Usable Verifiable Remote Electronic Voting case study HELIOS 18.07.2012 SecVote Dagstuhl Comments Based on research results from the project Usable Verifiability in Remote Electronic Voting Project funded by Research conducted

slide-1
SLIDE 1

Usable Verifiable Remote Electronic Voting case study HELIOS

18.07.2012 SecVote Dagstuhl

slide-2
SLIDE 2

2 SecVote - Dagstuhl

Comments

  • Based on research results from the project “Usable

Verifiability in Remote Electronic Voting”

– Project funded by – Research conducted by M. Maina Olembo

  • Assumptions:

– voter cast vote from trustworthy environment – voter receives authentication tokens (PWD) over secure channel

  • Focus on individual verifiability

– Cast as intended

slide-3
SLIDE 3

3 SecVote - Dagstuhl

Overview

1. Why Helios and how Helios works? 2. Helios version 1.0 interfaces 3. Cognitive Walkthrough (KOKV2011)

1. Findings 2. Improved Interfaces

4. User study (KKOVV2011)

1. Design 2. Findings

5. Online survey

1. Design 2. Findings

6. Next steps

slide-4
SLIDE 4

4 SecVote - Dagstuhl

Why ?

  • Proposed by Ben Adida in 2008: http://heliosvoting.org/
  • Implemented verifiable electronic voting protocol

– User interface – Opensource system – Well studied from security point of view

  • Has been used in legally binding elections
  • in academic contexts: UCL, Princeton, IACR, …
slide-5
SLIDE 5

5 SecVote - Dagstuhl

How Helios works?

key holder 1 key holder 2 key holder 3 key holder 4 key holder 5 pk4 out of 5

slide-6
SLIDE 6

Invitation Email • Election URL • Direct Voting URL • Election Fingerprint • Email Address • Password Voting Booth • Election Fingerprint • Voting Instructions • Button: Start Press Button: Start Click 2nd URL Voting Booth • Election Fingerprint • Questions • Check Boxes • Button: Review Choices Voting Booth • Election Fingerprint • All Choices • Link: Update • Button: Encrypt Ballot Press Button: Review Choices Press Button: Encrypt Ballot Voting Booth • Election Fingerprint • Ballot Fingerprint • Button: Submit Encrypted Ballot • Button: Audit Ballot Press Button: Audit Ballot Voting Booth • Election Fingerprint • Box: Audited Ballot Information • Link: Helios Verifier • Button: Back to Choices Helios Verifier • Empty Box • Button: Verify Copy and paste Audited Ballot Information into Empty Box Helios Verifier • Box with Audited Ballot Information • Button: Verify • Result Verifying Process Press Button: Verify Press Button: Back to Choices Close Verifier to end Verifying Process Voting Booth • Election Fingerprint • Ballot Fingerprint • Panel: Email • Panel: Password • Button: Send Press Button: Submit Ballot Press Button: Send Confirmation Email • Election Fingerprint • Ballot Fingerprint Loop Click Link: Verifier Click Link: Update Independent application in separate window Helios Voting • Election ID • Election Fingerprint • Link:Vote • Link: Audit • Link: Bulletin Board • Box: Administration Click 1st URL Click Link Vote

How Helios works?

write down/ store/ print ballot fingerprint Compare

slide-7
SLIDE 7

7 SecVote - Dagstuhl

Bulletin Board

Pseudonym/Voter’s ID1 ballot fingerprint1 Pseudonym/Voter’s ID2 ballot fingerprint2 …… ….. …. Pseudonym/Voter’s IDn ballot fingerprintn

slide-8
SLIDE 8

8 SecVote - Dagstuhl

Important aspects

  • Separation of vote preparation/encryption and vote casting

Everyone, including auditors or election observers can verify cast as intended

  • Software commits to its encryption by displaying a hash of the

ciphertext = ballot fingerprint

To ensure that the software provides the same ciphertext for verification and vote casting

slide-9
SLIDE 9

9 SecVote - Dagstuhl

Important aspects

  • Voter can verify as many (test) ballots as he/she wants

From the software’s perspective, it cannot encrypt the wrong candidate with a sufficiently high probability of not being detected

  • In order to ensure the secrecy of the vote, it is not possible to first

verify and then cast this ballot but needs first to be reencrypted New ballot fingerprint The voter cannot verify the encrypted ballot he finally casts but must trust the system due to previous checks.

