DAILY NEWS BUILDING BLOCK 1315 LOT(S) 0,24,1001 Exterior Landmark Designation List 145: LP-1049 July 28, 1981 Interior Landmark Designation List 290: LP-1982 March 10, 1998 DOCKET#: LPC-19-12293 Table of Contents Area of Proposed Work Sidewalks & Existing Conditions New Storefront Infjll Storefront and Door Details Proposed Signage Issuances June 27, 2017 First Submission December 5, 2017 CB6 Presentation December 28, 2017 Second Submission January 4, 2018 LPC Presentation

Main Entrance East 42nd Street Proposed Area of Storefront Alteration Area Not Afgected by Interior Modifjcations 1 Lobby Area Afgected by Interior Tenant Tenant Tenant Modifjcations Globe Area of Designated Interior Landmark Lobby Service Second Avenue Alleyway FEC Consulate UP FEC FEC Restaurant Parking Ramp Loading Dock East 41st Street Consulate Proposed Change to Entrance Existing Entrance 1 Photo of lobby rotunda and globe (Giorgio Galeotti) New Storefront Infill Area of Proposed Work Daily News Building — 220 East 42nd Street — LPC-19-12293 Ground Floor January 4, 2018 1

Proposed Area of Storefront Alteration 407’ 407’ TOP OF BUILDING TOP OF BUILDING Floors Not Afgected by Interior Modifjcations Floors Afgected by Interior Modifjcations South Elevation (41st Street) - Existing Condition South Elevation (41st Street) - Proposed Modifjcations New Storefront Infill Area of Proposed Work Daily News Building — 220 East 42nd Street — LPC-19-12293 Overall South Elevation (41st Street) January 4, 2018 2

Existing Entrance (2012; without scafgolding) with Proposed Area of Work Indicated Note: Existing ground fmoor aluminum and glass storefront and stone cladding was installed around 1983-1986 as infjll of the former loading docks conform with the Storefront Master Plan. 41st Street Looking West (proposed entrance location in foreground) New Storefront Infill Photographs of Existing Conditions Daily News Building — 220 East 42nd Street — LPC-19-12293 Area of Proposed Work January 4, 2018 3

LEVEL 02 17' - 0" EQ EQ EQ EQ EQ EQ EXISTING MASONRY OPENING PROPOSED SIGN NEW GLASS 11' - 9" STOREFRONT PROPOSED PROPOSED (SET BACK) REVOLVING DOUBLE DOOR DOOR Proposed 41st Street Storefront - Elevation (with sign) GROUND + 2' 2' - 0" GROUND 0' - 0" 18' - 3 1/2" EXISTING STOREFRONT BAY LEVEL 02 LEVEL 02 17' - 0" 17' - 0" EXISTING LIGHT EQ EQ FIXTURE TO REMAIN EQ EQ EQ EQ ORNAMENTAL HEADER TO REMAIN EXISTING MASONRY OPENING EXISTING EXISTING STOREFRONT STOREFRONT TO BE TO BE REMOVED REMOVED EXISTING NEW GLASS 11' - 9" DOORS STOREFRONT PROPOSED PROPOSED REVOLVING TO BE DOUBLE DOOR REMOVED DOOR GROUND + 2' GROUND + 2' 2' - 0" 2' - 0" STONE STONE GROUND GROUND 0' - 0" 0' - 0" 18' - 3 1/2" STONE PANELING AND STEPS EXISTING STOREFRONT BAY TO BE REMOVED Existing 41st Street Storefront - Elevation Proposed 41st Street Storefront - Elevation (without sign) Note: Brick, stone and metal header are not being removed and will be protected during construction. New Storefront Infill Proposed Storefront Infill Daily News Building — 220 East 42nd Street — LPC-19-12293 Existing and Proposed Elevations January 4, 2018 4

17 18 Property Line A CEMENT PLASTER SOFFIT PAINTED DARK BRONZE LEVEL 02 17' - 0" UP UP 18" 5' - 3" LOUVER INTAKE AND DUCTWORK ELEV. SEE PROPOSED METAL PANEL (DARK BRONZE TO MATCH MULLION) PROPOSED SIGN LOCATION EXISTING MASONRY OPENING PROPOSED REVOLVING DOOR 11' - 9" 8' - 0" GROUND + 2' 5' - 3" 2' - 0" A GROUND NEW SIDEWALK 0' - 0" Property Line 18' - 3 1/2" EXISTING MASONRY OPENING Proposed 41st Street Storefront - Section EXISTING SIDEWALK NOT A DISTINCTIVE SIDEWALK (PATCH WHOLE FLAGS AS NEEDED) Notes: Proposed awning sign will be mounted to the new wall and soffjt and not the existing TRANSFORMER VAULT brick facade or ornamental header Proposed 41st Street Storefront - Enlarged Plan New Storefront Infill Proposed Storefront Infill Daily News Building — 220 East 42nd Street — LPC-19-12293 Enlarged Plan and Section January 4, 2018 5

2 3 4 Main Entrance, left side (42nd street) Main Entrance, center (42nd street) Main Entrance, right side (42nd street) Note: Main entrance is the only entrance with polished brass trim. Designated Interior Landmark visible within. 4 3 2 6 5 FEC UP FEC FEC 5 6 Retail entrance (42nd street, non-landmarked facade) 2nd Avenue Entrance (42nd street, non-landmarked facade) Photo Key Plan New Storefront Infill Photographs of Existing Conditions Daily News Building — 220 East 42nd Street — LPC-19-12293 Existing Entrances January 4, 2018 6

