SLIDE 1
USABILITY INTRODUCTION
USABILITY AND USER INTERFACE DESIGN
TO BE PREPARED FOR THIS CLASS…
YOU WILL HAVE WORKED THROUGH THE LYNDA.COM UX-1 SECTION.
USABILITY INTRODUCTION USABILITY AND USER INTERFACE DESIGN TO BE - - PowerPoint PPT Presentation
USABILITY INTRODUCTION USABILITY AND USER INTERFACE DESIGN TO BE - - PowerPoint PPT Presentation
USABILITY INTRODUCTION USABILITY AND USER INTERFACE DESIGN TO BE PREPARED FOR THIS CLASS YOU WILL HAVE WORKED THROUGH THE LYNDA.COM UX-1 SECTION. FOR THIS CLASS USABILITY WHAT is Usability? WHY is Usability important? USER
SLIDE 2
SLIDE 3
FOR THIS CLASS…
WHAT is Usability? WHY is Usability important?
USABILITY USER REQUIREMENTS ANALYSIS
WHAT is User Requirements Analysis? HOW do we execute and apply it to Usability?
SLIDE 4
WHAT IS USABILITY?
SLIDE 5
LEARNABILITY
Nielson and Norman
USABILITY
How easy is it for users to accomplish basic tasks the first time they encounter the design?
SLIDE 6
EFFICIENCY
Nielson and Norman
USABILITY
Once users have learned the design, how quickly can they perform tasks?
SLIDE 7
MEMORABILITY
Nielson and Norman
USABILITY
When users return to the design after a period of not using it, how easily can they reestablish proficiency?
SLIDE 8
ERRORS
Nielson and Norman
USABILITY
How easy How many errors do users make, how severe are these errors, and how easily can they recover from the errors?
SLIDE 9
SATISFACTION
Nielson and Norman
USABILITY
How pleasant is it to use the design?
SLIDE 10
WHY IS USABILITY IMPORTANT?
SLIDE 11
USABILITY Source: https://www.nngroup.com/articles/usability-101-introduction-to-usability/ What — Definition of Usability
Usability is a quality attribute that assesses how easy user interfaces are to use. The word "usability" also refers to methods for improving ease-of-use during the design process. Usability is defined by 5 quality components:- Learnability: How easy is it for users to accomplish basic tasks the first time they encounter the design?
- Efficiency: Once users have learned the design, how quickly can they perform tasks?
- Memorability: When users return to the design after a period of not using it, how easily can they reestablish proficiency?
- Errors: How many errors do users make, how severe are these errors, and how easily can they recover from the errors?
- Satisfaction: How pleasant is it to use the design?
- Definition of Utility = whether it provides the features you need.
- Definition of Usability = how easy & pleasant these features are to use.
- Definition of Useful = usability + utility.
Why Usability Is Important
On the Web, usability is a necessary condition for survival. If a website is difficult to use, people leave. If the homepage fails to clearly state what a company offers and what users can do on the site, people leave. If users get lost on a website, they leave. If a website's information is hard to read or doesn't answer users' key questions, they leave. Note a pattern here? There's no such thing as a user reading a website manual or otherwise spending much time trying to figure out an interface. There are plenty of other websites available; leaving is the first line of defense when users encounter a difficulty. The first law of ecommerce is that if users cannot find the product, they cannot buy it either. For intranets, usability is a matter of employee productivity. Time users waste being lost on your intranet or pondering difficult instructions is money you waste by paying them to be at work without getting work done. Current best practices call for spending about 10% of a design project's budget on usability. On average, this will more than double a website's desired quality metrics (yielding an improvement score of 2.6) and slightly less than double an intranet's quality metrics. For software and physical products, the improvements are typically smaller — but still substantial — when you emphasize usability in the design process. For internal design projects, think of doubling usability as cutting training budgets in half and doubling the number of transactions employees perform per hour. For external designs, think of doubling sales, doubling the number of registered users or customer leads, or doubling whatever other KPI (key performance indicator) motivated your design project. SLIDE 12
USER REQ. ANALYSIS
Source: https://www.nngroup.com/articles/usability-101-introduction-to-usability/ How to Improve Usability
There are many methods for studying usability, but the most basic and useful is user testing, which has 3 components:- Get hold of some representative users, such as customers for an ecommerce site or employees for an intranet (in the latter case, they should work outside your department).
- Ask the users to perform representative tasks with the design.
- Observe what the users do, where they succeed, and where they have difficulties with the user interface. Shut up and let the users do the talking.
When to Work on Usability
Usability plays a role in each stage of the design process. The resulting need for multiple studies is one reason I recommend making individual studies fast and cheap. Here are the main steps: 1. Before starting the new design, test the old design to identify the good parts that you should keep or emphasize, and the bad parts that give users trouble. 2. Unless you're working on an intranet, test your competitors' designs to get cheap data on a range of alternative interfaces that have similar features to your own. (If you work on an intranet, read the intranet design annual to learn from other designs.) 3. Conduct a field study to see how users behave in their natural habitat. 4. Make paper prototypes of one or more new design ideas and test them. The less time you invest in these design ideas the better, because you'll need to change them all based on the test results. 5. Refine the design ideas that test best through multiple iterations, gradually moving from low-fidelity prototyping to high-fidelity representations that run on the computer. Test each iteration. 6. Inspect the design relative to established usability guidelines whether from your own earlier studies or published research. 7. Once you decide on and implement the final design, test it again. Subtle usability problems always creep in during implementation. Don't defer user testing until you have a fully implemented design. If you do, it will be impossible to fix the vast majority of the critical usability problems that the test uncovers. Many of these problems are likely to be structural, and fixing them would require major rearchitecting. The only way to a high-quality user experience is to start user testing early in the design process and to keep testing every step of the way.Source: http://www.usabilitypartners.se/services/user-requirements-analysis.php
Typical requirements gathering and analysis methods include:- Surveys – both open-ended and focused surveys, conducted electronically or on paper.