slide-10
SLIDE 10

10 SecVote - Dagstuhl

Individual verifiability – stored as cast

  • Use ballot finger print from vote casting
  • Verify whether is stored on the bulletin board next to the

voter’s ID / pseudonym by comparing

  • Remarks:

– Can be repeated during the vote casting phase as well as during and after the tallying phase – Voter or external observers verify that encrypted votes match to published hash values

slide-11
SLIDE 11

11 SecVote - Dagstuhl

Properties and Assumptions

Properties Verifiability Coercionresistance Receiptfreeness Assumptions

  • Cryptography works
  • Trusted environment
  • Not coercion

resistant (voter ID tied to hash value on Bulletin Board)

  • Cryptography works
  • Trusted environment
  • (nk+1) honest key

trustee

slide-12
SLIDE 12

12 SecVote - Dagstuhl

Helios version 1.0

slide-13
SLIDE 13

13 SecVote - Dagstuhl

Helios version 1.0

slide-14
SLIDE 14

SecVote

slide-15
SLIDE 15

15 SecVote - Dagstuhl

slide-16
SLIDE 16

16 SecVote - Dagstuhl

slide-17
SLIDE 17
slide-18
SLIDE 18
slide-19
SLIDE 19

19 SecVote - Dagstuhl

Cognitive Walkthrough [KOKV11]

slide-20
SLIDE 20

20 SecVote - Dagstuhl

Cognitive Walkthrough [KOKV11]

  • Carried out on Helios version 1.0 and later on version 3.0

– Interfaces evaluated from voter perspective

  • How usable is it to cast and verify a vote?

– Five experts from security, evoting and psychology – Fictitious university president election

slide-21
SLIDE 21

21 SecVote - Dagstuhl

might be scary ? ? What to do with the ballot fingerprint / receipt ? ? O/0?

slide-22
SLIDE 22

? where ? “ … how your options where encrypted”? How to continue verifying / casting a ballot? verify/audit?

slide-23
SLIDE 23

? “ … how your options where encrypted”? ? how to continue?/ vote cast? Independent? anything to verify? what to do if it does not match? C&P is error prone

slide-24
SLIDE 24

24 SecVote - Dagstuhl

Cognitive Walkthrough [KOKV11]

  • Carried out on Helios version 1.0 and later on version 3.0

– Interfaces evaluated from voter perspective

  • How usable is it to cast and verify a vote?

– Five experts from security, evoting and psychology – Fictitious university president election

slide-25
SLIDE 25

25 SecVote - Dagstuhl

?

slide-26
SLIDE 26

26 SecVote - Dagstuhl

? ! Missing instruction: comparison new: trust?

slide-27
SLIDE 27

27 SecVote - Dagstuhl

? new ? ? verify again? ?

slide-28
SLIDE 28

28 SecVote - Dagstuhl

Independent? ? even worse!

slide-29
SLIDE 29

29 SecVote - Dagstuhl

Findings

Complicate (many steps) and error prone verifiability Missing: clear terminology and clear instructions Same design for verification and main voting interface Irritation to authenticate at the end of the voting process

slide-30
SLIDE 30

30 SecVote - Dagstuhl

Improved Interfaces (1)

Clear instructions To authenticate servers

slide-31
SLIDE 31

31 SecVote - Dagstuhl

Improved Interfaces (2)

Added verifiability step Instructions to voters

slide-32
SLIDE 32

32 SecVote - Dagstuhl

Improved Interfaces (3)

Back and Forward Buttons

slide-33
SLIDE 33

33 SecVote - Dagstuhl

Improved Interfaces (4)

Shortened verification code Options for voter

slide-34
SLIDE 34

34 SecVote - Dagstuhl

Improved Interfaces (5)

Trusted institutions for verification

slide-35
SLIDE 35

35 SecVote - Dagstuhl

Improved Interfaces (6)

Simplified results Clear instructions

slide-36
SLIDE 36

36 SecVote - Dagstuhl

Improved Interfaces (5)

Only button

slide-37
SLIDE 37

37 SecVote - Dagstuhl

Improved Interfaces (7)

