE 9

Material and Design

A extremely simple circuit design with only two switches. The switch controls the wheel of the opposite side

slide-10
SLIDE 10

Illustration of cleaning robot

slide-11
SLIDE 11

Circuit Design

The switch will change the direction of the current when closed Close Switch

slide-12
SLIDE 12

Material and Design

A extremely simple circuit design with only two switches. The switch controls the wheel of the opposite side

slide-13
SLIDE 13

Material and Design

A extremely simple circuit design with only two switches. The switch controls the wheel of the opposite side

slide-14
SLIDE 14
slide-15
SLIDE 15

Angle Adjustment to Wall

slide-16
SLIDE 16

Normal commercial robot : use of random cleaning path Bed Closet

May result in area not cover by the cleaning robot

slide-17
SLIDE 17

Illustration of cleaning path phase 1 Bed Closet

slide-18
SLIDE 18

Illustration of cleaning path phase 2 Bed Closet

slide-19
SLIDE 19

Experiment: comparing efficiency

Fixed distance travelled Compare surface covered Most efficient cleaning path?

slide-20
SLIDE 20

266 S$

Icon adapted from Q10 https://www.qoo10.sg/item/GRUNN-GRUNN-ROBOT-VACUUM-CLEANER-I1/

slide-21
SLIDE 21

Two-person hostel room

slide-22
SLIDE 22

1.94m 0.6m 2.3m 3m 1.03m

Normal Design 59.9%

slide-23
SLIDE 23

1.94m 0.6m 2.3m 3m 1.03m

Normal Design 59.9%

slide-24
SLIDE 24

1.94m 0.6m 2.3m 3m 1.03m L=14894.211 A=2775088 C=1112405 P=59.9%

Normal Design

slide-25
SLIDE 25
slide-26
SLIDE 26

1.94m 0.6m 2.3m 1.03m 3m L=14894.211 A=2775088 C=1112405 P=59.9%

Normal Design

slide-27
SLIDE 27

1.94m 0.6m 2.3m 3m 1.03m A=1641*1247+649*1065+547*334- 181*549-303*151 =2775088

Normal Design

slide-28
SLIDE 28

1.94m 0.6m 2.3m 1.03m 3m L=14894.211 A=2775088 C=1112405 P=59.9%

Normal Design

slide-29
SLIDE 29

Calculation

C=183*238+514*753+145*312+359*1221+922*215+118*273 =1144619 P=1-(1144619/ 2775088) =0.599146 =59.9%

slide-30
SLIDE 30

1.94m 0.6m 2.3m 3m 1.03m

68.5% Low-cost Design

slide-31
SLIDE 31

Experimental results

1.94m 0.6m 2.3m 3m

59.9%

Normal Design

1.94m 0.6m 2.3m 1.03m

68.5%

Low-cost Design

slide-32
SLIDE 32

Experimental results: 4-person room Normal Design Low-cost Design

293cm 230cm 229cm 133cm

66.3%

231cm 293cm 230cm 229cm 133cm

71.3%

106cm

slide-33
SLIDE 33

Experiment: comparing efficiency

Icon adapted from lazada https://www.lazada.sg/products/ecovacs-deebot-m81-pro-vacuum-cleaning-robo

slide-34
SLIDE 34

90.6% Normal Design

slide-35
SLIDE 35

91.9% Low-cost Design

slide-36
SLIDE 36

90.6%

Normal Design

91.9%

Low-cost Design

Experimental results

slide-37
SLIDE 37

Experimental results

68.5 71.3 91.9

59.9 66.3 90.6

Room 1 Room 2 Room 3

Nomral commercial Low Cost

slide-38
SLIDE 38

Experimental results

266 S$ 529 S$

Estimated cost of operation system

40-50 S$

Cost of Low cost obstacle avoiding system without microchip

2 S$

slide-39
SLIDE 39

Future Work

Gap 1 : Unable to go back to charging station Gap 2: Angle of turning Solution : Magnetic Switch Solution : find average HDB width

slide-40
SLIDE 40

AUTOMATION can be achieved even WITHOUT MICROCHIP.

slide-41
SLIDE 41

Thank You

SHAO YURUI