- Interviews – typically conducted face-to-face, but also over the telephone if deemed more appropriate.
- Focus groups – whilst being poorly suited to evaluating a product, focus groups are useful for discussing possible user requirements and brainstorming ideas.
- Field studies – observing the end-user situation and the environment in which a new product or system will be used is often extremely useful in understanding user needs.
- Evaluation of an existing product – provides a range of useful information (even competitor products can be tested). Usability evaluation reveals and clarifies good and bad aspects of current solutions
- valuable input to new design work.
- Task analysis – a deeper analysis of users work with a system, useful for analyzing how user's work tasks should be supported by functionality in a system.
- User personas and usage scenarios – concrete and illustrative data about typical users, their characteristics, usage situation, tasks and goals. Particularly useful in supporting early user interface design
- Formulation of usability goals and overall design criteria – help focus and steer the design process, supporting the evaluation of early concepts, prototypes and final designs.
SLIDE 13
WHAT IS USER REQUIREMENTS ANALYSIS?
SLIDE 14
USER REQ. ANALYSIS
SOURCE: https://usabilitygeek.com/an-introduction-to-website-usability-testing/ Usability Testing is a technique used to evaluate a product (in this case a website) by testing is on users. Most people who set up a usability test carefully construct a scenario wherein a person performs a list of tasks that someone who is using the website for the first time is likely to perform. Someone else observes and listens to the person who is performing the tasks while taking notes. Watching someone perform common tasks on a website is a great way to test whether the site is usable because you will immediately be able to see whether they are able to perform the tasks and any difficulties they have while doing so. There are 3 main categories of usability testing:- Explorative: Used early in product development to assess the effectiveness and usability of a preliminary design or prototype, as well as users’ thought processes and conceptual understanding.
- Assessment: Used midway in product development or as an overall usability test for technology evaluation. Evaluates real-time trials of the technology to determine the satisfaction,
- Comparative: Compares two or more instructional technology products or designs and distinguishes the strengths and weaknesses of each.
SLIDE 15
SLIDE 16
Examples of Information Gathering: market research, target audiences, user screening/testing Stakeholder Analysis, Secondary market research, Context of use, Task analysis, Rich pictures - associative testing User Needs Identification: surveys, polls (opportunity to insert activity - easy polls), focus groups, and evaluation of competitor’s websites/systems Evaluation: Prototype stage Analysis of Use: heat maps - hot jar demo. Test, test, and test again. Its never done!
SLIDE 17
What was the key principle of User Centered Design?
Answer: meeting needs and efficient use
SLIDE 18
Source: https://www.lynda.com/User-Experience-tutorials/Understanding-benefits-user-centered-design/490750/582568-4.html?
srchtrk=index%3a13%0alinktypeid%3a2%0aq%3aux+design%0apage%3a1%0as%3arelevance%0asa%3atrue%0aproducttypeid%3a2The key principle of user-centered design is that if you gather data from users and then incorporate your findings into your product design, you'll be more likely to meet their true needs, which means they'll probably like your product more and be more efficient using it. But there's another big benefit to following user-centered design techniques. It's often hard to turn empathy-based concepts like users' thoughts, feelings, frustrations, and desires into something systematic that team members can use to build products. As a result, products tend not to make an emotional impact on users. The techniques we describe in this course show how to take these empathetic elements and turn them into something systematic. In other words, user-centered design gives you a way of adding emotional impact to your products. Development team members often find it hard to truly understand the wants and needs that drive users. Team members are often experts in their domain with a great understanding of technology and a systematic approach to thinking about the world. And users, in contrast, are often not so expert at working with software and apps and don't have such a focus on understanding how technology works. They just want their tech stuff to help them in their lives. If you apply it properly, user-centered design lets you translate the wants and needs of end users into specifications for building technological solutions. The user-centered design process I'll show you helps you turn the empathetic needs of users into systematic building blocks.
SLIDE 19
What is User Centered Design based on?
Answer: data
SLIDE 20
Source: https://www.lynda.com/User-Experience-tutorials/Building-products-user-centered-design/490750/582580-4.html?
srchtrk=index%3a13%0alinktypeid%3a2%0aq%3aux+design%0apage%3a1%0as%3arelevance%0asa%3atrue%0aproducttypeid%3a2 Using Personas, Ideation Techniques, Storyboards, Prototypes Personas are imaginary yet realistic and detailed descriptions of the users of your product. They provide a basis for design discussions by concentrating many pieces of user data into key focused, believable descriptions of your primary audience. Creating personas gives the team a shorthand way of describing who they're building things for. Rather than saying "the user," which could mean anyone, they focus- n some set characters with specific attributes, means that the product development takes those personas' needs into account.
- elastic. That way the whole team is developing for a common set of user attributes, which leads to creating a much more consistent
- interface. Even if the persona you create is slightly different from reality, users will much prefer a consistent interface over an inconsistent
- ne.
- projects. Even when we apply the constraints later, the act of thinking more broadly about the problem leads to better solutions. Those
- benefits. Everyone on the team can propose new ideas regardless of their graphical skills. The group moves from individual ideas to
- consensus. People gain understanding of why certain ideas may or may not work. And everyone feels like they were involved in design
- decisions. That feeling of investment in the UI will ensure that the whole team cares deeply about future design and usability work.
- shot. Here we use it to plan out interactions before we build them.
- ver.
SLIDE 21
FOR NEXT CLASS…
Thursday
- Quiz
- Workshop
- Review next weeks homework