Explanation for voter Automatically reencrypted

slide-38
SLIDE 38

38 SecVote - Dagstuhl

Comparison

Old New

Click Audit (Drops down to give more information) Click Verify Encryption Click verify the ballot Click link to select information Rightclick and copy Click Ballot Verifier link Click on verifying institute Paste information in ballot verifier window Click Verify Close window Click close window (as in PPT) Click Back to Voting Click enter new vote button (as in PPT) Click Confirm button to reencrypt or Update to change vote [automatic]

slide-39
SLIDE 39

39 SecVote - Dagstuhl

User Study [KKOVV2011]

slide-40
SLIDE 40

40 SecVote - Dagstuhl

Design of the user study (lab study)

  • Mock mayoral election in Darmstadt
  • Material/Interface in German
  • 34 participants
  • Asked to put on a modified bicycle

helmet with a video camera and eye tracking

  • Participants cast a vote w/o

instructions (2 rounds)

– Would people verify? How? – Can people verify if we tell them to do so? – Instructions emphasized verifying with different techniques, different votes

  • 3 questionnaires

Note: hard for participants to take it serious as it is not a secret election due to eye tracker and log files

slide-41
SLIDE 41

41 SecVote - Dagstuhl

General Usability (after round 1)

fully agree do not agree

slide-42
SLIDE 42

42 SecVote - Dagstuhl

General Usability

  • 1 of 20 who answered that they verified further stated not

having noticed that the code changed (round 1)

  • 1 of the remaining 14 stated this in round 2

Most of participates noticed it

  • After round 2
  • 8 of 34 participants stated that it was not clear to them that they had

to compare the verification codes or/and the candidates

  • All stated that it was clear to them that their vote was not cast after

having verified

slide-43
SLIDE 43

43 SecVote - Dagstuhl

How many people verified?

  • 20 of 34 participants (58%) verified in the first run (log files)

– 10 with technical background verified – 10 without technical background verified

No correlation between technical background and interest in verifying

– All did some comparison, some only very quick (eye tracking)

  • 28 of 34 (82%) claimed to have verified at least once

– Some participants confused “verifying” with double checking that their ballot was correctly filled. – 2 went to the verification page but then back without having verifieid

slide-44
SLIDE 44

44 SecVote - Dagstuhl

Duration for vote casting

minutes From enter URL/ press enter and cast vote / entered correct credentials

slide-45
SLIDE 45

45 SecVote - Dagstuhl

Preferred method of verification of the security code

  • Round 1:

– 17 wrote down, 9 saved, 4 printed – none compared with displayed commitment if printed or stored

slide-46
SLIDE 46

46 SecVote - Dagstuhl

Is the authentication at the end of the voting process irritating?

fully agree do not agree

slide-47
SLIDE 47

47 SecVote - Dagstuhl

Do people have enough information to properly verify and cast their vote?

  • 16 of 34 participants (47%): not enough information

– Participants without technical background complained that the first page (with the instructions) contained too much information at once (some didn’t even read it) – Participants with technical background wanted more information about the security of the system (papers, security proofs, statements from other institutions regarding the level of security etc.)

  • 31 of 34 participants (91%): concept of verifiability needs to

be introduced before using this kind of voting system

slide-48
SLIDE 48

48 SecVote - Dagstuhl

Trust regarding ballot secrecy

  • Concerns about their vote secrecy….

– “The institutions can see my vote!” “… but they have strong privacy policies” – “derive vote from verification code is possible for institutes for whom else? – 26 participants (76%) answered that they were irritated by the changing verification code – 2 out of 20 in first round modified vote after having verified

  • Possible reason

– Idea behind reencrypting the ballot after verification unclear – Concept of test vote unclear

fully agree do not agree

slide-49
SLIDE 49

49 SecVote - Dagstuhl

Trust in correct vote casting & tallying

  • Participants were not able to verify the proper tallying at all

Trust level in the proper tallying was expected to be lower than in correct vote casting

  • Possible reason: People were not aware that these are two

different concepts

fully agree do not agree

slide-50
SLIDE 50

50 SecVote - Dagstuhl

General comments

  • “Normal people will find it too complicated.” (with technical

background)

  • “Good to know it is encrypted” (without technical background)
  • “Got confused with the different verification codes”
  • “Writing down a new security code each time annoys me.”
  • “I do not understand the idea behind the verification code”
  • “Why should I trust the verification procedure if I should not trust

the voting system”

slide-51
SLIDE 51

51 SecVote - Dagstuhl

Findings

  • Most people are able to verify (at least with quick check)
  • People do not get the idea of test ballots to verify
  • People do not understand what they can verify and what not
slide-52
SLIDE 52

52 SecVote - Dagstuhl

Online survey

  • Carried out to identify voters’ mental model of verifiability

– Are voters aware of verifiability? – Do they see a need to verify their votes? – Are there factors that are more likely to cause voters to verify? – What terminology is adequate to communicate verifiability to voters?

