SLIDE 1
Slide 1
Slide 2
Introduction
- Temporal bone surgery among most complex
- Average $80,000/year to properly train ENT surgeons
- Lack of cadaveric training material
Using FLeX for Real-time Fluid Simulation in Virtual Surgery Brad - - PowerPoint PPT Presentation
Using FLeX for Real-time Fluid Simulation in Virtual Surgery Brad - - PowerPoint PPT Presentation
Using FLeX for Real-time Fluid Simulation in Virtual Surgery Brad Hittle May 11 th 2017 Slide 1 Introduction Temporal bone surgery among most complex Average $80,000/year to properly train ENT surgeons Lack of cadaveric training
SLIDE 2
SLIDE 3
Slide 3
Virtual Surgery
- Complex surgeries
- Teaching/Training
- Informative feedback
SLIDE 4
Slide 4
Fluid Simulation?
- Multi-instrument process
- Visibility
- Temperature
SLIDE 5
Slide 5
Fluid Setup
- Fixed number of particles
- Recycle particles
- Blood and saline same phase
- Multiple mesh collisions
- Signed Distance Field (SDF)
SLIDE 6
Slide 6
SDF Issues
- Too expensive for real-time performance
- Particles fall through SDF
Dataset Size 768
3 (s)
384
3 (s)
192
3 (s)
96
3 (s)
Intel Xeon E5-1650 v3 3.5 GHz 2179.01 216.517 19.6141 1.52809
SLIDE 7
Slide 7
SDF Approximation
- Subsample
- Edge detection
- Shelling algorithm
- Scale
SLIDE 8
Slide 8
SDF Results
0.001 0.01 0.1 1 10 768 384 192 96 Time (s) Quadro K5000 Quadro M5000 Quadro P5000 Quadro GP100
SLIDE 9
Slide 9
Cost of Approximation?
SLIDE 10
Slide 10
Irrigation
- Emitters
- Absorbers
SLIDE 11
Slide 11
Blood Label
- Setup
- Algorithm
- Cull Extra Voxels
SLIDE 12
Slide 12
Bleeding
- Create static emitter
- Constant bleeders for critical structures
- Blood and saline mixing
SLIDE 13
Slide 13
Multi-thread configuration
void updateThread (FluidSim *sim) { sim->init (); std::thread upThread = std::thread([sim] { updateThread(sim); }); while (!sim->ShuttingDown) { double dt = 1.0 / float (sim->DeltaTime); double startTime = timer.read (); sim->update (); while (timer.read () - startTime < dt){} } upThread.join(); }
SLIDE 14
Slide 14
Multi-thread configuration
void updateThread (FluidSim *sim) { sim->init (); std::thread upThread = std::thread([sim] { updateThread(sim); }); while (!sim->ShuttingDown) { double dt = 1.0 / float (sim->DeltaTime); double startTime = timer.read (); sim->update ();
while (timer.read () - startTime < dt){}
} upThread.join(); }
SLIDE 15
Slide 15
Multi-GPU
Main Thread (Render) Fluid Update Update Fluid buffers For Rendering Add emitter Remove suction FLeX Update GPU 0 GPU 1 Update Volume for SDF
SLIDE 16
Slide 16
Simulation in Action
SLIDE 17
Slide 17
Simulation in Action
SLIDE 18
Slide 18
Simulation in Action
SLIDE 19
Slide 19
Simulation in Action
SLIDE 20
Slide 20
Special Thanks
- Hector Medina-Fetterman
- Dennis Sessanna (NVIDIA)
- Funded by NIDCD - R01 DC011321 (2011-2016)