8 9 Restaurant Entrance with retractable awning Restaurant Entrance (2nd avenue) (41st street) 7 Brazilian Consulate Entrance (41st Street) FEC UP Note: FEC FEC Entrance to Brazilian Consulate added in 2012. 9 Certifjcate of Appropriateness 13-7869 (LPC 13-8265). 7 8 10 10 Existing restaurant signage Photo Key Plan New Storefront Infill Photographs of Existing Conditions Daily News Building — 220 East 42nd Street — LPC-19-12293 Existing Entrances January 4, 2018 7

Detail of Corner of Existing Storefront (boundary of removal indicated) Detail of Corner of Existing Storefront Sill (all to be removed) Detail of Corner of Existing Storefront Header (boundary of removal indicated) Notes: Probes were not performed for this project. Stone paneling will be separated along joint lines. Door and windows are not considered distinctive or historic. New Storefront Infill Photographs of Existing Conditions Daily News Building — 220 East 42nd Street — LPC-19-12293 Details of Existing Conditions January 4, 2018 8

Proposed 41st Street Storefront - Elevation with Proposed Signage Proposed 41st Street Storefront - Perspective with Proposed Signage Notes: Sign to project no more than 18” and will not be illuminated to comply with zoning regulations. Trim color to match that of the storefront mullions. New Storefront Infill Proposed Signage Details Daily News Building — 220 East 42nd Street — LPC-19-12293 Frosted Glass with Non-Illuminated Letters January 4, 2018 9

Light blue symbols painted to match 100% cyan Light blue symbols painted to match 100% cyan Dark blue letters/symbols painted to Dark blue letters/symbols painted to 2" A match PMS 286C match PMS 286C 5'-2 1 / 2 " +/- (VIF) EQ. 2" 1'-6" Max. 1'-7" 2'-3" 2 EQ. ELEVATION - EXTERIOR SIGNAGE 1 Proposed 41st Street Storefront - Signage Elevation ALIGN 1" ALIGN 2" Existing building facade 2" 1” thick frosted glass panel 1” thick frosted glass panel 1" th. frosted glass panel 1/2” thick water-jet cut aluminum letters and logo painted on all sides 2" Aluminum frame colored to match existing architectural mullions, mechanically fastened to new construction (not existing building facade) Proposed 41st Street Storefront - Section with Proposed Signage Proposed 41st Street Storefront - Signage Detail Proposed 41st Street Storefront - Signage Detail Notes: Sign to project no more than 18” and will not be illuminated to comply with zoning regulations. Trim color to match that of the storefront mullions. New Storefront Infill Proposed Signage Details Daily News Building — 220 East 42nd Street — LPC-19-12293 Frosted Glass with Non-Illuminated Letters January 4, 2018 10

INSIDE 1" 1/2" SEE ELEV 2 1/2" 2 1/2" STOREFRONT SYSTEM EXISTING DECORATIVE METAL HEADER SEALANT AND BACKER ROD EXISTING EXTERIOR HEADER METAL PANEL, PAINTED DARK OUTSIDE 5' - 3" BRONZE CEMENT PLASTER SOFFIT, WATERPROOFING PAINTED DARK BRONZE VAPOR BARRIER SEE ELEV Proposed 41st Street Storefront - Enlarged Plan Detail at Jamb EXTERIOR VENT, WITH INSECT SCREEN; COLOR TO MATCH ADJACENT OUTSIDE STEEL TUBE HEADER INSIDE SEALANT AND BACKER ROD 1" STOREFRONT SYSTEM 2 1/2" Proposed 41st Street Storefront - Enlarged Section Detail at Header Proposed Swing Door Trim Color: Bronze (to match storefront mullions) New Storefront Infill Proposed Storefront Details Daily News Building — 220 East 42nd Street — LPC-19-12293 Typical Storefront Details January 4, 2018 11

INSIDE INSIDE OUTSIDE INSIDE STOREFRONT SYSTEM SEALANT AND BACKER ROD 1" REVOLVING DOOR 2 1/2" METAL PANEL, PAINTED REVOLVING DOOR HEADER AND GEARBOX DARK BRONZE 1/2" 4" EQ 4" EQ 2 1/2" REVOLVING DOOR HEAD 1" 4" 1/2" OPP PROPOSED STOREFRONT 1/2" OPP 1/2" METAL PANEL, PAINTED SEALANT AND BACKER ROD DARK BRONZE 4" OUTSIDE Proposed 41st Street Storefront - Enlarged Plan at Center Mullion OUTSIDE 5' - 3" METAL PANEL, PAINTED DARK BRONZE EXISTING EXTERIOR WALL EXISTING STONE CLADDING OUTSIDE INSIDE SEALANT AND BACKER ROD REVOLVING DOOR BEARING STAINLESS STEEL WALK-OFF MAT 1/4" 1/4" TOPPING SLAB Proposed Swing Door Trim Color: Bronze Proposed 41st Street Storefront - Enlarged Plan Detail at Revolving Door 4" (to match storefront mullions) EXISTING STRUCTURAL SLAB Proposed 41st Street Storefront - Enlarged Section Detail at Revolving Door New Storefront Infill Proposed Storefront Details Daily News Building — 220 East 42nd Street — LPC-19-12293 Revolving Door January 4, 2018 12