  • In Kenya and Germany

– Kenya: no postal voting, not possible to observe – Germany: 30% postal voting, possible to observe

slide-53
SLIDE 53

53 SecVote - Dagstuhl

Design

  • Interviews carried out as a pretest
  • Refined online questionnaire
slide-54
SLIDE 54

54 SecVote - Dagstuhl

First Findings

  • More familiar with aspects of universal verifiability

– Match number of voters to votes cast – Recount

  • Not as familiar with aspects of individual verifiability

– Seals at ballot boxes to ensure that they are not opened – Concerned about secrecy of the vote

  • General verifiability findings

– Some prefer delegating responsibility of verifying to others – More likely to verify with Internet voting than with paper based voting but

  • nly with first elections

– Verify if unexpected result (mentioned recount) – No need for traditional paper based elections because of trust in people who they know

  • More familiar terms than verifiability

– Monitor, observe

slide-55
SLIDE 55

55 SecVote - Dagstuhl

Next Steps

  • Improve usability of hash value

– Represent hash value graphically – Identify secure enough length for hash value – Analyze what are people willing to compare

  • Explain concept of “test” votes better
  • Changes to interface based on results

– Adopt wording – Number for each hash value – Go back to empty ballot – Only ‘write down’ option – Distribute receipt for ‘stored as cast’ verifiability – Use QR code and Android app for comparison

slide-56
SLIDE 56

UNIVERSITY PRESIDENT ELECTION

https://www.presidentelection.university.com

Instructions Ballot VerificationCode VoteCasting

You can now verify whether your ballot is correctly encrypted. Click on the logo of your choice. A new window will open with the results of the verification. In order to verify your vote, the ballot will be decrypted. Once the process is finalized, your vote will be reencrypted and a new verificationcode generated. You can continue with the voting process upon successful verification. If you notice any irregularities, cancel the election process immediately and contact the election officials [Telephone number: 123456789] Institutes:

Trust in verification device or voting environment enough

Enter a new vote to proceed with the election

slide-57
SLIDE 57

57 SecVote - Dagstuhl

Open Discussion

  • Currently: some cumbersome steps for the voter

– Check https for voting page – For each verified vote:

  • Write down hash value and compare with verification page of institute(s)
  • Check https for institute’s page

– For casting: Write down hash value and compare on board – In addition: check on bulletin board

  • Alternative: vote casting from different trusted institutions

– Check https for voting page – Could forward ballot fingerprint to delegate ‘stored as cast’ verification

  • Combination?
slide-58
SLIDE 58

58 SecVote - Dagstuhl

Questions?

slide-59
SLIDE 59

59 SecVote - Dagstuhl

Literature

Helios voting system: Adida, B. 2008. Webbased open audit voting. In Proceedings of the 17th symposium on security, pp. 335–348. Berkeley, CA, USA: USENIX Association.

[KOKV11] Usability Analysis of Helios An Open Source Verifiable Remote Electronic Voting System by Fatih Karayumak, Maina M. Olembo, Michaela Kauer, Melanie

  • Volkamer. In: Proceedings of the Electronic Voting Technology Workshop/Workshop on

Trustworthy Elections (EVT/WOTE), 2011.

[KKOVV11] User Study of the Improved Helios Voting System Interface by Fatih Karayumak, Michaela Kauer, Maina M. Olembo, Tobias Volk, Melanie Volkamer. In: SocioTechnical Aspects in Security and Trust (STAST), 2011 1st Workshop on , p. 3744, IEEE Digital Library, 2011. ISBN 1457711817.

[SN93] Mental models: Concepts for human computer interaction research by STAGGERS, N., AND NORGIO, A. F. Int. J. ManMachine Studies 38, 4 (1993), 587 605.
