Using linux throughout the complete UAV stack Koen Kooi <koen.kooi@linaro.org> ELC-E 2014, Dusseldorf something about dronecode.org announcement Basics of RC planes Show http://www.stormthecastle.com/model-


slide-1
SLIDE 1

Using linux throughout the complete UAV stack

Koen Kooi <koen.kooi@linaro.org> ELC-E 2014, Dusseldorf

slide-2
SLIDE 2

something about dronecode.org announcement

slide-3
SLIDE 3

Basics of RC planes

Show http://www.stormthecastle.com/model- airplanes/basics-of-controls-of-an-rc-airplane. htm in browser

slide-4
SLIDE 4
slide-5
SLIDE 5
slide-6
SLIDE 6

Receivers

Show http://orangerx.com/2014/01/25/r400- spektrumjr-dsm2-compatible-4ch-2-4ghz- receiver/ in browser

slide-7
SLIDE 7

http://orangerx.com/2014/01/25/r400-spektrumjr-dsm2-compatible-4ch-2-4ghz-receiver/

slide-8
SLIDE 8

Remote controls

Show http://www.open-tx.org/radios.html in browser

slide-9
SLIDE 9
slide-10
SLIDE 10

Telemetry

  • Battery state
  • Radio link state
  • Raw sensor data
  • Position
  • Processed sensor data
slide-11
SLIDE 11

Atmega based flightcontrollers

  • Needed for multirotors
  • Have I²C, SPI and UARTs
  • Different firmwares

○ multiwii ○ ardupilot

  • ~50Hz control loop
  • “multi core” solutions for GPS

support

slide-12
SLIDE 12
slide-13
SLIDE 13

Config tools

slide-14
SLIDE 14

Cortex-M based flightcontrollers

  • 32 bit
  • single precision floating point
  • >40MHz clock speed
  • More IO options
  • ~400Hz control loop
  • Multiple firmwares

○ baseflight (multiwii port) ○ taulabs ○ ardupilot

slide-15
SLIDE 15

Hybrids

  • Taulabs freedom

○ gumstix overo COM ○ cortex-M on baseboard ○ http://buildandcrash.blogspot.nl/2014/03/vertical- control.html

  • Flexbot + Arietta G25

○ AT91 ARM9 on COM ○ AT32u4 on flighcontroller ○ didn’t make it to ELC-E :(

slide-16
SLIDE 16

Hybrids

  • Quadcopter at the Intel booth
slide-17
SLIDE 17

Hybrids

  • Linux and FC communicate over (USB)

serial

  • Mainly for telemetry logging
  • Computer Vision
slide-18
SLIDE 18

Running linux on the flightcontroller

  • ‘hard’ realtime
  • userspace drivers
  • Only one real effort:

○ ardupilot

slide-19
SLIDE 19

Groundstations

  • qgroundcontrol (mavlink)
  • taulabs ground (taulabs)
  • Other, closed sourced ones
slide-20
SLIDE 20

Middleware

  • Mavconn
  • Mavproxy
slide-21
SLIDE 21

Mavlink example

Flexbot + arietta G25 minnowboard + webcam FRI2 running mavproxy Laptop running QGC arduino + sama5d3-xplained

slide-22
SLIDE 22

QGC demo
